INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. These instructions are supplementary to the Installation and Operating Instructions supplied with the fireplace and should be kept together. Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions OPTIONAL VERTICAL OR...
Power Vent Installation Locate the fireplace as per the main instructions supplied. Make the following modifications to add the components used with the Power Vent Kits. This Kit can only be used in conjunction with the “B” & “C” series versions of Town and Country fireplaces.
Horizontal (Side Wall) Venting This kit uses either Simpson Duravent GS direct vent pipe, Secure Vent direct vent pipe or Selkirk Direct-temp vent pipe with a 5” inner pipe and an 8” outer pipe. For part numbers see the table of venting components on page 11 of this manual.
Vertical (Through Roof) Venting This kit uses either Simpson Duravent GS direct vent pipe, Secure Vent direct vent pipe or Selkirk Direct-temp vent pipe with a 5” inner pipe and an 8” outer pipe. For part numbers see the table of venting components on page 11 of this manual.
Page 6
Vertical (Through Roof) Venting Fig. #5 Part F Vertical Rain Cap TCVT.8074 MUST ALIGN #8 x 1/2" S.S. (16 Required) Power Vent TCVT.PVB NOTE: Holes to secure rain cap are not predrilled Part D f i r e - p a r t s . c o m Junction Box Cover Part E Exhaust Shield...
Fig. #6 Control System Connection ACCESS PANEL The gas control system is located on the right hand side of the firebox behind an access panel and the decorative panel. 1. Remove burner assembly, burner media and decorative panels if already installed (see main installation manual for details).
Page 8
5. Connect the pressure switch jumper wires to the orange Fig. #10 wire. (Fig. # 10) 6. Attach a silicone tube from the upper pressure tap on the PRESSURE power vent adaptor (Fig. #4) to the low port of the pressure SWITCH switch.
Replacement Parts ITEM PART No. DESCRIPTION ITEM PART No. DESCRIPTION 8024 TUBE, 5/16” OD, 1/16” THICK INSIDE COVER BLOWER POWER VENT EXHAUST SHIELD 5027.15 PRESSURE SWITCH SECONDARY RAIN SHIELD 3/8” STRAIN RELIEF JUNCTION BOX #8 x 1/2” PAN HD SKT 18.8 STAINLESS STEEL TOP COVER ID x .379 OD x .062 THK EXHAUST SCREEN...
Page 12
f i r e - p a r t s . c o m TECHNICAL SUPPORT: (250) 748-1184 www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
