Output tab
Each output panel contains adjustable features for each audio output on the IN1606.
Features include mix options, output limiter, and volume control.
Output 1/2 panel
Figure 34. Output 1/2 Panel
1. Click the tab.
Output
2.
For each output in the Output 1/2 panel, click the
a limiter in the output. The button turns blue when it is enabled.
3. For each output, select a
Output 1
Left Program
L and R Program
No Program
4. For each output, select the
output.
5. For each output, click and drag the handle of the output sliders, or enter a value in the
field below the sliders or click the Up or Down arrow button to adjust the output level.
Click the button for either slider to mute the output.
Mute
Click the button to control both sliders simultaneously.
Gang
6. Select the
Enable Meters
IN1606 Scaling Presentation Switcher • Internal Web Pages
radio button.
Mix Options
Output 1 and 2 Mix Options
Output 2 Note
Right Program Output 1 and 2 act as a stereo pair (default).
L and R Program L and R program audio are summed
on each output. They act as unique,
independent outputs with or without Mic.
No Program No program audio. Output 1 and 2 are
treated as unique, independent outputs with
or without Mic.
check box to include the mic/line mix in the
Mic/Line
check box to display output meters.
button to enable or disable
Limiter
