Page 1: User Manual
USER MANUAL POWERPACK PRIME SERIES 1 - 3 KVA... - Page 2 UDD-SD-113/ Release Date: 26.12.2014/Rev No: 0/Rev. Date...
- Page 3 USER MANUAL POWERPACK PRIME SERIES 1 - 3 KVA UDD-SD-113 About The Manual This manual is prepared for the users of Powerpack Prime Series 1-3 kVA. Companion Manuals For further information about this device and its options, please visit www.makelsan.com.tr Updates Please visit www.makelsan.com.tr for updates.
-
Page 4: Table Of Contents
POWERPACK PRIME SERIES 1-3 kVA CONTENTS CONTENTS 1 PRODUCT INTRODUCTION ............................5 1.1 Function description ............................. 5 1.2 Front Panel ................................6 1.2.1 Front View ................................6 1.2.2 LCD and LED Display ............................6 1.2.3 Button ..................................7 1.3 Rear panel ................................. 8 1.4 Mode description .............................. - Page 5 POWERPACK PRIME SERIES 1-3 kVA CONTENTS 4 MAINTENANCE ................................22 4.1 Maintenance Safety Instructions ........................22 4.2 Typical Troubleshooting ..........................24 4.3 Battery Maintenance ............................25 4.4 Contact the service centre ..........................26 5 TRAMSPORT and STORAGE ............................ 26 6 STANDARDS .................................. 26 7 GUARANTEE ..................................
-
Page 6: Product Introduction
POWER RPACK PRIM E SERIES 1- -3 kVA 1 PR RODUC CT INT TRODU UCTION 1.1 Fun nction des cription This product is a true onl line double -conversion n UPS (Unin nterruptible e Power Su upply). It prov ides perfect t protection for critical... -
Page 7: Front Panel
POWERPACK PRIME SERIES 1-3 kVA 1.2 Front Panel 1.2.1 Front View 2K/3K 1.2.2 LCD and LED Display... -
Page 8: Button
POWERPACK PRIME SERIES 1-3 kVA LED definition There are total 4 LEDs to indicate the status of UPS. Name Colour Function To indicate that the UPS is in bypass mode, and the load Bypass LED Orange current is directly from the mains power. -
Page 9: Rear Panel
POWERPACK PRIME SERIES 1-3 kVA 1.3 Rear panel... -
Page 10: Mode Description
POWERPACK PRIME SERIES 1-3 kVA Communication port Mains input protection (RS232) Intelligent card slot Mains input power cord Output terminal block Output socket 1.4 Mode description Line mode Line mode means that the mains input is rectified/converted by the AC/DC section and then inverted to stable output by DC/AC section. - Page 11 POWERPACK PRIME SERIES 1-3 kVA 1. If Line LED flashes, it means that the input may have something wrong, such as input L and N line reversed or the grounding wire is not connected properly. 2. If the load level is higher than 100%, the buzzer will beep once every 0.5 second as a warning for the over-loading condition.
-
Page 12: Product Specification
POWER RPACK PRIM E SERIES 1- -3 kVA Bypa ass mode Bypass mode mean ns that the U UPS provide es the powe r through th he internal bypass path h to load directly without any y regulation n. If the cont roller detect ts the mains s is abnorma... -
Page 13: Environment Specification
POWERPACK PRIME SERIES 1-3 kVA 1.5.2 Environment Specification Model Operating 0-40°C Temperature Storage -25-55°C Temperature <1000m @ full load <2000m @ 91%load Altitude <3000m @ 82%load <4000m @ 74%load Relative Humidity 20%-90% <45dB @ 1 <50dB @ 1 meter from front... -
Page 14: Electrical Specification
POWERPACK PRIME SERIES 1-3 kVA 1.5.4 Electrical Specification Model 2000VA/1600 3000VA/2400 1000VA/800W Power Input Current (Max.) 14.3A Voltage Range 80VAC-285VAC(Default 180-264VAC) Frequency Range 40-70Hz Input Power ≧0.98 @ full load Factor Output Voltage 200*/208*/220/230/240VAC (sine-wave) Synchronizing mains input @ line mode Frequency 50/60Hz ±... -
Page 15: Communication Port
POWERPACK PRIME SERIES 1-3 kVA 1.6 Communication Port 1.6.1 RS232 The communication port (RS232) is for the connection with PC which is installed with monitoring software. Pin assignment of the DB-9 connector is shown below: Pin# Definition TXD (output) RXD (input) 1.6.2 Intelligent Card... -
Page 16: Installation
POWER RPACK PRIM E SERIES 1- -3 kVA 2 IN STALL LATION 2.1 Safe fety Instru ctions for Installatio Pleas e read the f following s afety instru uctions bef fore installa ation! Insta allation Per rsonnel his product must be ins stalled only by qualifie... -
Page 17: Unpacking And Inspection
POWER RPACK PRIM E SERIES 1- -3 kVA Battery Strictly follow w the princ ciple of “sam me voltage, s same type” when conn ecting mult i battery packs in n parallel. DC breaker o or fuse must t be used as a protection n device bet tween the ex... -
Page 18: Operation
POWER RPACK PRIM E SERIES 1- -3 kVA 3 OP PERAT TION 3.1 Ope eration Sa afety Instru uctions Please e read the f following s afety instru uctions bef fore operati ion! Oper ration pers onnel he product i s designed t to be opera ted by gene... -
Page 19: Start The Ups With Mains (Ac Source)
POWERPACK PRIME SERIES 1-3 kVA 3.2 Start the UPS with mains (AC source) 1. Press the on/off button of the UPS front panel continuously for more than 1 second. The buzzer will beep once, the numeric area of LCD display will be lighted in sequence, after a few... -
Page 20: Connect Loads To Ups
POWERPACK PRIME SERIES 1-3 kVA 3. When the UPS enters battery mode normally, the Inverter LED, and Battery LED will be on, the Bypass LED will off. 4. Press the battery test button for 0.5 second, UPS will show the information on LCD display as followings in a circular order. -
Page 21: Charge The Batteries
POWERPACK PRIME SERIES 1-3 kVA 3.5 Charge the batteries 1. When the UPS is connected to normal mains, the charger will start to work and charge the batteries automatically. 2. It is suggested to charge the batteries for 10 hours at least before the UPS performs battery mode. -
Page 22: Turn Off The Ups With Battery (Dc) Only
POWERPACK PRIME SERIES 1-3 kVA 3.9 Turn off the UPS with battery (DC) only 1. To turn off the UPS in battery mode, please press the ON/OFF button continuously for more than 1 second. 2. After pressing the ON/OFF button, the buzzer will sound beep once. The numeric area of LCD... -
Page 23: Maintenance
POWER RPACK PRIM E SERIES 1- -3 kVA 4 MA AINTE NANCE 4.1 Ma intenance e Safety Ins structions Please e read the f following sa afety instru uctions befo ore mainten nance! Main ntenance Pe ersonnel This p product mu ust be main ntained onl... - Page 24 POWER RPACK PRIM E SERIES 1- -3 kVA Batte CAUTI ION: Only q qualified per sonnel can r replace the b batteries! A batt tery can pre esent a risk of electrica al shock and d high shor rt circuit cur rrent.
-
Page 25: Typical Troubleshooting
POWERPACK PRIME SERIES 1-3 kVA 4.2 Typical Troubleshooting If the LCD display shows any abnormal code, and the buzzer is alarming, that means UPS is running under abnormal status; please firstly analyze and resolve the problem by using ”The common troubleshooting table”, if the problem can’t be solved, please contact with distributor or service center. -
Page 26: Battery Maintenance
POWERPACK PRIME SERIES 1-3 kVA Continuously Bus voltage to low beep Continuously Bus short beep Continuously Inverter Soft Start beep up fail Continuously Inverter voltage beep too high Continuously Inverter voltage beep too low Continuously Output short beep Load off the unnecessary device, make sure... -
Page 27: Contact The Service Centre
POWERPACK PRIME SERIES 1-3 kVA 4.4 Contact the service centre When contact with distributor or service center for troubleshooting, please provide the following information: 1. Model name of product 2. Serial number of product 3. The date when the problem found 4. -
Page 28: Guarantee
POWERPACK PRIME SERIES 1-3 kVA 7 GUARANTEE 7.1 Terms of Guarantee Our products are under a two-year guarantee starting from the date of delivery against malfunctions resulting from production, material and workmanship faults. Malfunctions due to such type of faults will be removed without claiming any price of workmanship or spare parts to be replaced. -
Page 29: Cases Not Covered By The Guarantee
MAKELSAN according to the direction to be made by the MAKELSAN head office. For malfunctions in the scope of guarantee, shipment fees are under the responsibility of MAKELSAN on the condition that products are delivered to the contracted freight company. - Page 30 POWERPACK PRIME SERIES 1-3 kVA and accidents, impacts, electric, shipment, natural disasters, not limited to the ones listed above, are not covered in the scope of product guarantee. In the general examination performed during the breakdown acceptance process, certain troubles causing products not to be covered in the scope of guarantee might not be understood.
- Page 31 CERTIFICATE OF GUARANTEE Certificate Approval Date : --/--/---- MANUFACTURER COMPANY Certificate No TITLE MAKELSAN MAKİNE KİMYA ELEKTRİK SAN. TİC. A.Ş. ADDRESS Deri Organize SanayiBölgesi 2.Yol I-5 Parsel P.K. 34957 TELEPHONE 0216 – 428 65 80 0216 – 327 51 64...
- Page 32 NOTICE 8 – Under no circumstances shall the customer treat the product with the aim of repair, apart from MAKELSAN authorized service personnel. 9 – Damages and results originating from the violation of the 8 Article shall be invoiced to the customer.
-
Page 33: Contact Information
POWERPACK PRIME SERIES 1-3 kVA CONTACT INFORMATION 8 CONTACT INFORMATION www.makelsan.com.tr Headquarter: İstanbul Deri Organize Sanayi Bölgesi 2. Yol I -5 Parsel 34956 Tuzla/ İstanbul : 0216 428 65 80 : 0216 327 51 64 E-mail makelsan@makelsan.com.tr İzmir Office : Halkapınar Mah. 1348 Sok. 2AE Keremoğlu İş Merkezi Yenişehir – İzmir... - Page 36 Headquarter: İstanbul Deri Organize Sanayi Bölgesi 2. Yol I -5 Parsel 34956 Tuzla/ İstanbul : 0216 428 65 80 : 0216 327 51 64 E-mail makelsan@makelsan.com.tr İzmir Office : Halkapınar Mah. 1348 Sok. 2AE Keremoğlu İş Merkezi Yenişehir – İzmir...
