- Page 1 Page.1 OPERATING AND INSTALLATION INSTRUCTIONS Trimline 14038 Panorama/Corner (1040/1041/1042) Trimline 12038 Panorama/Corner (1045/1046/1047) Trimline 6345 Panorama/Corner (1053/ 1054/1055) Trimline 10038 Panorama/Corner (1056/ 1057/1058) Trimline 3863 Panorama/Corner (1070/1071/1072/1073)
-
Page 2: Table Of Contents
Page.2 TABLE OF CONTENTS 1 . General Page 3 1.1 Contents of the package 2. Safety device Page 4 2.1 Safety 3. Remote control Page 5 3.1 General 3.2 Manual transmitter 3.3 Screen setup 3.4 Time setup 3.5 Setting the Timer 3.6 Controls (Manual transmitter) 3.7 Possible error messages 3.8 Setting the flame size / Extinguishing the fire... -
Page 3: General
Gas fires must not be placed on or against flammable materials (curtains, etc.). 1.1 Contents of the packaging 1 x Fully assembled unit: Trimline 14038 Pano/Corner ore Trimline 6345 Pano/Corner ore Trimline 10038 Pano/Corner ore Trimline 3863 Pano/Corner 1 x Convection set 1 x Remote control... -
Page 4: Safety Device
Page.4 2. SAFETY DEVICE The unit is fully safeguarded by means of thermo-electric pilot light protection to prevent unforeseen discharge of gas from the main burner. 2.1 Safety Do not place ceramic burner decoration material or logs against the pilot burner. Ensure the pilot light is able to burn freely over the main burner. -
Page 5: Remote Control
REMOTE CONTROL Page.5 General The unit is operated using a radio-controlled remote control. This consists of a manual transmitter and a re- ceiver. The receiver is connected to the gas control block. The receiver and the gas control block are located in the operating box. If there is no change in flame height for a 6-houre period the transmission / communication turn down appli- cation wil turn down the pilot flame. -
Page 6: Possible Error Messages
Page.6 Operation (Remote Control) Igniting the flame Open the gas shut-off cock that has been installed in the gas pipe to the unit. Press the “O I” switch on the gas control block to the “I” position. Turn the operating button on the gas control block into the ON position. (large) switches on the remote control at the same time. - Page 7 Page.7 3.8 Setting the flame height / extinguishing the flame After the burner is ignited, the flame size will adjust to its maximum height automatically. Press the button (small) on the image of the flame to reduce the height and to switch the burner off. (Extinguishing the flame: “STAND BY”).
-
Page 8: Switching The Unit Off
Page.8 4.0 MANUAL CONTROL The unit may be operated by hand if there is a defect in the remote control. To do so, the ignite (piezo)cable of the receiver must first be removed and carefully slid into the piezo connector on the gas control block. Small metal circle for Manual ignition Main valve knob... -
Page 9: Initial Start-Up
Page.9 5. INITIAL START-UP The unit has a layer of heat-resistant varnish that resists very high temperatures. An unpleasant smell may de- velop in the first hours after starting the unit due to burning in of the varnish; however, this is not dangerous. To accelerate this process, allow the unit to burn at the highest setting for several hours and ventilate the area well. -
Page 10: Installation Instructions
Page.10 6. INSTALLATION INSTRUCTIONS Important The installation may only be performed by an authorised person 6.1 General instructions The gas fireplace must be installed, connected and inspected as a closed unit by a qualified fitter, according to national, regional, and local standards and regulations. The flue tube system and the outlets in the outer wall or roof face must also meet the requirements outlined in the applicable standards and regulations. -
Page 11: Concentric Flue System
Page.11 7. CONCENTRIC FLUE SYSTEM CC (See Page 33, 34, 35) The concentric flue system consists of a 100mm or 130mm Ø inner flue concentric with a 150 mm or 200 mm Ø outer flue. These flues have been set up concentrically; the combustion gases are exhausted through the internal flue while the fresh combustion air is supplied between the internal and external flues. - Page 12 Page.12 Roof-pass trough Storm collar Lead roofing sheet Roof bracket Fire protection plate Bend CC Pipe Wall bracket Bend Floor support Fire protection plate CC Pipe Wall bracket CC Pipe Floor support Fire protection plate CC Pipe Wall bracket Clamping strips CC fitted pipe...
-
Page 13: Installation Instructions Regarding Existing Flues
7.3 Installation instructions regarding existing flues. Page.13 Instructions The flue gas exhaust system falls within category C91 and must be built in accordance with national rules and regulations and the instructions of the manufacturer, as specified in the documentation and installation instructions. This means, among other things, that the chimney pass-through must not be smaller than 150 mm round / square, but no larger than 200 mm, and not ventilated by grilles etc. - Page 14 Page.14 9. Roof pass-through 8. Clamping strips 7. Chimney mounting plate (Renovation kit) 6. Flexible hose 316L 5. Slider (renovation kit) 4. Inner mounting plate (Renovation kit) 3. Clamping strips 2. CC Fitted pipe 1. Clamping strips...
-
Page 15: Instructions For The Mertik Maxitrol Gv60 And The Remote Control
Page.15 Instructions for the Mertik Maxitrol GV60 and the Remote Control: Ensure that the fuel supplied to the unit is clean and free from particles and moisture. Before a gas supply pipe (new or existing) is connected to the main gas pipe at the gas meter and to the gas control block of the unit, clean and dry compressed air should been blown through it. - Page 16 Page.16 Do not extend the thermocouple supplied to the pilot set Extending the thermocouple beyond its limit will lead to a reduction in voltage. This may, in turn, lead to the magnetic coil not being activated. Prevent leakage of the ignition spark to parts of the installation other than the ignition rod at the pilot. Ensure the ignition cable is not in contact with the shell or other metal parts.
-
Page 17: Mertik Gv60 Troubleshooting Flow Chart
Page.17 Mertik GV60 Troubleshooting Flow Chart ACTION Possible problem/cause Solution Option: wall switch START: Bent pin on switch, or cable not Straighten pin, replace wall switch press ON button > wall switch operating properly. or cable. works. Manual transmitter START: press Manual transmitter battery low. - Page 18 Page.18 ACTION Possible problem/cause Solution Ignition components not operating properly. Check connection between cable & IGN electrode. Check IGN electrode spark gap. Check IGN electrode for discharge to ground (break in ceramic). Check IGN cable for damage Increase distance between IGN cable and all metal parts.
- Page 19 Page.19 ACTION Possible problem/cause Solution Resistance in thermo Check cables and connections in current circuit too high. thermo current circuit. Magnet unit drops Not enough heat on Check position of pilot to (audible click) thermocouple. thermocouple and intensity of pilot flame.
- Page 20 Page.20...
-
Page 21: Maintenance Check-Up List
Page.21 9.0 MAINTENANCE CHECK-UP LIST. Fitter details: Name Address Unit serial number Date of purchase Installation date Comments Service and maintenance logbook: Service date Performed by Work activities performed... -
Page 22: Maintenance Activities
Page.22 10. Maintenance activities. . Please note: turn off the gas supply and power supply as much as possible during maintenance activities. Maintenance activities should be performed by a qualified fitter. Close the gas tap while maintenance activities are being performed. Inspect Work activities 1 General inspection... -
Page 23: Placing The Unit
Page.23 PLACING THE UNIT (first read “General instructions”) Please note: Before placing the unit, we recommend you first read Chapter 7 “Concentric flue system” on page 11. 11.1 Connection to the gas pipes You can determine where the gas pipes will be placed, dependent on the layout. Ensure control equipment is not twisted during installation and there is no excessive tension. -
Page 24: Fitting The Ceramic Log Inset
If you have opted for a panel set , you must install this first before placing the decorative set. Page.24 See section 11.6 The decorative log inset / pebbles or Carrara set may now be installed. Please see sections 11.3, 11.4 and 11.5 and the photos on pages 36 to 49 outlining the order in which items are placed. -
Page 25: Fitting The Optional Pebble Set
11.4 Fitting the optional pebble set (see page 50 and 51) Page.25 Scatter vermiculite evenly over the burner tray. Make sure the pilot light remains unobstructed. Place a row of medium-sized and large pebbles at the front of the burner plate Fill the burner tray with small and medium-sized pebbles from the front to the rear. - Page 26 12.1 Gas technische gegevens Page.26 1053/54/55 1053/54/55 1053/54/55 1056/57/58 1056/57/58 GASTYPE G30/31 G25/G20 G30/31 COUNTRY NO/ES/PT/DE/IE/ ES/PT/IE/GB/BE/FR/ NL/DE NL/NO/ES/PT/DE/IE/GB/ ES/PT/IE/GB/BE/FR/ GB/BE/FR/IT/LV/ LV/SI/EE/HU/LT/ BE/FR/IT/LV/SI/SK/EE/ LV/SI/EE/HU/LT/PL/ SI/SK/EE/HU/LT PL/CY/MT HU/LT CY/MT CATEGORY I2H/I2E/I2E+ I3B/P, I3+ I2L/I2ELL I2l/I2ELL/I2H/I2E/I2E+ I3B/P/I3+ PRIMAIRY AIR 1xØ10 1xØ7 3XØ16 1xØ10 2XØ5 3XØ16...
- Page 27 Page.27 13. PROBLEMS AND POSSIBLE SOLUTIONS Please first check if all guidelines were followed before attempting to solve any problems with the unit. Warning: Solving problems with your unit, whether gas related or electrical, must always be performed by a qualified tech- nician.
- Page 28 Page.28 Table of concentric pathways Pathway Illustration X total in Y total in Restriction metres metres min* max* min* max* 1040-1041-1042 1053-1054-1055 1045-1046-1047 1070-1071-1072-1073 1056-1057-1058 direct exterior wall outlet Direct Wall pass- through permit- ted only for NG mo- dels Remove Baffle plate ! Indirect exterior wall outlet Remove...
- Page 29 Page.29 Panorama 1040/1041/1042 280mm minimum measure with shortened legs Corner right (left) 280mm minimum measure with shortened legs...
- Page 30 Page.30 1045/1046/1047 Panorama 280mm minimum measure with shortened legs Corner right (left) 280mm minimum measure with shortened legs...
- Page 31 Page.31 1053/1054/1055 Panorama Corner right (left) 280mm minimum measure 280mm minimum measure with shortened legs with shortened legs 1056/1057/1058 Panorama Corner right (left) 1077 280mm minimum measure with shortened legs 280mm minimum measure with shortened legs...
- Page 32 Page.32 Panorama 1070/1071/1072/1073 Hoek rechts(links) 1000 280mm minimum measure with shortened legs 1000 Front 280mm minimum measure with shortened legs 280mm minimum measure with shortened legs...
- Page 33 Page.33...
- Page 34 Page.34 THC-CC Pipe Diameter 100-150 250/500/1000 199/448/946 130-200 250/500/1000 199/448/946 THC-CC Adjustable pipe Diameter 100-150 130-200 THC-CC Bend 15-30-45° Diameter 100-150 15/30/45 130-200 15/30/45 THC-CC Bend 90° Diameter 100-150 130-200 THC-CC Reducer diam. 100-130 THC-CC Clamping strips Diameter 100-150 145-160 130-200 195-210 THC-CC Wall bracket adjustable...
- Page 35 Page.35 THC-CC Ceiling support Diameter 100-150 130-200 THC-CC Roof support Diameter 100-150 130-200 THC-CC Bracket Diameter 100-150 130-200 THC-CC Centering plate Diameter 100-150 130-200 THC-CC Centering plate adjustable Diameter 100-150 130-200 THC-CC Roofing sheet sloping 0-10° Diameter 100-150 130-200 THC-CC Roofing sheet sloping 5-25° Diameter 100-150 130-200...
- Page 36 Page.36 THC-CC Roofing sheet sloping 20-45° (LEAD) Diameter 100-150 130-200 THC-CC Roofing sheet sloping 45-60° (LEAD) Diameter 100-150 130-200 THC-CC Storm collar Diameter 100-150 130-200 THC-CC Roof pass-through Diameter 100-150 THC-CC Wall pas-through Diameter 100-150 130-200 THC-CC Renovation Packet Diameter 100-150...
- Page 37 Page.37...
- Page 38 Page.38...
- Page 39 Page.39 1040/1041/1042...
- Page 40 Page.40...
- Page 41 Page.41...
- Page 42 Page.42 1045 / 1046 / 1047...
- Page 43 Page.43 1053/1054/1055...
- Page 44 Page.44 1053/1054/1055...
- Page 45 Page.45 1056/1057/1058...
- Page 46 Page.46...
- Page 47 1071/1072/1073 Page.47...
- Page 48 Page.48...
- Page 49 Page.49...
- Page 50 Page.50...
- Page 51 Page.51...
- Page 52 Pebbles Page.52 1053/1054/1055 en 1070/1071/1072/1073...
- Page 53 Pebbles Page.53 1040/1041/1042 en 1056/1057/1058 Carrara...
- Page 54 Page.54 Thermocet International B.V. Laagerfseweg 31 3931 PC Woudenberg www.thermocet.nl...
