Factory Default Settings

Function
Analog Output A Humidity, Units: Tdew °C, Range: –40°C to +60°C
Analog Output B Temperature, Units: Tmp °C, Range: 0 to 100°C
Units: psia, Range: 0–30, Default pressure: 14.70,
Pressure Input 1
Process pressure: disabled, 14.70
Alarm 1 Disabled, Humidity, Units: Tdew °C, Set Point: 100.00
Alarm 2 Disabled, Temperature, Units: Tmp °C, Set Point: 100.00
Auto Balance Interval: 720 minutes, Automatic, Disabled, Hold
Data Field 1
Humidity, Units: Tdew °C, Range: –40.000 to +60.000°C, Color: green, 1 decimal
Humidity, Units: %RH, Range: 0 to 100, Color: blue, 1 decimal
Data Field 2
Temperature, Units: Tmp °C, Range: 0 to 100, Color: red, 1 decimal
Data Field 3
Pressure, Units: psia, Range: 0 to 100, Color: yellow, 1 decimal
Data Field 4
Data Field 5 Humidity, Units: ppmv, Range: 0 to 1,000,000, Color: brown, 1 decimal
Data Field 6 Humidity, Units: ppmw, Range: 0 to 100, Color: violet, 1 decimal
Buzzer 15 msec
General Data Fields: 3, Lockout: disabled, Offsets and filters: 0
Special Molecular Weight of Gas: 28.9645
User Equation None entered
Communication Mode: All, Baud rate: 9600, Parity: none, Data bits: 8, Stop bits: 1,
Parameters Flow control: none
Humidity: Units: Tdew °C, Format: DP=##.#, Separator: CR-LF, Terminator: CR-LF,
Interval: 1 second, Time Stamp: Enabled, Show Status: Enabled
Temperature: Units: Tmp °C, Format: DP=##.#, Separator: CR-LF, Terminator: CR-LF,
Serial Outputs
Interval: 1 second, Time Stamp: Enabled, Show Status: Enabled
Pressure: Units: psia, Format: DP=##.#, Separator: CR-LF, Terminator: CR-LF,
Interval: 1 second, Time Stamp: Enabled, Show Status: Enabled
Humidity, Units: Tdew °C
Selected
Humidity, Units: % RH
Outputs
Temperature, Units: Tmp °C
Status: Disabled, Interval: 1 second, Separator: comma, Terminator: CR-LF,
Data Log
Parameters: humidity, Units: Tdew °C
Operation
As shipped from the factory, the Optica is normally programmed with
the configuration shown in Table 3-2 below.
Table 3-2: Factory Default Values
Setting
January 2006
3-9
