Opticon OPN-2001 Quick Start Manual

Hide thumbs Also See for OPN-2001:

Advertisement

Table of Contents

See also: User Manual
OPN-2001
1 Quick Start for the OPN-2001
1.1 PC
1.1.1 Initial Setup
1.1.2 Scan Barcodes
1.1.3 Download From the OPN-2001
1.2 Mac
1.3 APIs
2 OPN2001-2003 comparison
2.1 Setting the time on the OPN2001
2.1.1 Using the OPN Companion Application
2.1.2 Without companion app
2.2 FAQ
3 Factory Reset
4 Firmware
4.1 Loading Firmware
5 USB-HID
5.1 How to Configure the OPN2001 in HID Mode
5.2 How to Switch between HID Mode and Classic Mode
5.3 About Keyboard Mode
5.3.1 Other Features
6 Development
6.1 SDK for OPN200x Host Applications
7 OS Change Log
8 Downloads
8.1 Documents
8.2 Software
8.3 Drivers
Quick Start for the OPN-2001
Follow the instructions below to get started with the OPN-2001 on your platform.
PC
Using the OPN-2001 with a Windows PC requires you to download and install Opticon's PC USB
Drivers Installer, and an application to retrieve the data like the PC Companion Application. Both of
1 sur 13
OPN2001
18/04/2018 à 15:13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OPN-2001 and is the answer not in the manual?

Questions and answers

Related Manuals for Opticon OPN-2001

Summary of Contents for Opticon OPN-2001

  • Page 1 Follow the instructions below to get started with the OPN-2001 on your platform. Using the OPN-2001 with a Windows PC requires you to download and install Opticon's PC USB Drivers Installer, and an application to retrieve the data like the PC Companion Application. Both of 1 sur 13 18/04/2018 à...

  • Page 2: Initial Setup

    "trigger" will store barcodes, while scanning with the small button or "function" will remove barcodes. Below are some tips about scanning and removing barcodes from the device. When the OPN-2001 has a good scan, it will chime, the LED on the device will flash green, and the laser will turn off.
  • Page 3 Click "Delete barcodes" to erase the barcodes stored on the OPN-2001. In order to set up the OPN-2001 on the Mac, we will need to install the Mac Companion Application and configure the OPN-2001 to connect to the Mac. To install the Mac Companion Application, download the "OPN-2001 MAC Companion Application"...
  • Page 4 Once running Appload, select Settings > Port > Opticon Code Reader (1D) (COMX). Then choose Utilities > Send time. The time on your OPN2001 will be set to the time of your computer. My OPN-2001 has suddenly stopped beeping when I scan barcodes. Is it broken? 4 sur 13 18/04/2018 à 15:13...

  • Page 5: Factory Reset

    Factory Reset To factory reset the OPN-2001 please follow the below instructions. Ensure the OPN-2001 has sufficient charge (at the least the laser should come on with a trigger press when the unit is unplugged) Disconnect the OPN-2001 from any USB connections Press and hold both buttons (scan and clear) for 10 seconds At the end of the time you will hear a single tone indicating successful reset.

  • Page 6: Loading Firmware

    The main OS functions as a batch mode scanner and requires the use of the Companion Application. The OS also supports the function of the USB-HID (keyboard) mode. Loading Firmware The Firmware of the OPN-2001 can be upgraded (or reloaded in the case of a corrupt firmware) with the following instructions. Download and install the...

  • Page 7: Other Features

    Enable or Disable barcode for either option, then the END barcode. These options are disabled by default. By default, the OPN-2001 transmits an "Enter" key press after every barcode. To change this to a tab, or to change back to return, print this barcode sheet and scan SET, then the "Suffix for All...
  • Page 8 RBBV0140: Fixed a potential crash bug when syncing time with a PC, Added support of 'Send Time' command in Appload (for production purposes) Downloads Notice: The downloading and use of any Opticon software implies consent with Opticon's End User License Agreement.
  • Page 9 OPN-2001 User Manual A more detailed Download usage manual for the OPN-2001 Settings for HID Firmware (Alternate A page of Download custom settings barcodes exclusive to the alternate firmware RBB3640x Specification Manual A more detailed Download...
  • Page 10 HID modes on the OPN2001 Alternate OS. Software Software Description Version Download Appload Appload EAGV0170 Download Opticon's multi- purpose firmware update utility. It is a Windows PC application that provides the capability to download firmware onto most Opticon products. It...
  • Page 11 OPN-2001. This requires the OPN2001 Companion Application to download the data file. It also will operate as a USB-HID (keyboard) batch or real- time scanner. When disconnected it will store barcodes (dual tone beep) and then when the unit is plugged into the USB cable &...
  • Page 12 PC companion application this software is a free application provided by Opticon in order to get some out of the functionality with your OPN-2001 on a Macintosh computer running macOS. OPN SDK This SDK is Version 12 Download used to...
  • Page 13 USB-VCP mode when connected directly to a PC. The second driver is for Opticon's cradles and a few other products. The third and final is an ATEN driver for a popular RS232 <-> USB-VCP adapter. You...
