Quick Installation Guide
Set up with videos:
Scan the QR code or visit
https://www.tp-link.com/support/setup-video/#wi-fi-routers
to search for the setup video of your product model.
Unplug your modem, and remove
the backup battery if it has one.
Connect the powered-off
modem to the router's Internet
port with an Ethernet cable.
Power adapter
Power on the modem,
and then wait about 2
minutes for it to restart.
* Images may differ from actual products.
Connect the Hardware
If your internet comes from an Ethernet outlet, connect the router's Internet port to it, then follow Step 3 and Step 5.
If you want to configure this new router as an access point to extend your network, refer to the Access Point Mode
section on the back page.
Modem
Power adapter
Router
Connect the power adapter
to the router and turn it on.
Check for the following LEDs to confirm
the hardware connection, then refer to the
next section to set up the internet.
Power
2.4GHz
5GHz
Internet
On
On
On
On
Note: If the 2.4 GHz LED and 5 GHz LED are off, press and hold the
Wi-Fi On/Off button on the side panel for 2 seconds, then release
the button. Both LEDs will turn solid on.
Flip the page over to complete network setup.
