Town & Country Fireplaces TC36ST Installation And Operating Instructions Manual

Series c modular direct vent see-thru fireplace
Hide thumbs Also See for TC36ST:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual, Instruction and Installation Manual
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
WARNING:
If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or death.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch;
• Do not use any phone in your building.
• Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier call
the fire department.
Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless
a certified kit is used.
This appliance is suitable for installation in a
bedroom or bed sitting room
051109-44
TC36 SEE-THRU
INSTALLATION
AND OPERATING
INSTRUCTIONS
MODEL
TC36ST
SERIES C
MODULAR DIRECT VENT
SEE-THRU FIREPLACE
TC36_CSTE
5056.42801.C
