SPECIFICATIONS MANUAL
F-100 SR
Fixed Position 1D Linear Imager Scanner (80mm width model)
This manual provides specifications for
the F-100 SR fixed position 1D scanner.
1st

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F-100 SR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Opticon F-100 SR

  • Page 1 SPECIFICATIONS MANUAL F-100 SR Fixed Position 1D Linear Imager Scanner (80mm width model) This manual provides specifications for the F-100 SR fixed position 1D scanner.
  • Page 2 Please read this manual carefully before installing or using the product. Serial Number A serial number appears on all Opticon products. This official registration number is directly related to the device purchased. Do not remove the serial number from your Opticon device. Removing the serial number voids the warranty.
  • Page 3 SPECIFICATIONS MANUAL F-100 SR Revision History Product Name : F-100 SR Edition Date Page Section Description of Changes First 2018/02/21...
  • Page 4: Table Of Contents

    SPECIFICATIONS MANUAL F-100 SR Contents Abstract ........................1 Overview ........................1 Model details ........................ 2 Standard ........................... 2 Model Description ........................2 Basic Specifications ....................3 Detailed View ........................ 5 Detailed View ........................... 5 LED Indicator Specifications ....................6 Electrical Specifications ....................7 RS-232C Specification ......................
  • Page 5 SPECIFICATIONS MANUAL F-100 SR 9.3.1 USB Interface Specifications ..................18 9.3.2 USB Connector ....................... 18 9.3.3 USB Interface Circuit ...................... 19 9.3.4 USB Interface Cable ....................... 19 Environmental Specifications ................... 20 10.1 Temperature ........................... 20 10.2 Humidity ..........................20 10.3 Ambient Light Immunity ......................
  • Page 6 19.2 Mechanical Drawing / Dimensions ..................34 Table of Figures Figure 1: Detailed View of F-100 SR ....................... 5 Figure 2: Reading distance ........................8 Figure 3: Optical axis and Dead zone ..................... 8 Figure 4: Scan area and resolution ....................... 10 Figure 5: Barcode width .........................
  • Page 7: Abstract

    80mm wide barcodes. Overview The F-100 SR is a small size fixed position 1D linear imager scanner that allows for high speed reading of up to 80mm wide barcodes at a distance of 35mm. Its main features are as follows: ...
  • Page 8: Model Details

    SPECIFICATIONS MANUAL F-100 SR Model details The F-100 model name is constructed by a combination of following. Model Optional Focus Interface Cable length name AC Adapter None -RS232C -USB-COM F-100 None -USB None -RS232C(9P) -RS232C(LE) Standard The following specs are the standard products.
  • Page 9: Basic Specifications

    SPECIFICATIONS MANUAL F-100 SR Basic Specifications Item Specification Note RS-232C 150 to 115,200 bps Default: 9600 bps Full Speed 12 Mbps (HID/COM) Upper panel 3 colors LED Status LED (Green, Orange, Red) Buzzer Rumble at 3000Hz when reading success Linear Sensor Technology...
  • Page 10 SPECIFICATIONS MANUAL F-100 SR Item Specification Note Operating 0 to 40°C Temperature Storage -10 to 60°C Operating 20 to 85% (No condensing, no frost) Humidity Storage 20 to 90% (No condensing, no frost) Fluorescent light EAN/JAN 0.26mm Incandescent 5,000 lx or less Ambient light Optical axis angle 75°...
  • Page 11: Detailed View

    Detailed View Detailed View ② ① ③ ④ Figure 1: Detailed View of F-100 SR Name Description By pressing this key, the scanner starts reading barcodes. Scan key Pressing for more than 5seconds, the scanner shifts to read rate mode.
  • Page 12: Led Indicator Specifications

    SPECIFICATIONS MANUAL F-100 SR LED Indicator Specifications The status LED’s indicate the reading result and USB communication status. In read rate mode, the reading success rate is indicated by these three 3-color LED’s. Below is a more in-deapth description on these LED’s.
  • Page 13: Electrical Specifications

    SPECIFICATIONS MANUAL F-100 SR Electrical Specifications The F-100 consists out of an ‘Imager Section’, a decoder section that decodes the signal coming from the imager section, a ‘Communication Control Section’ that takes care of the communication with a host and finally a ‘Power Supply Section’ that generates the power supply voltages for the entire scanner.
  • Page 14: Optical Specifications

    SPECIFICATIONS MANUAL F-100 SR Optical Specifications Basic Optical Specifications Item Characteristics Scanning Technology Linear imager sensor Number of effective pixels Line sensor 2496 x 1 pixels Image capture speed ( Scan speed 700±10% scan/s Focal distance Distance from the front edge of scanner...
  • Page 15: Technical Specifications

    SPECIFICATIONS MANUAL F-100 SR Technical Specifications The conditions for technical specifications are as follows, unless otherwise specified in each section. Conditions Ambient Temperature and Humidity Room temperature, room humidity Ambient Light 500 to 1500 lux α = 0°, β = +15°, γ = 0° (refer to figure 6) Angles R = ∞...
  • Page 16: Scan Area

    SPECIFICATIONS MANUAL F-100 SR Scan Area The scan area is measured from the front edge of the scanner. Resolution: 0.125 - Resolution: 0.19 - [Unit: mm] Figure 4: Scan area and resolution When the barcode print quality or the conditions stated at the beginning of section 8 are not satisfied, the above reading range may not be reached.
  • Page 17: Printed Contrast Signal (Pcs)

    SPECIFICATIONS MANUAL F-100 SR Printed Contrast Signal (PCS) PCS 0.45 or higher Conditions ≥ ≥ 32% ( 80% reflectivity of space and quiet zone) Distance 35 mm from the front edge of the scanner Barcode width Maximum 60mm Barcode Code 39. Resolution = 0.19mm / PCS 0.45, specified in Section 8.1.
  • Page 18: Pitch, Skew And Tilt

    SPECIFICATIONS MANUAL F-100 SR Pitch, Skew and Tilt α = ±6° Pitch -30° ≤ β ≤ -10°, 10° ≤ β ≤ 30° Skew γ = ±10° Tilt Conditions Barcode Code 39. Resolution = 0.19mm / PCS 0.9, specified in Section 8.1.
  • Page 19: Motion Tolerance

    SPECIFICATIONS MANUAL F-100 SR Motion Tolerance When scanning barcodes that are moving vertically as shown in figure 8, the scanner usually has almost the same performance as when it is reading non moving barcodes. The scanning performance is only reduced when a barcode is moved at very high speed or when the height of the barcode is very small.
  • Page 20: Interface Specification

    SPECIFICATIONS MANUAL F-100 SR Interface Specification The F-100 SR interface is RS-232C (D-sub 9pin), RS-232C (Loose end) or USB (COM/HID). RS-232C Interface (D-Sub 9pin) 9.1.1 Initial Communication Settings Basic communication specs are as follows. Item Communication spec Default setting Baud rate...
  • Page 21: Rs-232C D-Sub 9Pin Circuit

    SPECIFICATIONS MANUAL F-100 SR 9.1.4 RS-232C D-Sub 9pin Circuit External device F-100 Barcode reader main S-GND circuit F-GND DC JACK Figure 11: Interface Circuit (RS-232C D-sub 9pin) 9.1.5 RS-232C D-Sub 9pin Interface Cable Cable length 2000 mm Wire conductors diameter AWG28 φ3.8mm...
  • Page 22: Rs-232C Interface (Loose End)

    SPECIFICATIONS MANUAL F-100 SR RS-232C Interface (Loose End) 9.2.1 Initial Communication Settings Basic communication specs are as follows. Item Communication spec Default setting Baud rate 150 to 115200 bps 9600 bps Data length 7 / 8 bits 8 bits Parity bits...
  • Page 23: Rs-232C Loose End Circuit

    SPECIFICATIONS MANUAL F-100 SR 9.2.4 RS-232C Loose End Circuit External device F-100 DC 5V OK / NG Maximum DC 24V load Barcode reader main circuit Trigger Trigger S-GND F-GND Figure 13: Interface Circuit (RS-232C Loose End) 9.2.5 RS-232C Loose End Interface Cable...
  • Page 24: Usb Interface

    Note: For the USB-COM interface model, the Opticon USB-COM driver must be installed on your host device. Please use the latest of the USB-COM version driver.
  • Page 25: Usb Interface Circuit

    SPECIFICATIONS MANUAL F-100 SR 9.3.3 USB Interface Circuit +3.3V USB A Connector Pin No. Signal VBUS Full Speed Shell Transceiver Buffers Figure 16: Interface Circuit (USB) 9.3.4 USB Interface Cable Cable length 2000 mm φ3.8mm Cable diameter Weight Approx. 60g 2000 ±...
  • Page 26: Environmental Specifications

    SPECIFICATIONS MANUAL F-100 SR Environmental Specifications 10.1 Temperature Scanning performance is guaranteed when the ambient temperature is within the following ranges: Operating Temperature 0 to 40 °C Storage Temperature -10 to 60 °C Conditions Barcode EAN/JAN-13 Resolution = 0.26 mm / PCS 0.9, specified in chapter 8.1...
  • Page 27: Ambient Light Immunity

    SPECIFICATIONS MANUAL F-100 SR 10.3 Ambient Light Immunity Scanning performance is guaranteed when the illumination on a barcode surface is between zero and the following values: Incandescent light 5,000 lx Fluorescent light 5,000 lx Sunlight 10,000 lx Conditions Barcode EAN/JAN-13 Resolution 0.26 mm / PCS 0.9 specified in chapter 8.1...
  • Page 28: Scan Key Durability

    SPECIFICATIONS MANUAL F-100 SR 10.5 Scan Key Durability Activating the scanner by pressing the trigger shall be possible after the following scan key strength test. Scan Key Strength Test: Affix the scanner as shown in the following picture. Press and release the scan key by a push rod with a diameter of 10mm with a force of 9.8N (1kgf) and repeat this 5 million...
  • Page 29: Vibration Strength (Without Packing)

    SPECIFICATIONS MANUAL F-100 SR 10.8 Vibration Strength (without packing) There shall be no malfunction after the following vibration test. Vibration test: Increase the frequency of the vibration from 10Hz to 100Hz at an acceleration velocity of 19.6m/s (2.0 G) for 30 minutes in the non-operating state. Repeat this twice for each of X, Y and Z direction.
  • Page 30: Regulatory Compliance

    SPECIFICATIONS MANUAL F-100 SR Regulatory Compliance 11.1 LED Safety IEC 62471:2006 Exempt Risk Group 11.2 Product Safety UL 60950-1, 2nd Edition, 2014-10-14 CAN/CSA C22.2 No. 60950-1-07, 2nd Edition, 2014-10 IEC 60950-1:2005 +A1:2009 +A2:2013 EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011 +A2:2013 11.3...
  • Page 31: Precautions

    ・ Do not plug/unplug the connectors while power is supplied. ・ Do not disassemble this product. ・ This product may be affected by a momentary voltage fluctuation caused by lightning. ・ Do not wrap F-100 SR cable around a host device (PC, tablet etc.). This may cause malfunction.
  • Page 32: Product Display

    SPECIFICATIONS MANUAL F-100 SR Product Display 15.1 Product Label Example of label attached to the scanner is shown below. Serial number is 6 digits from 000001. Refer 17.3 (Mechanical Drawing) for the allocation. Figure 22: Product Label 15.2 UL Label Example of UL label attached to the scanner is shown below.
  • Page 33: Packaging Specifications

    SPECIFICATIONS MANUAL F-100 SR Packaging Specifications 16.1 Individual Packaging Specification (RS-232C) Package size Approx. 122 x 112 x 38 (WDH mm) Weight Approx. 105 g (RS-232C model) Twist ties Mirror mat * Short side down. Place the bundled cable under the mirror mat.
  • Page 34: Individual Packaging Specification (Usb)

    SPECIFICATIONS MANUAL F-100 SR 16.2 Individual Packaging Specification (USB) Package size Approx. 122 x 112 x 38 (WDH mm) Weight Approx. 110 g (USB model) Twist ties Mirror mat * Short side down. Place the bundled cable under the mirror mat.
  • Page 35: Collective Packaging Specification

    SPECIFICATIONS MANUAL F-100 SR 16.3 Collective Packaging Specification Assembled package size Approx. 588 × 514 × 285 (WDH mm) Weight Approx. 14 kg (RS-232C model) Approx. 12.5 kg (USB model) ⑯ ⑰ ⑪ ⑱ ⑫ ⑥ ⑲ ⑬ ⑦ ①...
  • Page 36: Physical Features

    SPECIFICATIONS MANUAL F-100 SR Physical Features 17.1 Dimensions Approx. 45.5 (W) ×20.25 (D) ×19 (H) (mm, except protruding portion) 17.2 Weight Approx. 15 g (excluding cable) 17.3 Mechanical Drawing Scan key Status LED (45.5) Imaging lens Scan window Illumination LED lens...
  • Page 37: Factory Setting

    SPECIFICATIONS MANUAL F-100 SR Factory Setting 18.1 Default Setting (Part 1: Readable Codes) Minimum Transmit Calculate Transmit Code type Read Prefix Suffix digits other    UPC-A    UPC-A Add-on    UPC-E   ...
  • Page 38: Default Setting (Part 2: Read Options, Illumination Led, Trigger, Buzzer)

    SPECIFICATIONS MANUAL F-100 SR 18.2 Default Setting (Part 2: Read Options, Illumination LED, Trigger, Buzzer) Item Default Setting the number of characters Fixed length OFF all codes Read mode Single read Multiple read reset time 500 msec Add-on wait mode...
  • Page 39: Default Setting (Part 3: Communication Settings)

    Send “TAB key “after data Disable Send “→ key “after data Disable Other CDC-ACM compliant (USB-COM)* * The Opticon USB-COM driver must be installed on your host to use in USB-COM. Please contact sales offices for the manual and setting tools.
  • Page 40: Optional Ac Adapter

    SPECIFICATIONS MANUAL F-100 SR Optional AC Adapter 19.1 Electrical Specifications Rated output voltage 5.0V Rated output current 2.0A 19.2 Mechanical Drawing / Dimensions 1800 45 69.0 1 [Unit: mm] Figure 28: AC adapter Mechanical Drawing EIAJ Voltage type2 (EIAJ#2) [Unit: mm]...
