Page 1: Operating Instructions
Products Solutions Services BA01191D/06/EN/01.14 71209780 Valid as of version (Device firmware) Operating Instructions Proline Promass O 100 HART Coriolis flowmeter... - Page 2 • The manufacturer reserves the right to modify technical data without prior notice. Your Endress+Hauser Sales Center will supply you with current information and updates to these Instructions. Endress+Hauser...
-
Page 3: Table Of Contents
Preparing the measuring device ..24 10.1 Function check ..... . . 6.2.3 Mounting the measuring device ..24 Endress+Hauser... - Page 4 10.2.6 Configuring the local display ..58 13.3 Endress+Hauser services ....90 10.2.7 Configuring the HART input ..
-
Page 5: Document Information
A terminal which must be connected to ground prior to establishing any other connections. Equipotential connection A connection that has to be connected to the plant grounding system: This may be a potential equalization line or a star grounding system depending on national or company codes of practice. Endress+Hauser... -
Page 6: Tool Symbols
Symbols in graphics Symbol Meaning 1, 2, 3,... Item numbers Series of steps … A, B, C, ... Views A-A, B-B, C-C, ... Sections Flow direction Hazardous area Indicates a hazardous area. Safe area (non-hazardous area) Indicates the non-hazardous area. Endress+Hauser... -
Page 7: Documentation
• The W@M Device Viewer : Enter the serial number from the nameplate (www.endress.com/deviceviewer) • The Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2-D matrix code (QR code) on the nameplate. For a detailed list of the individual documents along with the documentation code (→... -
Page 8: Basic Safety Instructions
‣ Observe the specified pressure and temperature range. Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any Endress+Hauser... -
Page 9: Workplace Safety
It meets general safety standards and legal requirements. It also complies with the EC directives listed in the device-specific EC Declaration of Conformity. Endress+Hauser confirms this by affixing the CE mark to the device. -
Page 10: It Security
Operating Instructions. The device is equipped with security mechanisms to protect it against any inadvertent changes to the device settings. IT security measures in line with operators' security standards and designed to provide additional protection for the device and device data transfer must be implemented by the operators themselves. Endress+Hauser... -
Page 11: Product Description
Device version with HART communication type A0023153 1 Important components of a measuring device Sensor Transmitter housing Main electronics module Transmitter housing cover Transmitter housing cover (version for optional onsite display) Onsite display (optional) Main electronics module (with bracket for optional onsite display) Endress+Hauser... -
Page 12: Incoming Acceptance And Product
• If one of the conditions is not satisfied, contact your Endress+Hauser Sales Center. • Depending on the device version, the CD-ROM might not be part of the delivery! In such cases, the technical documentation is available via the Internet or via the Endress+Hauser Operations App, see the "Product identification"... -
Page 13: Transmitter Nameplate
"Supplementary device-dependent documentation" (→ 7) • The W@M Device Viewer: Enter the serial number from the nameplate (www.endress.com/deviceviewer) • The Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2-D matrix code (QR code) on the nameplate. 4.2.1... -
Page 14: Sensor Nameplate
(e.g. LA). If other optional specifications are also ordered, these are indicated collectively using the # placeholder symbol (e.g. #LA#). • If the ordered optional specifications do not include any safety and approval-related specifications, they are indicated by the + placeholder symbol (e.g. XXXXXX-ABCDE Endress+Hauser... -
Page 15: Symbols On Measuring Device
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury. Reference to documentation Refers to the corresponding device documentation. A0011194 Protective ground connection A terminal which must be connected to ground prior to establishing any other connections. A0011199 Endress+Hauser... -
Page 16: Storage And Transport
• Do not remove protective covers or protective caps installed on process connections. They prevent mechanical damage to the sealing surfaces and contamination in the measuring tube. Endress+Hauser... -
Page 17: Packaging Disposal
• Seaworthy packaging (optional): Wood crate, treated in accordance with ISPM 15 standard, which is confirmed by the affixed IPPC logo. • Carrying and mounting hardware: – Disposable plastic pallet – Plastic straps – Plastic adhesive strips • Dunnage: Paper cushion Endress+Hauser... -
Page 18: Installation
Pipe restrictions or the use of an orifice with a smaller cross-section than the nominal diameter prevent the sensor running empty while measurement is in progress. A0015596 4 Installation in a down pipe (e.g. for batching applications) Supply tank Sensor Orifice plate, pipe restriction Valve Batching tank Endress+Hauser... - Page 19 If a sensor is installed horizontally with a curved measuring tube, match the position of the sensor to the fluid properties. A0014057 5 Orientation of sensor with curved measuring tube Avoid this orientation for fluids with entrained solids: Risk of solids accumulating. Avoid this orientation for outgassing fluids: Risk of gas accumulating. Endress+Hauser...
-
Page 20: Requirements From Environment And Process
Ensure the system pressure is sufficiently high to prevent cavitation and outgassing. For this reason, the following mounting locations are recommended: • At the lowest point in a vertical pipe • Downstream from pumps (no danger of vacuum) A0015594 Endress+Hauser... - Page 21 Ensure that convection takes place on a sufficiently large scale at the transmitter neck. ‣ Ensure that a sufficiently large area of the housing support remains exposed. The uncovered part serves as a radiator and protects the electronics from overheating and excessive cooling. Endress+Hauser...
-
Page 22: Special Mounting Instructions
The position of the rupture disk is indicated on a sticker beside it. For additional information that is relevant to the process (→ 105). The existing connecting nozzles are not designed for a rinse or pressure monitoring function. Endress+Hauser... - Page 23 Experience shows that zero point adjustment is advisable only in special cases: • To achieve maximum measuring accuracy even with low flow rates • Under extreme process or operating conditions (e.g. very high process temperatures or very high-viscosity fluids). Endress+Hauser...
-
Page 24: Mounting The Measuring Device
• According to medium properties (outgassing, with entrained solids) Does the arrow on the sensor nameplate match the direction of flow of the fluid through the piping (→ 19)? Are the measuring point identification and labeling correct (visual inspection)? Endress+Hauser... - Page 25 Proline Promass O 100 HART Installation Is the device adequately protected from precipitation and direct sunlight? Are the securing screw and securing clamp tightened securely? Endress+Hauser...
-
Page 26: Electrical Connection
Pulse/frequency/switch output Standard installation cable is sufficient. Cable diameter • Cable glands supplied: M20 × 1.5 with cable 6 to 12 mm (0.24 to 0.47 in) • Spring terminals: Wire cross-sections 0.5 to 2.5 mm (20 to 14 AWG) Endress+Hauser... -
Page 27: Terminal Assignment
Output 2 "Output" 2 (L-) 1 (L+) 27 (–) 26 (+) 25 (–) 24 (+) Option B DC 24 V 4-20 mA HART (active) Pulse/frequency/switch output (passive) Order code for "Output": Option B: 4-20 mA HART with pulse/frequency/switch output Endress+Hauser... -
Page 28: Pin Assignment, Device Plug
For use in potentially explosive atmospheres, observe the information in the device- specific Ex documentation. 7.2.1 Connecting the transmitter The connection of the transmitter depends on the following order codes: • Housing version: compact or ultra-compact • Connection version: device plug or terminals Endress+Hauser... - Page 29 Device plug for signal transmission Device plug for supply voltage For device version with device plug: only pay attention to Step 6. 1. Depending on the housing version, loosen the securing clamp or fixing screw of the housing cover. Endress+Hauser...
-
Page 30: Special Connection Instructions
Do the cables comply with the requirements (→ 26)? Do the cables have adequate strain relief? Are all the cable glands installed, firmly tightened and leak-tight? Cable run with "water trap" (→ 30) ? Endress+Hauser... - Page 31 Is the terminal assignment or the pin assignment of the device plug correct? If supply voltage is present, is the power LED on the electronics module of the transmitter lit green (→ 11)? Depending on the device version, is the securing clamp or fixing screw firmly tightened? Endress+Hauser...
-
Page 32: Operation Options
Proline Promass O 100 HART Operation options Overview of operation options A0019598 Computer with Web browser (e.g. Internet Explorer) or with operating tool (e.g. FieldCare, AMS Device Manager, SIMATIC PDM) Field Xpert SFX350 or SFX370 Field Communicator 475 Control system (e.g. PLC) Endress+Hauser... -
Page 33: Structure And Function Of The Operating Menu
Submenu 1 Submenu n Diagnostics Parameter 1 Parameter n Submenu 1 Submenu n Operating menu for experts Expert Access status display Parameter n System Sensor Intput Output Communication Application Diagnostics A0018237-EN 10 Schematic structure of the operating menu Endress+Hauser... -
Page 34: Operating Philosophy
In addition to the measured values, status information on the device is also displayed and allows the user to monitor the status of the device. Furthermore the device data can be managed and the network parameters can be configured. Endress+Hauser... -
Page 35: Prerequisites
3. Configure the properties of the Internet protocol (TCP/IP) as defined in the table above. Starting the Web browser 1. Start the Web browser on the computer. 2. Enter the IP address of the Web server in the address line of the Web browser: 192.168.1.212 Endress+Hauser... -
Page 36: Logging On
0000 (factory setting); can be changed by customer (→ 72) If no action is performed for 10 minutes, the Web browser automatically returns to the login page. 8.3.5 User interface A0017757-EN Picture of device Function row with 6 functions Device tag Header Working area Navigation area Endress+Hauser... -
Page 37: Disabling The Web Server
The Web server for the measuring device can enabled and disabled as required via the Web server functionality parameter. Navigation "Expert" menu → Communication → Web server Parameter overview with brief description Parameter Description Selection Factory setting Web server functionality Switch the Web server on and off. • Off • On Endress+Hauser... -
Page 38: Logging Out
Options for remote operation via HART protocol Control system (e.g. PLC) Field Communicator 475 Computer with operating tool (e.g. FieldCare, AMS Device Manager, SIMATIC PDM) Commubox FXA195 (USB) Field Xpert SFX350 or SFX370 VIATOR Bluetooth modem with connecting cable Transmitter Endress+Hauser... -
Page 39: Field Xpert Sfx350, Sfx370
FieldCare Function scope FDT-based plant asset management tool from Endress+Hauser. It can configure all smart field devices in a system and helps you manage them. By using the status information, it is also a simple but effective way of checking their status and condition. - Page 40 6. Enter the device address in the IP address field and press Enter to confirm: 192.168.1.212 (factory setting); if the IP address is not known . 7. Establish the online connection to the device. For details, see Operating Instructions BA00027S and BA00059S Endress+Hauser...
-
Page 41: Ams Device Manager
See data (→ 43) 8.4.5 SIMATIC PDM Function scope SIMATIC PDM is a standardized, manufacturer-independent program from Siemens for the operation, configuration, maintenance and diagnosis of intelligent field devices via HART protocol. Source for device description files See data (→ 43) Endress+Hauser... -
Page 42: Field Communicator 475
Operation options Proline Promass O 100 HART 8.4.6 Field Communicator 475 Function scope Industrial handheld terminal from Emerson Process Management for remote configuration and measured value display via HART protocol. Source for device description files See data (→ 43) Endress+Hauser... -
Page 43: System Integration
• Field Xpert SFX350 Use update function of handheld terminal • Field Xpert SFX370 FieldCare • www.endress.com → Download Area • CD–ROM (contact Endress+Hauser) • DVD (contact Endress+Hauser) AMS Device Manager www.endress.com → Download Area (Emerson Process Management) SIMATIC PDM www.endress.com... - Page 44 • 9 = dynamic viscosity • 10 = kinematic viscosity • 11 = temp. compensated dynamic viscosity • 12 = temp. compensated kinematic viscosity • 13 = target mass flow • 14 = carrier mass flow • 15 = concentration Endress+Hauser...
-
Page 45: Other Settings
• Command 9 option: Read out the dynamic HART variables including the related status. • Command 33 option: Read out the dynamic HART variables including the related unit. • Command 48 option: Read out the complete device diagnostics. Endress+Hauser... - Page 46 The message is triggered if the measured value changes. Burst trigger level For entering the burst trigger value. Positive floating-point number 2.0E-38 Together with the option selected in the Burst trigger mode parameter the burst trigger value determines the time of burst message X. Endress+Hauser...
- Page 47 Positive integer 1 000 ms span between two burst commands of burst message X. Max. update period Use this function to enter the maximum Positive integer 2 000 ms time span between two burst commands of burst message X. Endress+Hauser...
-
Page 48: Commissioning
Enter tag for measuring point. Max. 32 characters, such as Promass letters, numbers or special characters (e.g. @, %, /). 10.2.2 Setting the system units In the System units submenu the units of all the measured values can be set. Endress+Hauser... - Page 49 The selected unit is taken from: Volume flow unit parameter Corrected volume flow unit Select corrected volume flow unit. Unit choose list Country-specific: • Nl/h Result • Sft³/h The selected unit applies for: • Output • Low flow cut off • Simulation process variable Endress+Hauser...
- Page 50 Unit choose list Country-specific: • °C (Celsius) Result • °F (Fahrenheit) The selected unit applies for: • Output • Reference temperature • Simulation process variable Pressure unit Select process pressure unit. Unit choose list Country-specific: • bar • psi Endress+Hauser...
-
Page 51: Selecting And Setting The Medium
Enter process pressure to be Positive floating- 0 bar selected in the Pressure used for pressure correction. point number compensation parameter: Fixed value External pressure The following option is Positive floating- 0 bar selected in the Pressure point number compensation parameter: External value Endress+Hauser... -
Page 52: Configuring The Current Output
Navigation "Setup" menu → Current output 1 to 2 Structure of the submenu → Current output 1 to 2 Assign current output Current span 4 mA value 20 mA value Failure mode Failure current Endress+Hauser... - Page 53 2.5 kg/h Failure mode Define output behavior in alarm condition. • Min. Max. • Max. • Last valid value • Actual value • Defined value Failure current Enter current output value in alarm 3.59 to 22.5 22.5 mA condition. Endress+Hauser...
-
Page 54: Configuring The Pulse/Frequency
0.05 to 2 000 ms 100 ms Failure mode Define output behavior in alarm condition. • Actual value No pulses • No pulses Invert output signal Invert the output signal. • No • Yes Frequency output Navigation "Setup" menu → Pulse/frequency/switch output Endress+Hauser... - Page 55 • Frequency fluctuation 1 • Oscillation amplitude 0 • Oscillation amplitude 1 • Oscillation damping 0 • Oscillation damping 1 • Tube damping fluctuation 0 • Tube damping fluctuation 1 • Signal asymmetry • Exciter current 0 • Exciter current 1 Endress+Hauser...
- Page 56 "Setup" menu → Pulse/frequency/switch output Structure of the submenu for the switch output Pulse/frequency/switch output → Operating mode Switch output function Assign diagnostic behavior Assign limit Assign flow direction check Assign status Switch-on value Switch-off value Failure mode Invert output signal Endress+Hauser...
- Page 57 Enter measured value for the switch-on Signed floating-point number 0 kg/h point. Switch-off value Enter measured value for the switch-off Signed floating-point number 0 kg/h point. Switch-on delay Define delay for the switch-on of status 0.0 to 100.0 s 0.0 s output. Endress+Hauser...
-
Page 58: Configuring The Local Display
Value 1 display 0% bargraph value 1 100% bargraph value 1 Value 2 display Value 3 display 0% bargraph value 3 100% bargraph value 3 Value 4 display End of wizard A0013797-EN 13 "Display" wizard in the "Setup" menu Endress+Hauser... -
Page 59: Configuring The Hart Input
Select the measured value that is shown on Picklist (see 1st display value) None the local display. 10.2.7 Configuring the HART input The HART input submenu contains all the parameters that must be configured for the configuration of the HART input. Endress+Hauser... -
Page 60: Configuring The Output
Enter value to be used by the device if input Signed floating-point number value from external device is missing. 10.2.8 Configuring the output conditioning The Output conditioning wizard contains all the parameters that must be configured for the configuration of output conditioning. Navigation "Setup" menu → Output conditioning Endress+Hauser... - Page 61 Damping output # Set reaction time for output signal to 0 to 999.9 s fluctuations in the measured value. Measuring mode output # Select measuring mode for output. • Forward flow Forward flow • Forward/Reverse flow • Reverse flow compensation Endress+Hauser...
- Page 62 Select measuring mode for output. • Forward flow Forward flow • Forward/Reverse flow • Reverse flow • Reverse flow compensation Operating mode totalizer # Select totalizer calculation mode. • Net flow total Net flow total • Forward flow total • Reverse flow total Endress+Hauser...
-
Page 63: Configuring The Low Flow Cut Off
Pressure shock suppression One of the following options is Enter time frame for signal 0 to 100 s selected in the Assign process suppression (= active pressure variable parameter: shock suppression). • Mass flow • Volume flow • Corrected volume flow Endress+Hauser... -
Page 64: Configuring The Partial Filled Pipe
Response time part. filled pipe One of the following options is Enter time before diagnostic 0 to 100 s detect. selected in the Assign process message is displayed for variable parameter: partially filled pipe detection. • Density • Reference density Endress+Hauser... -
Page 65: Advanced Settings
Navigation "Setup" menu → Advanced setup → Calculated values Structure of the submenu Calculated values → Corrected volume flow → Corrected volume flow calculation calculation External reference density Fixed reference density Reference temperature Linear expansion coefficient Square expansion coefficient Endress+Hauser... -
Page 66: Carrying Out A Sensor Adjustment
The Sensor adjustment submenu contains parameters that pertain to the functionality of the sensor. Navigation "Setup" menu → Advanced setup → Sensor adjustment Structure of the submenu Sensor adjustment → Installation direction → → Zero point adjustment Zero point adjustment control Progress Endress+Hauser... -
Page 67: Configuring The Totalizer
Totalizer operation mode Select totalizer calculation mode. • Net flow total Net flow total • Forward flow total • Reverse flow total Failure mode Define totalizer behavior in alarm condition. • Stop Stop • Actual value • Last valid value Endress+Hauser... -
Page 68: Carrying Out Additional Display Configurations
Decimal places 1 Value 2 display Decimal places 2 Value 3 display 0% bargraph value 3 100% bargraph value 3 Decimal places 3 Value 4 display Decimal places 4 Display language Display interval Display damping Header Header text Separator Backlight Endress+Hauser... - Page 69 Select the measured value that is shown on Picklist (see 1st display value) None the local display. 0% bargraph value 3 Enter 0% value for bar graph display. Signed floating-point number 100% bargraph value 3 Enter 100% value for bar graph display. Signed floating-point number Endress+Hauser...
-
Page 70: Simulation
The "Simulation" submenu enables you to simulate, without a real flow situation, various process variables in the process and the device alarm mode and to verify downstream signal chains (switching valves or closed-control loops). Navigation "Diagnostics" menu → Simulation Simulation → Assign simulation process variable Value process variable Simulation current output Endress+Hauser... - Page 71 • Off is selected in the Simulation output on and off. • Fixed value pulse output parameter. • Down-counting If the Fixed value option value is selected, the Pulse width parameter defines the pulse width of the pulses output. Endress+Hauser...
-
Page 72: Protecting Settings From Unauthorized
If no action is performed for 10 minutes, the Web browser automatically returns to the login page. The user role with which the user is currently logged on via the Web browser is indicated by the Access status tooling parameter. Navigation path: Operation → Access status tooling Endress+Hauser... -
Page 73: Write Protection Via Write Protection
If hardware write protection is enabled: the Locking status parameter displays the Hardware locked option(→ 74); if disabled, the Locking status parameter does not display any option (→ 74) 5. Reverse the removal procedure to reassemble the transmitter. Endress+Hauser... -
Page 74: Operation
The Process variables submenu contains all the parameters needed to display the current measured values for every process variable. Navigation "Diagnostics" menu → Measured values → Process variables Process variables Mass flow Volume flow Corrected volume flow Density Reference density Temperature Pressure value Endress+Hauser... -
Page 75: Totalizer
• Volume flow • Mass flow • Corrected volume flow 11.3.3 Output values The "Output values" submenu contains all the parameters needed to display the current measured values for every output. Navigation "Diagnostics" menu → Measured values → Output values Endress+Hauser... -
Page 76: Adapting The Measuring Device To The Process
Preset value parameter. Reset + totalize The totalizer is reset to 0 and the totaling process is restarted. Preset + totalize The totalizer is set to the defined start value in Preset value parameterand the totaling process is restarted. Endress+Hauser... - Page 77 • Preset + hold • Reset + totalize • Preset + totalize Preset value # Specify start value for totalizer. Signed floating-point number 0 kg Reset all totalizers Reset all totalizers to 0 and start. • Cancel Cancel • Reset + totalize Endress+Hauser...
-
Page 78: Diagnostics And Troubleshooting
(→ 35). 2. Clear the Web browser cache and restart the Web browser. Content of Web browser Unsuitable view settings. Change the font size/display ratio incomplete or difficult to read of the Web browser. Endress+Hauser... -
Page 79: Diagnostic Information Via Light Emitting
Status area with status signal Diagnostic information (→ 80) Remedial measures with Service ID Furthermore, diagnostic events that have occurred can be viewed in the Diagnostics menu: • Via parameters (→ 84) • Via submenu (→ 85) Endress+Hauser... -
Page 80: Calling Up Remedy Information
Remedy information can be called up in the working area of the user interface. The user is in the Diagnostics menu. 1. Call up the desired parameter. 2. On the right in the working area, mouse over the parameter. A tool tip with remedy information for the diagnostic event appears. Endress+Hauser... -
Page 81: Adapting The Diagnostic Information
Maintenance is required. The measured value is still valid. A0013957 Has no effect on the condensed status. A0023076 12.5 Overview of diagnostic information The amount of diagnostic information and the number of measured variables affected increase if the measuring device has one or more application packages. Endress+Hauser... - Page 82 1. Reset device 2. Contact service Alarm Electronic failure 1. Do not reset device Warning 2. Contact service I/O communication failed 1. Restart device Alarm 2. Change main electronic module Data storage 1. Insert DAT module 2. Change Alarm DAT module Endress+Hauser...
- Page 83 Contact service Alarm Special event 7 Contact service Alarm Special event 11 Contact service Alarm Diagnostic of process Current loop 1. Check wiring Alarm 2. Change I/O module Sensor temperature too Reduce ambient temp. around the Warning high sensor housing Endress+Hauser...
-
Page 84: Pending Diagnostic Events
To call up the measures to rectify a diagnostic event: • Via Web browser • Via "FieldCare" operating tool (→ 80) Other pending diagnostic events can be displayed in the Diagnostic list submenu(→ 85) Navigation "Diagnostics" menu Endress+Hauser... -
Page 85: Diagnostic List
In addition to the operation time of its occurrence, each event is also assigned a symbol that indicates whether the event has occurred or is ended: • Diagnostic event – : Event has occurred – : Event has ended • Information event : Event has occurred Endress+Hauser... -
Page 86: Filtering The Event Logbook
I1189 Backup compared I1209 Density adjustment ok I1221 Zero point adjust failure I1222 Zero point adjustment ok I1256 Display: access status changed I1264 Safety sequence aborted I1278 I/O module reset detected I1335 Firmware changed I1361 Wrong web server login Endress+Hauser... -
Page 87: Resetting The Measuring Device
Every parameter is reset to its factory setting. 12.10 Device information The Device information submenu contains all the parameters that display different information for identifying the device. Navigation "Diagnostics" menu → Device information Device information → Device tag Serial number Firmware version Endress+Hauser... - Page 88 Device revision Displays the device revision with which the 0 to 255 device is registered with the HART Communication Foundation. Device ID Displays the device ID for identifying the Positive integer 6-digit hexadecimal number device in a HART network. Endress+Hauser...
-
Page 89: 12.11 Firmware History
"Manufacturer' s information" document. The manufacturer' s information is available: • In the Download Area of the Endress+Hauser Internet site: www.endress.com → Download • Specify the following details: –... -
Page 90: Maintenance
(→ 104). 13.2 Measuring and test equipment Endress+Hauser offers a wide variety of measuring and test equipment, such as W@M or device tests. Your Endress+Hauser Sales Center can provide detailed information on the services. For a list of some of the measuring and test equipment, refer to the "Accessories"... -
Page 91: Repair
• Spare parts are grouped into logical kits with the associated Installation Instructions. • Repairs are carried out by Endress+Hauser Service or by correspondingly trained customers. • Certified devices can be converted into other certified devices by Endress+Hauser Service or at the factory only. Notes for repair and conversion For repair and modification of a measuring device, observe the following notes: •... -
Page 92: Disposing Of The Measuring Device
Ensure that the measuring device and all cavities are free of fluid residues that are hazardous to health or the environment, e.g. substances that have permeated into crevices or diffused through plastic. Observe the following notes during disposal: • Observe valid federal/national regulations. • Ensure proper separation and reuse of the device components. Endress+Hauser... -
Page 93: Accessories
Various accessories, which can be ordered with the device or subsequently from Endress +Hauser, are available for the device. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com. -
Page 94: System Components
The application already contains the data of your Endress+Hauser device. Endress +Hauser also takes care of maintaining and updating the data records. -
Page 95: Technical Data
The full scale values depend on the density of the gas and can be calculated with the formula below: = · ρ max(G) max(F) Maximum full scale value for gas [kg/h] max(G) Maximum full scale value for liquid [kg/h] max(F) Endress+Hauser... -
Page 96: Output
• Corrected volume flow • Density • Reference density • Temperature The range of options increases if the measuring device has one or more application packages. Pulse/frequency/switch output Function Can be set to pulse, frequency or switch output Version Passive, open collector Endress+Hauser... - Page 97 Depending on the interface, failure information is displayed as follows: Current output 4-20 mA Failure mode Selectable (as per NAMUR recommendation NE 43): • Minimum value: 3.6 mA • Maximum value: 22 mA • Defined value: 3.59 to 22.5 mA • Actual value • Last valid value Endress+Hauser...
- Page 98 The following connections are galvanically isolated from each other: • Outputs • Power supply Protocol-specific data HART • For information on the device description files (→ 43) • For information on the dynamic variables and measured variables (HART device variables) (→ 43) Endress+Hauser...
-
Page 99: Power Supply
(20 to 14 AWG) Cable entries • Cable gland: M20 × 1.5 with cable 6 to 12 mm (0.24 to 0.47 in) • Thread for cable entry: – NPT ½" – G ½" – M20 Cable specification (→ 26) Endress+Hauser... -
Page 100: Performance Characteristics
[mm] [kg/h] [kg/h] [kg/h] [kg/h] [kg/h] [kg/h] 180 000 18 000 9 000 3 600 1 800 350 000 35 000 17 500 7 000 3 500 800 000 80 000 40 000 16 000 8 000 1 600 Endress+Hauser... - Page 101 The response time depends on the configuration (damping). Influence of ambient o.r. = of reading; o.f.s. = of full scale value temperature Current output Temperature coefficient Max. ±50 ppm/°C o.f.s. or ±1 µA/°C Pulse/frequency output Temperature coefficient Max. ±50 ppm o.r. /100 °C Endress+Hauser...
- Page 102 –0.0035 –0.0002 –0.002 –0.0001 Design fundamentals o.r. = of reading, o.f.s. = of full scale value BaseAccu = base accuracy in % o.r., BaseRepeat = base repeatability in % o.r. MeasValue = measured value; ZeroPoint = zero point stability Endress+Hauser...
-
Page 103: Installation
16.7 Installation "Mounting requirements" (→ 18) 16.8 Environment Ambient temperature (→ 20) range Storage temperature –50 to +60 °C (–58 to +140 °F) (Order code for "Test, certificate", option JM) Climate class DIN EN 60068-2-38 (test Z/AD) Endress+Hauser... -
Page 104: Process
The sensor housing is filled with dry nitrogen and protects the electronics and mechanics pressure rating inside. Nominal pressure according to ASME BPVC. Secondary containment Secondary containment burst pressure nominal pressure (designed with a safety factor ≥ 4) [mm] [in] [bar] [psi] [bar] [psi] 1440 1360 1270 Endress+Hauser... - Page 105 – The flow velocity in the measuring tubes should not exceed half the sonic velocity (0.5 Mach). – The maximum mass flow depends on the density of the gas: formula (→ 95) Pressure loss To calculate the pressure loss, use the Applicator sizing tool (→ 111) Endress+Hauser...
-
Page 106: 16.10 Mechanical Construction
A0020640 14 Possible cable entries/cable glands Cable entry in transmitter housing, wall-mount housing or connection housing with internal thread M20 x Cable gland M20 x 1.5 Adapter for cable entry with internal thread G ½" or NPT ½" Endress+Hauser... - Page 107 • Stainless steel, 25Cr Duplex (Super Duplex) • Stainless steel, 1.4410 (F53) Safety Barrier Promass 100 Housing: Polyamide Process connections Flanges: – EN 1092-1 (DIN 2512N) – ASME B16.5 For information on the materials of the process connections (→ 106) Endress+Hauser...
-
Page 108: 16.11 Operability
Once the work is completed, plug the local display back on. Remote operation Via HART protocol This communication interface is present in the following device version: Order code for "Output", option B: 4-20 mA HART, pulse/frequency/switch output Endress+Hauser... - Page 109 Can be operated in the following languages: • Via "FieldCare" operating tool: English, German, French, Spanish, Italian, Chinese, Japanese • Via Web browser English, German, French, Spanish, Italian, Dutch, Portuguese, Polish, Russian, Turkish, Chinese, Japanese, Bahasa (Indonesian), Vietnamese, Czech Endress+Hauser...
-
Page 110: 16.12 Certificates And Approvals
EC Directives. These are listed in the corresponding EC Declaration of Conformity along with the standards applied. Endress+Hauser confirms successful testing of the device by affixing to it the CE mark. C-Tick symbol The measuring system meets the EMC requirements of the "Australian Communications and Media Authority (ACMA)". -
Page 111: 16.13 Application Packages
The application packages can be ordered from Endress+Hauser either directly with the device or subsequently. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com. -
Page 112: 16.15 Documentation
• The W@M Device Viewer : Enter the serial number from the nameplate (www.endress.com/deviceviewer) • The Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2-D matrix code (QR code) on the nameplate. Standard documentation... -
Page 113: Appendix
(→ 70) Totalizer handling → (→ 76) Control Totalizer 1 to 3 (→ 77) (→ 77) Preset value 1 to 3 (→ 76) Reset all totalizers 17.1.3 "Setup" menu Setup → (→ 48) Endress+Hauser... - Page 114 Assign flow direction (→ 57) check Assign status (→ 57) Value per pulse (→ 54) Pulse width (→ 54) Failure mode (→ 54) Minimum frequency (→ 56) value Maximum frequency (→ 56) value Endress+Hauser...
- Page 115 (→ 64) Low value partial filled (→ 64) pipe detection High value partial filled (→ 64) pipe detection Response time part. filled (→ 64) pipe detect. → (→ 59) HART input Capture mode (→ 60) Endress+Hauser...
- Page 116 (→ 65) calculation Corrected volume flow (→ 66) calculation External reference (→ 66) density Fixed reference density (→ 66) Reference temperature (→ 66) Linear expansion (→ 66) coefficient Square expansion (→ 66) coefficient Endress+Hauser...
- Page 117 (→ 59) Decimal places 4 (→ 70) Display language (→ 70) Display interval (→ 70) Display damping (→ 70) Header (→ 70) (→ 70) Header text Separator (→ 70) Backlight (→ 70) Endress+Hauser...
-
Page 118: Diagnostics" Menu
Operating time (→ 0 Diagnostic list → (→ 85) Diagnostics 1 to 5 (→ 85) Event logbook → (→ 85) Filter options (→ 86) Device information → (→ 87) Device tag (→ 88) Endress+Hauser... - Page 119 (→ 75) Temperature (→ 75) (→ 75) Pressure value Dynamic viscosity Kinematic viscosity Temp. compensated dynamic viscosity Temp. compensated kinematic viscosity Concentration Target mass flow Carrier mass flow Totalizer 1 to 3 → (→ 75) Endress+Hauser...
-
Page 120: Device Information
(→ 112) → → Performing verification Year Month Hour AM/PM Minute Verification mode External device information Start verification Progress Measured values Output values Status Overall result Verification results → Date/time Verification ID Operating time Overall result Sensor Sensor integrity Endress+Hauser... -
Page 121: Expert" Menu
Locking status (0004) (→ 74) Access status display (0091) Access status tooling (→ 73) (→ 72) Enter access code (0092) System (→ 122) Sensor (→ 123) Output (→ 127) Communication (→ 129) Endress+Hauser... - Page 122 Display interval (0096) (→ 70) Display damping (0094) (→ 70) Header (0097) (→ 70) Header text (0112) (→ 70) Separator (0101) (→ 70) Backlight (0111) Diagnostic handling → (→ 78) Alarm delay Diagnostic behavior Endress+Hauser...
- Page 123 392 Assign behavior of diagnostic no. 592 Assign behavior of diagnostic no. 992 Administration → (→ 72) Define access code (→ 72) Device reset (→ 87) Activate SW option Software option overview "Sensor" submenu Sensor → Endress+Hauser...
- Page 124 Mass unit (→ 49) Volume flow unit (→ 49) Volume unit (→ 49) Corrected volume flow (→ 49) unit Corrected volume unit (→ 50) Density unit (→ 50) Reference density unit (→ 50) Endress+Hauser...
- Page 125 User pressure factor (0579) Process parameters → (→ 48) Flow damping Density damping Temperature damping Flow override Low flow cut off → (→ 63) Assign process variable (→ 63) On value low flow cutoff (→ 63) Endress+Hauser...
- Page 126 Corrected volume flow → calculation Corrected volume flow (→ 66) calculation External reference (→ 66) density Fixed reference density (→ 66) Reference temperature (→ 66) Linear expansion (→ 66) coefficient Square expansion (→ 66) coefficient Endress+Hauser...
- Page 127 Temperature offset Temperature factor Calibration → Calibration factor Zero point Nominal diameter C 1 to 5 "Output" submenu → → (→ 52) Output Current output 1 Assign current output (→ 53) (0359) (→ 53) Current span (0353) Endress+Hauser...
- Page 128 Maximum frequency (→ 56) value (0454) Measuring value at (→ 56) minimum frequency (0476) Measuring value at (→ 56) maximum frequency (0475) Measuring mode (0479) Damping output Response time (0491) Failure mode (0451) (→ 56) Endress+Hauser...
- Page 129 "Communication" submenu Communication → HART input → Configuration → Capture mode (7001) Device ID (7007) Device type (7008) Manufacturer ID (7009) Burst command (7006) Slot number (7010) Timeout (7005) Failure mode (7011) Failure value (7012) Input Value (7003) Status (7004) Endress+Hauser...
- Page 130 HART message (0216) HART date code (0202) Hardware revision (0206) Software revision (0224) HART date code Output → (→ 43) Assign PV (0234) (→ 43) Primary variable (PV) (→ 43) (0201) Assign SV (0235) (→ 43) Endress+Hauser...
- Page 131 Event category 274 Event category 441 Event category 442 Event category 443 Event category 830 Event category 831 Event category 832 Event category 833 Event category 834 Event category 835 Event category 862 Event category 912 Event category 913 Endress+Hauser...
- Page 132 Diagnostics → (→ 78) Actual diagnostics (→ 85) (0691) Timestamp Previous diagnostics (→ 85) (0690) Timestamp Operating time from (→ 85) restart (0653) Operating time (0652) (→ 85) Diagnostic list → (→ 85) Endress+Hauser...
- Page 133 Electronic temperature → Minimum value Maximum value Medium temperature → Minimum value Maximum value Carrier pipe → temperature Minimum value Maximum value Oscillation frequency → Minimum value Maximum value Torsion oscillation → frequency Minimum value Maximum value Oscillation amplitude → Endress+Hauser...
- Page 134 Maximum value Heartbeat → (→ 112) Progress Customer (2750) Location (2751) Performing verification → Year (2846) Month (2845) Day (2842) Hour (2843) AM/PM (2813) Minute (2844) Start verification (12127) Progress Status Overall result (12149) → Verification results Date/time (12142) Endress+Hauser...
- Page 135 Assign simulation (→ 71) process variable (1810) Value process variable (→ 71) (1811) Simulation device alarm (→ 72) (0654) Order code for "Application package", option EB "Heartbeat Verification and Monitoring", see the Special Documentation for the device Endress+Hauser...
-
Page 136: Index
Enabling write protection ..... 72 Endress+Hauser services Declaration of Conformity ..... . 9 Define access code . - Page 137 Mounting dimensions Inspection check see Installation dimensions Connection ......30 Endress+Hauser...
- Page 138 Web server (submenu) ..... 37 Partial filled pipe detection ....64 Endress+Hauser...
- Page 139 Terminals ....... . . 99 Thermal insulation ......21 Tools Endress+Hauser...
