Serial Output Data

Item
The units of currently selected parameters are
Selected
shown, along with the number of decimals for each
Outputs
unit.
Time Stamp* Output date and time with each data string.
Output dew point sensor status with each data string
Show Status* (Heat, Cool, Balance, PACER, Service, Alarm 1,
Alarm 2).
Parameter Select a parameter to configure.
Units Set the units for the selected parameter.
Format* Choose output format for the selected parameter.
Separator* Choose separator to be used between parameters.
Terminator* Choose the terminator(s) for each group of data.
Interval (sec)* Enter the output interval in seconds.
Enter the number of decimal places for the selected
Decimals
parameter.
Control button to add the configured parameter to
ADD button the output list, using the units and number of
decimals designated.
Control button to remove from the output list the
REMOVE
parameter selected at the top of the serial output
button
menu.
4-18
Table 4-15: Serial Output Data Options
Function Available Options
Units of selected output are
displayed. Select one with the
UP/DOWN keys to change it or
delete it using REMOVE.
Enabled/Disabled
Enabled/Disabled
Humidity, Temperature, Pres-
sure or User Equation
See Table 4-1 on page 4-4 for
available units.
Dp=##.#, ###.#(Dp), No Label
Space, Comma, TAB, CR, CR-LF
Comma, CR, CR-LF
Enter a number.
Enter a number (6 maximum).
Select button and press ENTER.
Select button and press ENTER
