RSV4 R
Rear
pos. Description
1 Rear wheel spindle nut
2 Screws fastening sprocket on
sprocket mount

Removing the rear wheel

•
Place the vehicle on its rear service
stand.
•
Loosen and remove the nut on the
wheel spindle.
•
Retrieve the thrust washer and the left
hand chain tensioner skid.
R
EAR WHEEL
Type Quantity
M25x1.5 1
M10 5
Suspensions
Torque
120 Nm (88.5 lbf ft)
50 Nm (36.88 lbf ft)
Notes
-
-
SUSP - 385
