Elite Screens Evanesce AcousticPro UHD Series User Manual

In-ceiling electric motorized front projection screen

Advertisement

Quick Links

In-Ceiling Electric Motorized Front Projection Screen
Important Safety & Warning Precautions
Make sure to read this user's guide and follow the procedures below.
Caution: The screen's Black Top Drop is already set to its maximum drop limit. There is NO extra black drop material
in the roller. Please be aware that altering the vertical limit switch to drop the screen material off the roller voids your
warranty with Elite Screens
installations) to this unit are prohibited and will void your warranty.
For more information, please contact our Technical Support Department at
• Please retain this user's guide for future reference.
• To avoid damaging the unit, do not use with any unauthorized accessories not recommended by the manufacturer.
• Handle the unit carefully during transportation to avoid any damages.
• To ensure safe and reliable operation, direct connection to a properly grounded power source is advised.
• The power outlet supplying power to the unit should be close to the unit and easily accessible.
• Do not install the unit on uneven, inclined surfaces;
• Do not install in damp places to avoid an electric shock or short circuit.
• Do not place any heavy objects over the power cord.
• Position the power cord properly to avoid creating a trip obstacle.
• To avoid an electrical shock or fire, due to a loose contact or short circuit, do not overload the power cord.
• The internal & external parts of this unit are not end user serviceable. Do not attempt to disassemble this unit by
yourself. No one except authorized technicians can open and make repairs to this unit.
• Make sure the power source that this unit is connected to has a continuous power flow.
• If there is need to use an extension cord, make sure the cord has an equal rating as the appliance to avoid overheat.
• Do not handle the power plug when your hands are wet or your feet are in contact with water.
• Properly dispose of this equipment according to the environmental regulations in your area when product is no
longer of service.
Do not use this unit under the following circumstances.
• Disconnect the power cord under the conditions of heavy rain, wind thunder or lightning.
• Avoid direct sun light, rain shower and moisture.
• Keep away from fire sources and high temperature to prevent this device from overheating.
• Cut off the power supply first before transportation or maintenance.
To avoid possible injury and/or an electric shock, do not attempt to use this screen if there is obvious damage or
if there are any evident broken parts.
Rev.V05172023DT (DS0234)
Evanesce Series
User's Guide – E/H type (RC1) V1.0
For 140" models and above
Visit
www.elitescreens.com
®
. Unapproved changes or modifications (except for cutting the power cord for hardwire
1
for latest updated version.
www.elitescreens.com
www.elitescreens.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Evanesce AcousticPro UHD Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Elite Screens Evanesce AcousticPro UHD Series

  • Page 1 Please be aware that altering the vertical limit switch to drop the screen material off the roller voids your ® warranty with Elite Screens . Unapproved changes or modifications (except for cutting the power cord for hardwire installations) to this unit are prohibited and will void your warranty.
  • Page 2 Elite Screens is not liable for any faulty installations. Individual modifications to this product are prohibited and will void the warranty with the manufacturer. Please contact Elite Screens Customer Service for any questions.
  • Page 3 5 Ways to control your Evanesce screen 1. IR Remote control (Item A, Fig 1): The Infrared functions by direct line of IR Lens sight contact using an effective beam range of 25 feet within a 30-degree angle. (IR remote only) Aim the IR remote directly at either the IR receiver on the Wall Box Controller or on the screen to operate the screen.
  • Page 4 4.Wired 5-12 volt trigger (Fig 3): Requires a 3.5mm to 3.5mm mono cable (not included) Step 1: Connect one end of the RJ50 cable to the screen and the other end to the Wall box controller. Fig. 3 Step 2: Then connect one end the 3.5mm mono cable to the wall box controller and the other to the projector.
  • Page 5 The Evanesce includes a 3-Prong Power Cord for use in a non-concealed power outlet. If your installation will be entirely concealed (including the power outlet), Elite Screens strongly recommends a hardwire connection. Please refer to the image below for both 110v & 220v wiring information.
  • Page 6 Assembly 1. Insert the M6x13 hex screw (B) through the Hanging Bracket’s (C) screw hole and secure with the Hexagonal nut (A). Slide the Hanging Bracket (C) through the railing on top of the case. Repeat the same for the other side. 2.
  • Page 7 2. Make sure the end flanges are properly installed and leveled with the housing. 3. As a safety precaution four people are required for this installation. Ceiling End flange piece location For local Elite Screens contact or Technical Support, please visit www.elitescreens.com Rev.V05172023DT (DS0234) www.elitescreens.com...
