__ 22. Look at the Function/Data display on the control panel.
__ 23. Does 01 B V=S appear in the Function/Data display and the Normal mode
__ 24. Press the Power push button that is located on the control panel. There is
__ 25. Follow these steps to verify your disk unit configuration:
12
43xx Disk Unit, 71xx Disk Expansion Unit, 71xx Disk Unit Enclosure V5R3
__ Yes: Go to step 24.
__ No: Follow these steps:
__ a. Press the Increment/Decrement push button until 02 appears
in the Function/Data display.
__ b. Press the Enter push button on the control panel.
__ c. Press the Increment/Decrement push button until B appears in
the Function/Data display.
__ d. Press the Enter push button on the control panel.
__ e. Press the Increment/Decrement push button until N appears in
the Function/Data display.
__ f. Press the Enter push button on the control panel.
__ g. Press the Increment/Decrement push button until S appears in
the Function/Data display.
__ h. Press the Enter push button on the control panel.
__ i. Press the Increment/Decrement push button until 01 appears
in the Function/Data display.
__ j. Press the Enter push button on the control panel.
01 B N S should appear in the Function/Data display. If it does
not, repeat steps 21a through 21j.
__ k. Go to step 24.
indicator (OK) illuminated?
__ Yes: Continue with the next step.
__ No: Do the following:
__ a. Press the Mode Select button until the Normal mode indicator
(OK) lights up.
__ b. Press the Increment/Decrement push button until 02 appears
in the Function/Data display.
__ c. Press the Enter push button on the control panel.
__ d. Press the Increment/Decrement push button until B appears in
the Function/Data display.
__ e. Press the Enter push button on the control panel.
__ f. Press the Increment/Decrement push button until S appears in
the Function/Data display
__ g. Press the Enter push button on the control panel.
__ h. Press the Increment/Decrement push button until 01 appears
in the Function/Data display.
__ i. Press the Enter push button on the control panel.
01 B S should appear in the Function/Display panel. If it does
not appear, repeat steps 23a through 23i.
approximately a 10-second delay before the power-on light comes on, and
data appears in the Function/Data display.
Note: The system takes several minutes to power on and complete an IPL.
When the IPL is complete, the OS/400 signon display should appear
on your system unit console.
