TRIMLINE INSTALLATION INSTRUCTIONS
TRIMLINE INSTALLATIE VOORSCHRIFT
TRIMLINE INSTRUCTIONS DE INSTALLATION
TRIMLINE INSTALLATIONSVEJLEDNING
TRIMLINE INSTRUCCIONES DE INSTALACIÓN
TRIMLINE MONTAGEANLEITUNGEN
Trimline 100 DB Front
Trimline 100 DB Tunnel
Trimline 120 DB Front
Trimline 120 DB Tunnel
Trimline 140 DB Front
Trimline 140 DB Tunnel
Trimline 170 DB Front
Trimline 100 DB Frontal
Trimline 100 DB Tunnel
Trimline 120 DB Frontal
Trimline 120 DB Tunnel
Trimline 140 DB Frontal
Trimline 140 DB Tunnel
Trimline 170 DB Frontal
Trimline 100 DB Frente
Trimline 100 DB Tunel
Trimline 120 DB Frente
Trimline 120 DB Tunel
Trimline 140 DB Frente
Trimline 140 DB Tunel
( 1136 )
( 1135 )
( 1137 )
( 1138 )
( 1139 )
( 1149 )
( 1048 )
( 1136 )
( 1135 )
( 1137 )
( 1138 )
( 1139 )
( 1149 )
( 1048 )
( 1136 )
( 1135 )
( 1137 )
( 1138 )
( 1139 )
( 1149 )

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Trimline 100 DB Front and is the answer not in the manual?

Questions and answers

Related Manuals for Thermocet Trimline 100 DB Front

Summary of Contents for Thermocet Trimline 100 DB Front

  • Page 1 TRIMLINE INSTALLATION INSTRUCTIONS TRIMLINE INSTALLATIE VOORSCHRIFT TRIMLINE INSTRUCTIONS DE INSTALLATION TRIMLINE INSTALLATIONSVEJLEDNING TRIMLINE INSTRUCCIONES DE INSTALACIÓN TRIMLINE MONTAGEANLEITUNGEN Trimline 100 DB Front ( 1136 ) Trimline 100 DB Tunnel ( 1135 ) Trimline 120 DB Front ( 1137 ) Trimline 120 DB Tunnel...
  • Page 2 INSTALLATION INSTRUCTIONS Trimline assortiment Trimline 100 DB Front ( 1136 ) Trimline 100 DB Tunnel ( 1135 ) Trimline 120 DB Front ( 1137 ) Trimline 120 DB Tunnel ( 1138 ) Trimline 140 DB Front ( 1139 ) Trimline 140 DB Tunnel...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INSTALLATION INSTRUCTIONS Page. 3 General instructions PLACING THE APPLIANCE Page. 4 Connection the gas lines Preparation and installation Installing gas control GV60 INSTALLATION OF THE OPTIONAL BLACK GLASS, Page. 5 WALL OR LAMELS Installation instructions for optional Black glass set Installation instructions Optional wall set Installation instructions Optional Lamels set PLACING...

  • Page 4: Installation Instructions

    INSTALLATION INSTRUCTIONS The installation should be performed only by an authorized gasfitter 1.1 General instructions The gas fireplace must be installed, connected and inspected as a balanced flue fire by a qualified fitter, according to national, regional, and local standards and regulations. The flue system and the terminals in the outer wall or roof face must also meet the requirements outlined in the applicable standards and regulations.

  • Page 5: Placing The Appliance

    PLACING THE APPLIANCE "Concentric flue system" 2.1 Connection the gas lines You can determine where the gas pipes will be placed, depending on the positioning of the appliance. Ensure control equipment is not twisted during installation and there is no excessive tension. Accessibility of various connection pointsin relation to components need to be maintained.

  • Page 6: Installation Instructions For Optional Black Glass Set

    PLACING THE OPTIONAL BLACK GLASS, WALL OR LAMELS SET you must place it first before fitting the log ,the Pebble set and the Carrara / Basalt stones . 3.1 Installation instructions for optional Black glass set (see APPENDIX 9) Loosen the screws holding the bottom and top glass holders (APPENDIX 5-2). Place the suction cup(s) in the middle of the glass-panel and remove the panel by GENTLY moving this first upwards and then the lower edge of the glass-panel very carefully and slowly pulling toward you.

  • Page 7: Fitting The Ceramic Logs

    PLACEMENT OF THE CERAMIC LOG AND OPTIONAL PEBBLE SET Before placing the log set when heating on G25 20-25mBar (I2L / I2ELL) the premix brackets underneath double burner needs to be changed. (see APPENDIX 5 image 8) Method: Loosen the screws holding the bottom and top glass holders (see APPENDIX 5). Place the suction cup(s) in the middle of the glass-panel and remove the panel by GENTLY moving this first upwards and then the lower edge of the glass-panel very carefully and slowly pulling toward you.

  • Page 8: Technical Details Gv60

    TECHNICAL DETAILS GV60 Gas valve type : Mertik GV60 Burner control : B6R R8U Ignition : Remote control operation and Piezo ignition Gas connection : 3/8 "(External) A = Gas inlet B = Gas outlet rear burner C = Gas outlet front burner D = Thermocouple connection E = pilot burner connection Unit category : C11-C31-C91...

  • Page 9: Instructions For Mertik Maxitrol Gv60 Gascontrol Page

    6. INSTRUCTIONS FOR MERTIK MAXITROL GV60 GASCONTROL WARNING It is forbidden to start up the unit if window (s) is not present or broken! Ensure that the fuel supplied to the unit is clean and free from particles and moisture. Before a gas supply pipe (new or existing) is connected to the main gas pipe at the gas meter and to the gas control block of the unit, clean and dry compressed air should been blown through it.
  • Page 10 7. GAS TECHNICAL DATA 7. GAS TECHNICAL DATA 1135 / 1136 (100/100 Tunnel) GASTYPE G20/25 G30/31 PRESSURE 20//20-25 30//29-37//30-50 NL/NO/DK/DE/ES/PT/IE/GB/BE/FR/AT/SI/ NL/NO/DK/DE/ES/PT/IE/GB/BE/FR/AT/SI/ COUNTRY HU/PL/CY/MT/IT/CH/CZ/SK/SI HU/PL/CY/MT/IT/CH/CZ/SK/SI CATEGORY I2H//I2E+//I2E-I2ELL//I2L I3B/P//I3+//I3P PRIMAIRY AIR PRE PRESSURE MBAR 20//20-25 30//29-37//30-50 BURNERPRESSURE HIGH MBAR 14,4//17 15//14-18,5//15 BURNERPRESSURE LOW MBAR 7,1//8,5 10,7//10,7-13,2//10,7...
  • Page 11 1139 / 1149 (140/140 tunnel) GASTYPE G20/25 G30/31 PRESSURE 20//20-25 30//29-37//30-50 NL/NO/DK/DE/ES/PT/IE/GB/BE/FR/AT/SI/ NL/NO/DK/DE/ES/PT/IE/GB/BE/FR/AT/SI/ COUNTRY HU/PL/CY/MT/IT/CH/CZ/SK/SI HU/PL/CY/MT/IT/CH/CZ/SK/SI CATEGORY I2H//I2E+//I2E-I2ELL//I2L I3B/P//I3+//I3P PRIMAIRY AIR PRE PRESSURE MBAR 20//20-25 30//29-37//30-50 BURNERPRESSURE HIGH MBAR 14,3//17,8 24,6//24,6-30,4//24,6 BURNERPRESSURE LOW MBAR 13,2//16,6 11,8//11,8//14,4 INJECTOR SIZE Ø MM INJ.

  • Page 12: Concentric Chimney Lay Out Page

    8. CONCENTRIC CHIMNEY LAY OUT Table of concentric chimney lay out Lay out Restriction Illustration X total in meter Y total in meter min* max* min* max* Indirect exterior wall outlet None Roof termination without elbows from 6 meter Roof termination with 45º elbows** from X totaal + Y >...

  • Page 13: Concentric Flue System Page

    9. CONCENTRIC FLUE SYSTEM The concentric flue system is composed of an inner- and an outer tube. These tubes are concentrically arranged; through the inner tube, the combustion gases are evacuated and the fresh combustion air is supplied between the inner and outer tube. 9.1 Components of the concentric flue system.

  • Page 14: Installation Instructions Regarding Existing Flues

    9.3 Installation instructions regarding existing flues. (see APPENDIX 3) Instructions The flue gas exhaust system falls within category C91 and must be built in accordance with national rules and regulations and the instructions of the manufacturer, as specified in the documentation and installation instructions. This means, among other things, that the existing chimney must not be smaller than 150 mm round / square, but no larger than 200 mm, and not ventilated by grilles etc.

  • Page 15: Terminal Positions And Correct Functioning Page

    10. TERMINAL POSITIONS AND CORRECT FUNCTIONING Distance Dimensions Terminal position Distance to ventilation openings Local* Distance to ventilation openings Local* Distance to ventilation openings Local* Below a gutter soil pipes or drain pipes Below eaves Below carport, roof or balcony From Inner and outer corners From a vertical soil pipes or drain pipes Inside and outside of a corner...
  • Page 16 Hard (abrasive) sponges, steel wool, abrasives and cleaners with ammonia or acid (citric acid as well) Paper towels, ceramic cook top cleaner. Only use: water or suitable detergents. We advise our Thermocet cleaner. Procedure: Wear soft cotton gloves at all times.
  • Page 17 12. TROUBLESHOOTING LIST MERTIK GV60 ACTION Possible problem/cause Solution Option: wall switch START: Bent pin on switch, or cable Straighten pin, replace wall press ON button > wall switch not operating properly. switch or cable. works. Manual transmitter START: Manual transmitter battery Replace battery, 2x AAA 1.5V press both buttons to start low.
  • Page 18 No ACTION Possible problem/cause Solution Ignition components not operating Check connection between cable & IGN properly. electrode. Check IGN electrode spark gap. Check IGN electrode for discharge to ground (break in ceramic). Check IGN cable for damage Continuous spark Increase distance between IGN cable and all metal parts.
  • Page 19 No ACTION Possible problem/cause Solution Resistance in thermo Check cables and current circuit too high. connections in thermo current circuit. Magnet unit drops Not enough heat on Check position of pilot to (audible click) thermocouple. thermocouple and intensity of pilot flame. Motor turns to main Low voltage from Check connections and, if...
