Next Rtr Addr.: Displays the DDP or IP address of the next hop for the specified route. A DDP address is
displayed if the router shown is on the local AppleTalk network. DDP address means that a connection to the
next-hop router is by a native AppleTalk network (e.g., LocalTalk or EtherTalk Phase II). An IP address is
displayed if the Netopia R5000 Series Router is connected to the router shown using AURP. IP address means
a connection transports over AURP (AppleTalk encapsulated IP).
Pkts Fwded: The number of packets sent to the router shown.
Each row in the AppleTalk routing table corresponds to an AppleTalk route or network range. If the list of routes
shown exceeds the size of the screen, you can scroll through it by using SCROLL UP and SCROLL DOWN.
To scroll up, select SCROLL UP at the top of the table and press Return. To scroll down, select SCROLL DOWN
at the bottom of the table and press Return.
You can view all of the IP addresses currently being served by the Netopia R5000 Series Router from the
Served IP Addresses screen.
From the Statistics & Logs menu, select Served IP Addresses. The Served IP Addresses screen appears.
-IP Address-------Type----Expires--Client Identifier--------------------------
----------------------------------SCROLL UP-----------------------------------
192.168.1.100
192.168.1.101
192.168.1.102
192.168.1.103
192.168.1.104
192.168.1.105
192.168.1.106
192.168.1.107
192.168.1.108
192.168.1.109
192.168.1.110
192.168.1.111
192.168.1.112
192.168.1.113
---------------------------------SCROLL DOWN----------------------------------
Lease Management...
EN = Ethernet Address; AT = AppleTalk Address; CP = Profile Name; HX = hex
To manage DHCP leases, select Lease Management in this screen.
Served IP Addresses
DHCP 00:36 EN: 00-00-c5-4a-1f-ea
DHCP 00:58 EN: 08-00-07-16-0c-85
