FLITEWORK SHINY (FLWA4180)
Please read the instruction manual carefully and take notice of the safety guidelines.
If the model is given to a third party, always include this instruction manual to the model.
The Flitework Gmbh assumes no liability in case of misprints. Technical amendments reserved.
Distributed by
Instruction manual
Designed in Austria - Made in China
Wingspan
Length
Take off weight
Wing load
RC channels
Battery
- 1 -
1200 mm
1080 mm
915 g
36,7 g/dm²
Aileron, Elevator,
Throttle
3s 2200 mAh
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Hobbico FLITEWORK SHINY FLWA4180
Summary of Contents for Hobbico FLITEWORK SHINY FLWA4180
-
Page 1: Instruction Manual
Instruction manual FLITEWORK SHINY (FLWA4180) Wingspan 1200 mm Length 1080 mm Take off weight 915 g Wing load 36,7 g/dm² Aileron, Elevator, RC channels Throttle Battery 3s 2200 mAh Please read the instruction manual carefully and take notice of the safety guidelines. If the model is given to a third party, always include this instruction manual to the model. - Page 2 Installing the elevator........5, 6, 7 Installing the receiver..........7 Technical Data............1 Mounting the main wings..........7 Introduction............2 Center of gravity............8 General informations..........2 Setting the control throws.........8 Environment protection infos.........2 Lighting..............8 Safety precautions..........3 Spare parts...............9 Recommended accessories........3 Check the control directions........9 Additional items required........3 Check list..............9 Kit check..............3 Service lines.............9...
- Page 3 Before starting to build, use the Kit Contents list to take an inventory of this kit to make sure it is complete and inspect the parts to make sure they are of acceptable quality. If any parts are missing or are not of acceptable quality, or if you need assistance with assembly, contact Hobbico Product Support. Hobbico Product Support Service center Revell GmbH 3002 N.
- Page 4 1x Fuselage, including pre mounted elevator servo, brushless motor, ESC and LED illumination 1x Main wing with aileron servos and indirect lighting 1x Elevator with elevator flaps, hinges and connection clamp 1x Elevator linkage 1x Plastic screws and velcro tape for battery - 4 -...
- Page 5 Check with a measuring tape the distance from both sides, like you can see in the picture. Prepare the elevator , the elevator flaps, the connection bracket and the 6 piece fleece hinges. Mark the position of the elevator, using a fine non perma- nent marker on upper and lower side of the elevator.
- Page 6 CA drops on the covering film cause ugly smudges. Put out the lightning connector through the hole in eleva- tors upper side. Connect the BEC connector of the elevator with the con- First glue the hinges to the elevator flaps, using 5 min. nector, coming out of the tail of the fuselage.
- Page 7 Insert the elevator linkage and connect it to the elevator lever. Shorten the linkage and fix it on the servo arm. Use Put enough 5 min. epoxy into the slots and into the drilling thread lock for the clamp screw. for the bracket.
- Page 8 in the shown position. For a secure battery mounting we recommend to use a small sheet of anti-slip mat below the battery, glued to the bottom frame. Also a Flitework battery belt 200mm would be very useful. Insert the 2 connection bolts of the wing into the fuselage during claping the wing in its position.
- Page 9 3. Make certain that the control surfaces and the electric motor respond in the correct direction as shown in the diagram. If any of the controls FLWA4181 Shiny fuselage respond in the wrong direction, use the servo reversing in the transmitter to reverse the ser- FLWA4182 Shiny elevator complete vos connected to those controls.
-
Page 10: Personal Notes
Service department Revell GmbH Henschelstr. 20-30, 32257 Bünde, Germany Tel: +49 52239 65144 Email: service@hobbico.de Hobbico Product Support 3002 N. Apollo Drive Suite 1 Champaign IL 61822 USA Telephone: (217) 398-8970 ext. 6 Fax: (217) 398-7721 E-mail: airsupport@hobbico.com Service department Flitework GmbH Geymannstr. - Page 11 PERSONAL NOTES - 11 -...
- Page 12 Remember to think. Have a ball! But always stay in control and fly in a safe manner. GOOD LUCK AND GREAT FLYING! Flitework GmbH Tel: +43 664 3231059 Geymannstraße 27 Skype: flitework 4713 Gallspach Austria / Europe Mail.: office@flitework.at www.flitework.at - 12 -...
