White Knight eco 86A Instructions For Use Manual

Electronic sensing gas dryer
Hide thumbs Also See for eco 86A:

Advertisement

Table of Contents

ELECTRONIC SENSING GAS DRYER
GB
IMPORTANT
FOR USE IN THE UNITED KINGDOM AND IRELAND WITH NATURAL GAS ONLY
IMPORTANT
IMPORTANT: PLEASE READ THESE
INSTRUCTIONS THOROUGHLY BEFORE USING
THIS APPLIANCE. KEEP THEM IN A SAFE PLACE FOR
FUTURE REFERENCE.

SECTION 1: BEFORE USE

* Safety warnings
These notes are provided in the interest of safety. You must
read them before installing or using the appliance.
- This tumble dryer is intended for NORMAL DOMESTIC
USE ONLY.
- The dryer must be installed by a Registered Installer.
- Any electrical work required to install the appliance should be
carried out by a qualified person.
- The tumble dryer should be serviced by an appointed service
organisation and only genuine parts used.
- It is recommended that the dryer be serviced annually by a
person competent to service gas fired tumble dryers.
Under no circumstances should you attempt to repair the
appliance yourself. Repairs carried out by inexperienced
INSTRUCTIONS FOR USE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eco 86A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for White Knight eco 86A

Summary of Contents for White Knight eco 86A

  • Page 1: Section 1: Before Use

    INSTRUCTIONS FOR USE ELECTRONIC SENSING GAS DRYER IMPORTANT FOR USE IN THE UNITED KINGDOM AND IRELAND WITH NATURAL GAS ONLY IMPORTANT IMPORTANT: PLEASE READ THESE INSTRUCTIONS THOROUGHLY BEFORE USING THIS APPLIANCE. KEEP THEM IN A SAFE PLACE FOR FUTURE REFERENCE. SECTION 1: BEFORE USE * Safety warnings These notes are provided in the interest of safety.
  • Page 2 persons may cause serious injury. Consult your local appointed service engineer and insist on genuine spare parts. - The special mains cable and plug assembly must only be replaced with a genuine part available from the manufacturer or service agent. - Keep the packing materials from your machine away from children to avoid hazards.
  • Page 3 the drying cycle. This will require the appliance being restarted. - Under no circumstances should anything other than the recommended articles be placed in the tumble dryer. - It is dangerous to alter or modify the product in any way other than fitting authorised accessories.
  • Page 4 - DO NOT – allow children to tamper with the controls and keep them away from the dryer when it is in operation. - DO NOT – attempt to dry items containing foam rubber or rubber-like material. - DO NOT - place items contaminated with inflammable substances in the dryer, such as petrol, cleaning solvents, cooking oil fat, or hair lacquer.
  • Page 5 - Adequate ventilation has to be provided to avoid the back flow of gases into the room from appliances burning other fuels, including open fires. SECTION 1: BEFORE USE SECTION 2: INSTALLATION * Safety Warnings * User Information * Venting * Prior to Installation * Positioning and Air Supply * Final Installation...

  • Page 6: Section 3: Technical Specifications

    * Prior to Installation Check that the local distribution conditions, nature of gas, pressure and adjustment of the dryer are compatible. * Positioning and Air Supply The dryer must not be placed in a bedroom, bathroom, shower room, or locations where concentrations of flammable vapours may accumulate, but may be positioned against walls, other appliances, kitchen furniture and similar surfaces.

  • Page 7: Section 4: Control Panel

    SECTION 4: CONTROL PANEL Heat push button, press to select appropriate heat setting (some programs have limited choice of heat setting). High is used for drying cottons and linens; half heat is used for drying synthetics and delicates; cool does not apply any heat. “-”...

  • Page 8: Operation

    All programs from P1 to P9 can be used with the Delay Start feature. A maximum of 9 hours delay time is available in 1 hour increments. The anti-crease function can be selected to minimize creasing by continuing to turn the drum periodically after the main drying cycle has finished.

  • Page 9: Delay Start

    Select anti-crease function if required. Press the coloured Start button to commence the drying cycle. The drum will begin rotating and will stop automatically when your clothes are dry or the timed cycle has finished. An audible alert will sound to indicate that the drying cycle has finished.

  • Page 10: Approved Service Agents

    APPROVED SERVICE AGENTS: White Knight (Whirlpool) 0800 988 1323 (calls are free from landlines however calls from mobiles may be charged at your network provider’s rates) White Knight (0800 Repair): 0344 8797422 (Calls charged at basic rate).

  • Page 11: This Appliance Must Be Earthed

    Wall/Window Vent Kit - To make a permanent connection through a wall or window. Stacking Kit - To enable your dryer to be secured onto the top of a front loading washing machine (to save floor space). The above items can be purchased as accessories for your tumble dryer from your supplier. Instructions for stacking, if required, are supplied with the stacking kit.
  • Page 12 Gas SDO MF Suppliers name or trade mark WHITE KNIGHT Model identifier 86A - TYPE Rated capacity at full load Appliance type Energy efficiency class Energy consumption of the appliance* 261kWh The figures above is based on 160 drying cycles of the standard cotton programme at full and partial load and the consumption of the low-power modes.
