Aristel DV-38 Installation Manual

Hide thumbs Also See for DV-38:
Table of Contents

Advertisement

Quick Links

See also: System Installation Manual , User Manual
System Installation Manual
A
r
i
A
r
i
N
e
t
N
e

INSTALLATION GUIDE

Version number 1.1 issued November 2004
Aristel Networks Pty Ltd
Unit 3A, 100 Station Street
Nunawading VIC 3161
Telephone: 03 9837 2300
Facsimile:
03 9872 4433
Arista Systems Corporation
s
t
e
s
t
e
w
o
t
w
o
DV38
l
l
r
k
s
r
k
DV-38
s
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DV-38 and is the answer not in the manual?

Questions and answers

Related Manuals for Aristel DV-38

Summary of Contents for Aristel DV-38

  • Page 1: Installation Guide

    DV-38 System Installation Manual DV38 INSTALLATION GUIDE Version number 1.1 issued November 2004 Aristel Networks Pty Ltd Unit 3A, 100 Station Street Nunawading VIC 3161 Telephone: 03 9837 2300 Facsimile: 03 9872 4433 Arista Systems Corporation...

  • Page 2: Table Of Contents

    DV-38 System Installation Manual INTRODUCTION .....................4 GENERAL DESCRIPTION ................5 SYTEM CONFIGURATION................7 ..............7 YSTEM APACITY AND PECIFICATIONS KEY TELEPHONE SPECIFICATION..............8 SYSTEM MODEL DESCRIPTION ................9 FEATURE LIST.......................10 ENVIROMENTAL REQUIREMENT ...............12 EQUIPMENT REQUIREMENT ..............13 POWER SUPPLY AND KSU INSTALLATION..........14 PCB AND CABINET LAYOUT ..............15 D1MBUB (M ) ................16...
  • Page 3 DV-38 System Installation Manual D1STUB............42 NALOGUE EYPHONE IRING FOR 50 P (25 P ........43 AIRS MPHENOL ONNECTOR AYOUT D1SLCB .............44 INGLE HONE IRING ..............45 IRES HONE NSTALLATION .....................46 ENSOR NSTALLATION ...................47 WITCH NSTALLATION ..............48 XTERNAL USIC OURCE NSTALLATION RS232（SERIAL PRINTER PC）I...

  • Page 4: Introduction

    DV-38 System Installation Manual INTRODUCTION This manual provides detailed procedures to install your new ARISTEL DV-38 Digital Key Telephone System. Please read this entire section before proceeding with the actual installation. The National Electrical Code (NEC) requires the local telephone company (Telecom) to provide the primary protection devices for the telephone lines terminating at the customer’s site.

  • Page 5: General Description

    PCBs. All functions are able to be programmed to Macro keys, enabling complex functions to covert into single-keypad operation. This is an excellent option for the new digital age; Aristel DV-38 is the best partner to lead you into the diverse broadband world of telecommunications...
  • Page 6 DV-38 System Installation Manual Aristel DV-38 Digital Intelligent Key Phone System Multiple Processors. Time Division Multiplexing. Unique ARISTEL ASIC Chip “A-SERIES” Arista Systems Corporation...

  • Page 7: Sytem Configuration

    DV-38 System Installation Manual SYSTEM CONFIGURATION System Capacity and Specifications Expandable DV-38 Basic Capacity Max. Capacity Capacity POTS CO Line ISDN (BRI) 0 ~ 6 Digital 16/0 24/0 Key phone Analog 0/16 0/24 Single Line Phone Auto Attendant Voice Service...

  • Page 8: Key Telephone Specification

    DV-38 System Installation Manual KEY TELEPHONE SPECIFICATION DIGITAL KEY TELEPHONE Key Phone Model DKP30 DKP31 DKP32 DKP33 DKP50 DKP51 DKP52 DKP53 DSS Function Key 12 Keys 12 Keys 12 Keys 12 Keys 25 Keys 25 Keys 25 Keys 25 Keys 2 * 16 digits LCD …...

  • Page 9: System Model Description

    DV-38 System Installation Manual SYSTEM MODEL DESCRIPTION Model Description Remark Main Service Unit - Consisting of Plastic Cabinet + D1MBUB + D1-408DK Standard Shipment D1PWUA + D1TKUC + D1DLUB Main Service Unit - Consisting of (Plastic Cabinet + D1MBUB +...

  • Page 10: Feature List

    DV-38 System Installation Manual FEATURE LIST System Features List 3 Parties Conference Intercom Busy Reminder 5 Different Trunk Access Codes Incoming Hunting Account Code Incoming Paging Auto Attendant Intercom Hunting Auto Accessing Trunk Internal/External Music Source Automatic Answer Internal/External Paging...
  • Page 11 DV-38 System Installation Manual Station Features List 16×2 Dot-Matrix LCD Display Ergonomics Receiver Handset 5 Different Numbers Auto Redial Handsfree Dialing 9 Different Ringing Frequencies on Handsfree Conversation Key Station Hold/Exclusive Hold Adjustable LCD Angle (DKP50) Last Number Redial Back Light LCD Display...

  • Page 12: Enviromental Requirement

    DV-38 System Installation Manual ENVIROMENTAL REQUIREMENT The Key System Unit (KSU) should be installed at a clean, dry and secure location accessible only by authorized personnel. The location must have adequate ventilation and a temperature range between 0 ~ 45 C with a 10 ~ 90% non-condensing relative humidity.

  • Page 13: Equipment Requirement

    DV-38 System Installation Manual EQUIPMENT REQUIREMENT Prior to installation, carefully inspect all packages for evidence of damage. Compare the equipment received against equipment ordered to ensure that ALL components have been received. The following materials are required (not provided) for installation: Exterior grade plywood back board for the KSU.

  • Page 14: Power Supply And Ksu Installation

    DV-38 System Installation Manual POWER SUPPLY AND KSU INSTALLATION Attach the plywood back board to the selected location with the appropriate fasteners. A surge protector should be installed at the dedicated AC outlet. Connect Male-Tail, and connect the plug to each station board for station wiring;...

  • Page 15: Pcb And Cabinet Layout

    DV-38 System Installation Manual PCB AND CABINET LAYOUT SYSTEM INTER-CIRCUIT LAYOUT D1PWU D1SLC D1VSCA D1VMCA D1DLUB D1STUB D1MBUB D1RPCA D1TKUC D1RSC D1DTKA D1MFC Figure 1. System Inter-Circuit Layout AC Power Inlet. AC Power Switch. Power Indicator（LED Type）. DC Power Switch.

  • Page 16: D1Mbub (Mother Board Unit)

    DV-38 System Installation Manual D1MBUB (Mother Board Unit) Product: DV-38 Mother Board Unit Item: D1MBUB Size: 310 mm x 130 mm Function: 1. The motherboard control entire system functions and audio switching. 2. Motherboard supports External Music Source Input Terminal.
  • Page 17 13Px2 Wafer Connector for D1SLCB connection. 11. STA1~3: 30Px2 Header Connector for both D1DULB and D1STUB connection. 12. ASIC: Aristel proprietary ASIC. 13. LCD: Additional LCD connector for engineering system maintenance. 14. JP1: 3 Pins Wafer Jumper to turn ON/OFF Li battery power.

  • Page 18: D1Pwua (Power Board Unit)

    DV-38 System Installation Manual D1PWUA (POWER BOARD UNIT) Product: DV-38 POWER UNIT Item: D1PWUA Size: 270 mm x 95 mm Function: 1. To supply entire system power. 2. The input AC Voltage ranges are AC110V~240V 3. Support 24V Battery Charger for external Back-up Battery.

  • Page 19: D1Tkuc (Trunk Unit, 4 Trunk Ports)

    Function: 1. Support Polarity Reverse detection for each CO lines. 2. A maximum of 3 D1TKUC boards can be installed onto the DV-38 main frame. 4. Support either D1CIDC or D1MDCA connections on each CO line. The installation site of D1TKUC, D1DTKA Figure 4.

  • Page 20: D1Dtka (Isdn Bri Trunk Unit)

    DV-38 System Installation Manual D1DTKA (ISDN BRI Trunk Unit) Product: DV-38 ISDN TRUNK UNIT Item: D1DTKA (ISDN BRI CARD) Size: 162 mm x 122 mm Function Supports 2 lines of 2B+D interface which support 4 voice channels. The system provides 3 slots of ISDN Trunk Unit connector. (Maximum expansion capability: 6 lines for 2B+D or 12 lines for Voice channel.)
  • Page 21 DV-38 System Installation Manual JP1: Short: line termination enable (default). N/C: line termination disable. JP2: Short: line termination enable (default). N/C: line termination disable. JP3: please see below table for reference. Link # 0 Link # 1 Slot number of TKU...

  • Page 22: D1Dlub (Digital Key Station Unit, 8 Key Station Ports)

    Size: 162 mm x 155 mm Function: 1. Supports 8 ports of digital Key Phone interface. 2. Totally 3 pieces of D1DLUB could be installed onto the DV-38 main frame (24 Extensions Maximum). 4. D1DLUB fully compatible with DV-Series Key Telephones. Ex: DKP-30, DKP-31, DKP-32 DKP-33, DKP-50, DKP-51, DKP-52, DKP-53.

  • Page 23: D1Stub (Analog Key Station Unit, 8 Key Station Ports)

    Size: 162 mm x 155 mm Function: 1. Supports 8 ports of digital Key Phone interface. 2. Totally 3 pieces of D1STUB could be installed onto the DV-38 main frame (24 Extensions maximum). 3. D1STUB fully compatible with AV-Series Key Telephones. Ex: KP-10 Series , KP-20 Series or KP30 Series.

  • Page 24: D1Slcb (Single Line Station Card, 2 Slt Station Ports)

    DV-38 System Installation Manual D1SLCB (Single Line Station Card, 2 SLT Station Ports) Product: DV-38 SINGLE LINE STATION CARD Item: D1SLCB Size: 195 mm x 69 mm Function: 1. D1SLCB provides 2 SLT Stations Ports. It is installed on a special socket instead of occupying Extension ports socket.

  • Page 25: D1Rsca (Rs232 Card , 2400 Bps Serial Rs232 Port )

    Product: DV-38 RS232 CARD Item: D1RSCA Size: 51.5 mm x 69 mm Function: 2400bps Serial interface is used for SMDR and Aristel’s WinSM applications. The installation site of D1RSCC Figure 9. D1RSCC (RS232 Card, 2400bps Serial RS232 Port) CN: 10-Pins Male Wafer Connector. Connect to the position of Point 9 in Figure 1 by the special DB9 Cable [FD-10-9-400, Male Type] for the connection of either PC COM Port or Serial Printer.
  • Page 26 DV-38 System Installation Manual Transmit (SYS← Serial Printer) 3.2 JP3: 3-Pins Jumper Selection. Receive Transmit 3.3 JP2: 3-Pins Jumper Selection. PC COM Port (SYS← PC) Transmit (SYS→ Serial P rinter) JP1: 3-Pins Jumper Selection. Receive (SYS→ PC) Arista Systems Corporation...
  • Page 27 DV-38 System Installation Manual CAUTION! A. If the system’s RS232 is connected to PC, please make ALL jumpers to be [PIN1 + PIN2] SHORTED. B. If the system’s RS232 is connected to Serial Printer, please make ALL jumpers to be [PIN2 + PIN3] SHORTED.

  • Page 28: D1Vsca/B (Voice Service Card, 2 Voice Channel)

    DV-38 System Installation Manual D1VSCA/B (Voice Service Card, 2 Voice Channel) Product: DV-38 D1VSCA/D1VSCB Model: D1VSCA/D1VSCB Size: 138 mm x 69 mm Function: 1. D1VSCA is consisting of 2 voice service channels which provide 60 seconds nonvolatile memory space in each.

  • Page 29: D1Mfca (Multi Function Card, 2 Sensor + 2 Relays + 2 Door Phones)

    Relay Switch, 2 Ports of Multifunction Sensor interface, 2 ports of External Paging interface. 2. Multi function card is an important interface of communicating others related products in our DV-38 .ex, Sensor Control, Relay Control, External Paging, Fire Alarm, and Emergency Alarm. .etc. The installation site of D1MFCA Figure 11.

  • Page 30: D1Mdca (Metering Pulse Card)

    DV-38 System Installation Manual D1MDCA (Metering Pulse Card) Product: DV-38 Metering Pulse CARD Item: D1MDCA Size: 91 mm x 21 mm Function: Provide signal channel of the POTS CO line 12/16KHz Metering Pulse detection. The installation site of D1MDCA Figure 12. D1MDCA (Metering Pulse Card) CN2: To connect to the position [CH1~4B] where upon the D1TKUC.
  • Page 31 DV-38 System Installation Manual D1CIDC (CALLER ID Card) Product: DV-38 CALLER ID CARD Item: D1CIDC Size: 91 mm x 21 mm Function: Provide signal channel of the POTS CO line DTMF/FSK Calling Line Identification detection. The installation site of D1CIDC Figure 13.

  • Page 32: D1Rpca (Remote Programming Card, 2400Bps Standard Modem)

    Product: DV-38 REMOTE PROGRAMING CARD Item: D1RPCA Size: 70.5 mm x 69 mm Function: 1. Standard 2400bps Modem. 2. Cooperate with Aristel’s Win-SM for system remote programming and Maintenance. The installation site of D1RPCA Figure 14. D1RPCA (Remote Programming Card) RPC: 26-Pin Connector to connect to [RPC] position where upon the D1MBUB.

  • Page 33: D1Vmca (Voice Mail Card)

    DV-38 System Installation Manual D1VMCA (Voice Mail Card) Product: DV-38 VOICE MAIL CARD Item: D1VMCA Dimension: 225 mm x 124 mm Function: 1. Support 2 basic Voice mail on board and could be expanded up to 4 ports by D1VMEA.

  • Page 34: D1Vmea (Voice Mail Expansion Card)

    DV-38 System Installation Manual D1VMEA (Voice Mail Expansion Card) Product: DV-38 Voice Mail Expansion Card Item: D1VMEA Dimension: 41 mm x 41 mm Function: 1. Signal channel of Voice Mail for port expansion where upon the designated socket. 2. Basic 2 channels on one board, Maximum capability can be expanded to 4 channels.

  • Page 35: D1Vmfa (Expansion Flash Memory)

    DV-38 System Installation Manual D1VMFA (Expansion Flash Memory) Product: DV-38 Expansion Flash Memory Item: D1VMFA Size: 30 mm x 25 mm Function: 1. Each Expansion Flash Memory Card provides 8 hours memory space. 2. 6 hours basic capacity on the D1VMCA, 3 expansion flash memory cards could expand the memory up to 30 hours Maximum (6+24=30 hours).

  • Page 36: Installation And Wiring

    DV-38 System Installation Manual INSTALLATION AND WIRING AC POWER AND DC BATTERY BACK-UP INSTALLATION D1SLCB D1VSCA D1VMCA D1DLUB D1STUB D1RPCA D1RSC D1TKUC D1DTKA D1MFCA Installation Figure 18. AC Power and DC Battery Back-Up Arista Systems Corporation...
  • Page 37 DV-38 System Installation Manual NOTE. AC Power input to the system can be either 115VAC or 230VAC. system can detect the input voltage automatically. CAUTION There are Hazardous voltages present in the Power Supply. We recommend that the Power be switched off before opening any covers.

  • Page 38: D1Mbub Jumper Setting

    DV-38 System Installation Manual D1MBUB JUMPER SETTING Please refer Figure 2 the D1MBUB plot for detail positions. 1. Li Battery installation and jumper setting. 1.1 [JP1] – Li Battery power ON/OFF. 1.2 [BAT] – Battery Holder. CAUTION Danger of explosion if battery is incorrectly replaced.

  • Page 39: Pots Co Line Wiring For D1Tkuc

    DV-38 System Installation Manual POTS CO LINE WIRING FOR D1TKUC PFR1+PFT1 PFR1 ===> PF Tel. 1 PFT1 FAX-R+ FAX-T FAX-R ===> FAX Machine FAX-T COR4+COT4 COR4 ===> CO Line 4 COT4 1. There are 4 CO Line Ports that can be wired on D1TKUC, each CO Line Port containing 2-wires.

  • Page 40: D1Cidc And D1Mdca Installation

    DV-38 System Installation Manual D1CIDC and D1MDCA INSTALLATION D1CIDC / D1MDCA D1TKUC CH4A CH4B CH3B CH3A CH2B CH2A CH1B CH1A Figure 20. Metering Pulse Detection Card Installation 1. There is a maximum of 4 D1CIDC cards that can be installed in each D1TKUB, one card for one CO Line.

  • Page 41: Digital Keyphone Wiring For D1Dlub

    DV-38 System Installation Manual Digital Keyphone Wiring for D1DLUB D1DLUB Phone Box 4 Wires Figure 21. Digital Key Station Wiring on D1DLUB 1. (ST1)~(ST8) are all for the Digit Key Telephone connections. 2. BT/BR is the Data/Audio/Power pair（no polarity）. Arista Systems Corporation...

  • Page 42: Analogue Keyphone

    DV-38 System Installation Manual Analogue Keyphone Wiring for D1STUB D1STUB Phone Box 4 Wire Figure 22. Analogy Key Station Wiring on D1STUB 1. (ST10~(ST8) are all for the Analogy Key Telephone connections. 2. AT/AR is the audio pair；AT = Transmission（Green Color）, AR = Receiving（Red Color）.

  • Page 43: Layout

    DV-38 System Installation Manual 50 Pins (25 Pairs) Male Amphenol Connector Layout Pair D1DLUB D1STUB Pair 1 Pair 1 for Station 1 Pair 2 Pair 2 for Station 1 Pair 2 for Station 1 Pair 3 Pair 1 for Station 2...

  • Page 44: Single Line Phonew

    DV-38 System Installation Manual Single Line Phone Wiring For D1SLCB D1-SLCA Phone Box Wire Single Line Telephone Figure 23. SLT Station Wiring on D1SLCB Connect D1SLCB on D1MBUB. Only for 2 SLT ports (SLT1) and (SLT2) provided on D1SLCB can connect with Single Line Telephone.

  • Page 45: 2-Wires Door Phone

    DV-38 System Installation Manual 2-Wires Door Phone Installation PAGE PAGE Figure 24. Door Phone Wiring on D1MFCA 1. D1MFCA is an option, which must be installed to provide 2 Door Phone Connection. 2. This option allows the user to connect any kind of external 2-Wires Door Phone device.

  • Page 46: Sensor Installation

    DV-38 System Installation Manual Sensor Installation PAGE PAGE Figure 25. External Sensor Wiring on D1MFCA 1. D1MFCA is an option, which must be installed to provide 2 Sensor Connections. 2. This option allows the user to connect any kind of external SENSOR device, such as Door Sensor, Smoke Detector, or Heat Sensor, among others.

  • Page 47: Installation

    DV-38 System Installation Manual Door Switch Installation Connect to Door Switch Power PAGE PAGE Figure 26. Door Switch Wiring on D1MFCA 1. D1MFCA is an option, which must be installed to provide 2 Relay Connections. 2. This option allows the user to connect any kind of external Relay Control device, such as Door Switch, Loud Bell among others.

  • Page 48: Ource Installation

    DV-38 System Installation Manual External Music Source Installation D1MBUB External Music Source Figure 27. External Music Source Wiring on D1MBUB 1. Connect 2-conductor wiring cord from External Music Source to (EXMUSIC) on D1MBUB. Arista Systems Corporation...
  • Page 49 DV-38 System Installation Manual RS232（Serial Printer or PC）Installation View from the D1MBUB Male DB9 which is front of DB9 RS232 Output Port of the system D1TKUB Wiring table Inside Wiring table Female DB9(Pin Female DB9(Pin positions are positions are DB-9 Male Connector...
