Fully licensed through the
Red Bull GmbH - Austria
Technical data :PT17-XS
Wingspan
Length
Take off weight
Battery
RC Functions
Please read the instruction manual carefully and take notice of the safety guidelines.
If the model is given to a third party, always include this instruction manual to the model.
INSTRUCTION MANUAL
FLWA4110 - PT17-XS
1200 mm
970 mm
1600 g
4S 2500 mAh
4 channels
The Flitework Gmbh assumes no liability in case of misprints. Technical amendments reserved.
Distributed by
www.hobbico.de
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hobbico FLWA4110 - PT17-XS
Summary of Contents for Hobbico FLWA4110 - PT17-XS
-
Page 1: Instruction Manual
INSTRUCTION MANUAL FLWA4110 - PT17-XS Fully licensed through the Red Bull GmbH - Austria Technical data :PT17-XS Wingspan 1200 mm Length 970 mm Take off weight 1600 g Battery 4S 2500 mAh RC Functions 4 channels Please read the instruction manual carefully and take notice of the safety guidelines. -
Page 2: Table Of Contents
TABLE OF CONTENTS General informations ............2 Preflight ..................9 Environment protection infos ........2 Identify your model ............9 Introduction ................2 Charge the Batteries ............9 Safety precautions ...............3 Balance Propellers ............9 Additional items required ..........4 Ground check ..............9 Hardware and accessories ..........4 Range check ...............9 Engine safety precautions ..........10 Useful tools .................4 Spare parts for the PT17-XS ..........4... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS 7. If you are not already an experienced R/C pilot, you should fl y the model only with the help of a competent, experienced 1. Your PT17-XS should not be considered a toy, but rather a R/C pilot. sophisticated, working model that functions very much like a full-size airplane. -
Page 4: Additional Items Required
Tel: 01805 110111 (nur für Deutschland) (Anrufkosten: USEFUL TOOLS 14 Cent/Min. a. d. dt. Festnetz; Mobilfunk max. 42 Cent/Min.) ❍ Hobby knife Email: Hobbico-Service@Revell.de ❍ Philips screw driver ❍ Long nose pliers ❍ Hexagon screw driver 1,5 - 3mm ❍ Locking agent - blue ❍... -
Page 5: Content Of Delivery
CONTENT OF DELIVERY PART LIST • 1. Fuselage with installed brushless motor and ESC, incl. anodized spinner and installed tail landing gear. • 2. Set of main wings, painted and with all decals • 3. Wing struts • 4. Main gear •... -
Page 6: Adding The Wind Shields
❏ 3. Put the plastic covers over the landing gear and fi x them ❏ 2. Install the levers on the fl aps of elevator and rudder with 4 screws. and adjust the linkage so, that servos and fl aps are in neutral position. -
Page 7: Mounting The Upper Wing
❏ 3. Cover the slots of the aileron servocables with ❏ 2. Roughen the splicing spots and keep them free of dust. transparent adhesive tape. First glue the struts to the fuselage and wait until the epoxy glue is hardened. MOUNTING THE UPPER WING ❏... -
Page 8: Receiver Installation
RECEIVER INSTALLATION GET THE MODEL READY TO FLY CHECK THE CONTROL DIRECTIONS ❏ 1. Turn on the transmitter and receiver and center the trims. If necessary, remove the servo arms from the servos and reposition them so they are centered. Reinstall the screws that hold on the servo arms. -
Page 9: Set The Control Throws
SET THE CONTROL THROWS BALANCE PROPELLERS Use a ruler to accurately measure and set the control throw of each control surface as indicated in the chart that follows. If your radio does not have dual rates, we recommend setting the throws at the low rate settings. NOTE: The throws are measured at the widest part of the elevators, rudder and ailerons. -
Page 10: Engine Safety Precautions
ENGINE SAFETY PRECAUTIONS CHECK-LIST Failure to follow these safety precautions may result During the last few moments of preparation your mind may in severe injury to yourself and others. be elsewhere anticipating the excitement of the first flight. Because of this, you may be more likely to overlook certain ❍... - Page 11 ❍ 13. Secure the pressure tap (if used) to the muffler with PERSONAL NOTES high temp RTV silicone, thread locking compound or J.B.Weld. ❍ 14. Balance your propeller (and spare propellers). ❍ 15. Tighten the propeller nut and spinner. ❍ 16. Place your name, address, AMA number and telephone number on or inside your model.
- Page 12 Distributed by...
