- Page 1 Page.1 OPERATING AND INSTALLATION INSTRUCTIONS Apertura line...
-
Page 2: Table Of Contents
Page.2 CONTENTS 1. General Page 3 Important information Guarantee Contents of package 2. Operating instructions Page 4 The remote control unit and its operation Adjusting the temperature display (ºC and ºF) Setting the required temperature Setting the timer function Manual flame height adjustment using various modes Changing the battery Connections Technical specifications... -
Page 3: General
Page.3 We wish you happy heating with the purchase of this gas fire. Please read these instructions carefully before you install the fire and start using it. Keep these instructions in a safe place. Always quote type and serial number in the event of a problem. 1. -
Page 4: Operating Instructions
Page.4 2. Operating instructions The remote control and its operation. (See Page 14 diagram 6) Control buttons and other functions of the gas regulator block GV34 (A), the receiver G30-ZRRTT (F) and hand transmitter remote control G30-ZRHTT (B) Ensure that the batteries have been correctly placed in the remote control and battery holder/signal receiver (see Page 14-B1 and F2). -
Page 5: Manual Flame Height Adjustment Using Various Modes
Page.5 Manual flame height adjustment using various modes Press the high button to switch the fire on or to adjust the flame height upwards; use the low button to lower the flame height or until only the pilot light is burning. The manual control function overrides all functions. -
Page 6: Igniting The Pilot Light
Page.6 Igniting the pilot light The gas cock and air-inlet grids should be open in order to light the gas fire. · First ignite the pilot light by turning knob (A1) to the stop in the direction of position . Now push the knob in and wait several seconds (gas will flow out of the pilot light burner for the ignition of the pilot light). -
Page 7: Installation Instructions For The Apertura With Concentric Duct Connection
Page.7 4. Installation instructions for the Apertura with concentric duct connection General instructions The fire should only be installed and connected by a registered installer, in accordance with the local Gas Appliance Instructions. Also see Page 3 “Important information” Never place the fire against or in a flammable wall. The gas connection must be stress-free, to ensure no damage occurs to the gas regulating equipment. -
Page 8: Details Of The Gas Block Rc/Mc
Page.8 · Connection to the gas main (See Page 12 diag. 1-14B ). Make sure that the regulating equipment does not become twisted during connection and that no unnecessary tension develops. Ensure the accessibility of the connecting points for the various components. Check the gas tightness of the connections after they have been made. -
Page 9: Connection Options For Concentric Duct System
Page.9 The concentric duct system consists of the following components: ( see page 19 ) A. Concentric pipe. K. Flat roof flashing aluminium B. Concentric 45° bend. L. Storm collar / rosette C. Wall bracket. M. Horizontal terminal eccentric D. Not available N. - Page 10 Page.10 · Create an opening of 155 mm. in diameter in the outer wall (in a flammable external wall, provide for 50 mm. extra space all round the outer pipe) and mount the horizontal terminal with the wall plate on the in- side of the wall.
-
Page 11: Gas Specifications
Page.11 6. Gas specifications Apertura Category I2E+ I2E+ Country Pre-Pressure MBAR Burner Pressure MBAR 17,5 Injection Bore Smallest Bore Pilot Light CODE Min. Pressure MBAR Min. Load 10,8 10,8 10,8 10,8 10,8 Max. Load Consumption M³/h 1.226 1.128 1128 1128 1128 1128 Flue Gas Temp. - Page 12 Page.12...
- Page 13 Page.13...
- Page 14 Page.14 G20/30/31...
- Page 15 Page.15...
- Page 16 Page.16...
- Page 17 Page.17...
-
Page 18: Diagrams Pages 12 To
Page.18... -
Page 19: Cc Duct System Article Numbers
Page.19 CC FLUE SYSTEM PIECE CODE NUMBERS DESCRIPTION MEASURE CODE NR. CODE NR BLACK PAINTED ( mm ) STAINLES STEEL ALUMINIUM ** LEAD A) CONCENTRIC PIPE 1000 12965000 12965500 12965002 12965502 12965004 12965504 B) CONCENTRIC BEND 45° SET 12965012 12965512 C) WALL BRACKET 12965024 12965524... - Page 20 Page.20...
-
Page 21: Important Tips
Page.21 Important tips for heating with gas-fired or wood-fired stoves and fireplaces. Prevent discolouration of walls and ceilings! There are always dust particles in the air in every living space, even if it is regularly vacuumed! These particles are clearly visi- ble in rays of sunlight and they will not bother you as long as the concentration of particles in the air remains low. -
Page 22: Guarantee Conditions
Page.22 GUARANTEE CONDITIONS All appliances are supplied under a guarantee against material and manufacturing errors. The guarantee is limited to a maximum of the supply of a replace- ment component and only applies if the instructions for installation and use enclosed with the appliance have been followed, and if the product is being used under normal conditions in the dealer’s assessment.
