Fuel Pump - Yamaha 250GETO Service Manual

FUEL

Fuel pump

No.
1 Base
2 Gasket
3 Diaphragm
4 Body assembly
5 Nut
6 Screw
7 Washer
8 Check valve
9 Body
10 Gasket
11 Diaphragm
12 Collar
13 O-ring
14 Cover
15 Plate
16 Spring
17 Screw
4-13
Fuel system
Part name Q'ty
2
2
Not reusable
2
2
8
ø5 × 28 mm
8
8
8
2
2
Not reusable
2
4
4
Not reusable
2
2
2
ø5 × 35 mm
6
6G44030E
Remarks
6S35H11
