Removing the tail pipe

•
Loosen the sealing clamp between the
exhaust and the central manifold.
•
Unscrew and remove the front screw
fastening the exhaust to the chassis.
•
Unscrew and remove the upper attach-
ment screw fixing the exhaust pipe to
the chassis; retrieve the collar, the
washer and the nut.
DURING THIS OPERATION SUPPORT THE EXHAUST PIPE
SO THAT IT DOES NOT FALL.
•
Remove the exhaust end.
