USER MANUAL
Lion+ Series
650 - 2000 VA
Line Interactive UPS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lion+ Series and is the answer not in the manual?

Questions and answers

Related Manuals for MAKELSAN Lion+ Series

Summary of Contents for MAKELSAN Lion+ Series

  • Page 1 USER MANUAL Lion+ Series 650 - 2000 VA Line Interactive UPS...
  • Page 2 UDD-SD-110/ Release Date: 19.12.2014/Rev No: 2/Rev. : 30.07.2015 Date...
  • Page 3 LİON+ SERIES 650-2000VA USER MANUAL Lion+ Series 650 - 2000 VA Line Interactive UPS UDD-SD-110 UDD-SD-110/ Release Date: 19.12.2014/Rev No: 1/Rev. : 30.07.2015 Date...
  • Page 4 About The Manual This manual is prepared for the users of Lion+ Series 650-2000 VA. Companion Manuals For further information about this device and its options, please visit www.makelsan.com.tr Updates Please visit www.makelsan.com.tr for updates. Always use the latest manuals.

  • Page 5: Table Of Contents

    LİON+ SERIES 650-2000VA CONTENTS CONTENTS 1 Important Safety Instruction......................3 2 Package Contenst...........................5 3 Introduction ............................5 4 Product Overview ..........................6 4.1 Front Panel............................6 4.2 Back Panel ............................6 4.3 Display..............................7 4.4 Load Level Definition ........................7 4.5 Battery Capacity Definition........................8 4.6 Overload Definition..........................8 4.7 Battery Low Definition........................8 5 Installation and Initial Startup......................9 5.1 Placement and Storage Conditions .....................9...

  • Page 6: Important Safety Instruction

    1 Important Safety Instruction CAUTION: This product is specially designed for PCs and it is not recommended for use in any medical equipment, life-supporting system and other specific important equipment. CAUTION: Do not plug the UPS into its own output. CAUTION: Do not attach a power strip or surge suppressor to the UPS.
  • Page 7 servicing to qualified service personnel. CAUTION: If UPS is to be stored for a long time, it is recommended to recharge the batteries (by connecting the utility power to UPS, switch “ON”), once a month for 24 hours to avoid a full battery discharge. CAUTION: In case smoke is found coming out from the device, please cut off the power supply quickly and contact the distributor.

  • Page 8: Package Contenst

    • 3 Introduction Lion+ series is an intelligent and compact line interactive UPS (Uninterruptable Power Supply) which is designed to protect your personal computer or sensitive electronic equipments from all forms of power interference, including complete power failures. It is equipped with many features that allow any attached equipment to operate longer and more reliability.

  • Page 9: Product Overview

    4 Product Overview 4.1 Front Panel 650-850VA 1000-1500-2000VA 4.2 Back Panel 650-850VA 1000-1500-2000VA UDD-SD-110/ Release Date: 19.12.2014/Rev No: 1/Rev. Date : 30.07.2015...

  • Page 10: Display

    4.3 Display When in normal mode, it will display as below. When LCD starts to work, it will display all information for 3 seconds. When in AVR mode, it will display as below. And When in battery mode, it will display as below. And the mark will flicker every 1 second.

  • Page 11: Battery Capacity Definition

    4.5 Battery Capacity Definition 1B model battery definition; Battery bar indication Battery level Battery mode Other mode Battery voltage<11V Battery voltage<12.7V 11V≤battery voltage<11.5V 12.7V≤battery voltage<13.2V 11.5V≤battery voltage<12.5V 13.2V≤battery voltage<13.5V Battery voltage≥12.5V Battery voltage≥13.5V 2B model battery definition; Battery bar indication Battery level Battery mode Other mode...

  • Page 12: Installation And Initial Startup

    5 Installation and Initial Startup NOTE: Before installation, please inspect the unit. Be sure that nothing is damaged. 5.1 Placement and Storage Conditions Install the UPS in a protected area that is free of excessive dust and has adequate air flow around the unit, and is free from excessive dust, corrosive fumes and conductive contaminants.

  • Page 13: Connect The Loads

    5.3 Connect the Loads Plug in the loads to output receptacles on the rear panel of the UPS. Simply turn on the power switch of UPS unit, and devices connected to the UPS will be protected by UPS unit COUTION: Do not attach a power strip or surge suppressor t the UPS. COUTION: Never connect a laser printer or scanner to the UPS unit, because in-rush current generated by motor’s devices may cause the damage of the unit.

  • Page 14: Connect Usb Cable

    5.5 Connect USB Cable To monitor the UPS status, such as unattended UPS shutdown and start-up, by using bundled software, please connect the UPS and PC with USB cable included. 5.6 Turn On / Off The Unit Turn on the UPS unit by pressing the power switch. Turn off the UPS unit by pressing again the power switch UDD-SD-110/ Release Date: 19.12.2014/Rev No: 1/Rev.

  • Page 15: Functions And Operations

    6 Functions and Operations 6.1 DC Start Function DC Start Function enables UPS to be started up when AC utility power is not available and battery is fully charged. Just simply press the power switch to turn on the UPS. 6.2 Green Power Function These series are equipped with Green Power Function for saving power and protecting battery.

  • Page 16: Software Installation On Your Pc

    7 Software Installation On Your PC Connected by USB to a PC or notebook, the Software enables communication between the UPS and the computer. The UPS software monitors the status of the UPS, shuts down the system before the UPS is exhausted and can remotely observe the UPS via the Network (enabling users to manage their system more effectively).

  • Page 17: Maintenance

    8 Maintenance 8.1 General The UPS is virtually maintenance free: take care of proper environmental conditions and keep air inlets-outlets free of dust. 8.2 Fuses If the AC input fuse is defect, be sure it is replaced by a compatible fuse from the same make and type. Never short circuit batteries.

  • Page 18: Trouble Shooting

    9 Trouble Shooting Symptom Possible Cause Remedy No LED display on the 1. Battery weak. 1. Charge battery up to 8 hours. front panel. 2. Battery defect. 2. Replace with the same type of battery. 3. Power switch is not pressed. 3.
  • Page 19 CAPACITY 650VA/390W 850VA/510W 1000VA/600W 1500VA/900W 2000VA/1200W INPUT RATED VOLTAGE 220/230/240VAC VOLTAGE RANGE 162VAC-268VAC±%7 FREQUENCY RANGE 50/60Hz ±%1 OUTPUT RATED VOLTAGE 220/230/240VAC VOLTAGE PRECISION ±%10 (Battery mode) FREQUANCY MODE) same as mains FREQUANCY (BATTERY MODE) 50/60Hz ±%1Hz WAVEFORM Modified sine wave CREST FACTOR TRANSFER TIME 2 ~ 6 ms, 10 ms Max.

  • Page 20: Guarantee

    NET WEIGHT 4.35kg 5.15kg 9.07kg 10.74kg 10.74kg GROSS WEIGHT 4.55kg 5.35kg 10.2kg 12kg 12kg OPERATING ENVIRONMENT TEMPERATURE 0℃ ~ 40℃ STORAGE TEMPERATURE -20℃ ~ 55℃ RELATIVE HUMIDITY 0 to 90% AUDIBLE NOSE (at 1m) ≤40 dB ≤45 dB OTHER COMMUNICATION PORT SOFTWARE Windows family/Linux/Mac...
  • Page 21 MAKELSAN according to the direction to be made by the MAKELSAN head office. For malfunctions in the scope of guarantee, shipment fees are under the UDD-SD-110/ Release Date: 19.12.2014/Rev No: 1/Rev.

  • Page 22: Cases Not Covered By The Guarantee

    MAKELSAN on the condition that products are delivered to the contracted freight company. ! The device must be sent as packed in its original packaging as long as it is not desired by the service. Original packaging of devices should be preserved in order to use them for shipment of devices in terms of repairs to occur.

  • Page 23: Contact Information

    ! Damages and breakdowns resulting from treatments, internally or externally tampering, efforts to repair and spare part replacement of products, without approval of MAKELSAN, and those resulting from treatment of unauthorized service/dealer/person/establishment, are not covered in the scope of guarantee. Breakdown, cracks, scratches and wear, corrosion and dust to occur in time and by use in the outer surfaces of products (cabinet, cover, and front panel) are not covered in the scope of guarantee.
  • Page 24 Headquarter: İstanbul Deri Organize Sanayi Bölgesi 2. Yol I -5 Parsel 34956 Tuzla/ İstanbul : 0216 428 65 80 : 0216 327 51 64 E-mail makelsan@makelsan.com.tr İzmir Office : Halkapınar Mah. 1348 Sok. 2AE Keremoğlu İş Merkezi Yenişehir – İzmir...
