External Components - Compak A-8 Automatic Instruction Manual

5

External components

Hopper cover
1
Coffee bean hopper
2
Grind lock
3
Endless grind regulator
4
Dispenser cleaning cover
5
Display
6
Right button
7
Following option on the menu
Middle button
Starting menu and
8
confirmation
Left button
9
Previous option on the menu
Front push-button
10
Illuminated on-off switch
11
Support crutch
12
6
Installation
i
6.1. General warnings
The installer should read this instruction manual carefully before installing
the machine. The machine must be installed by qualified, authorized staff,
respecting the applicable safety and hygiene guidelines.
!
6.2. Important warnings
The operator must be a responsible adult and under no circumstances a
minor or a person unable to deal with said responsibility.
When handling the grinder, the following precautions must be taken into
consideration:
• Do not handle with bare feet
• Hands or feet must not be wet
• Do not submerge the machine in water
• Do not expose the machine to sunlight or other atmospheric
conditions
• Never insert any object into the coffee input or output openings
when the machine is turned on. (Please bear in mind that when the
grinder stops, the burrs continue to turn for a few seconds.)
• To disconnect the grinder, always pull out the plug and never the
electrical cable, to avoid the possibility of a short circuit.
i
6.3. Putting the grinder into place
The grinder should be installed on a smooth flat surface. In order to
guarantee the optimum performance of the appliance, the minimum
dimensions of the work place should be as follows:
Height (in / mm.)
A-8 Automatic 31.2 / 800
Width (in / mm.) Depth (in / mm.)
12.1 / 310 15.6 / 400
