Precautions:
The Reflexion portable floor pull-up projection screen series is an easy to use product that has the
ability to be used as a free-standing projection screen. For best results, please read the checklist below
before using the Reflexion projection screen.
Use only manufacturer approved accessories with this product.
Keep this product dry and away from excessively humid operating conditions.
Avoid keeping the screen in direct sunlight; it is destructive to vinyl and plastic.
Do not touch the screen with sharp or abrasive objects.
In order to maintain cleanliness of the screen, use mild soapy water with a soft cotton cloth and
avoid unnecessary skin contact with the material.
Do not wash the screen material or its black masking with strong solvents.
Keep this product clear from an open flame or other heat sources.
The images below are an example of what not to do with the Reflexion series.
Rev. 091412-JA
www.elitescreens.com
Reflexion Series
User's Guide
info@elitescreens.com
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Elite Screens Reflexion Series
Summary of Contents for Elite Screens Reflexion Series
- Page 1 Do not wash the screen material or its black masking with strong solvents. Keep this product clear from an open flame or other heat sources. The images below are an example of what not to do with the Reflexion series. Rev. 091412-JA www.elitescreens.com...
- Page 2 Components Set up Example of the installation bracket attached to the side of the base feet. Base Foot Bracket Installation Each installation bracket has an adjustable spring-mounted cleat that can be loosened by a “loop” or eye-bolt. Pulling on the loop releases the cleat allowing the bracket to attach to the railing and click into place on the back of the casing.
- Page 3 Detach the screen case from the base feet Pull up the loop (eye-bolt) to release the spring-cleat and tilt the projection screen’s metal casing forward away from the brackets. Lift the entire projection screen assembly up and away from the bracket/cleat assembly.
- Page 4 4. Twist the locking ring counter-clockwise to loosen the telescoping function of the upright support and raise the screen to its desired level. 5. Rotate the locking ring clockwise to lock the upright support at its desired height setting. 6. Here is a front view of the Reflexion projection screen when the set-up is complete. Rev.
- Page 5 Retracting the screen 1. Take hold of the top span of the upright support and with your free-hand, twist the locking ring in the counter-clockwise direction. This will release the lock and allow the upright support to telescope back into its compact form. 2.
- Page 6 4. Return the upright hook to its cradle. 5. The Reflexion is now packed and ready for its next use. For US Customer Service and Technical Support questions, please contact Elite Screens at: Telephone: (877) 511-1211 service@elitescreens.com Fax: +1-(562) 926-8433 techsupport@elitescreens.com...
