Page 1 C.T.M. MOBILITY SCOOTER C.T.M. MOBILITY SCOOTER C.T.M. MOBILITY SCOOTER HS-295E Instruction Booklet...
Page 2: Table Of Contents
HS-295E Instruction Booklet TABLE OF CONTENTS INTRODUCTION --------------------------------------------------------1 IMPORTANT PRECAUTIONS -----------------------------------------2 SAFETY INFORMATION ON ELECTROMAGNETIC ------------------------------------------------3 INTERFERENCE (EMI) -----------------------------------------6 IDENTIFICATION OF PARTS --------------------------------------9 OPERATING YOUR SCOOTER ------------------------------12 DISASSEMBLING YOUR SCOOTER ------------------------------14 RE-ASSEMBLING YOUR SCOOTER ---------------------------------------15 CHARGING THE BATTERIES -----------------------------------------17 CARE AND MAINTENANCE...
Page 3: Introduction
HS-295E Instruction Booklet INTRODUCTION Thank you and congratulations on purchasing your new C.T.M. Mobility Scooter. It is designed to provide you with transportation ability indoors and outdoors. We pride ourselves on providing safe and comfortable products. Our goal is to ensure your complete satisfaction with our product.
Page 4: Important Precautions
HS-295E Instruction Booklet IMPORTANT PRECAUTIONS •Only one person at a time could ride a C.T.M. Mobility Scooter. •Maximum load is 115 kg / 250 lbs. •Turn key off before getting on or off your scooter. •Always drive carefully with your feet on the scooter and be aware of others in your area.
Page 5: Safety Information On Electromagnetic Interference (Emi)
HS-295E Instruction Booklet SAFETY INFORMATION ON ELECTROMAGNETIC INTERFERENCE ( EMI ) CAUTION: It is very important that you read this information regarding the possible effects of Electromagnetic Interference on your motorized scooter. Powered wheelchairs and motorized scooters may be susceptible to electromagnetic...
Page 6 HS-295E Instruction Booklet 3.Long-range transmitters and transceivers such as commercial broadcast transmitters (radio and TV broadcast antenna towers) and amateur (HAM) radios. Other types of hand-held devices, such as cordless phones, laptop computers, AM/FM radios, TV sets, CD players, and cassette players,...
Page 7 HS-295E Instruction Booklet 4.Be aware that adding accessories or components, or modifying the motorized scooter, may make it more susceptible to EMI; and There is no easy way to evaluate their effect on the overall immunity of the motorized scooter.
Page 8: Identification Of Parts
Figure 1 - HS-295E Front View Self-Diagnostic Warning Light Battery Gauge Horn Button Free-Wheeling Release Lever Lever Speed Dial Knob Thumb Lever Main Key Switch Anti-Tip Wheels Figure 2 - HS-295E Top Control Panel Figure 3 - HS-295E Back View...
Page 9 HS-295E Instruction Booklet Function Of Parts： TOP CONTROL PANEL •Speed Dial Knob The image of rabbit means fast or high speed. The image of turtle means slow or low speed. By turning this knob towards chosen image you can control overall speed of the vehicle.
Page 10 HS-295E Instruction Booklet •Armrest Width Adjustment Thumbscrews Loosen two thumbscrews to adjust arm width; tighten again to lock in desired position. REAR BODY •Anti-Tip Wheels Added safety feature to keep scooter from tipping over. •Free-Wheeling Lever To push scooter for short distances, put it in freewheel mode by pushing forward on free-wheeling lever to N disable drive system and brake system.
Page 11: Operating Your Scooter
HS-295E Instruction Booklet OPERATING YOUR SCOOTER Before beginning your journey with your new scooter, make sure that scooter is on a level surface and clear of any obstacle. Although your scooter is able to climb slope, it is safer to practice on a level surface.
Page 12 HS-295E Instruction Booklet Keep in mind these rules： •Release thumb lever and allow scooter to stop completely before changing from forward to reverse, or reverse to forward. •When turning to a corner, swing the front wheels widely, so the back wheels will turn more tightly.
Page 13 HS-295E Instruction Booklet Do not attempt climb an incline grade of over 8 degrees： Attempting to turn scooter on a slope is not recommended, but if this is necessary turn scooter speed down to its minimum (turtle position) before proceeding.
Page 14: Disassembling Your Scooter
HS-295E Instruction Booklet DISASSEMBLING YOUR SCOOTER Extreme care must be taken when assembling or disassembling scooter. Please take care near any moving parts and or between opening and closing parts. Taking apart your scooter enables you to save space when keeping it in storage or to carry it along in your vehicle when going away from home.
Page 15 HS-295E Instruction Booklet Remove Front Basket (G) by lifting.(See Fig. 8) Rotate Hand Wheel Tiller Angle Adjustment (H) clockwise to adjust tiller down. Rotate Wheel counterclockwise to lock tiller.(See Fig. 9) Figure 8 Figure 8 Figure 9 Figure 9 Pictured are 5 main parts after disassembling scooter. These parts consist of Front and Rear Sections, Seat, Basket, and Battery pack.(See Fig.
Page 16: Re-Assembling Your Scooter
HS-295E Instruction Booklet RE-ASSEMBLING YOUR SCOOTER To assemble scooter, you can repeat disassembly directions in reverse. Abbreviated directions are given below. Refer to Figures on pages 12 - 13 to locate the parts. 1.Rotate Hand Wheel Tiller Angle Adjustment clockwise to adjust tiller and counterclockwise to lock tiller into its upright position.
Page 17: Charging The Batteries
HS-295E Instruction Booklet CHARGING THE BATTERIES Your C.T.M. scooter is equipped with two sealed, maintanence free 12V. 12Ah. rechargeable batteries and one 24V/2A charger. Batteries must be charged before using scooter for first time and should be recharged after each day's use. Be sure power switch is in OFF position and free-wheeling lever is not in freewheel mode.
Page 18 HS-295E Instruction Booklet You can also charge your batteries on & off the scooter： 1. Switch your scooter off at tiller main switch. 2. Remove battery pack from scooter. 3. Please refer to above charging procedure for following actions. Figure 13 Figure 13 Keep in mind these rules：...
Page 19: Care And Maintenance
HS-295E Instruction Booklet CARE AND MAINTENANCE Taking care of your scooter will keep it in top-notch condition. It is recommended that you discuss with local authorized dealer for a preventative maintenance schedule scooter. Here are few maintenance guidelines： BODY COVER: if your scooter is dirty, use a damp or lightly soapy cloth to wipe it down.
Page 20: Troubleshooting
HS-295E Instruction Booklet TROUBLESHOOTING Flash Description Meaning The batteries are running low. Battery Low •Recharge the batteries The batteries have run out of charge Low Battery Fault •Recharge the batteries Battery voltage is too high. This may occur if overcharged &/or traveling down a long slope.
Page 21 HS-295E Instruction Booklet Other Problems： •The scooter will not move when the key is turned on: 1.Check battery gauge on control panel. Battery gauge should be in green area. 2.Check the Self-Diagnostic Warning Light. It should be steady. If it is flashing, see chart on page 18 for problem identification.
Page 22: Technical Specifications
HS-295E Instruction Booklet SPECIFICATION Overall Length 990 mm / 39" Overall Width 505 mm / 19.9" Overall Height 870 mm / 34.3" Wheels: Front 190 mm / 8" Wheels: Rear 190 mm / 8" Weight w/ Batteries 47.76 kg / 103 Ibs Max.
