Panel Layout

1.3
1.3.1

Top View

The router's LEDs are located on the top panel (view from top to bottom). You can check the router's working status
by following the LED Explanation table.
LED Explanation:
Name
(Power)
(Internet)
Status
On
System initialization complete.
System initializing or firmware upgrading is in process. Do not disconnect or
Flash
power off the router.
Off Power is off. Please ensure that the power adapter is connected correctly.
White
The network is available with a successful Internet connection.
Orange
The router connect to the Internet, but you can not access the Internet.
Off
There is no successful Internet connection or the router is operating in Bridge
Chapter 1 Get to Know About Your
Indication
Router4
