To add a new Frame Relay DLCI, select Add DLCI in the Frame Relay DLCI Configuration screen and press
Return. The Add DLCI screen appears.
DLCI Name:
DLCI Enabled:
DLCI Number (16-991):
Remote IP Address:
Data Flow Parameters---------------Use Default---------Value----
CIR:
Bc:
Be:
ADD DLCI NOW
Return accepts * ESC cancels * Left/Right moves insertion point * Del deletes.
Here you configure the parameters for a single DLCI (Data Link Circuit ID).
1. Select DLCI Name and enter a name for this individual Frame Relay DLCI profile. It can be any name you
want. For example: the name of your ISP or remote branch you're connecting to such as the corporate
headquarters of your company.
Note: The Netopia Router allows Frame Relay DLCIs to be named, so that you can easily reference and
differentiate them. This is accomplished by giving a DLCI Name to a DLCI Number.
2. Select DLCI Enabled and toggle it to Yes to activate the profile. If you disable this profile, the Netopia
Router will automatically disable and block access to a specific remote DLCI.
3. Select DLCI Number (16-991) and enter a number for this individual DLCI. Check with your Frame Relay
provider to find out what numbers are allocated for each of your DLCI profiles. The DLCI number range
should fall within the range of 16-991.
4. Select Remote IP Address and enter the remote IP address your ISP or network administrator gave you
that represents the remote sites IP address for their router. Press Return.
If you selected Standard or Buffered as the Tx Injection Management type in the Frame Relay Configuration
screen go to the next bulleted item below. If you selected None in the Frame Relay Configuration screen go to
step 6.
Below the Remote IP Address field, the following Data Flow Parameters appear:
The CIR (Committed Information Rate) represents the average capacity available to a given PVC (Per-
manent Virtual Circuit) or DLCI (Data Link Connection Identifier). The setting defaults to 64000, but
you may modify the capacity rate by toggling the selection in the Use Default field to No. You can then
enter a different capacity rate in the Value field.
The Bc (Committed Burst Size) represents the maximum amount of data that your Frame Relay service
Add DLCI
DLCI 16
Yes
16
0.0.0.0
Yes
Yes
Yes
CANCEL
