6.4. Installation of the coffee grinder
Before connecting the coffee grinder, check the following:
• That the data on the features label coincides with those of the power
supply.
• That the electrical current is appropriate for the machine.
• That the connection point to the power supply network is protected
with appropriate fuses.
• That the equipment is properly connected to a grounded socket in
accordance with the applicable safety guidelines.
i
*The coffee grinder should be used in areas with a room temperature
below 25/30ºC ( 77/86ºF ) and should not be installed in places (SUCH
AS INDUSTRIAL KITCHENS) where cleaning with water jets are
used.
7
Menu and adjustment
The grinder has a program that can be configured using the three frontal
buttons.
•Right button (7). Move to the next option.
•Middle button (8). Takes you to the configuration menu, visualizing the
first point on the menu. This button is to confirm the options with a quick
push. To return to the menu, hold the button longer.
•Left button (9). Returns to the previous option.
Menu structure
Level 1 Level 2 Level 3
1.1.1. Automatic
with predoses
1.1. Operation
mode
1.1.2. Automatic
1.1.3. Manual
1.2.1. Upper lid
1.2. Cleaning
1.2.2. Lower lid
1.3.1. English
1.3.2. French
1.3.3. German
1.3. Language
1.3.4. Italian
1.3.5. Portuguese
1.3.6. Spanish
1.4.1. Time
1.4. Date and
time
1.4.2. Date
1.5.1. Absolute
1.5. Number of
"Date + nº coffees"
coffees served
1.5.2. Relative "Date
reset + nº coffees"
*The grinding time can be varied manually during the grinder's
operation, only when the password is deactivated, using the left (-)
and right (+) buttons. The grinding time being used will be saved after
20 servings.
Level 4 Observations
1 push (10)= 1 pre-ground serving
2 pushes (10)= 2 pre-ground
servings (double time at 1 push)
Grinding time adjustable with left
button (9) (1 push=-0.1 sec.) or
right (7) (1 push=+0.1 sec.) at any
time. The change is made in the
third serving after the adjustment
(the two previous servings have
already been ground)
1 push (10)= 1 instant serving
2 pushes (10)= 2 instant servings
Grinding times are adjustable with
the menu and are independent
between them.
Amount of ground coffee based
on the time that the push-button
is held (1 push on, 2 push off).
st nd
1.2.1.1. Open
In the Automatic mode, with 5
sec. Pre-dosis, after closing the lids
1.2.1.2. Close
or exiting the menu, the grinder
1.2.2.1. Open
with grind coffee to fill the 2 pre-
dosis compartments.
1.2.2.2. Close
1.4.1.1. Hour
1.4.1.2. Minute
1.4.1.3. Second
1.4.2.1. Day
1.4.2.2. Month
1.4.2.3. Year
Date starting from the first day of
the grinder.
If no date appears, this means that
no reset has been made.
