Netopia R5000 User Reference Manual page 66

8-4 User's Reference Guide
Note: If you used Easy Setup to configure your router, you have already created a connection profile called
Easy Setup Profile. If you return to the Easy Setup menus and change the Data Link Encapsulation method
you set up in this step, the Easy Setup Data Link Encapsulation method will override this one and change
the default data link encapsulation method in use.
You are now finished configuring the Line Configuration screen. Press the Escape key to return to the WAN
Setup screen.
Note: If you selected Frame Relay as your data link encapsulation method, see
page 8-6 for more information.
The T1 Line Configuration screen is where you enter the configuration parameters for your T1 line, in order for
the Netopia Router to communicate with the physical connection.
Line Encoding...
Framing Mode...
Transmit ANSI PRMs:
Number of DS0 Channels:
First DS0 Channel:
Buildout (-dB)...
Channel Data Rate...
Clock Source...
Data Link Encapsulation...
Enter Information supplied to you by your telephone company.
1. Select Line Encoding and press Return. From the pop-up menu, highlight the encoding your telephone ser-
vice provider uses: B8ZS or AMI. The default setting is B8ZS. Press Return.
2. Select Framing Mode and press Return. From the pop-up menu, highlight either ESF or D4, depending on
the framing mode that your telephone service provider advises you to use. The default setting is ESF. Press
Return.
3. If you selected ESF framing mode, toggle Transmit ANSI PRMs either No (the default) or Yes. If you
selected D4 framing mode, this option is not available.
4. Select Number of DS0 Channels and enter the number of DS0 channels that you and your telephone
service provider have determined are necessary for your T1 line. The default setting for DS0 Channels is 1
(one). Press Return.
Note: Each DS0 channel represents a 56k or 64k increment in bandwidth. Selecting a number less than
the maximum of 24 specifies a fractional T1 interface.
T1 Line Configuration
B8ZS
ESF
No
1
1
0-0.6
Nx64k
Network
Frame Relay
"Configuring Frame Relay" on
