Furuno TZTL12F Installation Manual

Multi function display
Hide thumbs Also See for TZTL12F:
Table of Contents

Advertisement

Quick Links

See also: Operator's Manual
Installation Manual
Model
SAFETY INSTRUCTIONS ................................................................................................ i
SYSTEM CONFIGURATION ........................................................................................... ii
EQUIPMENT LISTS........................................................................................................ iii
1. MOUNTING..............................................................................................................1-1
1.1 Mounting Considerations ...................................................................................................1-1
1.2 Flush Mounting ..................................................................................................................1-2
1.4 Desktop Mounting (option).................................................................................................1-4
1.5 Installation of Transducers.................................................................................................1-6
1.6 Installation of Sensors (option) ........................................................................................1-16
2. WIRING....................................................................................................................2-1
2.1 Interface Connections (Rear of Unit) .................................................................................2-1
2.2 How to Secure and Waterproof Connections.....................................................................2-2
2.3 MULTI Cable......................................................................................................................2-2
2.4 Network Connector ............................................................................................................2-5
2.5 Video In, Video Out and USB Connections .......................................................................2-5
2.6 CAN bus (NMEA2000 Connector) .....................................................................................2-6
2.7 Example NavNet TZtouch2 System Configurations.........................................................2-10
3. HOW TO SET UP THE EQUIPMENT......................................................................3-1
3.1 How to Set Time Zone and Language ...............................................................................3-3
3.2 How to Set Units of Measurement .....................................................................................3-4
3.3 Initial Setup ........................................................................................................................3-5
3.4 How to Set Up the Radar ...................................................................................................3-9
3.5 How to Set Up the Sounder .............................................................................................3-12
3.6 Wireless LAN Setting .......................................................................................................3-17
APPENDIX 1 INSTALLATION OF TEMPERATURE SENSORS ............................AP-1
PACKING LISTS ......................................................................................................... A-1
OUTLINE DRAWINGS ................................................................................................ D-1
INTERCONNECTION DIAGRAM ................................................................................ S-1
www.furuno.com
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.

Advertisement

Table of Contents
loading

Related Manuals for Furuno TZTL12F

Summary of Contents for Furuno TZTL12F

  • Page 1: Table Of Contents

    EQUIPMENT LISTS......................iii 1. MOUNTING......................1-1 1.1 Mounting Considerations ....................1-1 1.2 Flush Mounting ........................1-2 1.3 Retrofit Kit for TZTL12F (option) and Front Fixing Panel Kit for TZTL15F (option) ...1-3 1.4 Desktop Mounting (option)....................1-4 1.5 Installation of Transducers....................1-6 1.6 Installation of Sensors (option) ..................1-16 2.
  • Page 2 ・FURUNO Authorized Distributor/Dealer 9-52 Ashihara-cho, Nishinomiya, 662-8580, JAPAN A : JAN 2015 Printed in Japan All rights reserved. A2 : AUG . 20, 2015 Pub. No. IME-44870-A2 ( GREG ) TZTL12F/TZTL15F 0 0 0 1 9 0 0 7 4 1 0...

  • Page 3: Safety Instructions

    Connection of an incorrect power Steering Standard supply can cause fire or damage Model compass compass the equipment. 0.75 m 0.50 m TZTL12F 0.75 m 0.45 m TZTL15F...

  • Page 4: System Configuration

    FA-30/50 HUB -101 SC-30 FAX-30 GP-330B FUSION-Link Equipment* FI-5002 FI-50/70 NAVpilot-700 IF-NMEA2K1/2 Multi Function Display* Multi Function Display* TZTL12F TZTL12F Remote Controller Wide Monitor MCU-002 CCD Camera TZTL15F TZTL15F CCD Camera SD Card Unit SDU-001 Event SW Transducer External Buzzer...

  • Page 5: Equipment Lists

    EQUIPMENT LISTS Standard supply Name Type Code No. Remarks TZTL12F Multi Function Display TZTL15F CP19-01800 000-027-063 For TZTL12F Installation Materials CP19-01900 000-027-064 For TZTL15F Accessories FP19-02011 001-337-390 Spare Parts SP19-00601 001-023-040 Fuses (Type: FBG0-A 125V 5A PBF, Code: 000-155-853-10, 2 pcs.)
  • Page 6 Thru-hull type, plastic Temperature Sensor T-04MSB 000-026-893 Thru-hull type T-04MTB 000-026-894 Transom mount Bracket 12 OP19-13 001-337-410-00 For TZTL12F Bracket 15 OP19-14 001-337-420-00 For TZTL15F Retrofit Kit For VX2 OP19-15 001-337-430-00 For TZTL12F 10.4" Retrofit Kit For MDF12 OP19-16 001-337-440-00...

  • Page 7: Mounting

    MOUNTING Mounting Considerations TZTL12F TZTL15F When selecting a mounting location for NavNet TZtouch2, keep the following in mind: • The temperature at the mounting location shall be between -15°C and +55°C. • The humidity at the mounting location shall be 93% or less at 40°C.

  • Page 8: Flush Mounting

    Note: Ensure the mounting location is flat, with no indents or protrusions, to allow a secure fit. 1. Prepare a cutout in the mounting location using the template (supplied) for the TZTL12F or TZTL15F. 2. Attach the flush mounting sponge, in the order indicated in the figure to...

  • Page 9: Retrofit Kit For Tztl12F (Option) And Front Fixing Panel Kit For Tztl15F (Option)

    Mounting panel Retrofit Kit for TZTL12F (option) and Front Fixing Panel Kit for TZTL15F (option) When upgrading to the TZTL12F or front-mounting the TZTL15F, use the kit which matches your old equipment. (Refer to the table below for details.) Optional kit Code No.

  • Page 10: Desktop Mounting (Option)

    Desktop Mounting (option) Follow the appropriate procedure below to mount the TZTL12F or TZTL15F. 1.4.1 How to mount the TZTL12F Use the optional kit Bracket12 (contents shown below), for mounting the TZTL12F. Type Code Contents Knob bolt  2 (Code No.: 100-365-900-10), Self-tapping...
  • Page 11 1. MOUNTING 1.4.2 How to mount the TZTL15F Use the optional kit Bracket15 (contents shown below), for mounting the TZTL15F. Type Code Contents Knob bolt  2 (Code No.: 100-346-502-10), Washer  2 OP19-14 001-337-420 (Code No.: 100-076-101-10), Self-tapping screws (SUS304 520) ...

  • Page 12: Installation Of Transducers

    1. MOUNTING Installation of Transducers 1.5.1 How to mount a transducer through the hull Transducer mounting location The thru-hull mount transducer provides the best performance of all, since the transducer protrudes from the hull and the effect of air bubbles and turbulence near the hull skin is reduced.

  • Page 13: Installation Procedure

    1. MOUNTING Installation procedure 1. With the boat hauled out of the water, mark the location chosen for mounting the transducer on the bottom of the hull. 2. If the hull is not level within 15° in any direction, fairing blocks made out of teak should be used between the transducer and hull, both inside and outside, to keep the transducer face parallel with the water line.
  • Page 14 1. MOUNTING Transducer preparation Before putting your boat in water, wipe the face of the transducer thoroughly with a detergent liquid soap. This will lessen the time necessary for the transducer to have good contact with the water. Otherwise the time required for complete "saturation" will be lengthened and performance will be reduced.
  • Page 15 1. MOUNTING 1.5.3 How to mount a transducer inside the hull The transducer may also be installed inside the hull on FRP boats. However, this installation method affects the ability to detect the bottom, fish and other objects because the ultrasound pulse is weakened when it passes through the hull. Note: This mounting method should not be used to mount the transducer that ™...
  • Page 16 1. MOUNTING 2) Put the transducer into water-filled plastic bag. Press the transducer against the chosen site. Plastic bag 3) Tap (power switch) to turn the power on. 4) After the startup procedure completes (approx. 90 seconds), the last used display appears. Water Tap the [Home] icon ( ) to...
  • Page 17 1. MOUNTING 5. Dry the face of the transducer and the hull. Coat the transducer face and mounting Transducer location with marine sealant. Hardening begins in approx. 15 to 20 minutes so do this step without delay. Marine sealant 6. Attach the transducer to the hull. Press the transducer firmly down on the hull and gently twist it back and forth to remove any air which may be trapped in...
  • Page 18 1. MOUNTING 1.5.4 Triducer DO NOT over-tighten screws, to prevent damage to the transducer. 525STID-MSD The optional triducer 525STID-MSD is designed for thru-hull mounting. ø 79 133 2.00"-12 UN threads ø 51 Unit: mm 525STID-PWD The optional transom mount triducer 525STID-PWD can be installed by the thru-hull method or the inside-hull method.
  • Page 19 1. MOUNTING Mounting location To ensure the best performance, the sensor must be submerged in aeration-free and turbulence-free water. Mount the sensor close to the centerline of your boat. On slower heavier displacement hulls, positioning it farther from the centerline is acceptable.
  • Page 20 1. MOUNTING 5. Using the three #10 x 1-1/4” self-tapping screws, temporarily screw the bracket to the hull. DO NOT tighten the screws completely at this time. Follow the step 1-4 in "How to attach the sensor to the bracket", before proceeding with "Adjustments".
  • Page 21 1. MOUNTING How to attach the sensor to the bracket 1. If the retaining cover near the top of the bracket is closed, open it by depressing the latch and rotating the cover downward. 2. Insert the sensor's pivot arms into the slots Step 1 Step 2 near the top of the bracket.

  • Page 22: Installation Of Sensors (Option)

    1. MOUNTING Installation of Sensors (option) 1.6.1 Speed/temperature sensors ST-02MSB, ST-02PSB The speed/temperature sensors (ST-02MSB, ST-02PSB) are designed for thru-hull mounting. Install them as shown in this section. Mounting considerations Select a suitable mounting location, considering the following: • Select a location where the transducer will not be damaged in trailering, launching, hauling, and storage.

  • Page 23: Wiring

    WIRING Interface Connections (Rear of Unit) Rear of TZTL12F/TZTL15F Rear of TZTL12F/TZTL15F Composite 2 Composite 2 Composite 1 Composite 1 Composite 1 Ground wire (Local supply, IV-8sq.)* EMI Core* EMI Core* TO: Ship’s ground MULTI cable MULTI cable Network Network...

  • Page 24: How To Secure And Waterproof Connections

    2. WIRING How to Secure and Waterproof Connections Where the unit is exposed to water spray or moisture, Video out, USB, Video In, NMEA2000, LAN network and Multi cable connections to the NavNet TZtouch2 must have at least IPx2 waterproof rating. All unused cable ends should be covered for protection.
  • Page 25 2. WIRING 2.3.1 How to isolate and secure unused wires 1. Cut the outer and inner sheaths lengthwise. Take care not to cut the wires. 2. Fold back the outer sheath, then fold back the inner sheath, covering the outer sheath.
  • Page 26 2. WIRING 2.3.3 How to connect the external buzzer Connect the optional external buzzer (OP03-136) following the procedure below. Note: The external buzzer does not require menu settings. 1. Cut the XH connector at the end of the external buzzer cable to an appropriate length for your installation.

  • Page 27: Network Connector

    Network Connector Like previous NavNet series equipment, the TZTL12F and TZTL15F may share Radar and Fish Finder images, and other information, across a TCP/IP Ethernet connection. Up to four NavNet TZtouch2 units may be connected to the same network at one time.

  • Page 28: Can Bus (Nmea2000 Connector)

    Video out (external HDMI monitor) A HDMI monitor can be connected to the NavNet TZtouch2 to repeat the screen at a remote location. The TZTL15F and TZTL12F are compatible with wide-screen HDMI monitors which meet the following minimum requirements: Resolution Vert.
  • Page 29 2. WIRING 2.6.2 How to connect the TZTL12F/TZTL15F to DRS radar sensors Note: The DRS4DL sensor does not have CAN bus connectors attached. In addition to the CAN bus port found on the NavNet TZtouch2, all DRS radar sensors have one powered CAN bus port (terminal strip connector). The total number of sensors that can be connected to the DRS CAN bus port without external power connection depends on power consumption.
  • Page 30 2. WIRING 2.6.3 NMEA0183 equipment data input Note: To output NMEA0183 data, see paragraph 2.3.2. To connect NMEA0183 equipment to NavNet TZtouch2, use the CAN bus network via the optional NMEA data converter IF-NMEA2K2 (or IF-NMEA2K1). This NMEA connection can accept a baud rate of 4800 or 38400. Heading input to NavNet TZtouch2 allows functions such as Radar Overlay and course stabilization (North up, Course up, etc.) in the radar operating modes.
  • Page 31 2. WIRING Description 129538 GNSS Control Status 129540 GNSS Satellites in View 129793 AIS UTC and Date Report 129794 AIS Class A Static and Voyage Related Data 129798 AIS SAR Aircraft Position Report 129808 DSC Call Information 129809 AIS Class B “CS” Static Data Report, Part A 129810 AIS Class B “CS”...

  • Page 32: Multi Function Display Tztl12F/Tztl15F

    Radar Sensor DRS4DL 12 or 24 VDC Multi Function Display TZTL12F/TZTL15F 12 or 24 VDC Matching Box MB-1100 600W Transducer Note: Matching Box MB-1100 required for some FURUNO transducers. See the INTERCONNECTION DIAGRAM at the back of this manual. 2-10...
  • Page 33 CAN bus CAN bus drop cable HUB-101* drop cable Multi Function Display Multi Function Display Multi Function Display Multi Function Display TZTL12F/TZTL15F TZTL12F/TZTL15F TZTL12F/TZTL15F TZTL12F/TZTL15F USB Hub* USB Hub* 12 to 24 12 to 24 VDC 12 to 24 VDC...
  • Page 34 2. WIRING This page is intentionally left blank. 2-12...

  • Page 35: How To Set Up The Equipment

    HOW TO SET UP THE EQUIPMENT This chapter shows you how to set up your system according to the equipment you have connected. Touch control description The touch control depends on the screen type. The basic operations to use during the installation setup are in the following table.
  • Page 36 3. HOW TO SET UP THE EQUIPMENT How to operate the menus The following procedure shows how to use the menu system. 1. Tap (power switch) to turn the power on. 2. After the startup process completes, the last used display appears and a warning message is displayed.

  • Page 37: How To Set Time Zone And Language

    3. HOW TO SET UP THE EQUIPMENT How to use the software keyboard Alphabet software keyboard Numeric software keyboard _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Description Cursor position is highlighted.

  • Page 38: How To Set Units Of Measurement

    3. HOW TO SET UP THE EQUIPMENT How to Set Units of Measurement 1. Tap the [Home] icon to show the home screen and display mode settings. 2. Tap [Settings] to show the [Settings] menu. 3. Drag the main menu to display [Units], then tap [Units]. 4.

  • Page 39: Initial Setup

    3. HOW TO SET UP THE EQUIPMENT Initial Setup This section shows you how to set your system according to the sensors you have connected. Note: Some units are set to metric in this section, actual setting ranges vary depending on the unit of measurement set in the [Units] menu. 1.
  • Page 40 Select the source for each data to input to the system. If two or more sources are connected for a data, select one using the pull-down dialog box. The FURUNO products are shown at the upper part of the list. [Sensor List] Show the information for sensors connected to your equipment.
  • Page 41 3. HOW TO SET UP THE EQUIPMENT [Initial Setup] menu - [DATA DAMPING] Menu item Description Options (setting range) [COG & SOG] Set data damping time. The lower the setting 0 to 59 (seconds) the faster the response to change. [Heading] [Speed Through Water] [Wind Speed &...
  • Page 42 3. HOW TO SET UP THE EQUIPMENT [Initial Setup] menu - [GRAPHIC INSTRUMENTS SETUP] Menu Item Description Options (setting range) Maximum Boat Speed Set the transducer’s maximum detectable 1 (kn) to 99 (kn) speed. Maximum Wind Speed Set the transducer’s maximum detectable 1 (kn) to 99 (kn) speed.

  • Page 43: How To Set Up The Radar

    3. HOW TO SET UP THE EQUIPMENT [Initial Setup] menu - [Engine & Tank Automatic Setup] The TZTL will automatically detect engines and tanks connected to the same network. This is the recommended method for setting up engines and tanks. [Initial Setup] menu - [Engine &...
  • Page 44 3. HOW TO SET UP THE EQUIPMENT [Radar] menu - [Radar Initial Setup] Menu item Description Options (setting range) [Antenna Rotation] Select the speed of antenna rotation. [Auto], [24 RPM] [Antenna Heading Align] See "How to align the antenna [-179.9°] to [+180.0°] heading"...
  • Page 45 3. HOW TO SET UP THE EQUIPMENT How to align the antenna heading You have mounted the antenna unit facing straight ahead in the direction of the bow. Therefore, a small but conspicuous target dead ahead visually should appear on the heading line (zero degrees).

  • Page 46: How To Set Up The Sounder

    [ON], [OFF] [Fish Finder Select the sounder used. [TZTL12F] / Source] Note: Where the TZTL12F or TZTL15F’s nickname has [TZTL15F], been changed in [INITIAL SETUP] - [SENSOR LIST], the [DFF1/BBDS1], [Fish Finder Source] option reflects the name change. [DFF3], [DFF1- UHD] [Transducer Setup] Setup Transducer and Motion Sensor.
  • Page 47 3. HOW TO SET UP THE EQUIPMENT Options (setting Menu item Description range) [Auto Gain Offset If the auto gain offset is wrong, or there is a difference in [-5] to [5] the gain between the low and high frequencies, set an offset here to balance auto gain for the two frequencies.
  • Page 48 [TDID] cally selected. • [Manual]: Manually set up the transducer. • [Model]: Select the appropriate transducer model (for FURUNO or AIRMAR transducers) • [TDID]: Select the TDID for the transducer (for AIRMAR transducers with a TDID) [Model Number] Select the appropriate model number from the list.
  • Page 49 3. HOW TO SET UP THE EQUIPMENT Options Menu item Description (setting range) [Transducer Power LF] Set the transmission power for low frequency. [600], [1000] Note 1: This menu item is available only for DFF1, DFF1-UHD, BBDS1 and internal fish finder users.
  • Page 50 3. HOW TO SET UP THE EQUIPMENT Motion sensor menu Note: Motion sensor setup is not required if [Fish Finder Source] in the [Sounder] menu is set to [Internal]. When you tap [Transducer Setup] from the [Sounder] menu, the [Motion Sensor] menu is shown beneath the [Transducer Setup] menu.

  • Page 51: Wireless Lan Setting

    3. HOW TO SET UP THE EQUIPMENT Wireless LAN Setting 3.6.1 How to create a wireless LAN network Smart devices connected to this wireless network may also connect directly to the unit, allowing use of the NavNet TZtouch2 applications. 1. Tap the Home icon ( ) to show the home screen and display mode settings.
  • Page 52 3. HOW TO SET UP THE EQUIPMENT This page is intentionally left blank. 3-18...

  • Page 53: Appendix 1 Installation Of Temperature Sensors

    APPENDIX 1 INSTALLATION OF TEMPERATURE SENSORS The installation instructions in this chapter are copied from the manufacturer's (AIRMAR Technology Corporation) installation guide, which is included with your sensor. The model numbers mentioned within the documentation should be read as follows: T42 =>...
  • Page 54 APPENDIX 1 INSTALLATION OF TEMPERATURE SENSORS AP-2...
  • Page 55 APPENDIX 1 INSTALLATION OF TEMPERATURE SENSORS AP-3...
  • Page 56 APPENDIX 1 INSTALLATION OF TEMPERATURE SENSORS AP-4...
  • Page 57 APPENDIX 1 INSTALLATION OF TEMPERATURE SENSORS AP-5...
  • Page 58 C4489-Z01-D C4487-Z01-D...
