Network Menu - GE Optica Operator's Manual

January 2006

Network Menu

Item
Host Name Enter the host name for the Optica unit of the LAN.
Domain Enter the Domain name for the local network.
IP Address Use the left and right arrow keys to select between
Type* DHCP and Static IP.
If you choose to specify an IP address, you must
IP Address*
enter it here.
If you choose to specify an IP address, you must
Subnet Mask*
enter a Subnet Mask.
Default If you choose to specify an IP address, you must
Gateway* enter a Default gateway.
OK button Save changes and return to the previous screen.
Help button Display help for the network screen.
*
You may need to contact your local network administrator for this information.
4-12
Networking settings including IP Address, Subnet Mask and Default
Gateway. Generally, you will obtain these settings from your network
administrator. This menu is accessed by selecting the Network
control button on Menu 1 and pressing ENTER.
Figure 4-4: Network Menu
Table 4-9: Network Settings Options
Function Available Options
Get the IP from the Server,
or Specify an IP Address.
Enter four decimal integers
between 0 and 255.
Enter four decimal integers
between 0 and 255.
Enter four decimal integers
between 0 and 255.
Enter a number (6 maximum).
Programming the VGA Optica
