Aristel AV256 Installation Manual

Hide thumbs Also See for AV256:
Table of Contents

Advertisement

Quick Links

Download this manual See also: System Administrator Manual
256
256
AV
AV
A
r
i
s
t
e
l
N
e
t
w
o
r
k
s
A
r
i
s
t
e
l
N
e
t
w
o
r
k
s

INSTALLATION GUIDE

Aristel Networks Pty Ltd
Unit 1, 25 Howleys Rd.
Notting Hill VIC 3168
Telephone:
03 9542 2300
Facsimile:
03 8544 3299
Aristel Networks Issued March 2001
AV256
Version number 1.0 issued March 2001
System Installation Manual
page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AV256 and is the answer not in the manual?

Questions and answers

Related Manuals for Aristel AV256

Summary of Contents for Aristel AV256

  • Page 1: Installation Guide

    System Installation Manual AV256 INSTALLATION GUIDE Version number 1.0 issued March 2001 Aristel Networks Pty Ltd Unit 1, 25 Howleys Rd. Notting Hill VIC 3168 Telephone: 03 9542 2300 Facsimile: 03 8544 3299 Aristel Networks Issued March 2001 page 1...

  • Page 2: Table Of Contents

    9.12 A4VSUA (V ................21 OICE ERVICE 9.13 A2RSCA (RS232 CARD, SMDR S ) ........21 ERIAL ESIGN 9.14 A2RPCA (R ) ............... 22 EMOTE ROGRAMMING 9.15 A2MFCA (M ) ................. 23 ULTI UNCTION Aristel Networks Issued March 2001 page 2...

  • Page 3: Specifications Are Subject To Change Without Notice

    NSTALLATION SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE Introduction This manual provides detail procedures for installing the Aristel Aristel AV-256. Read this entire section before proceeding with the actual installation. The National Electrical Code (NEC) requires the Local operation telephone company (teleco) to provide primary protection devices on telephone lines terminated at customer’s site.

  • Page 4: Equipment Requirement

    1-pair or 2-pairs or 3-pairs from the end of male Amphenol cable to the connecting blocks to the terminals. Connect the plugs from RJ11 jack on CO Line Interface to the exchange CO Line for connecting external CO Line. Aristel Networks Issued March 2001 page 4...

  • Page 5: System Modules

    Optional Card design) 5. TYPES OF KEY TELEPHONE Model Description Color 15 Buttons Key Telephone KP10XW STANDARD PHONE (without LCD and Handsfree) White KP10XHW STANDARD HANDSFREE PHONE (without LCD, but with White Handsfree) Aristel Networks Issued March 2001 page 5...
  • Page 6 BIG LCD DELUXE PHONE (with Big LCD and Handsfree) Charcoal 64 Buttons Console Phone DSS64W DSS CONSOLE PHONE (with 64 DSS buttons only) White DSS64C DSS CONSOLE PHONE (with 64 DSS buttons only) Charcoal Aristel Networks Issued March 2001 page 6...

  • Page 7: Specification

    0~2 (per cabinet) Relay Switches 0~16 Sensor Interfaces 0~16 Fax Monitor 0~10 System Battery Charger Interface 0~1 (per cabinet) RS232 for SMDR Remote Programming Speed Dial 0~1200 External Music External Paging Intercom Paths (Local) 0~48 Aristel Networks Issued March 2001 page 7...

  • Page 8: Electrical & Other Specifications

    Key Telephone Dimension (mm) Working Temperature C ~ 45 C (32 F ~ 113 Working Humidity 10% ~ 90% relative non-condensing Switch Mode Space Division Matrix (SDM) Control Mode 8/16 bits CPU, Registered Program Aristel Networks Issued March 2001 page 8...

  • Page 9: Features List

    Door Switch (Open/Close) Door Phone Connection Dual-Direction Amplifier Easy Installation And Operation Exclusive Hold Recall Fax Monitor Flash Time Setting Flexible Ringing Flexible Expansion Flexible Function Key Setting Forced Account Code Help List Aristel Networks Issued March 2001 page 9...
  • Page 10 Speed Dial For Both System And Private Station Message Detail Record (SMDR) Switching Link Maintenance System Battery Back Up For Data System Data Initial System Data Print Out Text Message Time-Reminding Service Toll Restriction Aristel Networks Issued March 2001 page 10...

  • Page 11: Station Features List

    Do Not Disturb (DND) Door Switch Sensor Control Door Phone Call Signaling Dual Color LED Flash (Open Loop Time Flash) Forced Account Code Door Phone External Music Source External Paging Equipment Forced Account Code Aristel Networks Issued March 2001 page 11...
  • Page 12 Photo Interrupted For Hook Switch Privacy Release Pulse/Tone Conversion Save Number Redial Speed Dialing Speed Dial Number Storage Station Lock/Unlock Station Morning Call Service Toll Restriction Tri-Status LED Indication Trunk Queuing Volume Digital Control Zone Paging Aristel Networks Issued March 2001 page 12...

  • Page 13: Pcb And Cabinet Layout

    Screw hole Radiator hole AC power connector Figure 1.1 AV-256 System Three-Dimensional Layout 1. System dimension 555mm W × 228mm D × 400mm H 2. System AC Power 115/230VAC ± 10%, 60/50 Hz Aristel Networks Issued March 2001 page 13...

  • Page 14: System One Cabinet Inter -Circuit Layout

    System Installation Manual 9.2 AV256 System one cabinet Inter-Circuit Layout AC Power Switch A4MBUA AC Power FUSE AC Power Indication LED DC Power FUSE DC Power Switch DC Connector A4MPUA A2PSUA A4IPUA 8 I/O Interface Slots for A2TKUA or A4STUA...
  • Page 15 ON and other mini switches must be OFF. Figure 1.3 AV256 (two cabinets) Installation Layout AV-256 (two cabinets Max. Capacity): 128 Ports / 16 Slots CO Line (two cabinets Max. Capacity): 40 Intercom Line (two cabinet Max. Capacity): 128...
  • Page 16 System Installation Manual Aristel Networks Issued March 2001 page 16...

  • Page 17: System Three Cabinets Inter-Circuit Layout

    System Installation Manual 9.2.2 AV256 System three cabinets Inter-Circuit Layout Connective Cable Dip Switch for the setting of the cabinet’s position number. In the 1 cabinet, the 1 mini switch must be ON and other mini switches must be OFF.

  • Page 18: System Wall Mounting Installation

    Intercom Line (four cabinets Max. Capacity): 256 9.3 AV-256 System Wall Mounting Installation Wall Mounting Position Hole Front Cover Wall Mounting Hole Figure 1.6 AV-256 System Wall Mount Layout 9.4 A4MBUA (Mother Board Unit) A4MBUA Aristel Networks Issued March 2001 page 18...

  • Page 19: A2Psua /A2Pwua (Switching Power Supply)

    System Installation Manual Figure 1.7 A4MBUA 9.5 A2PSUA /A2PWUA (Switching Power Supply) AC Power Input Output Power Trimming Power Fuse Power Output Connecter Aristel Networks Issued March 2001 page 19...
  • Page 20 System Installation Manual brown black blue white green white green black brown blue Figure 1.8 A2PWUA Module Layout Aristel Networks Issued March 2001 page 20...

  • Page 21: A4Mpua

    11111111 11111111 11111111 11111111 1111 2 pcs. 00001111 11111111 11111111 11111111 1111 3 pcs. 00000000 11111111 11111111 11111111 1111 4 pcs. 00000000 00001111 11111111 11111111 1111 10 pcs. 00000000 00000000 00000000 00000000 0000 Aristel Networks Issued March 2001 page 21...

  • Page 22: Unit

    System Installation Manual 9.7 A4IPUA (Interface Processing Unit) For RS232 connection For A2MFCA connection RS232 output connector EPROM ; for IPU software The indication lamp to perform the system is working Figure 1.10 A4IPUA Aristel Networks Issued March 2001 page 22...

  • Page 23: A2Tkua

    Note If A2TKUA is installed in the first position among A2TKUA cards, it’s CON1 must be all shorted by jumpers. If A2TKUA is installed in the second position among A2TKUA cards, then it’s CON2 must be shorted by jumpers, and so on Aristel Networks Issued March 2001 page 23...

  • Page 24: A4Stua

    Insert to any slot from IO1 to IO8 of the system The indication lamp for A4STUA is working if it is flashing Figure 2.7 A4STUA (for AV256) 9.10 A4SLUA (Single Line Station Unit) WP5007 connector Insert to any slot from IO1...

  • Page 25: A4Slua/C

    Insert to any slot from IO1 to IO8 of the system The indication lamp for the engaged Station Figure 1.13 A4HYUA Consisting of (2 Key Station Ports) + (6 Single Line Station Ports) and One Port Aristel Networks Issued March 2001 page 25...
  • Page 26 System Installation Manual per Station. Aristel Networks Issued March 2001 page 26...

  • Page 27: A4Vsua

    Recording or Playing Figure 1.14 A4VSUA PS: consisting of 4 Voice Channels (60 seconds per channel) 9.13 A2RSCA (RS232 CARD, for SMDR & Serial Port) Connect to A2MAUA RSC1/RSC2 Aristel Networks Issued March 2001 page 27...

  • Page 28: A2Rpca (Remote Programming Card)

    System Installation Manual Figure 1.15 A2RSCA 9.14 A2RPCA (Remote Programming Card) Connect to A4MPUA RPU1/RPU2 Aristel Networks Issued March 2001 page 28...

  • Page 29: A2Mfca (Multi Function Card)

    System Installation Manual Figure 3.5 A2RPCA (for AV64/256) 9.15 A2MFCA (Multi Function Card) Connect to A4MPUA Figure 1.16 A2MFCA Note S1~S4 ; for external sensors connection. S1 is for the 1 sensor, S2 is for Aristel Networks Issued March 2001 page 29...

  • Page 30: Wp5007 Wiring

    No Connection Pin24 No Connection Pin49 No Connection Pin25 No Connection Pin50 No Connection 10. System Installation 10.1 System Back-up Battery Installation System Back-Up Battery Installation Female Connector System Back-Up Battery Male Connector Aristel Networks Issued March 2001 page 30...
  • Page 31 System Installation Manual Figure 1.17 Battery Back-Up Installation Layout Aristel Networks Issued March 2001 page 31...

  • Page 32: Fax Machine Installation

    There is one FAX path in each A2TKUA interface card. The path is controlled by FAX Monitor ability. The FAX path is paralleled with the forth trunk (CO4) in each A2TKUA. § Using 2-conductor wiring cable to the fifth RJ11 Jack (FAX) on A2TKUA. Aristel Networks Issued March 2001 page 32...

  • Page 33: Key Telephone Installation

    System Installation Manual 10.3 Key Telephone Installation 10.3.1 General key Station Installation 66M1-50 Type Terminal Block A2STUA/A4STUA Phone Box 4-Conductor 4-Conductor Module Connector Wiring Cord Insert to any slot of the System WP 5007 Aristel Networks Issued March 2001 page 33...
  • Page 34 System Installation Manual Figure 3.9 General Key Station Installation Layout Aristel Networks Issued March 2001 page 34...

  • Page 35: Ohca Key Station Installation

    OR/OT: Audio Pair of OHCA, OR = Receiving (White Color), OT = Transmission (Blue Color). This Audio pair is and must be come from “AT8” and “AR8” which is for the eight (8th) Key Station. Aristel Networks Issued March 2001 page 35...

  • Page 36: Single Line Telephone Installation

    Insert to any slot of the System WP5007 20-pairs Figure 4.1 Single Line Telephone Installation Layout Male Connector 10.4 Door Phone Installation A4MPUA Insert to the slot of MAUA/B of the System 2-Conductor Wiring Cord Aristel Networks Issued March 2001 page 36...

  • Page 37: External Music Source Installation

    System Installation Manual Figure 1.20 Door Phone Installation Layout 10.5 External Music Source Installation A4MPUA Insert to the slot of MAUA/B of the System Aristel Networks Issued March 2001 page 37...

  • Page 38: External Paging Equipment Installation

    After External Music Source has been installed, it is necessary to select the external melody is for Background Music or Music On Hold by Jumper Selection on A4MPUA. 10.6 External Paging Equipment Installation A4MPUA Insert to the slot of A4MPUA of the System Aristel Networks Issued March 2001 page 38...

  • Page 39: Multifunction Card Installation

    § Connect 2-conductor wiring cord from External Paging Equipment to “External Page” connector on A4MPUA. Please refer to Figure 4.4. 10.7 Multifunction Card Installation A2MFCA Figure 1.23 A2MFCA Installation Layout 10.8 RS232 Installation Aristel Networks Issued March 2001 page 39...
  • Page 40 Modular Connector and D-type Connector according to Figure 4.6. § Connect 6-Conductor Modular Connector with 6-Conductor Wiring Cord to RS232 port on A4IPUA; and connect D-type Connector to Serial Printer With RS232 Interface as in Figure 4.6. Aristel Networks Issued March 2001 page 40...
