StarTech.com IES101G2SFPW Quick Start Manual

8-port gigabit ethernet switch with 2 sfp connections - managed
Hide thumbs Also See for IES101G2SFPW:
Table of Contents

Advertisement

Quick Links

Download this manual
8-Port Gigabit Ethernet Switch with 2
SFP Connections - Managed
IES101G2SFPW
FR: Guide de l'utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l'uso - it.startech.com
For the latest information, technical specifications, and support for
this product, please visit www.StarTech.com/IES101G2SFPW.
Manual Revision: 01/17/2017
*actual product may vary from photos

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IES101G2SFPW and is the answer not in the manual?

Questions and answers

Related Manuals for StarTech.com IES101G2SFPW

Summary of Contents for StarTech.com IES101G2SFPW

  • Page 1 8-Port Gigabit Ethernet Switch with 2 SFP Connections - Managed IES101G2SFPW *actual product may vary from photos FR: Guide de l’utilisateur - fr.startech.com DE: Bedienungsanleitung - de.startech.com ES: Guía del usuario - es.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com IT: Guida per l’uso - it.startech.com...
  • Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...

  • Page 3: Table Of Contents

    Table of Contents Introduction ....................1 Product diagram ............................1 Package contents ............................2 Requirements ............................. 3 About the LED indicators ..............3 Insert an SFP transceiver into the switch ...........4 Wire the power inputs ................4 Reboot the network switch ..............4 Reset to the default factory settings ..........5 Installation ....................6 Install the network switch onto a wall ....................

  • Page 4: Introduction

    Introduction Use the IES101G2SFPW to add up to 10 GbE devices to your network. The IES101G2SFPW features eight RJ45 ports, two SFP connections, and management support. Product diagram Front view RJ45 ports 1 to 4 Mounting hole Mounting hole Power LED...

  • Page 5: Package Contents

    Bottom view Reset button SFP ports (dust covers installed) Package contents • 1 x network switch • 1 x universal power adapter (NA/JP, UK, EU, ANZ) • 1 x terminal block connector • 4 x screw anchors • 4 x screws •...

  • Page 6: Requirements

    This network switch is OS independent and doesn’t require any additional drivers or software. Requirements are subject to change. For the latest requirements, please visit www.StarTech.com/IES101G2SFPW. About the LED indicators This network switch features eight RJ45 link and activity LEDs, a SFP link and activity LEDs for the two SFP ports, and a power LED.

  • Page 7: Insert An Sfp Transceiver Into The Switch

    Insert an SFP transceiver into the switch Inserting an SFP transceiver into the network switch is optional and isn’t required to use the switch. You don’t need to turn off the network switch before you can plug in and remove SFP transceivers from the network switch.

  • Page 8: Reset To The Default Factory Settings

    Reset to the default factory settings You can use the Reset button to reset the network switch to the following default factory settings: Default user name: admin Default password: admin Default IP address: 192.168.0.100 Subnet mask: 255.255.255.0 Default gateway: 192.168.0.254 •...

  • Page 9: Installation

    Installation Install the network switch onto a wall The mounting holes on the network switch are 8 mm in diameter, and the distance between the two holes is 163 mm. 1. Hold the network switch against the wall in the area that you want to install it, and use a pencil to trace the location of the four mounting holes onto the wall.

  • Page 10: Install The Switch Onto A Magnetic Surface

    Install the switch onto a magnetic surface 1. Push each of the attaching pins into a locking pin. 2. Insert the attaching and locking pins into one of the mounting holes on the network switch, through a washer, and into a magnet. Note: To prevent the magnets from becoming loose, make sure that you position the magnet so that the flat side is against the network switch.

  • Page 11: Mount The Switch Onto A Din Rail

    Mount the switch onto a DIN rail 1. With the flat side of the DIN rail positioned against the network switch, line up the holes on the DIN rail with the holes on the switch. 2. Insert the DIN-rail screws through the DIN rail and into the network switch. (figure 3) 3.

  • Page 12: Technical Support

    Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
  • Page 13 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
