Aristel AV-8 System Administrator Manual

Hide thumbs Also See for AV-8:
Table of Contents

Advertisement

Quick Links

Aristel
Aristel
System Administrator's Manual
Arista Systems Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AV-8 and is the answer not in the manual?

Questions and answers

Related Manuals for Aristel AV-8

Summary of Contents for Aristel AV-8

  • Page 1 Aristel Aristel System Administrator’s Manual Arista Systems Corporation...

  • Page 2: Table Of Contents

    SYSTEM ADMINISTRATOR’S MANUAL Table Of Contents KEY TELEPHONE LAYOUT................3 KEY TELEPHONE STATION OPERATION ............5 ANSWERING CALLS ..................5 BABY LISTENING ..................5 BACKGROUND MUSIC ................5 CALL FORWARD ..................6 CALL SIGNAL ....................6 CALL SPLIT ....................6 CALL TRANSFER ..................7 CALL WAITING .....................7 CHECK IN / CHECK OUT ................8 CONFERENCE .....................8 DAY SWITCHING / NIGHT SWITCHING ............8 DATE / TIME SETTING.................8...
  • Page 3 REVIEW RS232 STATUS (C ) ..........18 ONSOLE SPEED DIAL ....................18 STATION OPERATION HELP LIST ............19 TOLL PASSWORD ..................19 VOICE MESSAGE ..................20 VOLUME / FREQUENCY CONTROL ............21 SINGLE LINE TELEPHONE STATION OPERATION ........22 ANSWERING CALLS................22 CALL FORWARD ..................22 CALL SIGNAL .....................23 CALL SPLIT ....................23 CALL TRANSFER ..................23 CALL WAITING ...................23...

  • Page 4: Key Telephone Layout

    A. KEY TELEPHONE LAYOUT For 15 Keys Model Aristel Features: Hook Switch Handpiece Wall Mount Clip Speaker Handset Cradle Dial Keypad Quick Reference Card Microphone Function Keys DSS Keys LCD Display Line Cord Jack Handset Cord Jack Table/Wall Mount Bracket...
  • Page 5 For 25 Keys Model Aristel Features: Hook Switch Handpiece Wall Mount Clip Speaker Handset Cradle Dial Keypad Quick Reference Card Microphone Function Keys DSS Keys LCD Display Line Cord Jack Handset Cord Jack Calculator Function (for 25 keys display Models only)

  • Page 6: Key Telephone Station Operation

    NOTE 1 NOTE 1: [#]+[4]+[0]+[1] = C.O. Line 1 [#]+[4]+[0]+[2] = C.O. Line 2 MODEL SPECIAL CODE …………………………………… #401 ~ #403 AV-8 [#]+[4]+[1]+[0] = C.O. Line 10 #401 ~ #404 AV-12 [#]+[4]+[1]+[1] = C.O. Line 11 #401 ~ #412 AV-38 ……………………………………...

  • Page 7: Call Forward

    4. CALL FORWARD All Incoming Call Forward Handset On Hook. Step 1: Step 2: Press DSS key assigned for [CFW] function in system Program Zone 500 and then enter [Forwarded Station Number], or press [FUNC] + [21] + [Forwarded Station Number].

  • Page 8: Call Transfer

    7. CALL TRANSFER Announced Transfer Step 1: During the call, press [HOLD] to put call on hold. Step 2: Dial required station number. Step 3: Wait for the called station to answer. Step 4: Hang up handset (refer to Program Zone 234). Unannounced Transfer (Camp On) Step 1: During the call, press [HOLD] to put call on hold.

  • Page 9: Check In / Check Out

    Step 4: Once the busy CO in CO queue is free it will recall to the call waiting station and can then be used when the station answers it. 9. CHECK IN / CHECK OUT (Console Only) Check in : Step1: On Hook, press[Func]+[DSS1]+[Ext.

  • Page 10: Do Not Disturb

    13. DO NOT DISTURB Step 1: Handset on Hook. Step 2: Press the DSS key assigned for Do Not Disturb [DND] function in Program Zone 500. Step 3: Repeat Step 2 to cancel. 14. DOOR PHONE Call Door Phone Step 1: Lift handset (or press [SPK] on Key Telephone) and listen for dial tone. Step 2: After dial tone is heard, dial [#]+[61] to call Door Phone 1 or [#]+[62] to call Door Phone 2, or press key programmed as Door Key in Program Zone 500.

  • Page 11: Non Enforced Account Codes/S

    18. NON ENFORCED ACCOUNT CODES/S (Refer to System Administrator’s Manual for programming details) Step1: During call, press [SAVE]+[Message Wait]+[Account Number]+[SAVE] 19. HAND MODE SWITCHING Handset To Handsfree Mode Step 1: Press [AT/MIC] DSS key assigned in Program Zone 500 during conversation and then hang up.

  • Page 12: Individual Alarm

    Retrieving Exclusive Hold External Calls Step 1: While call is on hold, lift handset or press [SPK]. Step 2: Press DSS key assigned for the held call (LED is slow Flashing as Green color) NOTE 10 or dial the held CO number by [SPECIAL CODE] NOTE 1 on page 1 NOTE 10: If retrieving the held call from other key telephone, lift the handset, and press DSS key assigned for the held call (LED is steady Red color) or dial the held CO...

  • Page 13: Internal Calls

    Individual Station Alarm (Console Only) Step 1: Handset on Hook. Step 2: Press [FUNC]+[REDIAL]. Step 3: Dial the number of the station to be alarmed. Step 4: Enter the alarm time and duration. Step 5: Press [SAVE] to exit. Own Station Alarm Step 1: Handset on Hook.

  • Page 14: Lock/Unlock Rs232 (Console Only)

    26. LOCK/UNLOCK RS232 (Console Only) Step 1: Lift handset, or press [SPK]. Step 2: Press [#]+[53] to lock or unlocked RS232. 27. MACRO KEY ASSIGNMENT (Console Only) Step 1: Handset on Hook. Step 2: Press [FUNC]+[7]. Step 3: Press one DSS key from [DSS16 ~ DSS25]. The key selected must be a key that has not already been programmed as a Function Key in Program Zone 500.

  • Page 15: Morning Call

    Step 5: Once the message is selected the message will also be displayed on the LCD of a calling station. Step 6: Repeat Steps 1 and 2 and press [SPK] to cancel the message. 30. MORNING CALL Individual Station Morning Call (Console Only) Step 1: Handset on Hook.

  • Page 16: Paging Note 18

    Step 1: Handset on Hook. Monitor Step 1: Lift handset and dial number. Step 2: If the station or CO line is busy, press [#]. Step 3: During monitoring, the monitoring party can hear the existing conversation from the two monitored parties but the monitored parties cannot hear the monitoring party. Override Step 1: Lift handset and dial number.

  • Page 17: Pick Up

    35. PICK UP All Pick Up Step 1: Lift handset or leave handset on Hook during other station ringing (only Key Telephones can use this function when On Hook). Step 2: Press [∗]+[0]. Group Pick Up Step 1: Lift handset or leave handset on Hook during other station ringing (only Key Telephones can use this function when On Hook).

  • Page 18: Releasing Calls

    Station Interface. (Please refer to Program Zone 502-PORT-IP) NOTE 21: MM = System Model AV-8 AV-12 AV-38 AV-64 (8 slots) AV-64H (10 slots) AV-256 NOTE 22: The model number of the PCB where System Software is located: System Model AV-8...

  • Page 19: Review Rs232 Status (Console Only)

    REVIEW RS232 STATUS (Console Only) Step 1: Handset on Hook. Step 2: Press [TRF/FL] twice (in AV-8/AV-12/AV-38/AV-64/64H), or press [TRF/FL] 3 times (in AV-256). SMDR is unlock NOTE 22 VER:SSSSPORT:P NOTE 22: If system’s RS232 output is locked will display “SMDR is lock”, if system’s RS232 output is unlock will display ‘SMDR is unlock”...

  • Page 20: Station Operation Help List

    NOTE 24: During entering of names, press [DSS3] to go back to the previous position or [DSS4] to go forward to the next position to enter another letter. Name Speed Dial Operation (Any Key Station) Step 1: Assign a DSS key to be the Name Speed Dial function key in Program Zone 500 = FUNC 74.

  • Page 21: Voice Message

    VOICE MESSAGE -12/AV-38 Once installed the Voice Card is active and ready for Programming/recording. AV-64/AV-256 After installation, scroll through Program Zone 502-PORT-02 for Voice Channel Number NOTE 25 NOTE 25: The voice channel numbers must be entered in Program Zone 600 and 601. Record messages by dialing that voice channel number and follow the display.

  • Page 22: Volume / Frequency Control

    AV-64/AV-256 Step 1: Install Voice Card. Step 2: Scroll through Program Zone 502 to find extensions allotted to each Voice Channel in Voice Card as Voice Channel Number. Step 3: Dial those Voice Channel Numbers (depending upon record copy capability) and record messages in Program Zone 402.

  • Page 23: Single Line Telephone Station Operation

    SINGLE LINE TELEPHONE STATION OPERATION ANSWERING CALLS External Call Step 1: During incoming ringing lift handset of ringing station, or dial the incoming CO number by using [#401~#440] NOTE 1 on page 1 Other Call Step 1: During the incoming ringing, lift the handset of ringing station. CALL FORWARD 1.

  • Page 24: Call Signal

    CALL SIGNAL Changing Voice to Ring or Ring to Voice (Default should be set in Program Zone 207, Type=0 or 1) Step 1: During calling , press [∗] to change calling signal from Voice to Ring or Ring to NOTE 28 Voice.

  • Page 25: Conference

    Step 4: Once the busy CO in the CO queue is free, it will recall to the Call Waiting station and can then be used when the station answers it. NOTE: Refer to Zone 245 CONFERENCE One External + One Internal Conference Step 1: During conversation with an external (or internal) party, press [FLASH] to place the call on hold.

  • Page 26: External Calls (See Outgoing Calls)

    Step 3: Hang up. To Cancel Do Not Disturb Step 1: Lift handset. Step 2: Press [#]+[762]. Step 3: Hang up. EXTERNAL CALLS (See Outgoing Calls) FORCED ACCOUNT CODE Step 1: Lift handset. Step 2: Dial [#]+[7]+[∗]. Step 3: Enter Forced Account Code number assigned in Program Zone 403. Step 4: The system will automatically select a free CO for outgoing calls.

  • Page 27: Lock/Unlock Your Telephone

    Step 2: Listen for dial tone. Step 3: Dial [0] or [9]. Hot Call (Only available when Program Zone 508 is set for this station) Step 1: Lift handset. Step 2: The assigned station will be called automatically. Manual Call (Only available when Program Zone 505, P=4 is enabled) Step 1: Lift handset to call operator.

  • Page 28: Override And Monitor

    Step 2: Listen for Intercom Dial Tone. Step 3: Dial [#401~#440] NOTE 1 on page 1 Step 4: Listen for CO line Dial Tone and then dial required telephone number. OVERRIDE AND MONITOR Cancel Override and Monitor Step 1: Handset on Hook. Monitor Step 1: Lift handset and dial number.

  • Page 29: Pick Up

    1 or 2 or 3 or 8 on Day or Night. Step 2: To set up the Password for the Incoming Paging Password in Program Zone 301-05. For example, Zone 305-05=”23dddddd”. Step 3: External party makes an incoming call to the system through DISA trunk. Step 4: Once the system has answering the incoming call, the external call can dial [#]+[1], followed by [Incoming Paging Password] to make paging to all internal stations.

  • Page 30: Speed Dial

    SPEED DIAL Individual Speed Dial Programming Step 1: Lift handset. Step 2: Press [#]+[78]. Step 3: After a one-second tone is heard, enter Individual Speed Dial Code [0~9]. Step 4: Enter [00] for first available trunk line or CO Number for a specific Line. Step 5: Enter telephone number.

  • Page 31: Arista Systems Corporation

    Arista Systems Corporation. The information contained herein is subject to change without notice at the discretion of Arista Systems Corporation. Copyright 2001 by Arista Systems Corporation All rights reserved Arista Systems Corporation http://www.aristel.com...
