Technical
Information
TI 094D/24/ae
Electromagnetic flow
measuring system
PROline promag 10 P
Flow measurement in chemical
or process applications
Application
Electromagnetic flowmeter for measuring
liquids with a minimum conductivity of
50 µS/cm, such as:
• Acids or alkalis
• Chemically loaded wastewater
• Paints
• Sewage sludge
Nominal diameters from 1" to 12"
Maximum fluid temperature:
PTFE: 265°F (130°C)
Sensor fitting lengths to ISO and DVGW
Features and benefits
• Ideal for simple measuring tasks -
current output for displaying the
current flow, pulse output for driving
an external totalizer or as status
output
• Guaranteed safety of application -
Promag 10 offers all basic functions
to guarantee a high degree of
reliability and measured value stability
• Optimum process control based on an
accuracy of ± 0.5%
• PTFE lining guarantees maximum
resistance in the case of aggressive
fluids and temperatures up to 265°F
• Used in difficult conditions (in shafts,
areas with vibration, or permanently
under water) - the sensor can be
installed separate from the transmitter
and is availalbe with NEMA 6P (IP 68)
protection.
• Service friendly - functional design
makes maintenance work easier -
HART
®
, Fieldtool and FieldCheck
provide support right down to device
verification without the need for sensor
removal.
The Power of Know How
Advertisement
Table of Contents
Related Manuals for Endress+Hauser PROline promag 10 P
Summary of Contents for Endress+Hauser PROline promag 10 P
-
Page 1: Measuring System
Electromagnetic flow Technical Information measuring system TI 094D/24/ae PROline promag 10 P Flow measurement in chemical or process applications Application • PTFE lining guarantees maximum resistance in the case of aggressive Electromagnetic flowmeter for measuring fluids and temperatures up to 265°F liquids with a minimum conductivity of 50 µS/cm, such as:... -
Page 2: Function And System Design
PROline Promag 10 P Function and system design Measuring principle Faraday’s law of induction states that a voltage is induced in a conductor moving in a magnetic field. In electromagnetic measuring, the flowing medium corresponds to the moving conductor. The induced voltage is proportional to the flow velocity and is detected by two measuring electrodes and transmitted to the amplifier. -
Page 3: Power Supply
PROline Promag 10 P Output Output signal Current output: Active, galvanically isolated, full scale value selectable temperature coefficient: typically 1.1 µA/°F (2 µA/°C) Resolution: 1.5 µA ≥ 250Ω) ® Active: 4 to 20 mA, R < 700Ω (HART Pulse output: Passive, open collector, 30 VDC, 250 mA, galvanically isolted. -
Page 4: Supply Voltage
PROline Promag 10 P Electrical connection, remote version Coil circuit Electrode circuit Meas.signal Pipe S1 E1 E2 S2GND E S n.c. n.c. n.c. E1 E2 GND E Cover of the connection compartment Cover of the sensor connection housing Signal cable Coil current cable n.c. -
Page 5: Potential Equalization
PROline Promag 10 P a = signal cable, b = coil current cable (maximum 16 AWG (2.5 mm 1 = Core 5 = Core strengthening 2 = Core insulation 6 = Cable shield 3 = Core shield 7 = Outer jacket... - Page 6 When using ground disks, note the following points: • Ground disks can be ordered from Endress+Hauser as an accessory • Ground disks (including seals) increase the installation length. Refer to the disk dimensions.
-
Page 7: Performance Characteristics
PROline Promag 10 P Pipes with cathodic protection If the medium cannot be grounded for process-related reasons, the measuring device must be installed in such a way as to be potential-free: • When installing the measuring device, make sure that there is an electrical connection between the two piping runs, 9 AWG copper wire (6 mm •... -
Page 8: Installation Instructions
PROline Promag 10 P Operating conditions: Installation Installation instructions Mounting location Correct measuring is possible only if the pipe is full. Avoid the following locations: • Highest point in the run. Risk of air accumulating • Directly upstream from an open pipe outlet in a down pipe Installation of pumps Do not install the sensor on the inlet side of a pump. - Page 9 PROline Promag 10 P Vertical pipes Install a siphon (2) or a vent valve (1) downstream of the sensor in vertical pipes longer than 15 feet (5 meters). This precaution is to avoid low pressure and the consequent risk of damage to the lining of the measuring tube. These measures also prevent the system losing prime, which could cause air inclusions.
- Page 10 PROline Promag 10 P Vibrations Secure the piping and the sensor if vibration is severe. Caution: It is advisable to install the sensor and transmitter separately if vibration is exces- sively severe. The sensor is shock and vibration resistant for acceleration up to 2 g in accordance with IEC 68-2-6.
-
Page 11: Operating Conditions: Environment
PROline Promag 10 P Length of connecting cable Permissible cable length Lmax depends on the conductivity of the medium. A minimum conductivity of 50 µS/cm is required. Ft (m) (50) (100) (200) Gray shaded area = permissible range for medium conductivity Lmax = length of connecting cable in feet (m) Medium conductivity in µ... - Page 12 As a rule, the pipeline diameter determines the sensor diameter. With a known flowrate and the help of the Endress+Hauser Flow Applicator, the best size can be selected. Generally, a velocity range of 6 to 10 ft/sec should be selected.
-
Page 13: Mechanical Construction
PROline Promag 10 P Mechanical construction Design, dimensions Remote transmitter dimensions Dimensions are in inches (mm) 6.34” - 7.13” (161 - 181) 4.76” 7.01” (121) 0.78” - 1.18” (178) (20 - 30) 5.91” (150) 12.9” (327.5) 6.99” 3.94” 5.24” (177.5) - Page 14 PROline Promag 10 P Promag 10 P (compact version) 6.34” - 7.13” (161 - 181) 4.76” 7.01” (121) 0.78” - 1.18” (178) (20 - 30) 5.91” (150) (DVGW) Nominal Weight * Size inches 7.87 9.72 3.31 4.72 3.70 13.0 1-1/2 7.87...
- Page 15 PROline Promag 10 P Promag 10 W (remote version) 6.73" 5.08" (171) (129) 5.63" (143) 4.01" (102) Nominal Weight * Size inches 7.87 11.2 7.95 3.31 4.72 3.70 1-1/2 7.87 11.2 7.95 3.31 4.72 3.70 7.87 11.2 7.95 3.31 4.72 3.70...
- Page 16 PROline Promag 10 P Ground disk, 1” to 12” Ø B Æ 0.26" (6.5) 0.59" (15) Ø A 0.39" (10) Ø D 0.08" Nominal size 1.18 2.44 3.05 77.5 3.44 87.5 1-1/2 1.75 44.5 3.23 3.98 4.06 2.22 56.5 3.98 4.55...
-
Page 17: Human Interface
® and FieldTool™ Certificates and approvals CE mark By attaching the CE mark, Endress+Hauser confirms that the instrument fulfills all the requirements of the relevant EC directives. Other standards and guidelines EN 60529: Degrees of protection by housing (IP code) -
Page 18: Supplemental Documentation
PROline Promag 10 P Accessories Various accessories, which can be ordered from Endress+Hauser, are available for the transmitter and the sensor. Contact your local representative or Endress+Hauser for detailed information. Supplemental documentation Technical Information Promag 10 W (TI 093D/24/ae) Technical Information Promag 10 H (TI 095D/24/ae) -
Page 19: Ordering Information
PROline Promag 10 P Ordering information Promag 10 P - Nominal diameter / maximum full scale 1” / 80 gpm 1-1/2” / 200 gpm 2” / 290 gpm 3” / 790 gpm 4” / 1240 gpm 6” / 2640 gpm 8”... - Page 20 Col. Jardines del Pedregal Phone: (317) 535-7138 Phone: (905) 681-9292 01900, Mexico D.F. 888-ENDRESS 800-668-3199 Mexico FAX: (317) 535-8498 FAX: (905) 681-9444 Phone: (525) 568-2405 FAX: (525) 568-7459 Endress+Hauser The Power of Know How TI 094D/24/ae/05.04 © 2004 Endress+Hauser, Inc.
