OF-500 OptiFiber Certifying OTDR
Technical Reference Handbook
You can save the last test you ran anytime before you
run another test or view stored records. This excludes
FiberInspector images and power meter results, which
you must save at the time of viewing.
If SAVE WARNING on the System tab is enabled, the
tester warns you if you are about to do something
that will delete an unsaved test from temporary
memory. The unsaved test is retained in temporary
memory even if you turn off the tester or remove the
battery pack.
Memory Capacity and Card Sizes
Supported
The number of test records you can save in a given
amount of memory space depends on what you save
in the records. For example, records that include video
probe endface images take more memory than records
without images.
The maximum amount of internal memory available
for test results depends on the space taken by the
tester's software and custom limits.
9-2
Notes
Memory card folders can store a maximum of
500 records each.
Loss/length tests in Smart Remote mode take
up two test records
OptiFiber software version 2.0 supports cards up to
4 gigabytes. Later versions may support larger cards.
Check the Fluke Networks Knowledge Base for the
latest information.
To see the memory space available, press
select Memory Status. Press
the memory card and internal memory status.
Table 9-1 describes the features of the memory status
screen.
Formatting a Memory Card
To format a memory card, insert the card into the
F
tester, press
; then select Format Memory Card
from the FUNCTIONS menu.
one for each fiber.
F
; then
A
to switch between
