- Page 1 Hands-free presentation Imager Scanner M-10 This manual provides specifications for the Specifications Manual M-10 hands-free presentation imager scanner.
-
Page 2: Serial Number
OR USING THE PRODUCT. Serial Number A serial number appears on all Opticon products. This official registration number is directly related to the device purchased. Do not remove the serial number from your Opticon device. Removing the serial number voids the warranty. - Page 3 M-10 Specifications Manual Revision History Specification No. : SS13063 Product name : M-10 Edition Date Page Section Description of Changes 2014/05/26 Initial release...
-
Page 4: Table Of Contents
M-10 Specifications Manual Contents Page 1. Abstract ............................1 2. Overview ............................1 3. Basic Specifications ........................2 4. Detailed View ..........................5 5. State Transition ...........................6 5.1.State Transition ........................6 5.2.Current Consumption ......................6 6. Electrical Specifications ......................7 6.1.USB Power Supply.........................7 6.2.AC Adapter Specifications .....................7 6.2.1. - Page 5 M-10 Specifications Manual 10.4.Dust & Water Proof Grade ....................21 10.5.Cable Strength ........................21 10.6.Cable Bending Strength .....................21 10.7.Vibration Strength (without Packing)..................21 10.8.Vibration Strength (in individual packing)................21 10.9.Drop Impact Strength (without packing)................22 10.10.Drop Impact Strength (in individual packing) ..............22 10.11.Electrical Specifications ....................22 11.
-
Page 6: Abstract
This manual provides specifications for the M-10 hands-free presentation imager scanner. 2. Overview The M-10 is a hands-free imager scanner that enables high speed presentation scanning of standard linear (1D) and 2D symbologies. Main features of the M-10 are as follows: •... -
Page 7: Basic Specifications
M-10 Specifications Manual 3. Basic Specifications Item Specification Note 32-bit RISC SDRAM 256 M bits (2 M × 4 Banks × 32 Bits ) Flash ROM 16 M bits (1 M × 16 Bits) Flash Memory RS-232C 300 bps ~ 115200 bps Default :9600bps USB2.0 Full Speed 12 Mbps (HID/COM) - Page 8 M-10 Specifications Manual Item Specification Note PDF417, MicroPDF417, Codablock F, QR Disable Code 128 Code , Micro QR Code, DataMatrix (ECC 0 - Symbologies when Codablock F is 140 / ECC 200), MaxiCode, Aztec Code, enabled. Chinese Sensible Code PDF417 : 0.169 (6.7mil)
- Page 9 M-10 Specifications Manual Item Specification Note Peak Wavelength: LED safety IEC 62471-1:2006 Exempt Risk Group 624 nm For residential, EMI/RFI VCCI / EN55022 / FCC Class-B commercial and light- industrial environments Product safety CE Marking For residential, Electromagnetic compatibility EN55024 (EN61000-6-1) Class-B...
-
Page 10: Detailed View
M-10 Specifications Manual 4. Detailed View Figure 1: Detailed View of M-10 Name Description A window to which codes are presented. Scan Window A trigger switch to read codes for use as a handheld scanner 1. Press the trigger switch once, then a green single aiming line lights up. -
Page 11: State Transition
(USB-COM or RS-232C) are available. 5.2. Current Consumption USB :5V, T=25°C Item Conditions Min. Typ. Max. Unit Read current Standby current Configured Auto trigger sleep current (default: 1 min) Non-Operation current Configured Note: Refer to “M-10 User’s Manual” for supported operation and commands. -
Page 12: Electrical Specifications
Power ripple : 100 mV p-p ( max, rated load ) 7. Interface Specifications The M-10 supports four types of interfaces; USB-HID, USB-COM and RS-232C. 7.1. The USB interface models have two specifications: HID (Human Interface Device Class) and COM (Communication Device Class). -
Page 13: Usb Connector
M-10 Specifications Manual 7.1.2. USB Connector Pin No. Signal name V bus Data ( － ) Data ( ＋ ) Front view Figure 3: USB Plug (A) 7.1.3. USB Interface Circuit Figure 4: Interface Circuit (USB) 7.1.4. USB Interface Cable... -
Page 14: Rs-232C
M-10 Specifications Manual 7.2. RS-232C The RS-232C interface has a specification for connecting to the host: D-Sub9pin. 7.2.1. Communication setting Baud rate : 300 ~ 115200 bps Data length : 7 / 8 bits Parity bits : No / Even / Odd parity... -
Page 15: D-Sub9Pin Assignment
M-10 Specifications Manual 7.2.4. D-Sub9pin Assignment Figure 7: RS-232C D-Sub 9pin Circuit Connector : D-Sub 9pin, female Power supply : EIAJ RC5320A (voltage classification 2) jack 7.2.5. RS-232C Cable Figure 8: Cable (RS-232C D-Sub 9pin) -
Page 16: Optical Specifications
M-10 Specifications Manual 8. Optical Specifications 8.1. Basic Optical Specifications Item Characteristics Scan method CMOS area sensor Monochrome Effective pixels (Column) × (Row) 752 × 480 (WVGA) Image capture speed Frame rate (*1) 60 fps Focal distance Distance from the front edge of scanner... -
Page 17: Aiming Pattern
M-10 Specifications Manual 8.2. Aiming Pattern The aiming is used for the following purpose: 1. Light source to indicate the appropriate reading range 2. Light source for auto trigger operation The aiming specifications are as follows: - An optical axis of imaging field of view and the center of horizontal aiming width coincide at a distance of L=50±20 mm from the front edge of the scanner. -
Page 18: Technical Specifications
M-10 Specifications Manual 9. Technical Specifications Code reading is performed by positioning the aiming light over the center of a code. The conditions for technical specifications are as follows, unless otherwise specified in each section. <Conditions> Temperature and humidity : Room temperature and room humidity... -
Page 19: Code Test Sample
M-10 Specifications Manual 9.1. Code Test Sample 1 D Barcodes <Code 39> Resolution Symbology Size (mm) No. of Digits 0.127 mm (5mil) 32 × 10 0.20 mm (7.9mil) Code 39 100 × 10 0.254 mm (10mil) 32.5 × 10 <Code 128>... -
Page 20: Scanning Area And Depth Of Field
M-10 Specifications Manual 9.2. Scanning Area and Depth of Field [ Unit ： mm ] 0.127(5mil) Code 39 0.254(10mil) 0.20(7.9mil) Code 128 0.33(13mil) 100% UPC/EAN 0.169(6.7mil) PDF417 0.254(10mil) 0.212(8.4mil) QR Code 0.381(15mil) 0.254(10mil) Data Matrix Figure 10: Scanning Area and Depth of Field... -
Page 21: Print Contrast Signal (Pcs)
M-10 Specifications Manual 9.3. Print Contrast Signal (PCS) PSC 0.3 or higher <Conditions> : 32% and higher (70% or higher reflectivity of white bar and quiet zone) Distance : 60 mm from the front edge of the scanner Barcode : 0.33mm PCS: 0.3 UPC/EAN specified in Section 9.1. -
Page 22: Pitch, Skew, And Tilt
M-10 Specifications Manual 9.6. Pitch, Skew, and Tilt Pitch : α = ± 50° Skew : β = ± 50° Tilt : γ = 360° <Conditions> Barcode : 0.33 mm UPC/EAN specified in Section 9.1 Distance : 65 mm from the front edge of the Scanner Curvature : R = ∞... -
Page 23: Scanning From Lcd Screen
M-10 Specifications Manual 9.8. Scanning from LCD Screen Codes displayed on LCD screens (brightness of white part 30 cd/m2 or more, contrast ratio 100:1) can be read. <Conditions> Code : Code for 0.381 mm QR Code specified in Section 9.1... -
Page 24: Auto Trigger
M-10 Specifications Manual 9.9. Auto Trigger The scanner starts scanning automatically when it detects a change in brightness that occurs when a barcode label is presented in front of it. The scanner should be triggered when a gray-colored paper is presented in front of a black-colored background paper.The scanner should also be triggered when a black-colored paper is presented in... -
Page 25: Environmental Specifications
: α = 0°, β =＋15°, γ = 0° Figure 17: Ambient Light Immunity Note: Scanning performance is guaranteed as far as the direct ambient light or specular reflection from the illumination LED does not enter the light receiving section of the M-10. -
Page 26: Dust & Water Proof Grade
M-10 Specifications Manual 10.4. Dust & Water Proof Grade IEC/EN 60529 Protection Level : IP52 10.5. Cable Strength There shall be no sign of malfunction after the following cable strength test. Cable Strength Test: Affix the scanner to an immovable object and pull it using a force of 24.5 N (2.5 kgf static loading) for 1 second. -
Page 27: Drop Impact Strength (Without Packing)
M-10 Specifications Manual 10.9. Drop Impact Strength (without packing) Drop height : 1.5m There shall be no sign of malfunction after the following drop test. Drop test: Drop the scanner three times (15 times in total), at each 5 face, from a height of 1.5m onto a concrete floor as shown below. -
Page 28: Regulatory Compliance
MTBF (Mean Time Between Failures) 50,000 hours Note: The reliability of the M-10 is guaranteed as far as it is operated under normal operating conditions in the range of advised operating temperature and without excessive electrical or mechanical shock. 14. Precautions Handle this product carefully. -
Page 29: Product Label
M-10 Specifications Manual 15. Product Label The product label is affixed to the scanner as shown below. Figure 20: Product Label Position Figure 21: Enlarged View of Label... -
Page 30: Packing Specifications
16.1. Individual Packaging 16.1.1. USB Type Approx. 245 mm ( W ) × 110 mm ( D ) × 84 mm ( H ) ( External dimensions ) The M-10 without cable Protection bag QUICK START GUIDE(ENG) Put a USB cable on the top of the bag... -
Page 31: Rs-232C Type
Specifications Manual 16.1.2. RS-232C Type Approx. 245 mm ( W ) × 110 mm ( D ) × 84 mm ( H ) ( External dimensions ) The M-10 without cable Protection bag QUICK START GUIDE(ENG) Put a RS-232C cable on the top of the bag... -
Page 32: Collective Packaging
M-10 Specifications Manual 16.2. Collective Packaging Approx. 600 mm ( W ) × 525 mm ( D ) × 290 mm ( H ) ( External dimensions ) 30sets Individual packaging box Order of 列 S /Nの 順 序 ①... -
Page 33: Physical Features
M-10 Specifications Manual 17. Physical Features 17.1. Dimensions Approx. 76 mm ( W ) × 70 mm ( D ) × 139.5 mm ( H ) Figure 25: Mechanical Drawing 17.2. Weight Approx. 250 g (excluding the cable) 17.3. Tilt Angle of Stand Forward : 60°... -
Page 34: Mounting Method
M-10 Specifications Manual 17.4. Mounting Method 1. Install the mounting screws. Insert the specified size of screws into the screw holes in the bottom the scanner and tighten them to fix the scanner in your desired location. Figure 27: Screw Mounting Position 2. -
Page 35: Default Setting
M-10 Specifications Manual 18. Default Setting 18.1. Default Setting Menu Code The M-10 is set to default settings by reading the following menu label regardless of the interface types. Default @MENU_OPTO@ZZ@BAP@ZZ@OTPO_UNEM@ 18.2. Supported Symbologies 18.2.1. 1D Barcodes Read Minimum Code type... -
Page 36: Gs1 Databar, Composite Code
M-10 Specifications Manual 18.2.3. GS1 Databar, Composite Code Read Code type Remarks setting GS1 DataBar ・GS1 DataBar Omnidirectional ・GS1 DataBar Truncated ○ ・GS1 DataBar Stacked ・GS1 DataBar Stacked Omnidirectional GS1 conversion (setting required) GS1 DataBar Limited ○ GS1 DataBar Expanded ・GS1 DataBar Expanded... -
Page 37: Other Default
Power supply 500 mA Vender ID 065A Product ID A002 Standards CDC-ACM * It is necessary to install Opticon USB Driver to a host. 18.6. RS-232C Default Item Default Setting Baud rate 9600 bps Parity bits No parity Data length... -
Page 38: Accessories
Specifications Manual 19. Accessories 19.1. AC Adapter Specifications The M-10 with RS-232C interfaces are shipped with a dedicated AC adapter “Universal AC Adapter Kit.” Plug connectors can be changed for each region. Refer to 19.2 for the detailed view. Item...
