5 Port Unmanaged Industrial Ethernet Switch
IES5102
*actual product may vary from photos
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 12/11/2014
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StarTech.com IES5102
Summary of Contents for StarTech.com IES5102
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 12/11/2014...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Introduction ....................1 Packaging Contents ..........................1 System Requirements ..........................1 Product Diagram ..................2 Front View ..............................2 LED Indicators............................. 2 Rear & Side View ............................2 Installation ....................3 DIN Rail Mounting............................. 3 Connecting to Power ..........................3 Network Connection .......................... -
Page 4: Introduction
Introduction Packaging Contents • 1x 5 Port Ethernet Switch (w/ Attached DIN Rail Bracket) • 1x Terminal Block • 1x Instruction Manual CD System Requirements • 2 or 3-wire 12~48V DC power source • 10/100Mbps compatible Ethernet network • RJ45 terminated Ethernet cabling (Cat 5 or better recommended) Instruction Manual... -
Page 5: Product Diagram
Product Diagram Front View RJ45 Device Port RJ45 Uplink Port LED Indicators The IES5102 has LED indicators for each of the RJ45 ports on the switch to show the status of each connection State Indication Steady Valid network connection established (Link) -
Page 6: Installation
Installation DIN Rail Mounting 1. Hook the top, fixed DIN rail bracket on the rear of the Ethernet Switch to the top edge of the DIN rail. 2. Push the lower portion of the Ethernet Switch back against the DIN rail, which will cause the bottom, spring-loaded DIN clip to snap in place. -
Page 7: Network Connection
Network Connection 1. Ensure that both the IES5102 and any devices that are to be connected to it are powered off. 2. Prepare the necessary cabling for each device that is to be attached to the IES5102. Use the following chart as reference for cabling types: Port Speed Max. -
Page 8: Specifications
Specifications Ports Industry Standards IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-TX), IEEE 802.3az (Energy Efficient Ethernet) External Ports 5 - RJ-45 Female 1 - Terminal Block (3 Wire) Maximum Data Transfer Rate 200 Mbps (Full-Duplex), 100 Mbps (Half- Duplex) Maximum Cable Length 328 ft [100 m] Flow Control IEEE 802.3x Full-Duplex... - Page 9 Input Voltage 12 ~ 48 DC Input Current 0.05 A ~ 0.2 A Power Consumption 2.12W Max Operating Temperature -10°C to 60°C (14°F to 140°F) Storage Temperature -25°C to 85°C (-13°F to 185°F) Humidity 5~95% RH (Non-Condensing) Instruction Manual...
-
Page 10: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 11 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
