- Page 1 INSTALLATION INSTRUCTIONS Trimline assortment Trimline 83 Front DB ( 1180) Trimline 83 Panorama DB ( 1181) Trimline 83 Corner Left DB ( 1182) Trimline 83 Corner Right DB ( 1183) Page.1...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INSTALLATION INSTRUCTIONS Page. 3 General instructions PLACING THE APPLIANCE Page. 4 Connection the gas lines Preparation and installation Installing gas control GV60 Installation Methods INSTALLATION OF THE OPTIONAL BLACK GLASS, Page. 6 WALL OR STONE MOTIF/QUILTED WALLSET Installation instructions for optional Black glass set Installation instructions Optional wall or stone motif ore Quilted wall set. -
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS NOTICE The installation should be performed only by an authorized gasfitter 1.1 General instructions The gas fireplace must be installed, connected and inspected as a balanced flue fire by a qualified fitter, according to national, regional, and local standards and regulations. The flue system and the terminals in the outer wall or roof face must also meet the requirements outlined in the applicable standards and regulations. -
Page 4: Placing The Appliance
PLACING THE APPLIANCE NOTICE Before installing the device it is recommended to first read Chapter 7 "Concentric flue system" 2.1 Connection the gas lines You can determine where the gas pipes will be placed, depending on the positioning of the appliance. Ensure control equipment is not twisted during installation and there is no excessive tension. -
Page 5: Installation Methods
2.4 Installation methods (see APPENDIX 2 fig. 1-2-3-4-5) Depending on the desired set-up, you can decide to work with a wide decorative trims or just to connect the plateau almost directly to the glass panes of the appliance. Work with the wide decorative trims at the panorama and corner devices (see APPENDIX 2 fig. 1) The wide decorative trims can easily be removed by lifting it up and taking it out forwards, paying attention to damage the glass pane and the plateau. -
Page 6: Installation Instructions For Optional Black Glass Set
PLACING THE OPTIONAL BLACK GLASS, WALL, RILLS OR BRICK INTERIOR NOTICE If you are selected a black glass, rilled or brick interior, you must place it first before fitting the log set. 3.1 Installation instructions for optional Black glass set (see Appendix 9) Remove the wide decorative trim and insert trim from the underside of the glass pane (see APPENDIX 5 fig. - Page 7 PLACEMENT OF THE CERAMIC LOG SET (see APPENDIX 8) Placement of the ceramic log set ( see Appendix 8) Standard all burners are mounted (1) and the perforated decoration plate is placed. For the easier removal of the decoration plate there are 2 integrated lifting brackets with which the entire plate including glass / glow material can be removed after the burners have been removed.
-
Page 8: Technical Details Gv60
TECHNICAL DETAILS GV60 Gas valve type : Mertik GV60 Burner control : B6R R8U Ignition : Remote control operation and Piezo ignition Gas connection : 3/8 "(External) A = Gas inlet B = Gas outlet rear burner C = Gas outlet front burner D = Thermocouple connection E = pilot burner connection Unit category : C11-C31-C91... -
Page 9: Instructions For Mertik Maxitrol Gv60 Gascontrol Page
7. INSTRUCTIONS FOR MERTIK MAXITROL GV60 GASCONTROL WARNING It is forbidden to start up the unit if window (s) is not present or broken! Ensure that the fuel supplied to the unit is clean and free from particles and moisture. Before a gas supply pipe (new or existing) is connected to the main gas pipe at the gas meter and to the gas control block of the unit, clean and dry compressed air should been blown through it. -
Page 10: Gas Technical Data Page
Remove batteries only with the red ribbon which is under the battery, not with metal tool Removing batteries with a metal object, the electronic control can permanently damage. NOTICE Waiting time of 5 minutes between each starting attempt 8. GAS TECHNICAL DATA Type of indication (s) 1180(front), 1181(Panorama), 1182(Corner Left), 1183(Corner Right) - Page 11 Type of 1180(front), 1181(Panorama), 1182(Corner Left), 1183(Corner Right) indication (s) Appliance C11,C31,C91 closed combustion Concentric flues systeem Holetherm CC 100-150/130-200 Gastype G30/31 G30/31 Prepressure in mBar (28-30)-37 30/50 NL/BE/CH/CY/CZ/ES/FR/GB/GR/IE/IT/LT/PT/ Country BE/CH/CY/CZ/ES/FR/GB/GR/IE/IT/LT/PT/SI/SK SI/SK/AT/CH/DE/FR/SK Category I3B/P Primary air L/R 4xø15, Mid 2xø15/1xø12 L/R 4xø15, Mid 2xø15/1xø12 Pre pressure mBar...
-
Page 12: Concentric Chimney Lay Out Page
9. CONCENTRIC CHIMNEY LAY OUT Table of concentric chimney lay out Lay out Illustration X total in Y total in me- Restriction meter min* max* min* max* 1180 > 1183 Indirect exterior wall outlet G20/G25 See provisions Indirect exterior wall outlet G20/G25 See provisions Roof termination without elbows See provisions... -
Page 13: Concentric Flue System
10. CONCENTRIC FLUE SYSTEM The concentric flue system is composed of an inner- and an outer tube. These tubes are concentrically arranged; through the inner tube, the combustion gases are evacuated and the fresh combustion air is supplied between the inner and outer tube. 10.1 Components of the concentric flue system. -
Page 14: Installation Instructions Regarding Existing Flues
10.3 Installation instructions regarding existing flues. (see Appendix 3) Instructions The flue gas exhaust system falls within category C91 and must be built in accordance with national rules and regulations and the instructions of the manufacturer, as specified in the documentation and installation instructions. This means, among other things, that the existing chimney must not be smaller than 150 mm round / square, but no larger than 200 mm, and not ventilated by grilles etc. -
Page 15: Terminal Positions And Correct Functioning Page
11. TERMINAL POSITIONS AND CORRECT FUNCTIONING Distance Dimensions Terminal position Distance to ventilation openings Local* Distance to ventilation openings Local* Distance to ventilation openings Local* Below a gutter soil pipes or drain pipes Below eaves Below carport, roof or balcony From Inner and outer corners From a vertical soil pipes or drain pipes Inside and outside of a corner... - Page 16 Hard (abrasive) sponges, steel wool, abrasives and cleaners with ammonia or acid (citric acid as well) Paper towels, ceramic cook top cleaner. Only use: water or suitable detergents. We advise our Thermocet cleaner. Procedure: Wear soft cotton gloves at all times.
-
Page 17: Troubleshooting List Mertik Gv60
13. TROUBLESHOOTING LIST MERTIK GV60 ACTION Possible problem/cause Solution Option: wall switch START: Bent pin on switch, or cable Straighten pin, replace wall press ON button > wall switch not operating properly. switch or cable. works. Manual transmitter START: Manual transmitter battery Replace battery, 2x AAA 1.5V press both buttons to start low. - Page 18 No ACTION Possible problem/cause Solution Ignition components not operating Check connection between cable & IGN properly. electrode. Check IGN electrode spark gap. Check IGN electrode for discharge to ground (break in ceramic). Check IGN cable for damage Continuous spark Increase distance between IGN cable and all metal parts.
- Page 19 No ACTION Possible problem/cause Solution Resistance in thermo Check cables and current circuit too high. connections in thermo current circuit. Magnet unit drops Not enough heat on Check position of pilot to (audible click) thermocouple. thermocouple and intensity of pilot flame. Motor turns to main Low voltage from Check connections and, if...
-
Page 20: Appendix 1 Dimensional Drawings
APPENDIX 1 DIMENSIONAL DRAWINGS Trimline 83 Front DB Trimline 83 Corner DB Trimline 83 Panorama DB Page.20... -
Page 21: Appendix 2 Built-In Examples
APPENDIX 2 BUILT-IN EXAMPLES MAX 1500 Page.21... - Page 22 Trimline 83 arrangement Trimline 83 hanging arrangement Page.22...
- Page 23 APPENDIX 2 BUILT-IN EXAMPLES Trimline 83 Panorama/Corner with standard wide trims Trimline 83 Front with wide trims Page.23...
- Page 24 APPENDIX 2 BUILT-IN EXAMPLES Trimline 83 Panorama/Corner plateau levelled built in 'direct' against glass windows Page.24...
-
Page 25: Appendix 3 Installation Instructions Regarding Flues
APPENDIX 3 INSTALLATION INSTRUCTIONS REGARDING FLUES Roof terminal Storm collar Lead roof flashing Roof support Fire stop plate pitched Adjustable length Wall bracket Elbow Floor/ceiling support Fire stop plate flat Concentric element Wall bracket Floor support Fire stop plate flat Locking band 9. -
Page 26: Appendix 4 Preparations And Installation
APPENDIX 4 PREPARATION AND INSTALLATION Page.26... - Page 27 APPENDIX 5 GV60 GEREED MAKEN VOOR INBOUW GAS VALVE TYRAPPS Page.27...
- Page 28 Page.28...
-
Page 29: Appendix 6 Placing The Optional Led Glowbed Unit
APPENDIX 6 PLACING THE OPTIONAL LED GLOWBED UNIT Page.29... - Page 30 Page.30...
-
Page 31: Fitting The Log Set
APPENDIX 7 FITTING LOG SET Page.31... - Page 32 APPENDIX 8 PLACING THE OPTIONAL BLACK GLASS, WALL OR LAMELS SET BLACK GLASS SET Page.32...
- Page 33 RILLED OR BRICK INTERIOR Thermocet International B.V. Laagerfseweg 31 3931 PC Woudenberg www.thermocet.nl Page.33...
