Netopia R5000 User Reference Manual page 135

To attach a SAP filter set, first define the filter set using the Filters and Filter Sets option (see step 8
below). Then select the filter set from the Ethernet Incoming SAP Filter Set pop-up menu. To detach the
filter set, select Detach Filter Set.
7. Select Default Gateway Address and enter the network address of the IPX network to which all packets of
unknown destination address should be routed.
Note: The default gateway address is usually set up to match the IPX Address in your network connection
profile.
8. To configure filters and filter sets, select Filters and Filter Sets and go to the IPX filters and filter sets
screens. For information on how to configure IPX filters and filter sets, see
9. Select IPX Wan Pool Base Address and enter the first IPX network address to be allocated to requesting
IPX WAN clients. The base address you enter must not conflict with other IPX networks assigned to your IPX
internet.
IPX routing tables provide information on current IPX routes and services.
To go to the IPX Routing Table screen, select IPX Routing Table in the Statistics & Logs screen. This table
shows detailed information about current IPX network routes.
Net Addr-Hops-Ticks-Type--Status-Interface--------------via Router------------
-----------------------------------SCROLL UP----------------------------------
00000020
00000030
00000033
00000100
00000110
---------------------------------SCROLL DOWN-----------------------------
UPDATE
To go to the IPX SAP Bindery Table screen, select IPX SAP Bindery Table in the Statistics & Logs screen. This
table shows detailed information about available IPX services and their location.
Main
Statistics & Logs
Menu
2 3 RIP Active Ethernet
2 12 RIP Active Ethernet
4 14 RIP Active Ethernet
2 7 RIP Active Ethernet
1 1 RIP Active Ethernet
• IPX Routing Table
• IPX SAP Bindery Table
IPX Routing Table
00000120:00000c465c2f
00000120:00000c465c2f
000000120:00000c465c2f
00000120:00000c465c2f
00000120:00000c465c2f
IPX Setup 10-5
"IPX filters" on page 13-23.
