Aristel AV-96 System Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
System Installation Manual
1
GENERAL DESCRIPTION.........................................................................................................1
2
SYSTEM'S SPECIFICATION .....................................................................................................2
2.1
2.2
'
2.3
2.4
2.5
3
PREPARATION & NOTE FOR THE SYSTEM'S INSTALLATION ...............................................6
3.1
3.2
3.3
4
AV-96 PCB & CABINET LAYOUT ..............................................................................................7
4.1
4.2
-
4.3
4.4
4.5
4.6
4.7
4.8
4.9
4.10
4.11
4.12
4.13
4.14
4.15
-
5
AV-96 SYSTEM WIRING & INSTALLATION.............................................................................22
5.1
5.2
5.3
5.4
5.5
5.6
5.7
-
...........................................................................................................2
.......................................................................................2
...............................................................................................................4
.....................................................................................5
..........................................................................................................6
-
V
...............................................................................................9
(A9MBUA) ............................................................................. 11
(A9PWUA)..........................................................................................12
(A9MPUA)..........................................................................13
(A9TKUA)............................................................................................14
(D1CIDC) .....................................................................................15
(A9STUA)........................................................................16
(A9SLUA) ...................................................................................17
(A9HYUA)..............................................................................18
(A9VSCA)..............................................................................19
(A6RPCA).................................................................20
(A6MFCA)............................................................................21
AC/DC.................................................................................22
-
......................................................................................................24
....................................................................................26
....................................................................................27
......................................................................................28
CONTENT
..................................................................................3
...............................................................................6
......................................................6
..............................................................................7
...............................................................................8
.....................................................................10
..................................................................23
.............................................................25
.....................................................................29
96
AV

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AV-96 and is the answer not in the manual?

Questions and answers

Related Manuals for Aristel AV-96

Summary of Contents for Aristel AV-96

  • Page 1: Table Of Contents

    PREPARATION & NOTE FOR THE SYSTEM’S INSTALLATION ..........6 ................6 REPARATION FOR YSTEM NSTALLATION ............6 PECIAL EQUIREMENTS FOR NSTALLATION NVIRONMENT ......................6 QUIPMENT EMARKS AV-96 PCB & CABINET LAYOUT ....................7 AV-96 T ................7 HREE DIMENSIONAL AYOUT AV-96 B ................8 UILT TANDARD AYOUT AV-96 I ....................9...
  • Page 2 System Installation Manual AV-96 M —D ..........30 ULTI FUNCTION ELAY WITCH NSTALLATION AV-96 E ..............31 XTERNAL USIC OURCE NSTALLATION 5.10 AV-96 E ................32 XTERNAL AGING NSTALLATION 5.11 AV-96 RS232 (SMDR) I ..................33 NSTALLATION CONTENT...

  • Page 3: General Description

    AV-96 KTS is of a cards insertion designs. The ports of Mother Board, Power Unit, Trunk/station Unit and peripherals act independently. All system’s ports use RJ45 Module Connector Wiring disregarding the traditional wiring method.

  • Page 4: System's Specification

    2.2 System’s General Specification The trunk cards and station units should be installed at any 12 free I/O interface slots. All the peripherals cards should be installed at the specified sockets. Expansion Maximum AV-96 Basic Capacity Capacity Capacity Co Line...

  • Page 5: System ' S General Specification

    System Installation Manual Electrical & Other Specifications AV-series AV-96 Input AC Voltage AC100 240 50/60hz System 170W Power Key Telephone 1~2W Consumption 0.85W Door Phone 0.5W System Power Back-up Battery 7AH 1~2 hours Outgoing Dialing Tone / Pulse Dialing Signal...

  • Page 6: System Modules

    System Installation Manual 2.4 System Modules Model No. Description Remark A9-96A MAIN EQUIPMENT, consisting of (A9CBMA + A9MPUA) Standard Shipment MAIN CABINET, consisting of (Plastic Cabinet + A9MBUA + A9CBMA Spare Part A9PWUA) A9PWUA SWITCHING POWER SUPPLY UNIT Spare Part A9MBUA MOTHER BOARD UNIT, consisting of 12 I/O slots.

  • Page 7: System Capacity Configurations

    System Installation Manual 2.5 System Capacity Configurations Station Unit Quantity System capacity (Key Phone /SLT/Hybrid Station Unit; but only one pieces of Hybrid Station can be installed.) Trunk Unit Qty 1208 1216 1224 1232 1240 1248 1256 1264 1272 1608 1616 1624 1632...

  • Page 8: Preparation & Note For The System's Installation

    System Installation Manual Preparation & Note for the System’s Installation 3.1 Preparation for System Installation Please check whether the system capacity and the quantity of phones are suitable or not. Please prepare the necessary wires and instruments for installation. Please carefully read this manual before installation and follow up the procedures of installation on this manual.

  • Page 9: Pcb & Cabinet Layout

    AC Power Connector Fan Installation Hole Fuse Socket Battery Connector Main Cover Cabinet Handhold Side Cover System Wiring Outlet Main Cover Screw Socket Installation Socket Radiator Hole Chart 1 AV-96 Three-dimensional View Layout System dimensions mm : 440mm 305.6mm 202mm...

  • Page 10: Built-In Standard Rack Layout

    System Installation Manual 4.2 AV-96 Built-in Standard Rack Layout CO/Station Line Port RS232 Port External music/Paging Interface Wire harness Hole Peripherals Wiring Outlet Fixed to Rack Cabinet Handhold Hole Chart 2 AV-96 built-in Standard Rack Layout...

  • Page 11: Inter-Circuit Layout

    A9STUA, A2SLUA or A9HYUA Chart 3 AV-96 Inter-circuit Layout AV-96 Maximum Capacity: 96 Ports/12 free I/O interface slots CO Line Max. Capacity: 20 Ports Station Line Max. Capacity: 96 Ports (Key phone, SLT Station or Hybrid Station unit. But only...

  • Page 12: System Wall Mounting Installation

    Hanging measure scale Side Cover inside View Chart 4 AV-96 System Wall Mounting Installation System Suggested to be installed 10cm or more above ground, avoiding humidity. There are the two-way hanging measure scales on the inside-surface of System Side Cover,...

  • Page 13: Mother Board Unit (A9Mbua)

    12 free I/O interface slots for A9TKUA, Unit Slot A9STUA, A2SLUA or A9HYUA Chart 5 AV-96 Mother Board Unit A9MBUA A9MPUA and A9PWUA should be installed at the specified slots. The Station cards (A9STUA, A9HYUA or A9SLUA) can be installed at any 12 free I/O interface slots on A9MBUA.

  • Page 14: Power Unit (A9Pwua)

    Fan Power AC Power Battery Connector Connector Switch Connector Power Fuse 5A /250V Power Unit Output Pin designation Chart 6 AV-96 Power Unit A9PWUA This switching power provides Power Factor Correction (PFC). A9PWUA is a Full-Range Power Unit with AC100V~240V.

  • Page 15: Main Processing Unit (A9Mpua)

    Jumper Program protection Battery Chart 7 AV-96 Main Processing Unit (A9MPUA) A9MPUA should be inserted in the specified Slot on A9MBUA. System Main Program IC is inserted on A9MPUA. There are standard RS232, external music source and external paging ports on A9MPUA.

  • Page 16: Trunk Unit (A9Tkua)

    The Jumper to Select the Position of A9TKUA in the System Chart 8 AV-96 Trunk Unit (A9TKUA) A9TKUA should be installed at any free slot from IO1 to IO5 on A9MBUA in sequence. The jumper to select the position of A9TKUA in the system should be corresponding with the CO Line Expansion Jumper (See Table 5) on A9MPUA.

  • Page 17: Caller Id Card (D1Cidc)

    4.9 AV-96 Caller ID Card (D1CIDC) Socket Chart 9 AV-96 Caller ID Card (A9CIDC) Each DICIDC can be added to one A9TKUA CO Line. Caller ID function as well as incoming call forward can be supported not only key phone but...

  • Page 18: Key Phone Station Unit (A9Stua)

    4.10 AV-96 Key Phone Station Unit (A9STUA) Key Phone Station Line Port Chart 10 AV-96 Key Phone Station Unit (A9STUA) A9STUA can be installed at any free slots from IO1 to IO12 on A9MBUA. Each A9STUA contains 8 Key Phone station ports.

  • Page 19: Slt Station Unit (A9Slua)

    4.11 AV-96 SLT Station Unit (A9SLUA) SLT Station Line Port Chart 11 AV-96 SLT Station Unit (A9SLUA) A9SLUA can be installed at any free slot from IO1 to IO12 on A9MBUA. Each A9SLUA contains 8 Standard SLT station ports. All the station ports have short-circuit protector.

  • Page 20: Hybrid Station Unit (A9Hyua)

    System Installation Manual 4.12 AV-96 Hybrid Station Unit (A9HYUA) Hybrid Station Line Port Chart12 AV-96 Hybrid Station Unit (A9HYUA) A9HYUA can be installed at any free slot from IO1 to IO12 on A8MBUA. Each A9HYUA contains 8 station line ports, which was designed as hybrid ports for key phone or SLT.

  • Page 21: Voice Service Card (A9Vsca)

    Channel To adjust the playing Voice volume Chart 13 AV-96 Voice Service Card (A9VSCA) 2 pieces of Voice Service Card (A9VSCA) can be installed on the system. Each A9VSCA has 2 voice channels. Total 4 channels are usable. A9VSCA should be installed at the designed socket on system’s mother board.

  • Page 22: Remote Programming Card (A6Rpca)

    System Installation Manual 4.14 AV-96 Remote Programming Card (A6RPCA) Chart 14 AV-96 Remote Programming Card (A6RPCA) The system offers the function of Remote Programming maintenance. After installing A6RPCA in this system with PC and SM (system’s expert management program), the Remote Programming function will be workable.

  • Page 23: Multi-Function Card (A6Mfca)

    System Installation Manual 4.15 AV-96 Multi-function Card (A6MFCA) Chart14 AV-96 Multi-function Card (A6MFCA) Multi-function card (A6MFCA) provides 2 Door phone, 2 Relay and 2 Sensor interfaces. The application of multi-function sensor or relay needs the proper system software upon request.

  • Page 24: System Wiring & Installation

    External Battery Connector (Male) AC Power Input 100 240V External Battery (DC: 24V) Chart 16 AV-96 Power Installation AC/DC System Input AC Voltage: Full range of AC100 240 Back-up Battery: 24VDC System Maximum Power Consumption: 170W Working Temperature 0 ~45...

  • Page 25: System Back-Up Battery Installation

    Aristel Back-up Battery Back-up Battery Jumper Chart 17 AV-96 Back-up Battery Activation Installation Back-up Battery Jumper is jumped to “OFF” when ex-factory. Before start-up the system, Back-up Battery Jumper should be jumped to “ON”, so as to protect the programmed information from losing when power failure.

  • Page 26: Co Line Wiring

    A9TKUA Insert to Mother Board Unit (A9MBUA) Chart 18 AV-96 CO Line Wiring Each Trunk Unit (A9TKUA) contains 4 CO line ports. Maximum 5 pieces of A9TKUA (20 ports CO lines) can be installed. A9TKUA is equipped with RJ45 module connector.

  • Page 27: Power Failure Transfer (Pft) Phone Wiring

    Unit (A9MBUA) Connector Chart 19 AV-96 Power Failure Transfer (PFT) Phone Wiring Each CO Line each has an in-bridge port, the connector of the in-bridge port is same with SLT port. When power fails, please pull out the RJ45 connector on A9SLUA and insert into the Power Failure Transfer Phone port on A9TKUA, so as to normally use the CO Line.

  • Page 28: Key Phone Station Wiring

    Insert to Mother Board 7 AR 8 BT Unit (A9MBUA) Chart 20 AV-96 Key Phone Station Wiring ! ! ! ! Each Key Station Unit (A9STUA) contains 8 key phone ports. Every RJ45 can be connected to 2 pieces of key phone.

  • Page 29: Single Line Station Wiring

    SLT 2 : (6 AT 7 AR) Unit (A9MBUA) Chart 21 AV-96 Single Line Station Wiring Each Single Line Station Unit (A9SLUA) contains 8 SLT ports. Every RJ45 can be connected 2 pieces of SLT. There are maximum 12 pieces of A9SLUA (96ports SLT) can be installed in the system.

  • Page 30: Door Phone Installation

    2-Conductor Wiring A6MFCA Insert to Mother Board Unit (A9MBUA) Chart 22 AV-96 Door Phone Installation (DOOR1, DOOR2) ports are located on A6MFCA (Standard 2-conductor wiring door phone, with non-polarity). The system offers two door phone installation interfaces (DOOR1, DOOR2). Also refer to the System Programming Zone 602.

  • Page 31: Multi-Function Sensor Installation

    System Installation Manual 5.7 AV-96 Multi-function Sensor Installation Sensor (2-Conductor Wiring) A6MFCA Insert to Mother Board Unit (A9MBUA) 23 AV-96 Multi-function Sensor Installation (SEN1, SEN2) ports locate on A6MFCA (Standard 2-conductor wiring, with non-polarity). The system offers two multi-function sensor installation interfaces (SEN1, SEN2).
  • Page 32 Insert to Mother Board Unit (A9MBUA) Chart 24 AV-96 Multi-function Relay—Door Switch Installation The application of the Relay can be changed by the system programming. Built-in 2-conductor wiring for this installation. For the details of wiring, please see above chart 24.
  • Page 33 Music Music Unit (A9MBUA) Chart 25 AV-96 External Music Source Installation External music source (Volume Adjustable) input is located on A9MPUA. The system offers a group of external music source input. When using external music source as MOH or BGM, Internal/External Music Source Jumper...
  • Page 34 Connect to Music A9MPUA Source/Paging Insert to Mother Board Unit (A9MBUA) Chart 26 AV-96 External Paging Installation External paging input (EXT PAGE) is located on the A9MPUA. The system offers a group of external paging. 2 wires are used for external paging.
  • Page 35 A9MPUA Insert to Mother Board Unit (A9MBUA) Chart 27 AV-96 RS232 SMDR Installation The system provides 1 RS-232 output outlet. RS-232 output port is located on A9MPUA, using a 6-conductor RJ11 connector. RS-232 port provides the functions of SMDR and PC-online system programming maintenance.
  • Page 37 Key Telephone System AV-96 System Installation Manual...
  • Page 39 DOC : AV-96 System Installation Manual Edition Version: 1.0 Editor : Sherry Wang Date : 2005/09/01...
