Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Enlarged version
Toshiba Personal Computer
PORTÉGÉ A600
Maintenance Manual
First edition September 2008
TOSHIBA CORPORATION
File Number 960-710
[CONFIDENTIAL]
Downloaded from
www.Manualslib.com
manuals search engine

Advertisement

Table of Contents
loading

Related Manuals for Toshiba PORTÉGÉ A600

Summary of Contents for Toshiba PORTÉGÉ A600

  • Page 1 Toshiba Personal Computer PORTÉGÉ A600 Maintenance Manual First edition September 2008 TOSHIBA CORPORATION File Number 960-710 [CONFIDENTIAL] Downloaded from www.Manualslib.com manuals search engine...
  • Page 2 © 2008 by Toshiba Corporation. All rights reserved. Under the copyright laws, this manual cannot be reproduced in any form without the prior written permission of Toshiba. No patent liability is assumed with respect to the use of the information contained herein.
  • Page 3 NOTE: “Note” contains general information that relates to your safe maintenance service. Improper repair of the computer may result in safety hazards. Toshiba requires service technicians and authorized dealers or service providers to ensure the following safety precautions are adhered to strictly.
  • Page 4 The manual is divided into the following parts: Chapter 1 Hardware Overview describes the PORTEGE A600system unit and each FRU. Chapter 2 Troubleshooting Procedures explains how to diagnose and resolve FRU problems. Chapter 3 Test and Diagnostics describes how to perform test and diagnostic operations for maintenance service.
  • Page 5 Conventions This manual uses the following formats to describe, identify, and highlight terms and operating procedures. Acronyms On the first appearance and whenever necessary for clarification acronyms are enclosed in parentheses following their definition. For example: Read Only Memory (ROM) Keys Keys are used in the text to describe many operations.

  • Page 6: Table Of Contents

    Table of Contents Chapter 1 Hardware Overview Features ........................1-1 System Unit Block Diagram ..................1-8 3.5-inch Floppy Disk Drive (USB External) ............1-14 2.5-inch Hard Disk Drive..................1-15 1.8-inch Solid State Drive (SSD)................1-17 DVD-Super Multi Drive Optical Drive (ODD) ............1-18 Keyboard.........................
  • Page 7 Chapter 2 Troubleshooting Procedures Troubleshooting ......................2-1 Troubleshooting Flowchart..................2-3 Power Supply Troubleshooting.................. 2-8 System Board Troubleshooting................2-18 USB FDD Troubleshooting ..................2-33 Keyboard and Touch pad Troubleshooting.............. 2-43 Display Troubleshooting..................2-45 Optical Disk Drive Troubleshooting................ 2-47 2.10 Modem Troubleshooting..................2-50 2.11 LAN Troubleshooting....................
  • Page 8 Chapter 3 Tests and Diagnostics The Diagnostic Test ....................3-1 Executing the Diagnostic Test ................... 3-4 Setting of the hardware configuration ............... 3-9 Heatrun Test......................3-11 Subtest Names......................3-12 System Test......................3-14 Memory Test......................3-16 Keyboard Test......................3-17 Display Test ......................3-18 3.10 Floppy Disk Test......................
  • Page 9 3.32 SETUP ........................3-81 Chapter 4 Replacement Procedures Overview........................4-1 Appendices Appendix A Handling the LCD Module ................A-1 Appendix B Board Layout ....................B-1 Appendix C Pin Assignments.................... C-1 Appendix D Keyboard Scan/Character Codes ..............D-1 Appendix E Key Layout.....................E-1 Appendix F Wiring Diagrams....................
  • Page 10 [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...

  • Page 11: Chapter 1 Hardware Overview

    Chapter 1 Hardware Overview [CONFIDENTIAL] Downloaded from www.Manualslib.com manuals search engine...
  • Page 12 1 Hardware Overview 1-ii [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...
  • Page 13 1 Hardware Overview Chapter 1 Contents Features........................1-1 System Unit Block Diagram..................1-8 3.5-inch Floppy Disk Drive (USB External)............1-14 2.5-inch Hard Disk Drive ..................1-15 1.8-inch Solid State Drive (SSD) ................1-17 DVD-Super Multi Drive Optical Drive (ODD)............1-18 Keyboard .........................1- 19 TFT Color Display ....................1- 20 Power Supply......................1- 21 1.10 Batteries........................1- 23...
  • Page 14 1 Hardware Overview Figures Figure 1-1 Front of the computer ..................1- 7 Figure 1-2 System unit configuration................1- 8 Figure 1-3 System unit block diagram ................1- 9 Figure 1-4 3.5-inch FDD (USB External) ..............1- 15 Figure 1-5 2.5-inch HDD ....................1- 16 Figure 1-6 DVD Super Multi drive ................1- 20 Figure 1-7...

  • Page 15: Features

    1.1 Features 1 Hardware Overview Features The Toshiba PORTEGE A600 Personal Computer uses extensive Large Scale Integration (LSI), and Complementary Metal-Oxide Semiconductor (CMOS) technology extensively to provide compact size, minimum weight, low power usage and high reliability. This computer incorporates the following features.
  • Page 16 1 Hardware Overview 1.1 Features Some models are equipped with a "Solid State Drive (SSD)" instead of a hard disk drive. • 64GB,128GB USB FDD A 3.5-inch USB FDD accommodates 2HD (1.44MB) or 2DD (720KB) disks. Optical Drive (SATA ODD) The computer (Some models) contains a DVD Super Multi drive (double layer).
  • Page 17 1.1 Features 1 Hardware Overview Batteries The computer has two batteries: a rechargeable Lithium-Ion main battery pack and RTC battery (that backs up the Real Time Clock and CMOS memory. Universal Serial Bus (USB2.0) Two USB ports are provided. The ports comply with the USB2.0 standard, which enables data transfer speeds 40 times faster than USB1.1 standard.
  • Page 18 1 Hardware Overview 1.1 Features Docking interface port The docking interface port enables connection of an optional Slim Port Replicator II. It provides additional features as follows: • RJ45 LAN jack • External monitor port • DC IN 15V jack •...
  • Page 19 The computer (Some models) is equipped with PCI Express Mini Card type 3G card TOSHIBA Assist button When this button is pressed during power-on, the PC is connected to "Toshiba Assist". When this button is pressed during power-off, the PC is turned on and connected to "Toshiba Assist".

  • Page 20: Figure 1-1 Front Of The Computer

    1 Hardware Overview 1.1 Features Figure 1-1 Front of the computer [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...

  • Page 21: Figure 1-2 System Unit Configuration

    1.1 Features 1 Hardware Overview The system unit configuration is shown in figure 1-2. Figure 1-2 System unit configuration PORTEGE A600 Maintenance Manual (960-710 [CONFIDENTIAL] Downloaded from www.Manualslib.com manuals search engine...

  • Page 22: System Unit Block Diagram

    1 Hardware Overview 1.2 System Unit Block Diagram System Unit Block Diagram Figure 1-3 is a block diagram of the system unit. Figure 1-3 System unit block diagram [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...
  • Page 23 1 Hardware Overview The system unit is composed of the following major components: Microprocessor ® The Toshiba PORTEGE A600 computer is equipped with an Intel Core 2 Duo ULV Processor. These processors incorporate a math co-processor, a 3MB L2 cache memory.
  • Page 24 1 Hardware Overview 1.2 System Unit Block Diagram North Bridge (Intel Cantiga GS :Intel GS45) • Penryn Processor System Bus Supports • System Memory supports :DDR2-667／DDR2-800, 5GB max. • Internal Graphics High-performance mode：533MHz /1.05V ：320MHz / 1.00V Low-power mode • DMI(Direct Media Interface) •...
  • Page 25 1.2 System Unit Block Diagram 1 Hardware Overview Card controller (R5C847) • - PCI Interface • - SD/MMC, Memory Stick, xD card Controller VGA Controller An internal Graphics Controller in North Bridge is used. Sound Controller • HD Audio Link (Intel High Definition Audio I/F) and RealTec ALC262 •...
  • Page 26 1 Hardware Overview 1.2 System Unit Block Diagram Internal LAN Controller • Intel made only GigaBit Ether is used. • This controller has the following functions: – PCI-Ex connection – Controller ：Intel madeBoazman (WG82567LM /WG82567LV) : GLCI(PCI-Ex)/LCI Connection – Supports Gigabit Ethernet –...
  • Page 27 1.2 System Unit Block Diagram 1 Hardware Overview PSC (Power Supply Controller) • One TMP86FS49AUG chip is used. • This controller controls the power sources. EEPROM for security • M24C08-WDW6TP (ST micro) chip is used. • SLB9635 TT 1.2（Infineon）chip is used. Clock Generator •...

  • Page 28: Inch Floppy Disk Drive (Usb External)

    1 Hardware Overview 1.3 3.5-inch Floppy Disk Drive (USB External) 3.5-inch Floppy Disk Drive (USB External) The 3.5-inch FDD is a thin, high-performance reliable drive that supports 720KB (formatted) 2DD and 1.44MB (formatted) 2HD disks. The FDD is shown in figure 1-4. The specifications for the FDD are listed in Table 1-1. Figure 1-4 3.5-inch FDD (USB External) Table 1-1 3.5-inch FDD specifications TEAC FD-05PUB-337...

  • Page 29: Inch Hard Disk Drive

    The computer supports a 80GB, 120GB, 160GB, 200GB or 250GB. The HDD is shown in figure 1-5. Specifications are listed in Table 1-2. Figure 1-5 2.5-inch HDD Table 1-2 2.5-inch HDD specifications Items Specifications TOSHIBA TOSHIBA TOSHIBA TOSHIBA G8BC0004G080 G8BC0004G120...
  • Page 30 1 Hardware Overview 1.4 2.5-inch Hard Disk Drive Table 1-2 2.5-inch HDD specifications Specifications HGST HGST HGST HGST HGST Items G8BC00051 G8BC00051 G8BC00051 G8BC00046 G8BC0005 1250 Outline Width (mm) 100.2±0.25 Dimensio Height (mm) 9.5±0.2 Depth (mm) 69.85±0.25 Weight (g) 95 max 102 max Storage size (formatted) 80GB...

  • Page 31: Inch Solid State Drive (Ssd)

    Some models are equipped with a "Solid State Drive (SSD)" instead of a hard disk drive. The computer supports a 64GB and 128GB. The specifications of SSD are listed by the table 1-3. Table 1-3 1.8-inch Solid State Drive (SSD) specifications Items Specifications TOSHIBA TOSHIBA G8BC0004X641 G8BC0004X121 Outline Width 53.60...

  • Page 32: Dvd-Super Multi Drive Optical Drive (Odd)

    1 Hardware Overview 1.6 DVD-Super Multi Drive Optical Drive (ODD) DVD-Super Multi Drive Optical Drive (ODD) The DVD Super Multi drive accommodates either 12 cm (4.72-inch) or 8 cm (3.15-inch) CD-ROM, DVD-ROM, CD-R, CD-RW, DVD-R, DVD+R, DVD-RW, DVD+RW, DVD- RAM. The specifications are listed in Table 1-4.

  • Page 33: Keyboard

    1.7 Keyboard 1 Hardware Overview Keyboard The keyboard is mounted 85(US)/87(UK) keys that consist of character key and control key, and in conformity with JIS. The keyboard is connected to membrane connector on the system board and controlled by the keyboard controller. Figure 1-6 is a view of the keyboard.

  • Page 34: Tft Color Display

    1 Hardware Overview 1.8 TFT Color Display TFT Color Display The TFT color display consists of 12.1-inch WXGA LCD module. 1.8.1 LCD Module The LCD module used for the TFT color display uses a white LED backlight as the light source and can display a maximum of 16M colors with 1,200 x 800 resolutions.

  • Page 35: Power Supply

    1.9 Power Supply 1 Hardware Overview Power Supply The power supply supplies many different voltages to the system board and performs the following functions: 1. Judges that the DC power supply (AC adapter) is connected to the computer. 2. Detects DC output and circuit malfunctions. 3.
  • Page 36 1 Hardware Overview 1.9 Power Supply Table 1-6 Power supply output rating ACPI state S3/S4/S5 S4/S5 S4/S5 M state Moff Moff Moff Moff Wakeup Powe Voltage Name Object r line name × × × × × × IGD-PGV × × ×...

  • Page 37: Batteries

    1.10 Batteries 1 Hardware Overview 1.10 Batteries The computer has three types of batteries as follows: Main battery pack RTC battery The battery specifications are listed in Table 1-7. Table 1-7 Battery specifications Battery name Material Output Capacity voltage Main battery G71C00085110/210/710/810 Lithium-Ion 10.8 V...
  • Page 38 1 Hardware Overview 1.10 Batteries 1.10.2 Battery Charging Control Battery charging is controlled by a power supply microprocessor. The microprocessor controls whether the charge is on or off and detects a full charge when the AC adaptor and battery are attached to the computer. The system charges the battery. Battery Charge When the AC adaptor is attached, there are two types of charge: When the system is powered off and when the system is powered on.
  • Page 39 1.10 Batteries 1 Hardware Overview Data preservation time When turning off the power in being charged fully, the preservation time is as following Table 1-9. Table 1-9 Data preservation time Condition preservation time Standby About 2 days Battery(2,900 mAh) Shutdown About 55 days Battery(2,900 mAh) Standby About 5 days Battery(5,800 mAh)

  • Page 40: Ac Adaptor

    1 Hardware Overview 1.11 AC Adapter 1.11 AC Adapter The AC adapter is also used to charge the battery. Table 1-11 lists the AC adapter specifications. Table 1-11 AC adapter specifications Parameter Specification G71C00098210 (2-pin)/ G71C00098310 (2-pin) / G71C00062310(2-pin) Power Input voltage 100V/240V Input frequency...

  • Page 41: Chapter 2 Troubleshooting Procedures

    Chapter 2 Troubleshooting Procedures [CONFIDENTIAL] Downloaded from www.Manualslib.com manuals search engine...
  • Page 42 Troubleshooting Procedures 2-ii [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...
  • Page 43 Troubleshooting Procedures Chapter 2 Contents Troubleshooting ......................2-1 Troubleshooting Flowchart..................2-3 Power Supply Troubleshooting.................. 2-8 Procedure 1 Power Status Check ............... 2-8 Procedure 2 Error Code Check ..............2-10 Procedure 3 Connection Check..............2-16 Procedure 4 Charging Check ..............2-16 Procedure 5 Replacement Check .............
  • Page 44 Troubleshooting Procedures Display Troubleshooting..................2-45 Procedure 1 Diagnostic Test Program Execution Check ......2-45 Procedure 2 Connector and Cable Check..........2-45 Procedure 3 Replacement Check ............. 2-46 Optical Disk Drive Troubleshooting................ 2-47 Procedure 1 Diagnostic Test Program Execution Check ......2-47 Procedure 2 Connector Check and Replacement Check......
  • Page 45 Troubleshooting Procedures 2.17 Fingerprint sensor ....................2-65 Procedure 1 Setting Windows Log-ON password ........2-66 Procedure 2 Registration of fingerprint............ 2-66 Procedure 3 Authentication of fingerprint ..........2-67 Procedure 4 Connector Check and Replacement Check......2-68 2.18 Web camerta Troubleshooting................. 2-69 Procedure 1 Check on Windows OS............
  • Page 46 Troubleshooting Procedures 2-vi [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...

  • Page 47: Troubleshooting

    The implement for the Diagnostics procedures is referred to Chapter 3. Also, following implements are necessary: 1. Phillips screwdrivers (For replacement procedures) 2. Implements for debugging port check • Toshiba MS-DOS system FD • RS-232C cross cable • Test board with debug port test cable •...
  • Page 48 2 Troubleshooting Procedures 2.1 Troubleshooting There are following two types of connections in the figure of board and module connection in and after 2.3 Power Supply Troubleshooting. (1) Cable connection is described in the figure as line. (2) Pin connection is described in the figure as arrow. <e.g>...

  • Page 49: Troubleshooting Flowchart

    Before going through the flowchart steps, verify the following: Ask him or her to enter the password if a password is registered. Verify with the customer that Toshiba Windows is installed on the hard disk. Non- Windows operating systems can cause the computer to malfunction.
  • Page 50 2 Troubleshooting Procedures 2.2 Troubleshooting Flowchart Figure 2-1 Troubleshooting flowchart (1/2) [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...
  • Page 51 2.2 Troubleshooting Flowchart 2 Troubleshooting Procedures Figure 2-1 Troubleshooting flowchart (2/2) PORTEGE A600 Maintenance Manual (960-710) [CONFIDENTIAL] Downloaded from www.Manualslib.com manuals search engine...
  • Page 52 2 Troubleshooting Procedures 2.2 Troubleshooting Flowchart If the diagnostics program cannot detect an error, the problem may be intermittent. The Test program should be executed several times to isolate the problem. Check the Log Utilities function to confirm which diagnostic test detected an error(s), then perform the appropriate troubleshooting procedures as follows: 1.
  • Page 53 2.2 Troubleshooting Flowchart 2 Troubleshooting Procedures 15. If a malfunction is detected on the fingerprint sensor, perform the Fingerprint Sensor Troubleshooting Procedures in Section 2.18. 16. If a malfunction is detected on the Web camerta, perform the Web camerta Troubleshooting Procedures in Section 2.19. 17.

  • Page 54: Power Supply Troubleshooting

    2 Troubleshooting Procedures 2.3 Power Supply Troubleshooting Power Supply Troubleshooting The power supply controller controls many functions and components. To determine if the power supply is functioning properly, start with Procedure 1 and continue with the other Procedures as instructed. The procedures described in this section are: Procedure 1: Power Status Check Procedure 2: Error Code Check Procedure 3: Connection Check...
  • Page 55 2.3 Power Supply Troubleshooting 2 Troubleshooting Procedures Table 2-2 DC IN icon DC IN icon Power supply status Lights blue DC power is being supplied from the AC adapter. Blinks orange Power supply malfunction Doesn’t light Any condition other than those above. *1 When the power supply controller detects a malfunction, the DC IN icon blinks orange.
  • Page 56 2 Troubleshooting Procedures 2.3 Power Supply Troubleshooting Procedure 2 Error Code Check If the power supply microprocessor detects a malfunction, the DC IN icon blinks orange. The blink pattern indicates an error as shown below. Start Off for 2 seconds Error code (8 bit) “1”...
  • Page 57 2.3 Power Supply Troubleshooting 2 Troubleshooting Procedures Check 1 Convert the DC IN icon blink pattern into the hexadecimal error code and compare it to the tables below. Then go to Check 2. Table 2-3 Error code Error code Where error occurs DC Power (AC Adapter) Main battery 2nd battery...
  • Page 58 2 Troubleshooting Procedures 2.3 Power Supply Troubleshooting Main Battery Error code Meaning Main battery discharge current is over 0.5A. Main battery charge current is over 2.3A. The compensation value of [0A] is not within the limits from design data (± 15LSB).
  • Page 59 2.3 Power Supply Troubleshooting 2 Troubleshooting Procedures E3V output Error code Meaning E3V voltage is over 3.96V. E3V voltage is under 2.81V when the computer is powered on. E3V voltage is under 2.81V when the computer is booting up. E3V voltage is under 2.81V when EV power is maintained. 1R5-E1V output Error code Meaning 1R5-E1V voltage is over 1.80V.
  • Page 60 2 Troubleshooting Procedures 2.3 Power Supply Troubleshooting 1R05-E1V output Error code Meaning 1R05-E1V voltage is over 1.26V. 1R05-E1V voltage is under 0.89V when the computer is powered on. 1R05-E1V voltage is under 0.89V when the computer is booting up. 1R05-E1V voltage is under 0.89V when EV power is maintained. 1R5-E1V output Error code Meaning...
  • Page 61 2.3 Power Supply Troubleshooting 2 Troubleshooting Procedures Check 2 In the case of error code 10h or 12h: Make sure the AC adapter and AC power cord are firmly plugged into the DC IN 15 V socket and wall outlet. If the cables are connected firmly, go to the following step.
  • Page 62 2 Troubleshooting Procedures 2.3 Power Supply Troubleshooting Procedure 3 Connection Check The wiring diagram related to the power supply is shown below: Any of the connectors may be disconnected. Perform Check 1. Check 1 Make sure the AC adapter and the AC power cord are firmly plugged into the DC IN jack and wall outlet.
  • Page 63 2.3 Power Supply Troubleshooting 2 Troubleshooting Procedures Procedure 5 Replacement Check The power is supplied to the system board by the AC adapter. If either the AC adapter or the system board was damaged, perform the following Checks. To disassemble the computer, follow the steps described in Chapter 4, Replacement Procedures.

  • Page 64: System Board Troubleshooting

    2 Troubleshooting Procedures 2.4 System Board Troubleshooting System Board Troubleshooting This section describes how to determine if the system board is malfunctioning or not. Start with Procedure 1 and continue with the other procedures as instructed. The procedures described in this section are: Procedure 1: Message Check Procedure 2: Debugging Port Check Procedure 3: Diagnostic Test Program Execution Check...
  • Page 65 2.4 System Board Troubleshooting 2 Troubleshooting Procedures Procedure 1 Message Check When the power is turned on, the system performs the Initial Reliability Test (IRT) installed in the BIOS ROM. The IRT tests each IC on the system board and initializes it. If an error message is shown on the display, perform Check 1.
  • Page 66 2 Troubleshooting Procedures 2.4 System Board Troubleshooting Check 3 The IRT checks the system board. When the IRT detects an error, the system stops or an error message appears. If one of the following error messages (1) through (17), (23) or (24) is displayed, go to Procedure 4.
  • Page 67 2.4 System Board Troubleshooting 2 Troubleshooting Procedures Procedure 2 Debugging Port Check (Boot Mode) Check the D port status by a serial port test. The tool for serial port test is shown below. Figure 2-2 Debug port (Boot mode) error status The test procedures are follows: 1.
  • Page 68 2 Troubleshooting Procedures 2.4 System Board Troubleshooting 6. When the D port status is FFFFh (normal status), go to Procedure 4. 7. When the D port status falls into any status in Table 2-4, execute Check 1. 2-22 [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...
  • Page 69 2.4 System Board Troubleshooting 2 Troubleshooting Procedures Table 2-4 Debug port error status (1/8) System BIOS Boot block processing Debug BIOS processing Target Device IC No. Code CPU setup IC1050(CPU) MCH initialization MCH(register) IC1200(MCH) ICH (register, PIT ICH initialization IC1600(ICH) controller, MEM I/O) EC access check IC3200(EC/KBC)
  • Page 70 2 Troubleshooting Procedures 2.4 System Board Troubleshooting Table 2-5 Debug port error status (2/8) System BIOS IRT processing Debug BIOS processing Target Device IC No. Code CPU setup IC1050(CPU) ICH(PCIRegister,PITContro Initialization of ICH, MCH, and Super IC1600(ICH) ller) F100 IC1200(MCH) MCH(PCIRegister) IC2000(SDController) SDController...
  • Page 71 2.4 System Board Troubleshooting 2 Troubleshooting Procedures Table 2-6 Debug port error status (3/8) EC/KBC(EC,KBC) IC3200(EC/KBC) EC data reading BIOS processing reading 2 ICH (CMOS,PICController, IC1600(ICH) setup of ICH (IDE) IDEController,SoundController, IC1200(MCH) setup of ICH (Azalia) ModeController,PCI Expess, IC1420,1421,1430,1431(RAM) setup of MCH USBController,PCIRegister, IC1440,1441,1450,1451(RAM) Thermal control setup...
  • Page 72 2 Troubleshooting Procedures 2.4 System Board Troubleshooting Table 2-7 Debug port error status (4/8) EC/KBC(EC) IC3200(EC/KBC) BIOS ROM check IC1200(VGA,MCH) Display setup MCH(MEM I/O) IC1420,1421,1430,1431(RAM) F112 IC1440,1441,1450,1451(RAM) Display setup CN1410(RAM Conn.) Display setup ICH(CMOS) IC1600(ICH) F113 Display check ICH(CMOS) IC1600(ICH) Display setup IC1200(VGA) F114...
  • Page 73 2.4 System Board Troubleshooting 2 Troubleshooting Procedures T Table 2-8 Debug port error status (5/8) ICH(CMOS,MEM I/O) IC1600(ICH) Display setup Keystroke check IC1200(VGA) setup of RAM data EC/KBC(EC,KBC) IC3200(EC/KBC) PC card setup IC1420,1421,1430,1431(RAM) Display setup BIOSROM IC1440,1441,1450,1451(RAM) F121 setup of RAM data PC Card Controller CN1410(RAM Conn.) setup of ICH (PCI)
  • Page 74 2 Troubleshooting Procedures 2.4 System Board Troubleshooting Table 2-9 Debug port error status (6/8) System BIOS SUSPEND processing F137 F138 IC1050(CPU) CPU setup F139 It branches to Resume (F13C)/Boot (F141). ICH(USB Controller) IC1600(ICH) F13A setup of ICH ICH(USBController,PITControll IC1600(ICH) setup of ICH Preservation of CPU IC1050(CPU) HDD setup...
  • Page 75 2.4 System Board Troubleshooting 2 Troubleshooting Procedures Table 2-10 Debug port error status (7/8) System BIOS RESUME processing F100 Refer to IRT processing F101 Refer to IRT processing F102 Refer to IRT processing F103 Refer to IRT processing F128 IC1050(CPU) Initialization of ICH (PIT) PIT initialization error ICH (PITController,MEM...
  • Page 76 2 Troubleshooting Procedures 2.4 System Board Troubleshooting Table 2-11 Debug port error status (8/8) EC/KBC(EC) IC3200(EC/KBC) IC1200(VGA) ICH(USBController) IC1600(ICH) IC1420,1421,1430,1431(RAM) F130 Password processing IC1440,1441,1450,1451(RAM) CN1410(RAM Conn.) ICH(DMAC) IC1600(ICH) F131 setup of ICH (DMAC) ICH(CMOS,MEM I/OS, IC1600(ICH) setup of ICH (PCI) IC3200(EC/KBC) CPU setup PITController,PICController)
  • Page 77 2.4 System Board Troubleshooting 2 Troubleshooting Procedures NOTE: Status outputted by the test means the last error detected in the debug port test. Check 1 If the D port is status F11Eh or F120h is displayed, go to “HDD Trouble shooting Procedure in Section 2.6.
  • Page 78 2 Troubleshooting Procedures 2.4 System Board Troubleshooting Procedure 3 Diagnostic Test Program Execution Check Execute the following tests from the Diagnostic Test Menu. These tests check the system board. Refer to Chapter 3, Tests and Diagnostic, for more information on how to perform these tests.

  • Page 79: Usb Fdd Troubleshooting

    2.5 USB FDD Troubleshooting 2 Troubleshooting Procedures USB FDD Troubleshooting This section describes how to determine if the USB FDD is functioning properly. Perform the steps below starting with Procedure 1 and continuing with the other procedures as required. Procedure 1: USB FDD Head Cleaning Check Procedure 2: Diagnostic Test Program Execution Check Procedure 3: Connector Check Procedure 4: Replacement Check...
  • Page 80 2 Troubleshooting Procedures 2.5 USB FDD Troubleshooting Procedure 2 Diagnostic Test Program Execution Check Insert the Diagnostics Disk in the USB FDD, turn on the computer and run the test. Refer to Chapter 3, Tests and Diagnostics, for more information about the diagnostics test procedures. Make sure the floppy disk is formatted correctly and that the write protect tab is disabled.
  • Page 81 2.5 USB FDD Troubleshooting 2 Troubleshooting Procedures Procedure 3 Connector Check The connection of USB port is shown in the following figure. Check 1 Check the connection of the USB FDD. If the USB FDD is still not functioning properly, perform Check 2. Check 2 As the connection may be defective, disassemble the computer and check each connection.
  • Page 82 2 Troubleshooting Procedures 2.5 USB FDD Troubleshooting Procedure 4 Replacement Check The USB FDD or USB FDD cable may be defective or damaged. Replace it with a new one. If the USB FDD is still not functioning properly, perform the following. If USB port 0 does not work properly, perform check 1.
  • Page 83 For the backup, refer to the User’s Manual. Procedure 1 Partition Check Insert the Toshiba MS-DOS system disk and start the computer. Perform the following checks: Check 1 Input C: and press Enter. If you cannot change to drive C, go to Check 2. If you can change to drive C, go to Procedure 2.
  • Page 84 2 Troubleshooting Procedures 2.6 HDD/SSD Troubleshooting Procedure 2 Message Check When the power is turned on, the system performs the Initial Reliability Test (IRT) installed in the BIOS ROM. When the test detects an error, an error message is displayed on the screen. Make sure no floppy disk is in the FDD.
  • Page 85 2.6 HDD/SSD Troubleshooting 2 Troubleshooting Procedures Procedure 3 Format Check The computer’s HDD is formatted using the DOS FORMAT program or the physical format program of the test program. To format the HDD, start with Check 1 below and perform the other steps as required.
  • Page 86 2 Troubleshooting Procedures 2.6 HDD/SSD Troubleshooting Procedure 4 Diagnostic Test Program Execution Check The HDD test program is stored in the Diagnostics Disk. Perform all of the HDD tests in the Hard Disk Drive Test. Refer to Chapter 3, Tests and Diagnostics, for more information about the HDD test program.
  • Page 87 2.6 HDD/SSD Troubleshooting 2 Troubleshooting Procedures Procedure 5 Connector Check and Replacement Check The SATA HDD/ SATA SSD may be disconnected, or the 2.5 SATA HDD/ 1.8 SATA SSD, 2.5HDD FPC/1.8 SSD FPC or system board may be damaged. Disassemble the computer following the steps described in Chapter 4, Replacement Procedures and perform the following checks: Check 1...
  • Page 88 2 Troubleshooting Procedures 2.6 HDD/SSD Troubleshooting Check 2 The 2.5 SATA HDD/ 1.8 SATA SSD may be damaged. Replace it with a new one following the instructions in Chapter 4, Replacement Procedures and check the operation. If the problem still exists, perform Check 3. Check 3 The 2.5HDD FPC/1.8 SSD FPC may be damaged.

  • Page 89: Keyboard And Touch Pad Troubleshooting

    2.7 Keyboard and Touch Pad Troubleshooting 2 Troubleshooting Procedures Keyboard and Touch Pad Troubleshooting To determine if the computer’s keyboard or touch pad is functioning properly, perform the following procedures. Start with Procedure 1 and continue with the other procedures as instructed.
  • Page 90 2 Troubleshooting Procedures 2.7 Keyboard and Touch Pad Troubleshooting Procedure 2 Connector Check and Replacement Check The keyboard, or touch pad may be damaged. Disassemble the computer following the steps described in Chapter 4, Replacement Procedures, and perform the following checks: 1.

  • Page 91: Display Troubleshooting

    2.8 Display Troubleshooting 2 Troubleshooting Procedures Display Troubleshooting This section describes how to determine if the computer’s display is functioning properly. Start with Procedure 1 and continue with the other procedures as instructed. Procedure 1: Diagnostic Test Program Execution Check Procedure 2: Connector Check and Cable Check Procedure 3: Replacement Check Procedure 1...
  • Page 92 2 Troubleshooting Procedures 2.8 Display Troubleshooting Procedure 3 Replacement Check The LCD module and system board are connected to display circuits. Any of these components may be damaged. Refer to Chapter 4, Replacement Procedures. Check 1 Replace the LCD cable with a new one following the instructions in Chapter 4, Replacement Procedures and test the display again.

  • Page 93: Optical Disk Drive Troubleshooting

    2.9 Optical Drive Troubleshooting 2 Troubleshooting Procedures Optical Drive Troubleshooting This section describes how to determine if the optical drive (Super Multi drive) in the Slim Select Bay is functioning properly. Perform the steps below starting with Procedure 1 and continue with the other procedures as required.
  • Page 94 2 Troubleshooting Procedures 2.9 Optical Drive Troubleshooting Procedure 2 Connector Check and Replacement Check (for SATA ODD model) The optical drive (DVD Super Multi drive) is connected to the system board. The connectors may be disconnected from the system board or may be damaged. Disassemble the computer following the steps described in Chapter 4, Replacement Procedures and perform the following checks: Check 1...
  • Page 95 2.9 Optical Drive Troubleshooting 2 Troubleshooting Procedures Procedure 2 Connector Check and Replacement Check (for PATA ODD model) The optical drive (DVD Super Multi drive) is connected to the system board. The connectors may be disconnected from the system board or may be damaged. Disassemble the computer following the steps described in Chapter 4, Replacement Procedures and perform the following checks: Check 1...

  • Page 96: Modem Troubleshooting

    2 Troubleshooting Procedures 2.10 Modem Troubleshooting 2.10 Modem Troubleshooting To check if modem is malfunctioning or not, follow the troubleshooting procedures below as instructed. Procedure 1: Diagnostic Test Program Execution Check Procedure 2: Connector Check and Replacement Check Procedure 1 Diagnostic Test Program Execution Check Execute Modem test in the LAN/Modem/Bluetooth/IEEE1394 test program.
  • Page 97 2.10 Modem Troubleshooting 2 Troubleshooting Procedures Check 2 Modem cable or MDC cable may be faulty. Replace it with a new one. If the problem still occurs, perform Check 3. Check 3 MDC may be faulty. Replace it with a new one following the steps in Chapter 4, Replacement Procedure.

  • Page 98: Lan Troubleshooting

    2 Troubleshooting Procedures 2.11 LAN Troubleshooting 2.11 LAN Troubleshooting To check if the computer’s LAN is malfunctioning or not, follow the troubleshooting procedures below as instructed. Procedure 1: Diagnostic Test Program Execution Check Procedure 2: Connector Check and Replacement Check Procedure 1 Diagnostic Test Program Execution Check Execute LAN test in the LAN/Modem/Bluettoth/IEEE1394 test program.

  • Page 99: Wireless Lan Troubleshooting

    2.12 Wireless LAN Troubleshooting 2 Troubleshooting Procedures 2.12 Wireless LAN Troubleshooting To check if the computer’s Wireless LAN is malfunctioning or not, follow the troubleshooting procedures below as instructed. Procedure 1: Transmitting-Receiving Check Procedure 2: Antennas’ Connection Check Procedure 3: Replacement Check Procedure 1 Transmitting-Receiving Check Before starting the test, make sure the wireless communication switch is set in the ON...
  • Page 100 2 Troubleshooting Procedures 2.12 Wireless LAN Troubleshooting Procedure 2 Antennas' Connection Check The wireless LAN function-wiring diagram is shown below: Any of the connections may be defective. Disassemble the computer following the steps described in Chapter 4, Replacement Procedures, and perform the following checks: Check 1 Make sure the wireless communication switch is “On”.
  • Page 101 2.12 Wireless LAN Troubleshooting 2 Troubleshooting Procedures Procedure 3 Replacement Check Wireless LAN card, wireless LAN antenna or system board may be faulty. Refer to Chapter 4, Replacement Procedures, for instructions on how to disassemble the computer and then perform the following checks: Check 1 Wireless LAN antenna may be faulty.

  • Page 102: Bluetooth Troubleshooting

    2 Troubleshooting Procedures 2.13 Bluetooth Troubleshooting 2.13 Bluetooth Troubleshooting This section describes how to determine if the computer’s Bluetooth is functioning properly. Perform the steps below starting with Procedure 1 and continuing with the other procedures as required. Procedure 1: Diagnostic Test Program Execution Check Procedure 2: Connection Check Procedure 3: Replacement Check Procedure 1...
  • Page 103 2.13 Bluetooth Troubleshooting 2 Troubleshooting Procedures Procedure 2 Connection Check The Bluetooth function wiring diagram is shown below: Any of the connections may be disconnected. Disassemble the computer following the steps described in Chapter 4, Replacement Procedures, and perform the following checks: Check 1 Make sure the Bluetooth module is firmly connected to CN4400 on the sound board.
  • Page 104 2 Troubleshooting Procedures 2.13 Bluetooth Troubleshooting Procedure 3 Replacement Check The Bluetooth antenna, Bluetooth module, sound board and system board are connected to the circuits. Any of these components may be damaged. Refer to Chapter 4, Replacement Procedures, for instructions on how to disassemble the computer and then perform the following checks: Check 1 The Bluetooth module may be defective or damaged.

  • Page 105: Sound Troubleshooting

    2.14 Sound Troubleshooting 2 Troubleshooting Procedures 2.14 Sound Troubleshooting This section describes how to determine if the computer’s sound functions are functioning properly. Perform the steps below starting with Procedure 1 and continuing with the other procedures as required. Procedure 1: Diagnostic Test Program Execution Check Procedure 2: Connecor Check Procedure 3: Replacement Check Procedure 1...
  • Page 106 2 Troubleshooting Procedures 2.14 Sound Troubleshooting As the connection may be defective, disassemble the computer and check each connection. If the problem still occurs, go to Procedure 3. Procedure 3 Replacement Check If headphone does not work properly, perform check 1. If external microphone does not work properly, perform check 2.

  • Page 107: Troubleshooting

    2.15 3G Troubleshooting 2 Troubleshooting Procedures 2.15 3G Troubleshooting This section describes how to determine if the computer’s 3G is functioning properly. Perform the steps below starting with Procedure 1 and continuing with the other procedures as required. Procedure 1: Transmitting-Receiving Check Procedure 2: Antenna Connection Check Procedure 3: Replacement Check Procedure 1 Transmitting-Receiving Check...
  • Page 108 2 Troubleshooting Procedures 2.15 3G Troubleshooting Procedure 2 Antenna Connection Check The 3G wiring diagram is shown below: Any of the connections may be disconnected. Disassemble the computer following the steps described in Chapter 4, Replacement Procedures, and perform the following checks: Check 1 Make sure the 3G antenna cables are firmly connected to the 3G card and FSISD*(SD board).
  • Page 109 2.15 3G Troubleshooting 2 Troubleshooting Procedures Procedure 3 Replacement Check The 3G antenna, 3G card, SIM card, PCIe Mini Card FPC, FSISD*(SD board) and the system board are connected to the circuits. Any of these components may be damaged. Refer to Chapter 4, Replacement Procedures, for instructions how to disassemble the computer and then perform the following checks: Check 1...

  • Page 110: Sd Card Slot Troubleshooting

    2 Troubleshooting Procedures 2.16 SD card Slot Troubleshooting 2.16 SD card Slot Troubleshooting This section describes how to determine if the computer's Bridge media functions are functioning properly. Perform the steps below starting with Procedure 1 and continuing with the other procedures as required. Procedure 1: Check on Windows OS Procedure 2: Connector Check and Replacement Check Procedure 1...

  • Page 111: Fingerprint Sensor

    2.17 Fingerprint sensor Troubleshooting 2 Troubleshooting Procedures 2.17 Fingerprint sensor Troubleshooting CAUTION: To delete the account for confirming the fingerprint operation, it is necessary to log on by the account with the management authority. If the password has been set to log on, ask the Log-ON password to the user. To check if the Fingerprint sensor works correctly or not, follow the troubleshooting procedures below as instructed.
  • Page 112 2 Troubleshooting Procedures 2.17 Fingerprint sensor Troubleshooting Procedure 1 Setting Windows Log-ON password 1. Open [User Account] from [Control Panel]. 2. Click [User Account]. 3. Click the icon of the account (user’s name) that you want to set the password. 4.
  • Page 113 2.17 Fingerprint sensor Troubleshooting 2 Troubleshooting Procedures 7. When the Store to Sensor screen is displayed, check Store fingerprint to Sensor. Click Finish to complete fingerprint registration. Procedure 3 Authentication of fingerprint 1. Turn on the computer to start up Windows. 2.
  • Page 114 2 Troubleshooting Procedures 2.17 Fingerprint sensor Troubleshooting Procedure 4 Connector Check and Replacement Check The connection of the cable and board may be defective. Otherwise, they may be faulty. Disassemble the computer following the steps described in Chapter 4, Replacement Procedures, and perform the following checks: Check 1 Make sure the cables are firmly connected to the Finger/pad board and system...

  • Page 115: Web Camera Troubleshooting

    2.18 Web camera Troubleshooting 2 Troubleshooting Procedures 2.18 Web camera Troubleshooting To check if the computer’s web camera is malfunctioning or not, follow the troubleshooting procedures below as instructed. Procedure 1: Check on Windows OS Procedure 2: Connector Check and Replacement Check Procedure 1 Check on Windows OS Use the software, Camera Assistant Software, which is originally prepared in the computer to...
  • Page 116 2 Troubleshooting Procedures 2.18 Web camera Troubleshooting Check 2 The Web camera may be defective or damaged. Replace the drive with a new one. If there is still an error, go to Check 3. Check 3 The USB board may be defective or damaged. Replace the drive with a new one. If there is still an error, go to Check 4 Check 4 System board may be faulty.

  • Page 117: Intel Turbo Memory Troubleshooting

    2.19 Intel Turbo Memory Troubleshooting U(Not Used)U 2 Troubleshooting Procedures 2.19 Intel Turbo Memory Troubleshooting (Not Used) To check if Intel Turbo Memory is malfunctioning or not, follow the troubleshooting procedures below as instructed. Procedure 1: Check on Windows OS Procedure 2: Connector Check and Replacement Check Procedure 1 Check on Windows OS...
  • Page 118 2 Troubleshooting Procedures 2.19 Intel Turbo Memory Troubleshooting U(Not Used)U If any problems are found, perform the Procedure 2. Procedure 2 Connector Check and Replacement Check The connection of Intel Turbo Memory card may be faulty or the card may be defective. Disassemble the computer following the steps described in Chapter 4 and perform the following checks.

  • Page 119: Chapter 3 Tests And Diagnostics

    Chapter 3 Tests and Diagnostics [CONFIDENTIAL] Downloaded from www.Manualslib.com manuals search engine...
  • Page 120 Tests and Diagnostics 3-ii [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...
  • Page 121 Tests and Diagnostics Chapter 3 Contents The Diagnostic Test ....................3-1 3.1.1 Diagnostics menu ................. 3-1 3.1.2 H/W (Hardware) initial information setting tool........3-2 3.1.3 Heatrun test program................3-3 Executing the Diagnostic Test ................... 3-4 3.2.1 Diagnostics menu (T&D) ..............3-5 3.2.2 H/W initial information setting tool .............
  • Page 122 Tests and Diagnostics 3.20 ONLY ONE TEST....................3-40 3.21.1 Program Description ................3-40 3.21.2 Operations ..................3-40 3.21 Head Cleaning......................3-51 3.21.1 Function Description ................3-51 3.21.2 Operations ..................3-51 3.22 Log Utilities ......................3-52 3.22.1 Function Description ................3-52 3.22.2 Operations ..................
  • Page 123 Tests and Diagnostics Tables Table 3-1 Subtest names ....................3-12 Table 3-2 Error codes and error status names ..............3-35 Table 3-3 Hard disk controller status register contents............3-38 Table 3-4 HDC Error register contents ................3-39 PORTEGE A600 Maintenance Manual (960-710) [CONFIDENTIAL] Downloaded from www.Manualslib.com...
  • Page 124 Tests and Diagnostics 3-vi [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...

  • Page 125: The Diagnostic Test

    3.1 The Diagnostic Test 3 Tests and Diagnostics The Diagnostic Test This chapter explains how to use the Diagnostic Test programs to test the functions of the computer’s hardware modules. The Diagnostics Programs are stored on some Diagnostic Disks. There are Service Program Modules (DIAGNOSTIC MENU) and the Test Program Modules (DIAGNOSTIC TEST MENU) on the Diagnostic Disk.
  • Page 126 A cleaning kit to clean the floppy disk drive heads (Head Cleaning) An external display supporting monitor ID (Expansion test) A CD test media TOSHIBA CD-ROM TEST DISK or ABEX TEST CD-ROM (Sound test) A DVD test media (DVD-ROM TEST DISK TSD-1) (Sound test)
  • Page 127 3.1 The Diagnostic Test 3 Tests and Diagnostics The Diagnostics Disk (Main T&D) 3.1.3 Heatrun test program The heatrun test starts automatically after the selection. You will need the following equipment to perform this program. The Diagnostics Disk (Main T&D) PORTEGE A600 Maintenance Manual (960-710) [CONFIDENTIAL] Downloaded from...

  • Page 128: Executing The Diagnostic Test

    3 Tests and Diagnostics 3.2 Executing the Diagnostic Test Executing the Diagnostic Test To start the Repair test program, follow these steps: 1. Insert the Repair test program disk in the USB floppy disk drive or Optical disk drive. 2. Turn on the computer while pressing U key. The following menu appears. NOTE: The following menu is an example when Repair test program is performed from the floppy disk.
  • Page 129 Set the highlight bar to 3, and press Enter. The following DIAGNOSTIC TEST MENU will appear: TOSHIBA personal computer XXXXXX DIAGNOSTICS version X.XX (c) copyright TOSHIBA Corp. 20XX DIAGNOSTICS MENU : 1 - DIAGNOSTIC TEST 2 – ONLY ONE TEST...
  • Page 130 Set the highlight bar to 1, and press Enter. The following DIAGNOSTIC TEST MENU will appear: TOSHIBA personal computer XXXXXX DIAGNOSTICS version X.XX (c) copyright TOSHIBA Corp. 20XX DIAGNOSTIC TEST MENU : 1 - SYSTEM TEST 2 - MEMORY TEST...
  • Page 131 3.2 Executing the Diagnostic Test 3 Tests and Diagnostics Select the option you want to execute and press Enter. When you select 1- SYSTEM TEST, the following message will appear: SYSTEM TEST NAME XXXXXX xxxxxxx DIAGNOSTIC TEST VX.XX [Ctrl]+[Break] : test end [Ctrl]+[C] : key stop SUB-TEST...
  • Page 132 3 Tests and Diagnostics 3.2 Executing the Diagnostic Test Use the up and down arrow keys to move the cursor to “ERROR STOP”. Use the right and left arrow keys to move the cursor to the desired option and press Enter. Selecting YES of ERROR STOP stops the test program when an error is found and displays the operation guide on the right side of the display screen as shown below: ERROR STATUS NAME...

  • Page 133: Setting Of The Hardware Configuration

    3.3 Setting of the hardware configuration 3 Tests and Diagnostics Setting of the hardware configuration To execute this program, input 1 in the startup menu. Then press Enter to select the (2)- . The H/W initial information setting tool consists of four subtests. Initial config set Input the number you want to execute and press Enter.
  • Page 134 3 Tests and Diagnostics 3.3 Setting of the hardware configuration 7. “Create DMIINFO TXT (Y/N)?” is displayed. Press Y, then the DMI information (text data) is written to the Floppy disk, etc. Setting of the HWSC Setting of the UUID Display of the DMI information (including UUID) After completion of the above settings, H/W configuration &...

  • Page 135: Heatrun Test

    3.4 Heatrun Test 3 Tests and Diagnostics Heatrun Test To execute this program, press 2, Repair Heatrun and press Enter in the startup menu, press Enter. After selecting this test, the same subtests as 3.23 RUNNING TEST is executed successively. For more details on the procedure and test content, refer to RUNNING TEST.

  • Page 136: Subtest Names

    3 Tests and Diagnostics 3.5 Subtest Names Subtest Names Table 3-1 lists the subtest names for each test program in the DIAGNOSTIC TEST MENU. Table 3-1 Subtest names (1/2) Test Name Subtest No. Subtest Name SYSTEM ROM checksum Fan ON/OFF Geyserville Quick charge DMI read...
  • Page 137 3.5 Subtest Names 3 Tests and Diagnostics Table 3-1 Subtest names (2/2) Test Name Subtest No. Subtest Name PRINTER Ripple pattern [Not supported] Function Wraparound FIR/SIR Point to point (send) ASYNC [Not supported] FIR/SIR Point to point (receive) Wraparound (board) HARD DISK Sequential read Address uniqueness...

  • Page 138: System Test

    3 Tests and Diagnostics 3.6 System Test System Test To execute the System Test select 1 from the DIAGNOSTIC TEST MENU, press Enter and follow the directions on the screen. Move the highlight bar to the subtest you want to execute and press Enter.
  • Page 139 3.6 System Test 3 Tests and Diagnostics If the CPU supports Gerserville (SpeedStep), this Subtest checks that the CPU operating clock speed can be changed. If the CPU does not support Gerserville (SpeedStep), the following message is displayed and the test is ended. This chip is not supported Subtest 04 Quick Charge...

  • Page 140: Memory Test

    3 Tests and Diagnostics 3.7 Memory Test Memory Test To execute the Memory Test, select 2 from the DIAGNOSTIC TEST MENU, press Enter and follow the directions on the screen. Move the highlight bar to the subtest you want to execute and press Enter.

  • Page 141: Keyboard Test

    3.8 Keyboard Test 3 Tests and Diagnostics Keyboard Test To execute the Keyboard Test, select 3 from the DIAGNOSTIC TEST MENU, press Enter and follow the directions on the screen. Move the highlight bar to the subtest you want to execute and press Enter.

  • Page 142: Display Test

    3 Tests and Diagnostics 3.9 Display Test Display Test To execute the Display Test, select 4 from the DIAGNOSTIC TEST MENU, press Enter and follow the directions on the screen. Move the highlight bar to the subtest you want to execute and press Enter.
  • Page 143 3.9 Display Test 3 Tests and Diagnostics Subtest 04 Gradation & Mode test for VGA This subtest displays gradations for following modes. To change the mode, press Enter. [Mode 12] [Mode 13] [Mode 3] [Mode 111 640*480 64K] [Mode 112 640*480 16M] [Mode 114 800*600 64K]...
  • Page 144 3 Tests and Diagnostics 3.9 Display Test Subtest 06 “H” Pattern Display This subtest displays a full screen of “H” patterns. HHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHH HHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHH HHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHH HHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHH HHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHH HHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHH HHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHH HHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHH HHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHH HHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHH HHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHH HHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHH HHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHH HHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHH HHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHH To exit this subtest and return to the DISPLAY TEST menu, press Enter. NOTE: The last row may not be completely filled.

  • Page 145: Floppy Disk Test

    3.10 Floppy Disk Test 3 Tests and Diagnostics 3.10 Floppy Disk Test CAUTION: Before running the floppy disk test, prepare a formatted work disk. Remove the Diagnostics Disk and insert the work disk into the FDD. The contents of the floppy disk will be erased. To execute the Floppy Disk Test, select 5 from the DIAGNOSTIC TEST MENU, press Enter and follow the directions displayed on the screen.
  • Page 146 3 Tests and Diagnostics 3.10 Floppy Disk Test Select the number of the subtest you want to execute and press Enter. The following message will appear during the floppy disk test. xxx DIAGNOSTIC TEST VX.XX FLOPPY DISK IN PROGRESS XXXXXXX [Ctrl]+[Break] : test end [Ctrl]+[C]...

  • Page 147: Printer Test

    3.11 Printer Test 3 Tests and Diagnostics 3.11 Printer Test CAUTION: Printer Test is not supported for this model. To execute the Printer Test, select 6 from the DIAGNOSTIC TEST MENU, press Enter and follow the directions on the screen. NOTE: An IBM compatible printer must be connected to the system to execute this test.
  • Page 148 3 Tests and Diagnostics 3.11 Printer Test Subtest 02 Function This subtest is for IBM compatible printers, and tests the following functions: Normal print Double-width print Compressed print Emphasized print Double-strike print All characters print This subtest prints the various print types shown below: Subtest 03 Wraparound NOTE: To execute this subtest, a printer wraparound connector must be connected to the...

  • Page 149: Async Test

    3.12 Async Test 3 Tests and Diagnostics 3.12 Async Test CAUTION: Printer Test is not supported for this model. To execute the Async Test, select 7 from the DIAGNOSTIC TEST MENU, press Enter and follow the directions displayed on the screen. Move the highlight bar to the subtest you want to execute and press Enter.

  • Page 150: Hard Disk Test

    3 Tests and Diagnostics 3.13 Hard Disk Test 3.13 Hard Disk Test To execute the Hard Disk Test, select 8 from the DIAGNOSTIC TEST MENU, press Enter, and follow the directions on the screen. CAUTION: The contents of the hard disk will be erased when subtest 02, 03, 04, 06, 08 or 09 is executed.
  • Page 151 3.13 Hard Disk Test 3 Tests and Diagnostics 4. The Hard Disk Test message will appear after you respond to the Detail Status prompt. Select the number of the subtest you want to execute and press Enter. The following message will appear during each subtest. XXX DIAGNOSTIC TEST VX.XX HARD DISK TEST XXXXXXX [Ctrl]+[Break] :...
  • Page 152 3 Tests and Diagnostics 3.13 Hard Disk Test Subtest 04 Cross talk & peak shift This subtest writes eight types of worst pattern data (listed below) to a cylinder, then reads the data while moving from cylinder to cylinder. (Test the data interference in the neighbor track) Worst pattern data Cylinder...

  • Page 153: Real Timer Test

    3.14 Real Timer Test 3 Tests and Diagnostics 3.14 Real Timer Test To execute the Real Timer Test, select 9 from the DIAGNOSTIC TEST MENU, press Enter and follow the directions on the screen. Move the highlight bar to the subtest you want to execute and press Enter.
  • Page 154 3 Tests and Diagnostics 3.14 Real Timer Test Subtest 03 Real time carry CAUTION: When this subtest is executed, the current date and time are erased. This subtest checks the real time clock increments, making sure the date and time are displayed in the following format: Current date : 12-31-1999 Current time : 23:59:58 The real time increments are automatically executed and the following is...

  • Page 155: Ndp Test

    3.15 NDP Test 3 Tests and Diagnostics 3.15 NDP Test To execute the NDP test, select 10 from the DIAGNOSTICS TEST MENU, press Enter and follow the directions on the screen. CAUTION: Judge the existence of high-speed operation processor by 1bit of the composition byte.

  • Page 156: Expansion Test

    3 Tests and Diagnostics 3.16 Expansion Test 3.16 Expansion Test To execute the expansion test, select 11 from the DIAGNOSTICS TEST MENU, press Enter and follow the directions on the screen. Subtest 01 PCMCIA wraparound [It is not supported] CAUTION: PCMCIA wraparound test is not supported for this model. NOTE: To execute this subtest, the PC card wraparound connector is required.
  • Page 157 3.16 Expansion Test 3 Tests and Diagnostics Subtest 02 RGB monitor ID NOTE: To execute this subtest, monitor supporting EDID (Extended Display Identification Data) is required. Connect a wraparound connector to CRT monitor for the test of ID acquisition. This subtest is executed by using VESA command. CAUTION: It becomes NG because the priority is given to the internal monitor in a simultaneous display mode.

  • Page 158: Cd-Rom/Dvd-Rom Test

    To execute the CD-ROM/DVD-ROM test, select 12 from the DIAGNOSTICS TEST MENU, press Enter and follow the directions on the screen. NOTE: For the subtest 01, 02 and 03, use the TOSHIBA CD-ROM TEST DISK TDY-01 or ABEX TEST CD-ROM TCDR-702 and DVD-ROM TEST DISK TSD-1.

  • Page 159: Error Code And Error Status Names

    3.18 Error Code and Error Status Names 3 Tests and Diagnostics 3.18 Error Code and Error Status Names Table 3-2 lists the error codes and error status names for the Diagnostic Test. Table 3-2 Error codes and error status names (1/3) Device name Error code Error status name...
  • Page 160 3 Tests and Diagnostics 3.18 Error Code and Error Status Names Table 3-2 Error codes and error status names (2/3) Device name Error code Error status name FDD - BAD COMMAND ERROR FDD - ADDRESS MARK NOT FOUND FDD - WRITE PROTECTED FDD - RECORD NOT FOUND FDD - DMA OVERRUN ERROR FDD - DMA BOUNDARY ERROR...
  • Page 161 3.18 Error Code and Error Status Names 3 Tests and Diagnostics Table 3-2 Error codes and error status names (3/3) Device name Error code Error status name (HDD) HDD - WRITE FAULT HDD - STATUS ERROR HDD - BAD SECTOR HDD - ACCESS TIME ERROR HDD - NO HDD HDD - DMA CRC ERROR...

  • Page 162: Hard Disk Test Detail Status

    3 Tests and Diagnostics 3.19 Hard Disk Test Detail Status 3.19 Hard Disk Test Detail Status When an error occurs in the hard disk test, the following message is displayed: HDC status = XXXXXXXX Detailed information about the hard disk test error is displayed on the screen by an eight-digit number.
  • Page 163 3.19 Hard Disk Test Detail Status 3 Tests and Diagnostics Tables 3-4 HDC Error register contents Name Description “0” … Not used (Bad block mark) “1” … A bad block mark is detected. “0” … There is no uncorrectable data error. (Uncorrectable) “1”...

  • Page 164: Only One Test

    3 Tests and Diagnostics 3.20 ONLY ONE TEST 3.20 ONLY ONE TEST 3.20.1 Program Description This program tests the unique functions of this model. 3.20.2 Operations Select test 2 from the DIAGNOSTIC MENU and press Enter. The following menu appears in the display.
  • Page 165 3.20 ONLY ONE TEST 3 Tests and Diagnostics Subtest 01 Pressed Key Display When you execute this subtest, the keyboard layout is drawn on the display as shown below. When any key is pressed, the corresponding key on the screen changes to the key character that was pressed.
  • Page 166 3 Tests and Diagnostics 3.20 ONLY ONE TEST Subtest 02 Touch Pad This subtest checks the functions of the touch pad as shown below. A) Direction and parameter B) Switching function check. This test displays the response from the touch pad and touch pad switch. When moving your finger on the touch pad towards the upper left, the <POINTING>...
  • Page 167 3.20 ONLY ONE TEST 3 Tests and Diagnostics Subtest 03 Wireless communication Switch This subtest checks if the Wireless communication switch works properly. If the test is started with the switch ON, following message appears in the display. Wireless communication Switch is set to a start position (OFF) Slide the switch to OFF position.
  • Page 168 3 Tests and Diagnostics 3.20 ONLY ONE TEST Press 9 and Enter to return to ONLY ONE TEST menu. Subtest 05 This subtest checks if each LED lights properly. The following message appears in the display in order. Follow the instructions in the display to execute the test.
  • Page 169 3 Tests and Diagnostics Subtest 06 Button This subtest checks the moving of the of the front operation panel button. Press the Toshiba Assist button and Back light On/Off button after the following message appears. Step 1 Press Function button (Toshiba Assist button) OK message appears in the display if the test ends without an error.
  • Page 170 3 Tests and Diagnostics 3.20 ONLY ONE TEST The following message appears in the display. < ------ Volume Down -------- > Volume Up! Step5 Volume dial is turned to the left. OK message appears in the display if the test ends without an error. Press any key return to each Steps if NG! or Press any key message apprears <...
  • Page 171 3.20 ONLY ONE TEST 3 Tests and Diagnostics Subtest 7 Acceleration sensor This subtest detects and corrects the each axis (X, Y, Z). NOTE: Make sure that this subtest is executed on the following condition: 1. Flat desk with vertical plane to get the stability of machine. 2.
  • Page 172 3 Tests and Diagnostics 3.20 ONLY ONE TEST When this subtest is selected, the following message appears in the display. The heaven surface establishes in the upper direction Press [Enter] key NOTE: Be sure to execute the test with the display panel opened. Set the machine on the flat desk.
  • Page 173 3.20 ONLY ONE TEST 3 Tests and Diagnostics Rev B Subtest 8 Docker Dock/Undock This subtest is executed with an Slim Port Replicator II. installed. Press Enter while pushing the eject button of the Slim Port Replicator II. the following message appears. Pushing Eject-SW, and press [Enter] Key Press Enter without pushing the eject button of the Slim Port Replicator II.
  • Page 174 3 Tests and Diagnostics 3.20 ONLY ONE TEST Subtest A E2PROM (MAC/GUID) It checks whether the MAC address, GUID of IEEE1394 information are written. Subtest B Intel AMT It checks whether the Intel AMT corde versions information are written. is required for an AMT check.

  • Page 175: Head Cleaning

    3.21 Head Cleaning 3 Tests and Diagnostics 3.21 Head Cleaning 3.21.1 Function Description This function cleans the heads in the FDD by executing a series of head load/seek and read operations. A cleaning kit is necessary to perform this program. 3.21.2 Operations 1.

  • Page 176: Log Utilities

    3 Tests and Diagnostics 3.22 Log Utilities 3.22 Log Utilities 3.22.1 Function Description This function logs error information generated while a test is in progress and stores the results in RAM. This function can store data on a floppy disk or output the data to a printer. NOTE: Connect USB FDD, when you perform the DIAGNOSTIC PROGRAM from the DVD-ROM.
  • Page 177 3.22 Log Utilities 3 Tests and Diagnostics 3.22.2 Operations 1. Select 5 and press Enter in the DIAGNOSTIC MENU, logs error information into RAM or onto a floppy disk. The error information is displayed in the following format: XXXXX ERRORS TS-NO PASS STS ADDR...

  • Page 178: Running Test

    3 Tests and Diagnostics 3.23 Running Test 3.23 Running Test 3.23.1 Function Description This function automatically executes the following tests in sequence: 1. System test (subtest 01) 2. Memory test (subtests 01, 02) 3. Display test (subtest 01) 4. Real timer test (subtest 02) 5.

  • Page 179: Floppy Disk Drive Utilities

    1. FORMAT NOTE: This program is only for testing a floppy disk drive. The option is different from the Toshiba MS-DOS FORMAT command. This program can format a floppy disk in the following formats: (a) 2DD: Double-sided, double-density, double-track, 96/135 TPI, MFM mode, 512 bytes, 9 sectors/track.
  • Page 180 3 Tests and Diagnostics 3.24 Floppy Disk Drive Utilities 3.24.2 Operations 1. Selecting 7 from the DIAGNOSTIC MENU and pressing Enter displays the following message: [ FDD UTILITIES ] 1 - FORMAT 2 - COPY 3 - DUMP 4 – HDD-ID READ 9 - EXIT TO DIAGNOSTICS MENU 2.
  • Page 181 3.24 Floppy Disk Drive Utilities 3 Tests and Diagnostics 3. COPY program (a) When COPY is selected, the following message appears: FLOPPY DISK FORMAT & COPY : VX.XX Type select (0:2DD,3:2HD) ? (b) Selecting a media/drive type number will display a message similar to the one below: Insert source disk into drive A: Press any key when ready.
  • Page 182 3 Tests and Diagnostics 3.24 Floppy Disk Drive Utilities 4. DUMP program (a) When DUMP is selected, the following message appears: DIAGNOSTICS-HARD DISK & FLOPPY DISK DUMP : VX.XX Drive type select (1:FDD, 2:HDD) ? (b) Select a drive type. If is selected, the display will go to step (h).
  • Page 183 3.24 Floppy Disk Drive Utilities 3 Tests and Diagnostics (k) The following message will appear. To finish the dump, select 3. Press number key (1:up,2:down,3:end) ? (l) The following message will appear. Selecting 2 returns to the FDD UTILITIES MENU. Another dump (1:Yes,2:No) ? 5.

  • Page 184: System Configuration

    3 Tests and Diagnostics 3.25 System Configuration 3.25 System Configuration 3.25.1 Function Description The System Configuration program contains the following configuration information for the computer: 1. Processor Type [Code/L2 cache] 2. Chip set [VRAM] 3. BIOS ROM version [1st ID, 2nd ID] 4.
  • Page 185 3.25 System Configuration 3 Tests and Diagnostics 3.25.2 Operations Select 8 from the DIAGNOSTIC MENU and press Enter. Then, the following system configuration appears in the display. System Configuration Display: Ver X.XX [Machine Name???] - Processor Type = XXXXXX-XXXXXMHz Code = XX L2 Cache = XXXXXKB - Chip set = XXXXXX...

  • Page 186: Wireless Lan Test Program (Atheros)

    1. Slide the wireless communication switch to “ON” position. 2. Check the card type according to the following procedure: • Click [Start] -> [All Programs] -> [TOSHIBA] -> [Utilities] -> [PC Diagnostic Tool]. • Check the “Network”. If the “...
  • Page 187 3.26 Wireless LAN Test Program (Atheros) 3 Tests and Diagnostics Check of the antenna connection 1. Confirm that the icon for wireless LAN appears at the lower right of the screen under the circumstances the wireless LAN communication is available. (It is no problem if a cross is shown on the icon.) 2.

  • Page 188: Wireless Lan Test Program (Intel-Made A/B/G/N Setting Up Of Ref Pc)

    3 Tests and Diagnostics 3.27 Wireless LAN Test Program (Intel-made a/b/g/n Setting up of REF PC) 3.27 Wireless LAN Test Program (Intel-made a/b/g/n Setting up of REF PC) For the test of Intel-made wireless LAN cards, configure the test environment as shown below with the following equipment.
  • Page 189 3.27 Wireless LAN Test Program (Intel-made a/b/g/n Setting up of REF PC) 3 Tests and Diagnostics Open “My Computer” window and click “My Network places” on the left column. • Click “View network connections” on the left column. • The “Network Connections” window appears. Double-click “Local Area Connection”.
  • Page 190 3 Tests and Diagnostics 3.27 Wireless LAN Test Program (Intel-made a/b/g/n Setting up of REF PC) • Click “Install…” button on the “Local Area Connection Properties” window. Local Area Connection Properties window • Select “Protocol” on the “Select Network Component Type” window and click “Add…”...
  • Page 191 3.27 Wireless LAN Test Program (Intel-made a/b/g/n Setting up of REF PC) 3 Tests and Diagnostics • When “Install From Disk” window appears, click “Browse…” and specify the created “Clx_Res” folder. Then Click “OK”. (For the test, “PACKET.INF” file is used.) Install From Disk window •...
  • Page 192 3 Tests and Diagnostics 3.27 Wireless LAN Test Program (Intel-made a/b/g/n Setting up of REF PC) After the completion of REF PC setup, restart the WINDOWS. Then perform the Responder test program for Windows (WTWINSVR.EXE) in the Clx_Res folder. ・WTWINSVR.EXE Function : Transmitting/receiving of data to/from DUT via AP OS available : Windows XP only...

  • Page 193: Wireless Lan Test Program On Dut Pc (Intel-Made)

    3.28 Wireless LAN Test Program on DUT PC (Intel-made) 3 Tests and Diagnostics 3.28 Wireless LAN Test Program on DUT PC (Intel-made) 3.28.1 Wireless LAN Test Program (Intel-made : Shirley Peak) on DUT PC This section describes how to perform the wireless LAN transmitting-receiving test (Intel- made 802.11 a/b/g).
  • Page 194 3 Tests and Diagnostics 3.28 Wireless LAN Test Program on DUT PC (Intel-made) To execute the subtest, input the subtest number and press Enter. Subtest01 Communication test of 11a mode for 5100/5150 module (Two antenna type) This subtest execute transmitting/receiving test in 802.11a mode using the main antenna.
  • Page 195 3.28 Wireless LAN Test Program on DUT PC (Intel-made) 3 Tests and Diagnostics Subtest03 Communication test of 11g mode for 5100/5150 module (Two antenna type) This subtest execute transmitting/receiving test in 802.11g mode using the main antenna. If a defective is not found during the test, OK message will appear in the display.
  • Page 196 3 Tests and Diagnostics 3.28 Wireless LAN Test Program on DUT PC (Intel-made) Subtest06 Communication test of 11b mode for 5100/5150 module (Three antenna type) This subtest execute transmitting/receiving test in 802.11b mode using the main antenna. If a defective is not found during the test, OK message will appear in the display.

  • Page 197: Lan/Modem/Bluetooth/Ieee1394 Test Program

    3.29 LAN/Modem/Bluetooth/IEEE1394 Test Program 3 Tests and Diagnostics 3.29 LAN/Modem/Bluetooth/IEEE1394 Test Program This section describes how to perform the LAN/Modem/Bluetooth/IEEE1394 test with the test program. Insert the test program disk for LAN/Modem/Bluetooth/IEEE1394 test in FDD and turn on the power. The following message will appear: Microsoft Windows XX Startup Menu ---------------------------------- Modem...
  • Page 198 3 Tests and Diagnostics 3.29 LAN/Modem/Bluetooth/IEEE1394 Test Program Subtest01 (i82562 + ICHx) This subtest checks the operation of mini-PCI I/F by the loopback test in the chip. The following message will appear: [LAN transmit & receive test !] COMPLETED Repeat count = 00000 Error count 00000...
  • Page 199 3.29 LAN/Modem/Bluetooth/IEEE1394 Test Program 3 Tests and Diagnostics Subtest02 (GbE) This subtest checks the operation of mini-PCI I/F by the loopback test in the chip. Select 2 to execute and press Enter. The following message will appear: Testing adaptor...hit <ESC> to abort. External Loopback Test...PASSED Testing completed.
  • Page 200 3 Tests and Diagnostics 3.29 LAN/Modem/Bluetooth/IEEE1394 Test Program 3.29.2 Modem test For this subtest, connect the modem PCB and RJ11 connector with a harness. Use the dedicated “FAT-MODE inspection device (product code: QE2000P01 made by Nitto Denki Seisakusyo)” for the tests. ################################################################## ###### AC97' Modem Controller Diagnostics program...
  • Page 201 (A mobile phone with the Bluetooth function is also available.) ・ A Bluetooth card should be installed on the target computer. Install the Bluetooth function by clicking [All Programs] -> [TOSHIBA] -> [Bluetooth] -> [Bluetooth Settings]. Test procedure 1.
  • Page 202 3 Tests and Diagnostics 3.29 LAN/Modem/Bluetooth/IEEE1394 Test Program 5. Select “Diagnostics” tab and click “Run”. 6. Check the “Log” to confirm the test result. BT address of test computer BT address of responder device 7. When the BT (Bluetooth) address of the responder device appears, the Bluetooth card and antenna connection are OK.
  • Page 203 3.29 LAN/Modem/Bluetooth/IEEE1394 Test Program 3 Tests and Diagnostics 3.29.4 IEEE1394 test To execute this test, input 4 and press Enter. NOTE: Use another computer that can communicate by IEEE1394 (i. Link) cable as a reference machine to perform this test. The following menu will appear: ******************************************************************** ********...

  • Page 204: Sound Test Program

    Sound TEST disk cannot be used in PORTEGE A600. Therefore, please test the sound on Windows OS. 1) Play a music file. 2) click TOSHIBA-> utility -> "PC diagnostic tool." to test the sound Please check operation of speakers by one of methods. 3.31 3G Test program Therefore, please test the sound on Windows OS.

  • Page 205: Setup

    Tests and Diagnostics 3.32 SETUP 3.32.1 Function Description This program displays the current system setup information as listed below: 1. Memory 2. System Date/Time 4. Password (a) User Password (b) Supervisor Password 3. HDD Password (a) HDD (b) HDD Password Mode (c) User Password (d) Master Password 5.
  • Page 206 Tests and Diagnostics 9. Drives I/O (a) Built-in HDD (b) ODD (c) eSATA (d) SATA Controller Mode 10. PCI Bus 11. Display (a) LCD Display Stretch 12. Peripheral (a) Internal Pointing Device (b) Web Camera 13. Legacy Emulation (a) USB KB/Mouse Legacy Emulation (b) USB-FDD Legacy Emulation (c) USB Memory BIOS Support Type 14.
  • Page 207 Tests and Diagnostics 3.32.2 Accessing the SETUP Program While pressing ESC, turn on the power. Then press F1. The following display appears. PORTEGE A600 Maintenance Manual (960-710) [CONFIDENTIAL] 3-83 Downloaded from www.Manualslib.com manuals search engine...
  • Page 208 Tests and Diagnostics 3-84 [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...
  • Page 209 Tests and Diagnostics Moving Within the SETUP Menu and Changing Values to move between the two columns. Press ↑ and ↓ to move between 1. Press items in a column. Press Fn+↑ (PgUp) and Fn + ↓ (PgDn) to move between the two pages.
  • Page 210 Tests and Diagnostics SETUP Options The SETUP screen is divided into 14 functionally related groups. This section describes each group and its options. 1. Memory This group of options displays the computer’s memory. This field displays the total amount of memory installed and is automatically calculated by the computer.
  • Page 211 Tests and Diagnostics (b) HDD Password Mode This item registers HDD password and can be selected only for registering HDD password. To change HDD Password Mode when HDD password is registered, delete the registered HDD password first, and then register new password.
  • Page 212 Tests and Diagnostics NOTE: CD-ROM refers to a DVD Super Multi drive. (b) HDD Priority Use this option to set the booting priority from HDD or USB (USB Memory stick). Built-in HDD→ USB (Default) USB →Built-in HDD 6. Others Whether or not you need to configure the computer with these options depends primarily on the kind of software or peripherals you use.
  • Page 213 Tests and Diagnostics (c) Execute-Disable Bit Capability This option set the Execute-Disable Bit function of CPU to the operation system. Execute-Disable Bit gives higher security function preventing the PC from the computer viruses and buffer overflow problem on unauthorized access. Available Enable the Execute-Disable Bit function.
  • Page 214 Tests and Diagnostics (f) Auto Power On Use this option to set a time and date for automatic power on and enable or disable the ring indicator feature. Alarm Date Option appears only when Alarm Time is enabled. OPTIONS Alarm Time = Disabled Wake-up on LAN = Disabled...
  • Page 215 Tests and Diagnostics Critical Battery Wake-up Configures what action is taken when the remaining battery power is close to running out while the system is in Sleep Mode. This setting is only available when the Critical battery action in Windows is set to Hibernate (Default).
  • Page 216 Tests and Diagnostics 7. Configuration This option lets you set the device configuration. All Devices BIOS sets all devices. Setup by OS Initializes devices, which is needed to load an operating system. Operating system initializes other devices. (Default) NOTE: 1. When using installed OS, selecting “Setup by OS” is recommended. 2.
  • Page 217 Tests and Diagnostics Processing Speed This feature changes the CPU processing speed. High CPU operates at high speed. (Default in Full Power Mode) CPU operates at low speed. (Default in Low Power Mode) CPU Sleep Mode Use this option to enable or disable the CPU sleep function. Enabled Enables sleep mode.
  • Page 218 Tests and Diagnostics (b) PCI Express Link ASPM This option set the power-saving function of PCI Express on the following conditions. Auto PCI Express devices are not used while battery operation. (Default) Disabled Disable the Power-saving function and drive with maximum performance. Enabled PCI Express devices are not used.
  • Page 219 Tests and Diagnostics (d) SATA Controller Mode This feature sets the SATA Controller Mode. AHCI Sets AHCI which is the mode for VistaTM (default) Compatibility Sets the mode for legacy OS. Use this mode when the driver corresponding to AHCI is not used. 10.
  • Page 220 Tests and Diagnostics (b) Web Camera This option enables or disables the Web Camera Enabled Enables the Web Camera (Default) Disabled Disables the Web Camera 13. LEGACY EMULATION (a) USB KB/Mouse Legacy Emulation This option sets the Legacy support condition of the USB keyboard and the USB mouse.
  • Page 221 Tests and Diagnostics (b) Wireless LAN Enabled Enables functions. (Default) Wireless LAN Disabled Disables Wireless LAN functions. 15. Security Controller (a) TPM Disables the security controller called TPM (Trusted Platform Module). When the cursor is on the Enable (Disable) and the Space is pressed, message is displayed and the PC waits Y or N key input by the user.
  • Page 222 Tests and Diagnostics 16. Intel( R )AMT *AMT model only (a) MEBx SETUP This setting enables or disables the computer's MEBx SETUP Intel(R) AMT. Enabled Enables the MEBx SETUP. Disabled Disables the MEBx SETUP. (Default) 3-98 [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...

  • Page 223: Chapter 4 Replacement Procedures

    Chapter 4 Replacement Procedures [CONFIDENTIAL] Downloaded from www.Manualslib.com manuals search engine...
  • Page 224 4 Replacement Procedures 4-ii [CONFIDENTIAL] PORTÉGÉ A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...
  • Page 225 4 Replacement Procedures Chapter 4 Contents Overview........................4-1 Battery pack ......................4-10 SIM card ........................4-12 ExpressCard ......................4-13 SD/SDHC memory card ..................4-14 Memory module....................... 4-15 Base assembly......................4-18 Battery lock......................4-20 Wireless LAN card ....................4-21 4.10 SD board ........................4-23 4.11 Bluetooth module.....................
  • Page 226 4 Replacement Procedures Figures Figure 4-1 Removing the battery pack ................4-10 Figure 4-2 Removing the SIM card ................4-12 Figure 4-3 Removing the ExpressCard................4-13 Figure 4-4 Removing the SD/SDHC memory card ............4-14 Figure 4-5 Removing the memory cover............... 4-15 Figure 4-6 Removing the memory module..............
  • Page 227 4 Replacement Procedures Figure 4-31 Removing the speaker.................. 4-55 Figure 4-32 Removing the cover assembly/LCD assembly (1)........4-56 Figure 4-33 Removing the cover assembly/LCD assembly (2)........4-57 Figure 4-34 Removing the SW board................4-58 Figure 4-35 Removing the touch pad/fingerprint sensor board (1) ......... 4-61 Figure 4-36 Removing the touch pad/fingerprint sensor board (2) .........
  • Page 228 4 Replacement Procedures 4-vi [CONFIDENTIAL] PORTÉGÉ A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...

  • Page 229: Overview

    4.1 Overview 4 Replacement Procedures Replacement Procedures Overview CAUTION: The case and parts of this machine are delicate (thin) because this machine is lighter than a usual machine. Handle with care of installing/removing. This chapter describes the procedure for removing and replacing the field replaceable units (FRUs) in the PC.
  • Page 230 4 Replacement Procedures 4.1 Overview Please prepare required parts in advance, when replacing the following items. Parts List ITEM PART NAME Quantity ITEM No COVER ASSY TOUCH PAD MEMBRANE SWITCH TP BTN COV ASSY COVER ASSY PCB ASSY FMTFSx (Fingerprint sensor board) KEYBOARD UNIT INSULATOR KB Parts List...
  • Page 231 4.1 Overview 4 Replacement Procedures The main parts in this manual are indicated in the part list by the following names. Parts List Manual NAME PART NAME ITEM No System board PCB ASSY FMTXSx SW board PCB ASSY FMTXWx USB board PCB ASSY FMTUSx Sound board PCB ASSY FMTJAx...
  • Page 232 Please read the following safety instructions before disassembling the computer and always follow the instructions while working on the computer. DANGER: 1) Always use the genuine battery that is authorized by Toshiba or compatible with the unit. Since other battery packs have different specifications, they may be incompatible with the unit, and may burst or explode.
  • Page 233 4.1 Overview 4 Replacement Procedures Before You Begin Take note of the following points before starting work. Always remove the AC adapter and battery pack before commencing any of the procedures. The procedure for removing the battery pack is described in section “4.2. Battery Pack”. 1.
  • Page 234 4 Replacement Procedures 4.1 Overview Disassembly Procedures Four main types of cable connector are used. • Pressure plate connector • Spring connector • Back flip connector • Normal pin connector For pressure plate connectors, slide the pressure plate holding tags on both sides of the plastic pressure plate on the connector and pull the cable out from the connector.
  • Page 235 4.1 Overview 4 Replacement Procedures Assembly Procedures After the computer has been disassembled and the part that caused the fault has been repaired or replaced, the computer must be reassembled. Take note of the following general points when assembling the computer. •...
  • Page 236 NOTE: Toshiba recommends that you use an electric screwdriver for quick and easy operations. (except a M1.4 screw) Use a non electric screwdriver to fasten a M1.4 screw, because a boss for M1.4 screw maybe broken if the screw is driven with an electric screwdriver.
  • Page 237 4.1 Overview 4 Replacement Procedures Grip Color Some screws have a colored grip area to help you determine the length of the screw. [Normal grip] • Even numbered length screws: Brown • Odd numbered length screws: White Grip area • Special length screw: Blue [Special grip] •...

  • Page 238: Battery Pack

    4 Replacement Procedures 4.2 Battery pack Battery pack Removing the Battery pack To remove the battery pack, follow the steps below and refer to Figure 4-1. CAUTION: When handling battery pack, be careful not to short circuit the terminals. Also do not drop, hit or apply impact, do not scratch, break, twist or bend the battery pack.
  • Page 239 CAUTION: The battery pack is a lithium ion battery, which can explode if not properly replaced, used, handled or disposed of. For environmental reasons, collect the spent battery packs. Use only batteries recommended by Toshiba for replacements. NOTE: Check the battery’s terminals visually. If they are dirty, wipe them clean with a dry cloth.

  • Page 240: Sim Card

    4 Replacement Procedures 4.3 SIM card SIM card Removing the SIM card To remove the SIM card, follow the steps below and refer to Figure 4-2. 1. Release the hook. 2. Push the SIM card. It will pop out partly when you release, so pull out the card. SIM card Hook Figure 4-2 Removing the SIM card...
  • Page 241 4.4 ExpressCard 4 Replacement Procedures ExpressCard Removing the ExpressCard To remove the ExpressCard, follow the steps below and refer to Figure 4-3. CAUTION: Before you remove the ExpressCard, refer to the card’s documentation and to your operating system documentation for proper procedures and precautions.
  • Page 242 4 Replacement Procedures 4.5 SD/SDHC memory card SD/SDHC memory card Removing the SD/SDHC memory card To remove the SD/SDHC memory card, follow the steps below and refer to Figure 4-4. CAUTION: Before you remove the SD/SDHC memory card, refer to the card’s documentation and to your operating system documentation for proper procedures and precautions.

  • Page 243: Memory Module

    4.6 Memory module 4 Replacement Procedures Memory module Removing the Memory module To remove the memory module, confirm that the computer is shut down. Then follow the steps below and refer to Figure 4-5 and 4-6. CAUTION: When removing the memory module, make sure the computer is powered off. Removing a memory module with the power on might damage the module or the computer itself.
  • Page 244 4 Replacement Procedures 4.6 Memory module 3. Open the left and right latches outside and remove the memory module. Latch Latch Memory module Figure 4-6 Removing the memory module 4-16 [CONFIDENTIAL] PORTÉGÉ A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...
  • Page 245 4.6 Memory module 4 Replacement Procedures Installing the Memory module To install the memory module, confirm that the computer is shut down. Then follow the steps below and refer to Figure 4-5 and 4-6. CAUTION: When installing the memory module, make sure the computer is powered off. Inserting a memory module with the power on might damage the module or the computer itself.

  • Page 246: Base Assembly

    4 Replacement Procedures 4.7 Base assembly Base assembly Removing the Base assembly To remove the base assembly, follow the steps below and refer to Figure 4-7. 1. Remove the following screws securing the base assembly. • M2×4C ×1 (Described as “A” in the figure) BIND screw •...
  • Page 247 4.7 Base assembly 4 Replacement Procedures Installing the Base assembly To install the base assembly, follow the steps below and refer to Figure 4-7. 1. Set the base assembly to the cover assembly. 2. Secure the base assembly and cover assembly with the following screws. •...

  • Page 248: Battery Lock

    4 Replacement Procedures 4.8 Battery lock Battery lock Removing the Battery lock To remove the battery lock, follow the steps below and refer to Figure 4-8. 1. Remove the battery locks while pushing hooks inside to release them. CAUTION: When removing the battery lock L, be careful not to lose the SPG battery lock.

  • Page 249: Wireless Lan Card

    4.9 Wireless LAN card 4 Replacement Procedures Wireless LAN card Removing the Wireless LAN card To remove the wireless LAN card, follow the steps below and refer to Figure 4-9. 1. Turn up the insulator and disconnect three (or two) wireless LAN antenna cables from the connectors on the wireless LAN card.
  • Page 250 4 Replacement Procedures 4.9 Wireless LAN card Installing the Wireless LAN card To install the wireless LAN card, follow the steps below and refer to Figure 4-9. 1. Insert the wireless LAN card to the connector on the system board slantwise and press it to connect firmly.
  • Page 251 4.10 SD board 4 Replacement Procedures 4.10 SD board Removing the SD board To remove the SD board, follow the steps below and refer to Figure 4-10. 1. Remove the following screws and lift up the SD board (Be careful that the SD board FPC, wireless LAN antenna cable, 3G antenna cable and antenna relay cable are connected to the connector on the back of the SD board).
  • Page 252 4 Replacement Procedures 4.10 SD board Installing the SD board To install the SD board, follow the steps below and refer to Figure 4-10. 1. Connect the SD board FPC to the connector CN9710 on the back of the SD board. 2.

  • Page 253: Bluetooth Module

    4.11 Bluetooth module 4 Replacement Procedures 4.11 Bluetooth module Removing the Bluetooth module To remove the Bluetooth module, follow the steps below and refer to Figure 4-11. 1. Remove the following screw and lift up the Bluetooth module. • M2×3B ×1 S-THIN HEAD 2.
  • Page 254 4 Replacement Procedures 4.11 Bluetooth module Installing the Bluetooth module To install the Bluetooth module, follow the steps below and refer to Figure 4-11. 1. Connect the Bluetooth antenna cable and Bluetooth FFC to the connectors on the back of the Bluetooth module. 2.
  • Page 255 4.12 Optical disk drive (DVD-Super Multi drive)/MDC modem 4 Replacement Procedures 4.12 Optical disk drive (DVD-Super Multi drive)/MDC modem Removing the Optical disk drive/MDC modem To remove the optical disk drive/MDC modem, follow the steps below and refer to Figure 4- 12 to 4-16.
  • Page 256 4 Replacement Procedures 4.12 Optical disk drive (DVD-Super Multi drive)/MDC modem 3. Remove the following screws and SD holder. • M2×4C ×2 BIND M2x4C BIND SD holder Figure 4-13 Removing the optical disk drive (2) 4. Remove the following screws, ODD FPC, ODD rear plate and ODD side plate. •...
  • Page 257 4.12 Optical disk drive (DVD-Super Multi drive)/MDC modem 4 Replacement Procedures 5. Remove the following screws securing the MDC modem. • M2×4C ×2 BIND 6. Turn up the insulator and take out the RJ11 harness from the slot. 7. Disconnect the MDC modem from the connector on the MDC FPC. 8.
  • Page 258 4 Replacement Procedures 4.12 Optical disk drive (DVD-Super Multi drive)/MDC modem 10. Remove the following screws and ODD upper. • M2×4C ×2 BIND M2x4C BIND ODD upper Figure 4-16 Removing the ODD upper 4-30 [CONFIDENTIAL] PORTÉGÉ A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...
  • Page 259 4.12 Optical disk drive (DVD-Super Multi drive)/MDC modem 4 Replacement Procedures Installing the optical disk drive/MDC modem To install the optical disk drive/MDC modem, follow the steps below and refer to Figure 4- 12 to 4-16. 1. Set the ODD upper and secure it with the following screws. •...
  • Page 260 4 Replacement Procedures 4.13 3G card 4.13 3G card Removing the 3G card To remove the 3G card, follow the steps below and refer to Figure 4-17. 1. Disconnect two 3G antenna cables from the connectors on the 3G card. 2.
  • Page 261 4.13 3G card 4 Replacement Procedures Installing the 3G card To install the 3G card, follow the steps below and refer to Figure 4-17. 1. Connect the 3G FPC to the connector CN2750 on the system board and secure it with following screws.

  • Page 262: Expresscard Slot

    4 Replacement Procedures 4.14 ExpressCard slot 4.14 ExpressCard slot Removing the ExpressCard slot To remove the ExpressCard slot, follow the steps below and refer to Figure 4-18. 1. Remove the following screws securing the ExpressCard slot. • M2×4C ×4 BIND screw 2.
  • Page 263 4.14 ExpressCard slot 4 Replacement Procedures Installing the ExpressCard slot To install the ExpressCard slot, follow the steps below and refer to Figure 4-18. 1. Stick the insulator. 2. Set the ExpressCard slot to the cover assembly and secure it with the following screws.
  • Page 264 4 Replacement Procedures 4.15 HDD/SSD 4.15 HDD/SSD CAUTION: Take care not to press on the top or bottom of the HDD or SSD. Pressure may cause data loss or damage to the device. There is a possibility that the black shield layer of the HDD FPC and SD board FPC is peeled off (different from the usual polyimide cover), if any tape is stuck to the black shield layer.
  • Page 265 4.15 HDD/SSD 4 Replacement Procedures 4.15.1 HDD Removing the HDD To remove the HDD, follow the steps below and refer to Figure 4-19. 1. Lift up the HDD from the slot. 2. Disconnect the HDD from the connector on the HDD FPC. Guide HDD FPC Guide...
  • Page 266 4 Replacement Procedures 4.15 HDD/SSD 4.15.2 SSD Removing the SSD To remove the SSD, follow the steps below and refer to Figure 4-20. 1. Remove the following screws securing the SSD. • M1.4×3B ×4 S-THIN HEAD 2. Disconnect the SSD from the connector on the SSD FPC. M1.4x3B S-THIN HEAD M1.4x3B S-THIN HEAD Guide...
  • Page 267 4.15 HDD/SSD 4 Replacement Procedures Installing the SSD To install the SSD, follow the steps below and refer to Figure 4-20. 1. Connect the SSD to the connector on the SSD FPC. 2. Set the SSD into the guides of the slot and secure it with the following screws. •...

  • Page 268: Rtc Battery

    4 Replacement Procedures 4.16 RTC battery Replacement Procedures 4.16 RTC battery CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the laws and ordinances of your local authority. Removing the RTC battery To remove the RTC battery, follow the steps below and refer to Figure 4-21.
  • Page 269 4.16 RTC battery 4 Replacement Procedures Installing the RTC battery To install the RTC battery, follow the steps below and refer to Figure 4-21. 1. Set the RTC battery to the RTC battery holder (INSULATOR RTC BATT) and close the RTC battery holder while sticking the cover portion with the double-sided tape.
  • Page 270 4 Replacement Procedures 4.17 Sound board/MIC harness 4.17 Sound board/MIC harness Removing the Sound board/MIC harness To remove the sound board/MIC harness, follow the steps below and refer to Figure 4-22 and Figure 4-23. 1. Remove the following screw securing the sound board. •...
  • Page 271 4.17 Sound board/MIC harness 4 Replacement Procedures 3. Disconnect the MIC harness from the connector CN6050 on the sound board and remove the MIC harness from the sound board. CN6050 MIC harness Figure 4-23 Removing the sound board/MIC harness (2) Installing the Sound board/MIC harness To install the sound board/MIC harness, follow the steps below and refer to Figure 4-22 and 4-23.

  • Page 272: Cooling Module

    4 Replacement Procedures 4.18 Cooling module 4.18 Cooling module Removing the Cooling module To remove the cooling module, follow the steps below and refer to Figure 4-24. CAUTION: The CPU can become very hot during operation. Be sure to let it cool before starting repair work.
  • Page 273 4.18 Cooling module 4 Replacement Procedures Installing the Cooling module To install the cooling module, follow the steps below and refer to Figure 4-24. 1. Wipe off the grease from the cool sheet. 2. Apply new grease on the CPU using a special syringe. 3.
  • Page 274 4 Replacement Procedures 4.19 DC-IN harness 4.19 DC-IN harness Removing the DC-IN harness To remove the DC-IN harness, follow the steps below and refer to Figure 4-25. 1. Disconnect the DC-IN harness from the connector CN8800 on the system board and remove the DC-IN harness from the slot.
  • Page 275 4.20 USB board/WL SW holder 4 Replacement Procedures 4.20 USB board/WL SW holder Removing the USB board/WL SW holder To remove the USB board/WL SW holder, follow the steps below and refer to Figure 4-26 to 4-28. 1. Open the insulators and release the cables. Insulator Figure 4-26 Removing the USB board/WL SW holder (1) PORTÉGÉ...
  • Page 276 4 Replacement Procedures 4.20 USB board/WL SW holder 2. Open the insulator and take out the RJ45 wire harness from the slot. 3. Disconnect the USB board FPC from the connector CN9610 on the USB board. 4. Open the insulator and disconnect the sensor harness from the connector CN9540 on the USB board and connector CN9630 on the SW board.
  • Page 277 4.20 USB board/WL SW holder 4 Replacement Procedures 7. Remove the WL SW holder adhered with the double-sided tape. WL SW holder Figure 4-28 Removing the USB board/WL SW holder (3) PORTÉGÉ A600 Maintenance Manual (960-710) [CONFIDENTIAL] 4-49 Downloaded from www.Manualslib.com manuals search engine...
  • Page 278 4 Replacement Procedures 4.20 USB board/WL SW holder Installing the USB board/WL SW holder To install the USB board/WL SW holder, follow the steps below and refer to Figure 4-26 to 4-28. 1. Set the WL SW holder in place and fix it with the double-sided tape. CAUTION: A double-sided tape is stuck to a new WL SW holder.
  • Page 279 4.21 System board 4 Replacement Procedures 4.21 System board CAUTION: When replacing with a new system board, the following procedures must be executed. (1) Before replacing the system board, execute subtest02 “DMI ggginformation save” in 3.3 Setting of the hardware configuration of gggChapter 3 Test program in order to save the DMI information from gggsystem board to floppy disk.
  • Page 280 4 Replacement Procedures 4.21 System board Removing the System board To remove the system board, follow the steps below and refer to Figure 4-29 and 4-30. 1. Remove the following screws securing the system board. • M2×4C ×1 BIND • M3×5C ×2 BIND 2.
  • Page 281 4.21 System board 4 Replacement Procedures 4. Disconnect the HDD FPC (or SSD FPC), USB board FPC, RJ45 wire harness, sound board FPC, Bluetooth FFC and MDC FPC from the connectors CN1900, CN9600, CN4100, CN9500, CN4400 and CN3010 on the system board. USB board FPC Bluetooth FFC (Connected to CN9600)
  • Page 282 4 Replacement Procedures 4.21 System board Installing the System board To install the system board, follow the steps below and refer to Figure 4-29 and 4-30. 1. Connect the HDD FPC (or SSD FPC), USB board FPC, RJ45 wire harness, sound board FPC, Bluetooth FFC and MDC FPC to the connectors CN1900, CN9600, CN4100, CN9500, CN4400 and CN3010 on the system board.
  • Page 283 4.22 Speaker 4 Replacement Procedures 4.22 Speaker Removing the Speaker To remove the speaker, follow the steps below and refer to Figure 4-31. 1. Take out the speaker from the slot. 2. Peel off the acetate tape. 3. Open the insulators and remove the speaker harness. Acetate tape Speaker Speaker harness...
  • Page 284 4 Replacement Procedures 4.22 Speaker To install the speaker, follow the steps below and refer to Figure 4-31. 1. Set the speaker to the slot. 2. Open the insulators and arrange the speaker harness in place. 3. Close the insulators and stick the acetate tape in place. 4-56 [CONFIDENTIAL] PORTÉGÉ...
  • Page 285 4.23 Cover assembly/LCD assembly 4 Replacement Procedures 4.23 Cover assembly/LCD assembly Removing the Cover assembly/LCD assembly To remove the cover assembly/LCD assembly, follow the steps below and refer to Figure 4- 32 to 4-34. 1. Open the insulators and release the antenna cables. Insulator Figure 4-32 Removing the cover assembly/LCD assembly (1) PORTÉGÉ...
  • Page 286 4 Replacement Procedures 4.23 Cover assembly/LCD assembly 2. Open the display at the angle of 90 degrees and put the computer on the stand. 3. Remove the following screws and separate the cover assembly and LCD assembly. • M2×4C ×2 BIND M2x4C BIND M2x4C BIND...
  • Page 287 4.23 Cover assembly/LCD assembly 4 Replacement Procedures 4. Remove the SW board from the cover assembly. SW board Hook Figure 4-34 Removing the SW board PORTÉGÉ A600 Maintenance Manual (960-710) [CONFIDENTIAL] 4-59 Downloaded from www.Manualslib.com manuals search engine...
  • Page 288 4 Replacement Procedures 4.23 Cover assembly/LCD assembly Installing the Cover assembly/LCD assembly To install the cover assembly/LCD assembly, follow the steps below and refer to Figure 4-32 to 4-34. 1. Set the SW board to the cover assembly. 2. Set the LCD assembly to the cover assembly and secure them with following screws. •...
  • Page 289 4.23 Cover assembly/LCD assembly 4 Replacement Procedures 3. Arrange the antenna cables in place and fix them with the insulators. CAUTION: Arrange the antenna cables at the lower left portion as shown in the figure below. Do not put the cables on the rib.
  • Page 290 4 Replacement Procedures 4.24 Touch pad/Fingerprint sensor board 4.24 Touch pad/Fingerprint sensor board Removing the Touch pad/Fingerprint sensor board To remove the touch pad/fingerprint sensor board, follow the steps below and refer to Figure 4-35 and 4-36. 1. Disconnect the membrane switch FPC from the connector on the touch pad. 2.
  • Page 291 4.24 Touch pad/Fingerprint sensor board 4 Replacement Procedures 5. Peel off the membrane switch adhered with the double-sided tape and remove the tip point of the FPC (connector terminal side) from the hole. 6. Remove the following screw and fingerprint sensor board adhered with the double- sided tape.
  • Page 292 4 Replacement Procedures 4.24 Touch pad/Fingerprint sensor board Installing the Touch pad/Fingerprint sensor board To install the touch pad/fingerprint sensor board, follow the steps below and refer to Figure 4-35 and 4-36. 1. Wipe off the double-sided tapes on the cover assembly and TPD BTN cover and stick a new double-sided tape on them.
  • Page 293 4.25 Keyboard 4 Replacement Procedures 4.25 Keyboard Removing the Keyboard To remove the keyboard, follow the steps below and refer to Figure 4-37. 1. Remove the aluminum tape from the back of the cover assembly. 2. Turn the cover assembly face up and peel off the keyboard adhered to the insulator. 3.
  • Page 294 4 Replacement Procedures 4.25 Keyboard Installing the Keyboard To install the keyboard, follow the steps below and refer to Figure 4-37. NOTE: Do not reuse the removed keyboard and insulator. Use new keyboard and insulator (INSULATOR KB). Wipe off the double-sided tapes left on the cover assembly and stick new double- sided tapes.
  • Page 295 4.26 LCD 4 Replacement Procedures 4.26 LCD Removing the LCD To remove the LCD, follow the steps below and refer to Figure 4-38 and 4-39. 1. Peel off three LCD cushions and one LCD mask seal from the LCD mask. 2.
  • Page 296 4 Replacement Procedures 4.26 LCD 3. Turn up the insulator and remove the LCD from the LCD cover. 4. Peel the insulator (HNS CONN INSULATOR) and disconnect the LCD harness from the connector on the LCD. CAUTION: When disconnecting the LCD harness from the LCD unit, peel off the adhered portion of the LCD harness very carefully.
  • Page 297 4.26 LCD 4 Replacement Procedures Installing the LCD To install the LCD, follow the steps below and refer to Figure 4-38 and 4-39. NOTE: When installing a new LCD harness, stick a new square cushion to the LCD harness. When installing a new LCD harness or LCD, stick a new insulator (HNS CONN INSULATOR) to the LCD harness.

  • Page 298: Camera Module

    4 Replacement Procedures 4.27 Camera module 4.27 Camera module Removing the Camera module To remove the camera module, follow the steps below and refer to Figure 4-40. 1. Take out the camera module from the slot and disconnect the camera harness from the connector on the camera module.
  • Page 299 4.27 Camera module 4 Replacement Procedures Installing the Camera module To install the camera module, follow the steps below and refer to Figure 4-40. 1. Connect the camera harness to the connector on a new camera module and stick the camera module in place.
  • Page 300 4 Replacement Procedures 4.28 Wireless LAN antenna/Bluetooth antenna/3G antenna 4.28 Wireless LAN antenna/Bluetooth antenna/3G antenna Removing the Wireless LAN antenna/Bluetooth antenna/3G antenna To remove the wireless LAN antenna/Bluetooth antenna/3G antenna, follow the steps below and refer to Figure 4-41. 1. Turn up the insulators fixing the wireless LAN antenna, Bluetooth antenna, 3G antenna and camera harness.
  • Page 301 4.28 Wireless LAN antenna/Bluetooth antenna/3G antenna 4 Replacement Procedures Please prepare required parts in advance, when replacing the following items. Parts List ITEM PART NAME Quantity ITEM No LCD COVER ASSY CAMERA MODULE ANTENNA 2.4/5.2GHZ 72, 73 LCD COVER (Wireless LAN antenna) ASSY ANTENNA 2.4/5.2GHZ (3G antenna)
  • Page 302 4 Replacement Procedures 4.28 Wireless LAN antenna/Bluetooth antenna/3G antenna Installing the Wireless LAN antenna/Bluetooth antenna/3G antenna To install the wireless LAN antenna/Bluetooth antenna/3G antenna, follow the steps below and refer to Figure 4-41. 1. Stick the wireless LAN antenna/Bluetooth antenna/3G antenna on the LCD cover in place.
  • Page 303 4.28 Wireless LAN antenna/Bluetooth antenna/3G antenna 4 Replacement Procedures CAUTION: Replacing the antennas with care of the followings: [Sticking the INSULATOR ANT HOLD S] 1. Peel off the separators of the INSULATOR ANT HOLD S (12pt) and stick the INSULATOR ANT HOLD S (12pt) to the LCD cover. PORTÉGÉ...
  • Page 304 4 Replacement Procedures 4.28 Wireless LAN antenna/Bluetooth antenna/3G antenna [Sticking the antennas Non 3G MODEL] <WL-LAN MODEL> 1. Stick the WL-LAN antenna Main (white) to the LCD cover. 2. Stick the WL-LAN antenna Sub (black) to the LCD cover. <BT MODEL> 3.
  • Page 305 4.28 Wireless LAN antenna/Bluetooth antenna/3G antenna 4 Replacement Procedures ＆ [Sticking the antennas 3G (EU) WL-LAN (Intel) MODEL] <WL-LAN MODEL> 1. Stick the WL-LAN antenna Main (white) to the LCD cover. <BT MODEL> 2. Stick the BT antenna (brown) to the LCD cover. <3G MODEL>...
  • Page 306 4 Replacement Procedures 4.28 Wireless LAN antenna/Bluetooth antenna/3G antenna 7. Stick the SQUARE INSULATOR (911) (5p) to the LCD cover to fix the antennas. 8. Stick the AL TAPE (451) (2p) on the 3G antennas. 4-78 [CONFIDENTIAL] PORTÉGÉ A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...
  • Page 307 4.28 Wireless LAN antenna/Bluetooth antenna/3G antenna 4 Replacement Procedures ＆ [Sticking the antennas 3G (EU) WL-LAN (Atheros) MODEL] <WL-LAN MODEL> 1. Stick the WL-LAN antenna Main (white) to the LCD cover. 2. Stick the WL-LAN antenna Sub (black) to the LCD cover. <3G MODEL>...
  • Page 308 4 Replacement Procedures 4.28 Wireless LAN antenna/Bluetooth antenna/3G antenna 7. Stick the SQUARE INSULATOR (911) (5p) to the LCD cover to fix the antennas. 8. Stick the AL TAPE (451) (2p) on the 3G antennas. 4-80 [CONFIDENTIAL] PORTÉGÉ A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...
  • Page 309 4.28 Wireless LAN antenna/Bluetooth antenna/3G antenna 4 Replacement Procedures [Arranging the harnesses WL-LAN MODEL] 1. Arrange the harnesses and fix them with the INSULATOR ANT HOLD S (12pt). PORTÉGÉ A600 Maintenance Manual (960-710) [CONFIDENTIAL] 4-81 Downloaded from www.Manualslib.com manuals search engine...
  • Page 310 4 Replacement Procedures 4.28 Wireless LAN antenna/Bluetooth antenna/3G antenna [Arranging the harnesses] 4-82 [CONFIDENTIAL] PORTÉGÉ A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...
  • Page 311 4.29 Hinge 4 Replacement Procedures 4.29 Hinge Removing the Hinge To remove the hinge, follow the steps below and refer to Figure 4-42. 1. Remove the following screws securing the hinges. • M2×6C ×2 S-THIN HEAD • M2×2.4C ×2 S-THIN HEAD 2.
  • Page 312 4 Replacement Procedures 4.29 Hinge Installing the Hinge To install the hinge, follow the steps below and refer to Figure 4-42. 1. Set the key plate and hinges (right and left) to the LCD cover, and secure them with the following screws. •...

  • Page 313: Appendices

    Appendices [CONFIDENTIAL] Downloaded from www.Manualslib.com manuals search engine...
  • Page 314 Appendices App-ii [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...
  • Page 315 Appendices Appendix Contents Appendix A Handling the LCD Module ................A-1 Appendix B Board Layout ....................B-1 *) Front View ..............B-1 FMTXS System board ( *) Back View..............B-3 FMTXS System board ( (FMTFS*) View Finger Sensor board ..............B-5 *) View SW board (FMTSW ..................B-6 Jack board (FMTJA*) View...................B-7 USB board (FMTUS*) View ................B-8...
  • Page 316 Appendices C.10 CN4100 LAN interface connector (8-pin)............C-11 C.11 CN4400 Bluetooth interface connector (20-pin) ..........C-12 C.12 CN5080 CRT interface connector (15-pin)............C-12 C.13 CN5601 LCD interface connector (35-pin) ............C-13 C.14 CN8771 FAN interface connector (4-pin) ............C-14 C.15 CN8800 DC-IN connector (4-pin) ..............C-14 C.16 CN8810 Battery connector (10-pin) ..............C-14 C.17...
  • Page 317 Appendices C.37 CN2671 Antenna interface connector (3-pin).............C-27 C.38 CN2672 3G interface connector (3-pin) .............C-27 C.39 CN2673 WLAN interface connector (3pin)............C-27 C.40 CN9710 System board interface connector (20-pin) ..........C-28 C.41 IS2130 SD Card interface connector (12-pin) ............C-28 SD board (FMTSD*) C.42 CN1820 FMTPO* board interface connector (50-pin)........C-29 C.43 CN9710 System board interface connector (30-pin) ..........C-30...
  • Page 318 Appendices Appendix D Keyboard Scan/Character Codes ..............D-1 Appendix E Key Layout.....................E-1 United Kingdom (UK) Keyboard ................E-1 United States (US) Keyboard................. E-1 Appendix F Wiring Diagrams ................... F-1 RGB Monitor Loopback Connector ................ F-1 RS-232C Loopback Connector ................F-1 RS-232C direct connection cable (9-pin to 9-pin) ..........
  • Page 319 Appendices Figures Figure B-1 System board (FMTXS*) layout (front) ............B-1 Figure B-2 System board (FMTXS*) layout (back) ............B-3 Figure B-3 Finger Sensor board (FMTFS*) layout (front/back) ........B-5 Figure B-4 SW board (FMTSW*) layout (front/back) ...........B-6 Figure B-5 Jack board (FMTJA*) layout (front/back) ...........B-7 Figure B-6 USB board (FMTUS*) layout (front/back) ...........B-8 Figure B-7...
  • Page 320 Appendices Table B-11 SATA ODD FPC (FSISO*) connector (front)..........B-13 Table B-12 SATA HDD FPC (FMTSH*) connectos (front/back)........B-14 Table B-13 MDC interface FPC (FSIMD*) connectors (back) ........B-15 Table B-14 PCIe MiniCard FPC (FMT3G*) connectors (front)........B-16 Table B-15 PCIe MiniCard FPC (FSI3G*) connectors (front) .........B-17 App-viii [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710)
  • Page 321 Appendices System board Table C-1 Memory connector 2 (200-pin) ................C-1 Table C-2 HDD/SSD interface connector (25-pin)............C-4 Table C-3 eSATA&USB interface connector (11-pin)............C-5 Table C-4 Express card interface connector (40-pin) ............C-6 Table C-5 Docking interface connector (64-pin) ..............C-8 Table C-6 Mini PCI Express interface connector (52-pin) ..........C-9 Table C-7 FSI3G* board interface connector (25-pin) ...........C-10 Table C-8...
  • Page 322 Appendices Table C-29 Speaker interface connector (2-pin) ...............C-22 Table C-30 System board interface connector (36-pin) ............C-23 Table C-31 Microphone interface connector (6-pin) ............C-24 Table C-32 Headphone interface connector (6-pin)............C-24 USB board Table C-33 USB (PORT0) interface connector (4-pin).............C-25 Table C-34 WebCam interface connector (6-pin) .............C-25 Table C-35 System board interface connector (20-pin) ............C-26 Table C-36 FMTSW* board interface connector (3-pin)..........C-26 SD board...
  • Page 323 Appendices MDC interface FPC Table C-54 System board interface connector (12-pin) ............C-36 Table C-55 MDC interface connector (12-pin)..............C-36 PCIe MiniCard FPC Table C-56 Mini Card Slot2 interface connector (50-pin)..........C-37 Table C-57 System board interface connector (25-pin) ............C-38 Table C-58 SIM Card interface connector (12-pin) ............C-38 PCIe MiniCard FPC Table C-59 Mini Card Slot2 interface connector (50-pin)..........C-39 Table C-60 System board interface connector (25-pin) ............C-40...
  • Page 324 Appendices App-xii [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...

  • Page 325: Appendix A Handling The Lcd Module

    Appendix A Handling the LCD Module Appendices Appendix A Appendix A Handling the LCD Module Precautions for handling the LCD module The LCD module can be easily damaged during assembly or disassembly. Observe the following precautions when handling the LCD module: 1.
  • Page 326 Appendices Appendix A Handling the LCD Module 3. If the panel’s surface gets dirty, wipe it with cotton or a soft cloth. If it is still dirty, try breathing on the surface to create a light condensate and wipe it again. If the surface is very dirty, we recommend a CRT cleaning agent.
  • Page 327 Appendix A Handling the LCD Module Appendices 5. Glass is used in the panel, so be careful not to drop it or let it strike a hard object, which could cause breakage or cracks. 6. CMOS-LSI circuits are used in the module, so guard against damage from electrostatic discharge.
  • Page 328 Appendices Appendix A Handling the LCD Module 7. Do not expose the module to direct sunlight or strong ultraviolet rays for long periods. 8. Do not store the module at temperatures below specifications. Cold can cause the liquid crystals to freeze, lose their elasticity or otherwise suffer damage. 9.
  • Page 329 Appendix A Handling the LCD Module Appendices 10. If you transport the module, do not use packing material that contains epoxy resin (amine) or silicon glue (alcohol or oxide). These materials can release gas that can damage the panel’s polarization. PORTEGE A600 Maintenance Manual (960-710) [CONFIDENTIAL] Downloaded from...
  • Page 330 Appendices Appendix A Handling the LCD Module [CONFIDENTIAL ] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...

  • Page 331: Appendix B Board Layout

    Appendix B Board Layout Appendices Appendix B Board Layout System board (FMTXS*) Front View Figure B-1 System board(FMTXS*) layout (front) [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...
  • Page 332 Appendices Appendix B Board Layout Table B-1 System board(FMTXS*) connectors (front) Number Name CN1900 HDD/SSD I/F connector CN3010 MDC I/F connector CN4100 LAN I/F connector CN4400 Bluetooth I/F connector CN9500 FMTJA* board I/F connector CN9600 FMTUS* board I/F connector IC1200 North Bridge Cantiga-GS IC1600 South Bridge ICH9M...
  • Page 333 Appendix B Board Layout Appendices System board (FMTXS*) Back View Figure B-2 System board(FMTXS*) layout (back) [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...
  • Page 334 Appendices Appendix B Board Layout Table B-2 System board (FMTXS*) connectors and ICs (back) Number Name CN1410 Memory connector 2 CN1970 eSATA&USB I/F connector CN2520 Express card I/F connector CN2300 Docking I/F connector CN2600 Mini PCI Express I/F connector CN2750 FSI3G* board I/F connector CN3230 Keyboard I/F connector...
  • Page 335 Appendix B Board Layout Appendices Finger Sensor board (FMTFS*) View (front) (back) Figure B-3 Finger Sensor board (FMTFS*) layout (front/back) Finger Sensor MTFS back Table B-3 board (F *) connector ( Number Name System board I/F connector CN9810 [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...
  • Page 336 Appendices Appendix B Board Layout SW board (FMTSW*) View (front) (back) 4 SW board MTSW Figure B- *) layout (front/back) 4 SW board MTSW Table B- *) connector (back) Number Name CN9630 FMTUS* board I/F connector [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...
  • Page 337 Appendix B Board Layout Appendices Jack board (FMTJA*) View (front) (back) Jack board MTJA Figure B-5 *) layout (front/back) Jack board MTJA Table B-5 *)connector (front/back) Number Name CN4620 USB(port6) I/F connector CN6050 Int-Microphone I/F connector CN6350 Speaker I/F connector CN9510 System board I/F connector J6051...
  • Page 338 Appendices Appendix B Board Layout USB board (FMTUS*) View (front) (back) 6 USB board MTUS Figure B- *) layout (front/back) 6 USB board MTUS Table B- *) connector (back) Number Name CN4630 USB(Port0) I/F connector CN9540 WebCam I/F connector CN9610 System board I/F connector CN9620 FMTSW* board I/F connector...
  • Page 339 Appendix B Board Layout Appendices SD board (FSISD*) View for PORTEGE A600 (front) (back) SISD Figure B-7 SD board (F *) layout (front/back) SD board SISD front/back Table B-7 *) connector ( Number Name CN2671 Antenna I/F connector CN2672 3G I/F connector CN2673 WLAN I/F connector CN9710...
  • Page 340 Appendices Appendix B Board Layout SD board (FMTSD*) View for PORTEGE R600 (Not used) (front) (back) MTSD Figure B- SD board (F *) layout (front/back) 8 SD board MTSD front/back Table B- *) connector ( Number Name CN1820 FMTPO* board I/F connector CN9710 System board I/F connector IS2130...
  • Page 341 Appendix B Board Layout Appendices Antenna board (FMTAT*) View for PORTEGE R600 (Not used) (front) (back) Figure B- Antenna board (FMTAT*) layout (front/back) 9 Antenna board MTAT front/back Table B- *) connector ( Number Name CN2671 Antenna I/F connector CN2672 3G I/F connector CN2673 WLAN I/F connector...
  • Page 342 Appendices Appendix B Board Layout B.10 PATA ODD FPC (FMTPO*) View for PORTEGE R600 (Not used) (front) (back) MTPO Figure B- PATA ODD FPC (F *) layout (front) 8 PATA ODD FPC MTPO front Table B- *) connector ( Number Name CN1810 PATA ODD I/F connector...
  • Page 343 Appendix B Board Layout Appendices (front) (back) SISO Figure B- SATA ODD FPC (F *) layout (front/back) 11 SATA ODD FPC SISO front Table B- *) connector ( Number Name CN1950 SATA ODD I/F connector CN9400 System board I/F connector [CONFIDENTIAL] B-13 PORTEGE A600 Maintenance Manual (960-710)
  • Page 344 Appendices Appendix B Board Layout B.12 SATA HDD FPC (FMTSH*) View (front) (back) MTSH /back Figure B- SATA HDD FPC (F *) layout (front 12 SATA HDD FPC MTSH front/back Table B- *) connector ( Number Name CN1810 System board I/F connector CN1820 SATA HDD I/F connector B-14...

  • Page 345: Appendix B Board Layout

    Appendix B Board Layout Appendices B.13 MDC interface FPC (FSIMD*) View for PORTEGE A600 (front) (back) SIMD /back Figure B- MDC interface FPC (F *) layout (front 13 MDC interface FPC SIMD back Table B- *) connector ( Number Name CN3020 System board I/F connector CN3030...

  • Page 346: Pcie Minicard Fpc (Fmt3G*) View For Portege R600

    Appendices Appendix B Board Layout B.14 PCIe MiniCard FPC (FMT3G*) View for PORTEGE R600 (Not used) (front) MT3G Figure B- PCIe MiniCard FPC (F *) layout (front) 14 PCIe MiniCard FPC MT3G front Table B- *) connector ( Number Name CN2621 Mini Card Slot2 I/F connector CN2760...

  • Page 347: Pcie Minicard Fpc (Fsi3G*) View For Portege A600

    Appendix B Board Layout Appendices B.15 PCIe MiniCard FPC (FSI3G*) View for PORTEGE A600 (front) SI3G Figure B- PCIe MiniCard FPC (F *) layout (front) 15 PCIe MiniCard FPC SI3G front Table B- *) connector ( Number Name CN2621 Mini Card Slot2 I/F connector CN2760 FMTXS* board I/F connector IS2620...
  • Page 348 Appendices Appendix B Board Layout B-18 [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...

  • Page 349: Appendix C Pin Assignments

    Appendix C Pin Assignments Appendices Appendix C Pin Assignments System board (FMTXS＊) CN1410 Memory connector 2 (200-pin) Table C-1 Memory connector 2 (200-pin) (1/3) Pin No. Signal Name Pin No. Signal Name MRVREF-B0V BDQ02-B1P BDQ04-B1P BDQ00-B1P BDQ01-B1P BDM0-B1P BDQS0-B1N BDQS0-B1P BDQ05-B1P BDQ03-B1P BDQ06-B1P...
  • Page 350 Appendices Appendix C Pin Assignments Table C-1 Memory connector 2 (200-pin) (2/3) Pin No. Signal Name Pin No. Signal Name BDQ16-B1P BDQ22-B1P BDQ20-B1P BDQ23-B1P BDM2-B1P BDQS2-B1N BDQS2-B1P BDQ17-B1P BDQ18-B1P BDQ19-B1P BDQ21-B1P MCKE3-B1P MCKE4-B1P 1R8-B1V 1R8-B1V BBS2-B1P BMA14-B1P 1R8-B1V 1R8-B1V BMA12-B1P BMA11-B1P BMA09-B1P BMA07-B1P...
  • Page 351 Appendix C Pin Assignments Appendices Table C-1 Memory connector 2 (200-pin) (3/3) Pin No. Signal Name Pin No. Signal Name BDQ39-B1P BDQ35-B1P BDQ38-B1P BDQ34-B1P BDQ44-B1P BDQ41-B1P BDQ45-B1P BDQ40-B1P BDQS5-B1N BDM5-B1P BDQS5-B1P BDQ43-B1P BDQ47-B1P BDQ42-B1P BDQ46-B1P BDQ48-B1P BDQ54-B1P BDQ53-B1P BDQ50-B1P XMCK4-B1P XMCK4-B1N BDQS6-B1N BDQS6-B1P...

  • Page 352: Cn1900 Hdd/Ssd Interface Connector (25-Pin

    Appendices Appendix C Pin Assignments CN1900 HDD/SSD interface connector (25-pin) Table C-2 HDD/SSD interface connector (25-pin) Pin No. Signal Name Pin No. Signal Name ZSTTHD-P1P ZSTTHD-P1N ZSTRHD-P1N ZSTRHD-P1P [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...

  • Page 353: Cn1970 Esata&Usb Interface Connector (11-Pin

    Appendix C Pin Assignments Appendices CN1970 eSATA&USB interface connector (11-pin) Table C-3 eSATA&USB interface connector (11-pin) Pin No. Signal Name Pin No. Signal Name USB1PS-E5V ZUSBES-E3N ZUSBES-E3P ZSTTES-P1P ZSTTES-P1N ZSTRES-P1N ZSTRES-P1P PORTEGE A600 Maintenance Manual (960-710) [CONFIDENTIAL] Downloaded from www.Manualslib.com manuals search engine...

  • Page 354: Cn2520 Express Card Interface Connector (40-Pin

    Appendices Appendix C Pin Assignments CN2520 Expresscard interface connector (40-pin) Table C-4 Expresscard interface connector (40-pin) Pin No. Signal Name Pin No. Signal Name ZETCRD-P1P ZETCRD-P1N ZERCRD-P1P ZERCRD-P1N XPECRD-P0P XPECRD-P0N CPPE-E3N CRDCRQ-E3N CRD-P3V CRD-P3V CRD-P3V CRDRST-E3N CRD-E3V PEWAKE-E3N CRD1R5-P1V CRD1R5-P1V CRD-E3V CRD-E3V CPUSB-E3N...
  • Page 355 Appendix C Pin Assignments Appendices Blanc page PORTEGE A600 Maintenance Manual (960-710) [CONFIDENTIAL] Downloaded from www.Manualslib.com manuals search engine...

  • Page 356: Cn2300 Docking Interface Connector (64-Pin

    Appendices Appendix C Pin Assignments CN2300 Docking interface connector (64-pin) Table C-5 Docking interface connector (64-pin) Pin No. Signal Name Pin No. Signal Name DSKDC D-E5V DOCDT2-S3N DOCTYP-E3N EJCTRQ-S3N DOCVON-S3P DVIDET-P3N XDVCLK-P3P XDCCLK-P3N ZDVTX1-P3P ZDVTX1-P3N IDSCL-P3P IDSDA-P3P DRED-PXP DGREEN-PXP DBLUE-PXP DHSYNC-P3P LINK-E3N ACT-E3N...

  • Page 357: Cn2600 Mini Pci Express Interface Connector (52-Pin

    Appendix C Pin Assignments Appendices CN2600 Mini PCI Express interface connector (52-pin) Table C-6 Mini PCI Express interface connector (52-pin) Pin No. Signal Name Pin No. Signal Name PEWAKE-E3N WLAN-E3V 1R5-P1V WLNXRQ-P3N XPEWLN-P0N XPEWLN-P0P WLRFON-S3N IC2601-4pin ZERWL-P1N WLAN-E3V ZERWL-P1P WLWMDT-P3N 1R5-P1V ZETWL-P1N ZETWL-P1P...

  • Page 358: Cn2750 Fsi3G* Board Interface Connector (25-Pin

    Appendices Appendix C Pin Assignments CN2750 FSI3G* board interface connector (25-pin) Table C-7 FSI3G* board interface connector (25-pin) Pin No. Signal Name Pin No. Signal Name TMP3G-GND TMP3G-SXP 3GWAKE-S3N PLTRS1-E3N 3GRST-S3N 3GRFON-S3N ZUSB3G-E3N ZUSB3G-E3P 3GGPDT-P3N 3GLED-E3P 3GON-S3N CN3010 MDC interface connector (12-pin) Table C-8 MDC interface connector (12-pin) Pin No.

  • Page 359: Cn3230 Keyboard Interface Connector (30-Pin

    Appendix C Pin Assignments Appendices CN3230 Keyboard interface connector (30-pin) Table C-9 keyboard interface connector (30-pin) Pin No. Signal Name Pin No. Signal Name NUMLED-P5N ARWLED-P5N CAPLED-P5N KBRT06-S3N KBRT02-S3N KBRT03-S3N KBRT05-S3N KBRT01-S3N KBRT04-S3N KBRT07-S3N KBRT00-S3N KBSC00-S3N KBSC09-S3N KBSC03-S3N KBSC02-S3N KBSC05-S3N KBSC04-S3N KBSC06-S3N KBSC08-S3N...

  • Page 360: Cn4400 Bluetooth Interface Connector (20-Pin

    Appendices Appendix C Pin Assignments C.11 CN4400 Bluetooth interface connector (20-pin) Table C-11 Bluetooth interface connector (20-pin) Pin No. Signal Name Pin No. Signal Name BTMDL-P3N BTRST-S3N ZUSBBT-E3P ZUSBBT-E3N BT-P3V C.12 CN5080 CRT interface connector (15-pin) Table C-12 CRT interface connector (15-pin) Pin No.

  • Page 361: Cn5601 Lcd Interface Connector (35-Pin

    Appendix C Pin Assignments Appendices C.13 CN5601 LCD interface connector (35-pin) Table C-13 LCD interface connector (35-pin) Pin No. Signal Name Pin No. Signal Name LEDBL5-GND LEDBL4-GND LEDBL3-GND LEDBL2-GND LEDBL1-GND LEDBL0-GND LEDBL-PYV PNL-P2V PNL-P2V PNL-P2V PNL-P2V (IC5310-4) FSDA-P3P FSCL-P3P XITXCA-PYP XITXCA-PYN ZITDA2-PYP ZITDA2-PYN...

  • Page 362: Cn8771 Fan Interface Connector (4-Pin

    Appendices Appendix C Pin Assignments C.14 CN8771 FAN interface connector (4-pin) Table C-14 FAN interface connector (4-pin) Pin No. Signal Name Pin No. Signal Name FANGO-P3P (IC8773-4) C.15 CN8800 DC-IN connector (4-pin) Table C-15 DC-IN connector (4-pin) Pin No. Signal Name Pin No.

  • Page 363: Cn9400 Sata Odd Interface Connector (20-Pin

    Appendix C Pin Assignments Appendices C.18 CN9400 SATA ODD interface connector (20-pin) Table C-18 SATA ODD interface connector (20-pin) Pin No. Signal Name Pin No. Signal Name ZSTTOD-P1P ZSTTOD-P1N ZSTROD-P1N ZSTROD-P1P SODD-P5V SODD-P5V SODD-P5V SODD-P5V SODD-P5V PORTEGE A600 Maintenance Manual (960-710) [CONFIDENTIAL] C-15 Downloaded from...

  • Page 364: Cn9500 Fmtja* Board Interface Connector (36-Pin

    Appendices Appendix C Pin Assignments C.19 CN9500 FMTJA* board interface connector (36-pin) Table C-19 FMTJA* board interface connector (36-pin) Pin No. Signal Name Pin No. Signal Name USB2PS-E5V USB2PS-E5V USB2PS-E5V USB2PS-E5V USB2PS-E5V ZUSBP6-E3N ZUSBP6-E3P XAZBC0-P3P AZSYC0-P3P AZSDI0-P3P AZSDO0-P3P AZRST0-E3N SNDMUT-S3N AMPSD-S3N 1R5-P1V PCBEEP-P3P...

  • Page 365: Cn9600 Fmtus* Board Interface Connector (30-Pin

    Appendix C Pin Assignments Appendices C.21 CN9600 FMTUS* board interface connector (30-pin) Table C-21 FMTUS* board interface connector (30-pin) Pin No. Signal Name Pin No. Signal Name RESWON-S3N USB0PS-E5V USB0PS-E5V USB0PS-E5V USB0PS-E5V USB0PS-E5V WCAMEN-E3N ZUSBP0-E3N ZUSBP0-E3P GPBTNA-S3N GPBTNB-S3N PNLOFF-S3N ZUSBCM-E3N ZUSBCM-E3P CAMDET-P3N PORTEGE A600 Maintenance Manual (960-710)

  • Page 366: Cn9700 Fmtsd*/Fsisd* Board Interface Connector (30-Pin

    Appendices Appendix C Pin Assignments C.22 CN9700 FMTSD*/FSISD* board interface connector (30-pin) Table C-22 FMTSD*/FSISD* board interface connector (30-pin) Pin No. Signal Name Pin No. Signal Name SDAT3-P3P SDCMD-P3P SDCLK-P3P SDAT0-P3P SDAT1-P3P SDAT2-P3P SDCD-P3N SD-P3V SD-P3V SDWP-P3P ZUSBOD-E3N ZUSBOD-E3P MBVON-E5N PODDET-P3N C-18 [CONFIDENTIAL]...

  • Page 367: Cn9800 Fmtfs* Board Interface Connector (6-Pin

    Appendix C Pin Assignments Appendices C.23 CN9800 FMTFS* board interface connector (6-pin) Table C-23 FMTFS* board interface connector (6-pin) Pin No. Signal Name Pin No. Signal Name ZUSBFS-E3P ZUSBFS-E3N FGSPON-S3N C.24 CN9850 Membrane interface connector (24-pin) Table C-24 Membrane interface connector (24-pin) Pin No.

  • Page 368: Finger Sensor Board (Fmtfs*)

    Appendices Appendix C Pin Assignments Finger Sensor board (FMTFS*) C.25 CN9810 System board interface connector (6-pin) Table C-25 System board interface connector (6-pin) Pin No. Signal Name Pin No. Signal Name FGSPON-S3N ZUSBFS-E3N ZUSBFS-E3P C-20 [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...

  • Page 369: Sw Board (Fmtsw*)

    Appendix C Pin Assignments Appendices SW board (FMTSW*) C.26 CN9630 FMTUS* board interface connector (3-pin) Table C-26 FMTUS* board interface connector (3-pin) Pin No. Signal Name Pin No. Signal Name PNLOFF-S3N PORTEGE A600 Maintenance Manual (960-710) [CONFIDENTIAL] C-21 Downloaded from www.Manualslib.com manuals search engine...

  • Page 370: Jack Board (Fmtja*)

    Appendices Appendix C Pin Assignments JACK board (FMTJA*) C.27 CN4620 USB (PORT6) interface connector (4-pin) Table C-27 USB(PORT6) interface connector (4-pin) Pin No. Signal Name Pin No. Signal Name USB2PS-E5V ZUSBP6-E3N ZUSBP6-E3P C.28 CN6050 Int-Microphone interface connector (2-pin) Table C-28 Int-Microphone interface connector (2-pin) Pin No.

  • Page 371: Cn9510 System Board Interface Connector (36-Pin

    Appendix C Pin Assignments Appendices C.30 CN9510 System board interface connector (36-pin) Table C-30 System board interface connector (36-pin) Pin No. Signal Name Pin No. Signal Name USB2PS-E5V USB2PS-E5V USB2PS-E5V USB2PS-E5V USB2PS-E5V ZUSBP6-E3N ZUSBP6-E3P XAZBC0-P3P AZSYC0-P3P AZSDI0-P3P AZSDO0-P3P AZRST0-E3N SNDMUT-S3N AMPSD-S3N 1R5-P1V PCBEEP-P3P...

  • Page 372: J6050 Microphone Interface Connector (6-Pin

    Appendices Appendix C Pin Assignments C.31 J6050 Microphone interface connector (6-pin) Table C-31 Microphone interface connector (6-pin) Pin No. Signal Name Pin No. Signal Name EMICIN-PXP EMICB-P2V DETCTA-P4N EMICB-P2V C.32 J6310 Headphone interface connector (6-pin) Table C-32 Headphone interface connector (6-pin) Pin No.

  • Page 373: Usb Board (Fmtus*)

    Appendix C Pin Assignments Appendices USB board (FMTUS*) C.33 CN4630 USB (PORT0) interface connector (4-pin) Table C-33 USB(PORT0) interface connector (4-pin) Pin No. Signal Name Pin No. Signal Name USB0PS-E5V ZUSBP0-E3N ZUSBP0-E3P C.34 CN9540 WebCam interface connector (6-pin) Table C-34 WebCam interface connector (6-pin) Pin No.

  • Page 374: Cn9610 System Board Interface Connector (20-Pin

    Appendices Appendix C Pin Assignments C.35 CN9610 System board interface connector (20-pin) Table C-35 System board interface connector (20-pin) Pin No. Signal Name Pin No. Signal Name RFSWON-S3N USB0PS-E5V USB0PS-E5V USB0PS-E5V USB0PS-E5V USB0PS-E5V WCAMEN-E3N ZUSBP0-E3N ZUSBP0-E3P GPBTNA-S3N GPBTNB-S3N PNLOFF-S3N ZUSBCM-E3N ZUSBCM-E3P CAMDET-P3N C.36...
  • Page 375 Appendix C Pin Assignments Appendices SD board (FSISD*) for PORTEGE A600 C.37 CN2671 Antenna interface connector (3-pin) Table C-37 Antenna interface connector (3-pin) Pin No. Signal Name Pin No. Signal Name (FL2670-2) C.38 CN2672 3G interface connector (3-pin) Table C-38 3G interface connector (3-pin) Pin No.
  • Page 376 Appendices Appendix C Pin Assignments C.40 CN9710 System board interface connector (20-pin) Table C-40 System board interface connector (20-pin) Pin No. Signal Name Pin No. Signal Name SDAT3-P3P SDCMD-P3P SDCLK-P3P SDAT0-P3P SDAT1-P3P SDAT2-P3P SDCD-P3N SD-P3V SD-P3V SDWP-P3P C.41 IS2130 SD Card interface connector (12-pin) Table C-41 SD Card interface connector (12-pin) Pin No.
  • Page 377 Appendix C Pin Assignments Appendices SD board (FMTSD*) for PORTEGE R600 (Not used) C.42 CN1820 FMTPO* board interface connector (50-pin) Table C-42 FMTPO* board interface connector (50-pin) Pin No. Signal Name Pin No. Signal Name ODD-P5V ODD-P5V ODD-P5V ODD-P5V ODD-P5V ODD-P5V ODD-P5V PODDET-P3N...

  • Page 378: Cn9710 System Board Interface Connector (20-Pin

    Appendices Appendix C Pin Assignments C.43 CN9710 System board interface connector (30-pin) Table C-43 System board interface connector (30-pin) Pin No. Signal Name Pin No. Signal Name SDAT3-P3P SDCMD-P3P SDCLK-P3P SDAT0-P3P SDAT1-P3P SDAT2-P3P SDCD-P3N SD-P3V SD-P3V SDWP-P3P ZUSBOD-E3N ZUSBOD-E3P MBVON-E5N PODDET-P3N C.44 IS2130 SD Card interface connector (12-pin) Table C-41 SD Card interface connector (12-pin)

  • Page 379: Antenna Board (Fmtat*)

    Appendix C Pin Assignments Appendices Antenna board (FMTAT*) for PORTEGE R600 (Not used) C.45 CN2671 Antenna interface connector (3-pin) Table C-42 Antenna interface connector (3-pin) Pin No. Signal Name Pin No. Signal Name (FL2670-2) C.46 CN2672 3G interface connector (3-pin) Table C-43 3G interface connector (3-pin) Pin No.

  • Page 380: Pata Odd Fp C (Fmtpo*)

    Appendices Appendix C Pin Assignments PATA ODD FPC (FMTPO*) for PORTEGE R600 (Not used) C.48 CN1810 PATA ODD interface connector (50-pin) Table C-45 PATA ODD interface connector (50-pin) Pin No. Signal Name Pin No. Signal Name UIDRST-P3N UDD08-P3P UDD07-P3P UDD09-P3P UDD06-P3P UDD10-P3P UDD05-P3P...

  • Page 381: Cn1830 Fmtsd* Board Interface Connector (50-Pin

    Appendix C Pin Assignments Appendices C.49 CN1830 FMTSD* board interface connector (50-pin) Table C-46 FMTSD* board interface connector (50-pin) Pin No. Signal Name Pin No. Signal Name ODD-P5V ODD-P5V ODD-P5V ODD-P5V ODD-P5V ODD-P5V ODD-P5V UDCS3-P3N UDCS1-P3N UDA2-P3P UDA0-P3P UDA1-P3P IDEINT-P5P UDDACK-P3N UIORDY-P3P UDIOW-P3N...

  • Page 382: Cn1950 Sata Odd Interface Connector (13-Pin

    Appendices Appendix C Pin Assignments SATA ODD FPC (FSISO*) for PORTEGE A600 C.50 CN1950 SATA ODD interface connector (13-pin) Table C-47 SATA ODD interface connector (13-pin) Pin No. Signal Name Pin No. Signal Name ZSTTOD-P1P ZSTTOD-P1N ZSTROD-P1N ZSTROD-P1P SODDET-P3N SODD-P5V SODD-P5V C.51 CN9400 System board interface connector (20-pin) Table C-48 System board interface connector (20-pin)

  • Page 383: Sata Hdd Fpc (Fmtsh*)

    Appendix C Pin Assignments Appendices SATA HDD FPC (FMTSH*) C.52 CN1810 System board interface connector (25-pin) Table C-49 System board interface connector (25-pin) Pin No. Signal Name Pin No. Signal Name ZSTRHD-P1P ZSTRHD-P1N ZSTTHD-P1N ZSTTHD-P1P C.53 CN1820 SATA HDD interface connector (22-pin) Table C-50 SATA HDD interface connector (22-pin) Pin No.

  • Page 384: Mdc Interface Fpc (Fsimd*)

    Appendices Appendix C Pin Assignments MDC interface FPC (FSIMD*) for PORTEGE A600 C.54 CN3020 System board interface connector (12-pin) Table C-51 System board interface connector (12-pin) Pin No. Signal Name Pin No. Signal Name AZSDO1-P3P AZSYC1-P3P MDSDI1-E3P AZRST1-E3N XAZBC1-P3P C.55 CN3030 MDC interface connector (12-pin) Table C-52 MDC interface connector (12-pin) Pin No.

  • Page 385: Pcie Minicard Fpc (Fmt3G*)

    Appendix C Pin Assignments Appendices PCIe MiniCard FPC (FMT3G*) for PORTEGE R600 (Not used) C.56 CN2621 Mini Card Slot2 interface connector (50-pin) Table C-53 Mini Card Slot2 interface connector (50-pin) Pin No. Signal Name Pin No. Signal Name UIMPWR-E3V UIMDAT-E3P UIMCLK-E3P UIMRST-E3P 3GRFON-S3N...

  • Page 386: Cn2760 System Board Interface Connector (25-Pin

    Appendices Appendix C Pin Assignments C.57 CN2760 System board interface connector (25-pin) Table C-54 System board interface connector (25-pin) Pin No. Signal Name Pin No. Signal Name TMP3G-GND TMP3G-SXP 3GWAKE-S3N PLTRS1-E3N 3GRST-S3N 3GRFON-S3N ZUSB3G-E3N ZUSB3G-E3P 3GGPDT-P3N 3GLED-E3P 3GON-S3N C.58 IS2620 SIM Card interface connector (12-pin) Table C-55 SIM Card interface connector (12-pin) Pin No.

  • Page 387: Pcie Minicard Fpc (Fsi3G*)

    Appendix C Pin Assignments Appendices PCIe MiniCard FPC (FSI3G*) for PORTEGE A600 C.59 CN2621 Mini Card Slot2 interface connector (50-pin) Table C-56 Mini Card Slot2 interface connector (50-pin) Pin No. Signal Name Pin No. Signal Name UIMPWR-E3V UIMDAT-E3P UIMCLK-E3P UIMRST-E3P 3GRFON-S3N PLTRS1-E3N ZUSB3G-E3N...

  • Page 388: Cn2760 System Board Interface Connector (25-Pin

    Appendices Appendix C Pin Assignments C.60 CN2760 System board interface connector (25-pin) Table C-57 System board interface connector (25-pin) Pin No. Signal Name Pin No. Signal Name TMP3G-GND TMP3G-SXP 3GWAKE-S3N PLTRS1-E3N 3GRST-S3N 3GRFON-S3N ZUSB3G-E3N ZUSB3G-E3P 3GGPDT-P3N 3GLED-E3P 3GON-S3N C.61 IS2620 SIM Card interface connector (12-pin) Table C-58 SIM Card interface connector (12-pin) Pin No.
  • Page 389 Appendix D Keyboard Scan/Character Codes Appendices Appendix. D Appendix D Keyboard Scan/Character Codes Scan Codes Table D-1 Scan codes (set 1 and set 2) (1/4) Code set 1 Code set 2 Keytop Note Make Break Make Break ‘ ~ 7 & BkSp PORTEGE A600 Maintenance Manual (960-710) [CONFIDENTIAL]...
  • Page 390 Appendices Appendix D Keyboard Scan/Character Codes Table D-1 Scan codes (set 1 and set 2) (2/4) Code set 1 Code set 2 Keytop Note Make Break Make Break Caps Lock ‘ “ Enter Shift (L) No.102 , < . > Shift (R) [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710)
  • Page 391 Appendix D Keyboard Scan/Character Codes Appendices Table D-1 Scan codes (set 1 and set 2) (3/4) Code set 1 Code set 2 Keytop Note Make Break Make Break Ctrl Alt (L) Space ALT (R) ← Home ↑ ↓ PgUp PgDn →...

  • Page 392: Appendix D Keyboard Scan/Character Codes

    Appendices Appendix D Keyboard Scan/Character Codes Table D-1 Scan codes (set 1 and set 2) (4/4) Code set 1 Code set 2 Keytop Note Make Break Make Break PrintSc Pause — — — — Notes: 1. * Scan codes differ by mode. 2.
  • Page 393 Appendix D Keyboard Scan/Character Codes Appendices Table D-2 Scan codes with left Shift key Code set 1 Code set 2 Make Break Make Break E0 AA E0 35 E0 B5 E0 2A E0 F0 12 E0 4A E0 F0 4A E0 12 E0 AA E0 52 E0 D2 E0 2A E0 F0 12 E0 70 E0 F0 70 E0 12...
  • Page 394 Appendices Appendix D Keyboard Scan/Character Codes Table D-3 Scan codes in Numlock mode Code set 1 Code set 2 Make Break Make Break E0 2A E0 52 E0 D2 E0 AA E0 12 70 E0 F0 E0 F0 12 E0 2A E0 53 E0 D3 E0 AA E0 12 71 E0 F0 E0 F0 12...
  • Page 395 Appendix D Keyboard Scan/Character Codes Appendices Table D-5 Scan codes in overlay mode Code set 1 Code set 2 Keytop Make Break Make Break (–) Table D-6 No.124 key scan code Code set 1 Code set 2 Shift Make Break Make Break Prt Sc...
  • Page 396 Appendices Appendix D Keyboard Scan/Character Codes Table D-7 No.126 key scan code Shift Code set 1 Code set 2 Make Make Pause Common* E1 1D E1 F0 Ctrl* E0 46 7E E0 F0 *: This key generates only make codes. [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from...

  • Page 397: Appendix E Key Layout

    Appendix E Key Layout Appendices Appendix E Key Layout United Kingdom (UK) Keyboard Figure E-1 UK keyboard United States (US) Keyboard Figure E-2 US keyboard PORTEGE A600 Maintenance Manual (960-710) [CONFIDENTIAL] Downloaded from www.Manualslib.com manuals search engine...
  • Page 398 Appendices Appendix E Key Layout Thai Keyboard Figure E-3 Thai keyboard Canadian French Keyboard Figure E-4 Canadian French keyboard [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...

  • Page 399: Appendix F Wiring Diagrams

    Appendix F Wiring diagrams Appendices Appendix F Wiring diagrams RGB Monitor Loopback Connector Figure F-1 RGB Monitor Loopback Connector LAN Loopback Connector Figure F-2 LAN Loopback Connector PORTEGE A600 Maintenance Manual (960-710) [CONFIDENTIAL] Downloaded from www.Manualslib.com manuals search engine...
  • Page 400 Appendices Appendix F Wiring diagrams [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...

  • Page 401: Appendix Gbios Rewrite Procedures

    Appendix G BIOS rewrite procedures Appendices Appendix G Appendix G BIOS Rewrite Procedures This Appendix explains how to rewrite the system BIOS program when you update the system BIOS. Tools To rewrite the BIOS, you need the following tool: BIOS/EC/KBC rewriting disk Rewriting the BIOS 1.
  • Page 402 Appendices Appendix G BIOS rewrite procedures [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...

  • Page 403: Appendix Hec/Kbc Rewrite Procedures

    Appendix H EC/KBC rewrite procedures Appendices Appendix H Appendix H EC/KBC Rewrite Procedures This Appendix explains how to rewrite the EC/KBC system program when you update the EC/KBC system. It is necessary to rewrite the EC/KBC system program when the following changes are made. 1.
  • Page 404 Appendices Appendix H EC/KBC rewrite procedures [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...

  • Page 405: Appendix I Reliability

    Appendix I Reliability Appendices Appendix I Reliability Appendix I Reliability The following table shows MTBF (Mean Time Between Failures) in maximum configuration. Table I-1 MTBF Time (hours) 5,703.6ｈ PORTEGE A600 Maintenance Manual (960-710) [CONFIDENTIAL] Downloaded from www.Manualslib.com manuals search engine...
  • Page 406 Appendices Appendix I Reliability [CONFIDENTIAL] PORTEGE A600 Maintenance Manual (960-710) Downloaded from www.Manualslib.com manuals search engine...

Table of Contents
