Datalog

Item
Status* Enable or disable datalog.
Interval* Enter the logging interval in seconds.
Decimals Enter the number of decimal places for logged data.
Separator* Choose separator to be used between parameters.
Terminator* Choose the terminator(s) for each group of data.
Parameters Set the parameter to be programmed (below).
Units Set the units for the selected parameter.
REMOVE Control button to remove selected item from the list.
ADD Control button to add the selected unit to the list.
RESET Delete datalog files.
DOWNLOAD Control button to display the logged data on the
Download screen (see below).
*
Indicated items apply to the entire datalog file.
Programming the VGA Optica
Enter parameters for automatically logging data within the Optica.
This menu is accessed by selecting the Data Log control button on
Menu 1 and pressing ENTER.
Figure 4-5: Datalog Menu
The large window below the center of the screen shows a list of
parameters chosen for logging.
Table 4-10: Datalog Options
Function
January 2006
Available Options
Enabled/Disabled
Enter a number.
Enter a number (6 maximum).
Space, Comma, Tab
CR, CR-LF, LF
Humidity, Temperature,
Pressure, or User Equation
See Table 4-1 on page 4-4.
Select button and press ENTER.
Select button and press ENTER.
Select button and press ENTER.
Select button and press ENTER.
4-13
