Luxul AMS-1208P Quick Install Manual

Hide thumbs Also See for AMS-1208P:
Table of Contents

Advertisement

Quick Links

Quick Install Guide

AV Series 12-Port/8 PoE+
Gigabit Managed Switch
Use the AMS-1208P to:
Use the AMS-1208P to:
Seamlessly Integrate with
„
AV Rack Systems
Connect up to 8 PoE-Enabled
„
Devices (Max Output 130 Watts)
Optimize Your Network with VLAN,
„
QoS and PoE Management
Enhance Network Performance with
„
Layer 3 Static Routing
Simply Plug and Play
„
Simply Connected
AMS-1208P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMS-1208P and is the answer not in the manual?

Questions and answers

Related Manuals for Luxul AMS-1208P

Summary of Contents for Luxul AMS-1208P

  • Page 1: Quick Install Guide

    Simply Connected Quick Install Guide AMS-1208P AV Series 12-Port/8 PoE+ Gigabit Managed Switch Use the AMS-1208P to: Use the AMS-1208P to: Seamlessly Integrate with „ AV Rack Systems Connect up to 8 PoE-Enabled „ Devices (Max Output 130 Watts) Optimize Your Network with VLAN, „...

  • Page 2: Document Conventions

    No part of this publication may be modified or adapted in any way, for any purposes without permission in writing from Luxul. The material in this manual is subject to change without notice. Luxul reserves the right to make changes to any product to improve reliability, function, or design. No license is granted, either expressly or by implication or otherwise under any Luxul intellectual property rights.

  • Page 3: Package Contents

    AMS-1208P Front Panel View Rear Panel The rear panel of the AMS-1208P Switch includes 1 console port, 10 Gigabit RJ45 ports and 2 Gigabit SFP ports, as well as LED indicators for each port. Each port has one Link/Activity/PoE LED. A mode/reset button switches the display between Link/Activity and PoE modes.

  • Page 4: Led Indicators

    10/100Mbps device connected to the port. Flashing The Link/Activity LED flashes when a port is receiving or transmitting data. There is nothing connected to the port. 14203 Minuteman Drive, Suite 201, Draper, UT 84020-1685 | luxul.com | 801-822-5450 LUX-QIG-AMS-1208P 1224140959...

  • Page 5: Preparing For Installation

    Verify the ground connection of the outlet is functioning properly. „ Check the power cord to confirm a secure connection. „ When installing the AMS-1208P on a flat surface, attach the rubber feet to the „ bottom of the device to avoid scratching the surface. AMS-1208P INSTALLATION Installing the AMS-1208P in a Rack The AMS-1208P can easily be installed in a standard 19”...

  • Page 6: Desktop Setup

    AMS-1208P to an Ethernet enabled device (including servers, routers, and other switches) without a crossover cable. The AMS-1208P offers 2 Gigabit RJ-45 and 2 Gigabit SFP ports for expansion. This allows for the use of standard Ethernet cable or Gigabit optical fi ber for network expansion.

  • Page 7: Default Ip Address

    1208P and a router. Otherwise, loops can occur and result in network failure. Default IP Address The AMS-1208P default IP address is 192.168.0.3. This address can be changed. However, for hassle free installation of other plug and play Luxul devices, it is recommended that the default IP value be maintained. Login The AMS-1208P is not equipped with internal DHCP server.

  • Page 8: Warnings And Safety Information

    „ exposure to excessive heat or moisture. The AMS-1208P may become warm when in use for extended time periods. This is normal and is not a „ malfunction. DO NOT install where it will be exposed to paper, cloth or other flammable materials.
