Aristel Networks Pty Ltd
C-710 DECT Feature Phone
User Guide

1. GENERAL

The C710 is a desktop DECT GAP compatible handset.
The handset can be registered up to maximum of 4 different DECT GAP compatible base
stations. However, only one base station can be linked at a time. Roaming is NOT available.
Important note: some base station features may be unavailable because of proprietary service
menus and features associated with a particular base stations.

2. INSTALLATION

2.1. Battery

Before you use the unit for the first time, you must make sure the battery are charged for at least 10
hours. If you don't do this, the telephone will not function properly.
Installation of the battery
- Plug in the battery into compartment located in the rear of the unit.
Important Note: Only use the power supply unit provided to charge the battery.
Battery indicator:
The battery is 25% in capacity.
The battery is almost empty.
When the battery is low, you will hear warning signals and the battery symbol on the
display will blink.
Accessories Include :
DESK Handset ( 1 ), Battery ( 1 ) ,Adaptor ( 1 ) , User Guide ( 1 )
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C-710 and is the answer not in the manual?

Questions and answers

Related Manuals for Aristel C-710

Summary of Contents for Aristel C-710

  • Page 1: Aristel Networks Pty Ltd

    When the battery is low, you will hear warning signals and the battery symbol on the display will blink. Accessories Include : DESK Handset ( 1 ), Battery ( 1 ) ,Adaptor ( 1 ) , User Guide ( 1 ) C-710 DECT Feature Phone User Guide...
  • Page 2 2.2. Keypad 2.5. Register this unit to a DECT GAP base station Power On/Off Caller ID - List the caller ID and missed call Every new unit must be registered onto a DECT GAP base station before you can make Phone book - List the telephone number stored in phone book a phone call.
  • Page 3 3.4.2. Transferring an call to another handset 3.9. Memory dial M1~ M6 You can transfer an internal or external call to another handset. Answer the call. Press INT/OK key and then a handset No. Hang up the handset to disconnect the call and transfer the call to the called handset The call has now been transferred.
  • Page 4 5. PHONEBOOK 5.3. Changing a number and name from the Phonebook Press UP/DOWN key when the unit is in standby mode.. 5.1. Use of the alphanumerical keypad Select PHONE BOOK by using the UP and DOWN keys. Use the alphanumerical keypad to enter text. To select a letter, press the corresponding button. For Press INT/OK key to confirm.

  • Page 5: Handset Settings

    5.6. Erasing all numbers and name from the Phonebook 6. HANDSET SETTINGS Press UP/DOWN key when the unit is in standby mode. 6.1. Key lock Select PHONE BOOK by using the UP and DOWN keys. Press INT/OK to confirm. Select ERASE ALL by using the UP and DOWN keys. Press INT/OK key to confirm.
  • Page 6 6.4. Enable/disable the baby call function 6.7. Set PIN Code If you enable this function, the programmed number will be dialed automatically To change default handset PIN code. when pushing any keys. Press UP/DOWN key when the unit is in standby mode.. All other functions of the keypad will be disabled until the setting has been cancelled.

  • Page 7: Technical Data

    6.10. ERASE Caller List 7. TECHNICAL DATA • Standard: DECT ( Digital Enhanced Cordless Telecommunications ) GAP ( Generic Access Profile ) • Frequency range: 1880 ~~ 1900 MHz (BW=20MHz) • RF channels: 10 channels Press UP/DOWN key when the unit is in standby mode. •...
