- Page 1 ® Intel Xeon™ Processor with 512 KB L2 Cache System Compatibility Guidelines Order Number: 298645-001 January 2002...
- Page 2 Revised information will be published when the product is available. Verify with your local sales office that you have the latest datasheet before finalizing a design. The Intel® Xeon™ processor may contain design defects or errors known as errata which may cause the product to deviate from published specifications. Current characterized errata are available on request.
-
Page 3: Table Of Contents
Intel® Xeon™ Processor with 512 KB L2 Cache System Compatibility Guidelines Table of Contents Revision History .................. 4 Introduction ..................5 1.1 Audience..................5 1.2 References ..................5 Compatibility ..................6 SM_VCC ..................... 6 603-Pin Socket Pin Definition Changes ..........6 Power Sequencing .............. -
Page 4: Revision History
Intel® Xeon™ Processor with 512 KB L2 Cache System Compatibility Guidelines Revision History Revision Date Changes -001 January 2002 Initial Release... -
Page 5: Introduction
The information in this document should be used in conjunction with specifications presented in the latest version of the Intel® Xeon™ Processor with 512 KB L2 Cache at 1.80 GHz, 2 GHz, and 2.20 GHz Datasheet and Intel® Xeon™ Processor at 1.40 GHz, 1.50 GHz, 1.70 GHz and 2 GHz Datasheet, as well as information provided in other... -
Page 6: Compatibility
SM_VCC SM_VCC must be connected to the system 3.3 volt power supply since the Intel® Xeon™ processor with 512 KB L2 cache drives the voltage identification (VID) outputs using core circuitry powered by the SM_VCC supply. -
Page 7: Vcc Power Sequencing
Intel® Xeon™ Processor with 512 KB L2 Cache System Compatibility Guidelines Table 1. 603-Pin Socket Pin-Map Change Old Name New Name Comment RSVD Processor Power RSVD Processor Ground RSVD Processor Power RSVD Processor Ground RSVD Processor Power RSVD Processor Ground... - Page 8 4.0, a 3.3 volt power supply must be connected to the Intel® Xeon™ processor with 512 KB L2 cache SM_VCC pins (AE28 & AE29). SM_VCC is the supply voltage used for the SMBus functions and for the VID output signal circuits. The VID signals are programmed by Intel during the manufacturing process so that the VRM output voltage will be set correctly.
- Page 9 Intel® Xeon™ Processor with 512 KB L2 Cache System Compatibility Guidelines PWRGOOD input to the processor. PWR_OK will be deasserted when any output of an ATX12V-compliant or SSI-compliant power supply falls below regulation limits. It is important to maintain SM_VCC at any time the output of the VRM is enabled. Driving the VRM’s OUTEN with the PWR_OK signal will ensure correct sequencing at both power up...
-
Page 10: Power And Signal Levels
Intel® Xeon™ Processor with 512 KB L2 Cache System Compatibility Guidelines Power and Signal Levels The VID for the Intel® Xeon™ processor with 512 KB L2 cache is 1.500 volts compared to a VID level of 1.700 volts for the Intel Xeon processor. The Intel Xeon processor with 512... - Page 11 Intel® Xeon™ Processor with 512 KB L2 Cache System Compatibility Guidelines Xeon processor with 512 KB L2 cache operates at its tested frequency at initial power-on. If the processor needs to run at a lower core frequency, as must be done when a higher speed processor is added to a system that contains a lower frequency processor, the system BIOS is able to effect the change in the core to system bus ratio.
