Summary of Contents for Thermocet Trimline 100
- Page 1 Page.1 OPERATING AND INSTALLATION INSTRUCTIONS 1036 / 1037 / 1038 / 1039 Trimline 100 (1036) Trimline 120 (1037) Trimline Tunnel 120 (1038) Trimline 140 (1039)
-
Page 2: Table Of Contents
Page.2 OPERATING AND INSTALLATION INSTRUCTIONS TABLE OF CONTENTS 1 . General Page 3 1.1 Contents of the package 2. Safety device Page 4 2.1 Safety 3. Remote control Page 5 3.1 General 3.2 Manual transmitter 3.3 Screen setup 3.4 Time setup 3.5 Setting the Timer 3.6 Controls (Manual transmitter) 3.7 Possible error messages... -
Page 3: General
(curtains, etc.). Contents of the packaging 1 x Fully assembled unit: Trimline 100 (1036) or Trimline120 (1037) or Trimline Tunnel 120 (1038) or Trimline 140 (1039) 1 x Remote control 2 x Restriction plate 1 x 9V battery 4 x 1.5V AA batteries... -
Page 4: Safety Device
Page.4 2. SAFETY DEVICE The unit is fully safeguarded by means of thermo-electric pilot light protection to prevent unforeseen discharge of gas from the main burner. 2.1 Safety Do not place ceramic burner decoration material or logs against the pilot burner. Ensure the pilot light is able to burn freely over the main burner. -
Page 5: Remote Control
Page.5 REMOTE CONTROL General The unit is operated using a radio-controlled remote control. This consists of a manual transmitter and a re- ceiver. The receiver is connected to the gas control block. The receiver and the gas control block are located in the operating box. Manual transmitter The transmitter uses a radio-controlled signal. -
Page 6: Possible Error Messages
Page.6 Operation (Remote Control) Igniting the flame Open the gas shut-off cock that has been installed in the gas pipe to the unit. Press the “O I” switch on the gas control block to the “I” position. Turn the operating button on the gas control block into the ON position. Press the OFF (large) switches on the remote control at the same time. - Page 7 Page.7 3.8 Setting the flame height / extinguishing the flame After the burner is ignited, the flame size will adjust to its maximum height automatically. Press the button (small) on the image of the flame to reduce the height and to switch the burner off. (Extinguishing the flame: “STAND BY”).
-
Page 8: Switching The Unit Off
Page.8 4.0 MANUAL CONTROL The unit may be operated by hand if there is a defect in the remote control. To do so, the ignite (piezo)cable of the receiver must first be removed and carefully slid into the piezo connector on the gas control block. Small metal circle for Manual ignition Main valve knob... -
Page 9: Initial Start-Up
Page.9 5. INITIAL START-UP The unit has a layer of heat-resistant varnish that resists very high temperatures. An unpleasant smell may de- velop in the first hours after starting the unit due to burning in of the varnish; however, this is not dangerous. To accelerate this process, allow the unit to burn at the highest setting for several hours and ventilate the area well. -
Page 10: Installation Instructions
Page.10 6. INSTALLATION INSTRUCTIONS Important The installation may only be performed by an authorised person 6.1 General instructions The gas fireplace must be installed, connected and inspected as a closed unit by a qualified fitter, according to national, regional, and local standards and regulations. The flue tube system and the outlets in the outer wall or roof face must also meet the requirements outlined in the applicable standards and regulations. -
Page 11: Concentric Flue System
Page.11 7. Concentric flue system CC The concentric flue system consists of a 100 mm Ø inner flue concentric with a 150 mm Ø outer flue, or a 130 mm Ø inner flue concentric with a 200 mm Ø outer flue. These flues have been set up concentrically; the com- bustion gases are exhausted through the internal flue while the fresh combustion air is supplied between the inter- nal and external flues. -
Page 12: Construction Of Concentric Flue System
Page.12 7.2 Construction of concentric flue system CC Indirect wall connection. The outlet may also be installed above the exhaust in the wall, taking any hindrance to the sur rounding area into consideration, according to national, regional, local standards and regulations. Ensure wind pressure on the flue terminal is not too extreme, such as a balcony, flat roof, corners and in small alleys etc., as this may negatively influence the unit efficiency. -
Page 13: Installation Instructions Regarding Existing Flues
Page.13 7.3 Installation instructions regarding existing flues. Instructions The flue gas exhaust system falls within category C91 and must be built in accordance with national rules and regulations and the instructions of the manufacturer, as specified in the documentation and installation instruc- tions. - Page 14 Page.14...
-
Page 15: Instructions For The Mertik Maxitrol Gv60 And The Remote Control
Page.15 Instructions for the Mertik Maxitrol GV60 and the Remote Control: Ensure that the fuel supplied to the unit is clean and free from particles and moisture. Before a gas supply pipe (new or existing) is connected to the main gas pipe at the gas meter and to the gas control block of the unit, clean and dry compressed air should been blown through it. - Page 16 Page.16 Do not extend the thermocouple supplied to the pilot set Extending the thermocouple beyond its limit will lead to a reduction in voltage. This may, in turn, lead to the magnetic coil not being activated. Prevent leakage of the ignition spark to parts of the installation other than the ignition rod at the pilot. Ensure the ignition cable is not in contact with the shell or other metal parts.
- Page 17 Page.17...
-
Page 18: Maintenance Check-Up List
Page.18 9.0 MAINTENANCE CHECK-UP LIST. Fitter details: Name Address Unit serial number Date of purchase Installation date Comments Service and maintenance logbook: Service date Performed by Work activities performed... -
Page 19: Maintenance Activities
Page.19 10. Maintenance activities Please note: turn off the gas supply and power supply as much as possible during maintenance activities. Maintenance activities should be performed by a qualified fitter. Close the gas tap while maintenance activities are being performed Inspect Work activities 1 General inspection... -
Page 20: Installing The Unit
Page.20 11. PLACING THE UNIT (first read “General instructions”) Please note: Before placing the unit, we recommend you first read Chapter 7 “Concentric flue system” on page 11. 11.1 Unit components (see page 28, figures 5 and 6.) Unit Window Set screw Baffle plate Stainless steel front... -
Page 21: Fitting The Ceramic Log Inset
Page.21 Now determine the installation and assembly of the CC ducts and accessories. Please refer to Chapter 7 “Concentric flue system” on page 11 and the “Table of concentric pathways” on page 25. Install the Mertik control Box (12) in your chosen installation location. Please note: The distance between the control cabinet and the unit will be determined by the cable lengths from the control cabinet to the pilot burner and the gas block etc. -
Page 22: Technical Details Gv60
Page.22 12. TECHNICAL DETAILS GV60 Model : 1036-1037-1038-1039 Gas block type : Mertik GV60 Ignition : Distance operation and Piezo ignition Gas connection : 3/8" (Internal) A=Gas intake B=Gas exhaust C=Thermocouple connection D=Pilot burner connection Unit category : C11-C31-C91 Pilot flame : SIT 3 flames Combustion gas discharge and Combustion air supply : Concentric: Ø130 / 200 mm (Metaloterm US system number: 0063-CPD-6308) -
Page 23: Gas-Technical Specifications
Page.23 12.1 Gas -technical specifications UNIT 1036 1037 / 1038 1039 GASTYPE G25/G20 G30/31 G25/G20 G30/31 G30/31 COUNTRY NL/NO/ES/PT/ ES/PT/IE/GB/ NL/NO/ES/PT/ ES/PT/IE/GB/ NO/ES/PT/DE/ NL/DE/BE ES/PT/IE/GB/ DE/IE/GB/BE/ BE/FR/LV/SI/ DE/IE/GB/BE BE/FR/LV/SI/ IE/GB/BE/FR/ BE/FR/LV/SI/ FR/IT/LV/SI/SK/ EE/HU/LT/PL/ FR/IT/LV/SI/ EE/HU/LT/PL/ IT/LV/SI/SK/ EE/HU/LT/PL/ EE/HU/LT CY/MT SK/EE/HU/LT CY/MT EE/HU/LT CY/MT... -
Page 24: Problems And Possible Solutions
Page.24 13. PROBLEMS AND POSSIBLE SOLUTIONS Please first check if all guidelines were followed before attempting to solve any problems with the unit. Warning: Solving problems with your unit, whether gas related or electrical, must always be performed by a qualified tech- nician. -
Page 25: Table Of Concentric Pathways
Page.25 Table of concentric pathways Pathway Illustration X total in metres Y total in metres Restriction plate Other details min* max* min* max* Indirect exterior wall outlet Roof pass-through without slope from 3 metres Roof pass-through with 45º from 3 metres slope** Roof pass-through with 90º... -
Page 26: Illustrations
Page.26... - Page 27 Page.27 1036 1037 1039 1038...
- Page 28 Page.28...
- Page 29 Page.29...
- Page 30 Page.30 1036...
- Page 31 Page.31 1037 / 1038...
- Page 32 Page.32 1039...
- Page 33 Page.33 Pebles Carara...
- Page 34 Page.34...
- Page 35 Page.35...
- Page 36 Page.36 TTI d.o.o. Thermo Technology International...
