- Page 1 POWERPACK PLUS SERIES 1-2-3 kVA UNINTERRUPTIBLE POWER SUPPLIES U S E R M A N U A L O N L I N E U P S w ww. ma kel s a n.c om. t r...
- Page 2 Foreword Manual instruction Thanks for purchasing our UPS, it is safe and reliable, so few maintenance is required. Read this manual carefully and completely. It includes instructions of safety installation and operation. They will help your UPS obtain the longest life and service. This manual accounts the internal working principle and the relative protection functions.
-
Page 3: Table Of Contents
Content 1.Safety instruction ......................1 1.1 Safety instruction ....................1 1.2 Symbols indication ....................1 2.Product Introduction ...................... 3 2.1 The appearance of the product ................3 2.2 The principle of the product ................... 4 2.3 Model ........................4 3.Installation ........................5 3.1 Unpacking and inspection .................. -
Page 4: Safety Instruction
1. Safety instruction Abstract This chapter mainly introduce the safety marks and notes of 1KVA-3KVA series on-line UPS. Read this chapter carefully before operating on the equipment. Safety instruction There is dangerous voltage and high temperature inside the UPS. During the installation, operation and maintenance, please abide the local safety instructions and relative laws, otherwise it will result in personnel injury or equipment damage. - Page 5 Safety Symbol Indication Attention Static discharge sensitive Electric shock There are three levers of safety grade: Dangerous, Warning and Attention. The remark is on the right side of the safety symbol, the detailed comments is behind, shown as following: Dangerous Indicate risk of serious injury or death or seriously damage the equipment Warning：...
-
Page 6: Product Introduction
2. Product Introduction The appearance of the product FIG.1 Front Panel view FIG.2 1kVA Rear Panel view... -
Page 7: The Principle Of The Product
FIG.3 2/3kVA Rear Panel view The principle of the product FIG.4 UPS Principle Diagram 1.Input filter: Complete filtering the input AC utility power to provide the clean power for UPS. 2. AC/DC converter: Convert the filtered AC mains to DC and boost the DC for DC/AC inverter. -
Page 8: Installation
3. Installation Unpacking and inspection 1. Unpacking the UPS and check that whether it’s damaged during the transportation. If damaged or some parts missing, don’t start the machine and inform the carrier and franchiser. 2. Check the annex (please consult Appendix Table 1). 3. -
Page 9: Ups Output Connection
FIG.5 Input Connection UPS output connection FIG.6 Output connection To install the optional EBP(s) for a UPS(Standard unit):... -
Page 10: Long Backup External Battery Connection
Long backup external battery connection FIG.7 battery connection Warning: ★ Before installing battery, make sure that UPS and breaker are all turned off. Remove all your metallic adornment such as finger ring, watch, and so on before connecting battery. ★ No anti-connection or short circuit between the battery anode and cathode forever. Red cable connect with battery anode “+”... -
Page 11: Panel Display, Operation And Running
4. Panel display, operation and running The operation is simple, operators only need to read the manual and follow the operation instructions listed in this manual without any special training. Faceplate display illumination 4.1.1 Keys function FIG.8 front panel buttons instruction ON key （... - Page 12 Press and hold this key for more than 2 seconds: Circularly and orderly display the items every 2 seconds, when press and hold the key for some time again, it will turn to output status. Function setting mode: Press and hold the key for more than half a second (less than 2 seconds): Select the set option.
- Page 13 NOTE: As to the LED indication in different modes, please refer to the LED display panel and warning table. 4.1.3 LCD display functions The LCD displays as following Fig. LCD display comprises numerical value section, capacity graphics section, fan-status graphics section and charger-status graphics section. Numerical value section －...
-
Page 14: Operation
when charger works abnormally, the icon will flash in a whole, as Graphics(2): (2 ) When UPS is in battery mode, the number of the icons of the charger-state section will vary according to the changeable capacity of the battery (pane). For example, there are five panes in Fig.A,(as the right picture of the Graphics(3) shows), so the corresponding number of icons is five rows(as the left picture of the Graphics(3) shows),, followed by this rule,... -
Page 15: Parameter Setting
Turn off operation 4.2.2 Turn off the UPS in line mode ① Press and hold the OFF key for more than half a second to turn off the UPS and inverter. ② After UPS shutting down, LED go out and there is no output. If output is needed, you can set bps “ON”... - Page 16 ③ Confirm the ECO selecting interface. After selecting ON or OFF, press and hold the function setting key for more than half a second (less than 2 seconds). Now, the ECO setting function is completed and the “ON” or “OFF” below the “ECO” will light without flash.
- Page 17 below the bPS will flash. Press and hold the inquiring key for more than half a second (less than 2 seconds) to determine whether the bPS function is used or not. If used, the corresponding word is “ON”, if not, the word is “OFF”. It can be determined by yourself.
- Page 18 The numerical value below the OPU will flash. Press and hold the inquiring key more than half a second (less than 2 seconds), select the numerical value in accordance with “OPU” function. The provided voltages are 208V,220V, 230V, 240V you can choose anyone by yourself (The default is 220v). ③...
- Page 19 After selecting numerical value, press and hold the function setting key for more than half a second (less than 2 seconds). Now, the battery packs setting is confirmed and the battery type value below will flash。 ④ set the battery type in the same way. ⑤...
- Page 20 4.3.6 Automatic Battery Test mode setting(6) ① Enter the setting interface. Press and hold the function setting key for more than 2 seconds, then come to setting interface, Press and hold the inquiring key more than half a second(less than 2 seconds), select the function setting, choose Automatic Battery Test setting interface, at the moment, the letters “Abt”...
- Page 21 will flash. Press and hold the inquiring key for more than half a second (less than 2 seconds) to determine whether the “wc” function is used or not. If used, the corresponding word is “ON”, if not, the word is “OFF”. It can be determined by yourself.
- Page 22 ③Confirm the setting. After selecting EPO input polarity, press and hold the function setting key for more than half a second (less than 2 seconds). Now, the setting is confirmed. ④Exit from the setting interface. Press and hold function setting key for more than half a second (less than 2 seconds), exit from the setting interface and return to main interface.
-
Page 23: Parameters Inquiring
② Enter the output frequency of converter mode setting interface. Press and hold the function setting key for more than half a second(less than 2 seconds) , the letters “OPF” will stop flashing. The letters below the “OPF” will flash. Press and hold the scroll key for more than half a second (less than 2 seconds), select the output frequency, “50Hz”(output fixed to 50Hz and active converter mode) or “60Hz”(output... - Page 24 Load: Display the numerical value of the active power(WATT) and apparent power(VA) of the load. For example, as the following graphics shows: the WATT of the load is 100w, VA is 100VA (when disconnect load, it is a normal phenomenon to show a small numerical value of WATT and VA).
-
Page 25: Run Mode
Battery: Display the voltage and capacity of the battery ( determined by type). As the following graphics shows: the battery voltage is 28v, the capacity of battery is 100％ (the capacity of battery is approximately reckoned according to the battery voltage). Battery remaining time：Display the battery remaining time when under battery mode. - Page 26 Bypass yellow LED is on, the buzzer beeps once every 2 minutes . The warning red LED is on when beeping, LCD displays are according to the exact load and battery capacity. Turn to bypass mode under the following two conditions: ①...
- Page 27 When the input mains meets the input range of the ECO mode and start the ECO function, the UPS will works on ECO mode. If input AC mains exceeds the range of ECO several times in a row in a minute but stays in inverter input range, UPS will work on AC inverting mode automatically.
-
Page 28: Maintenance
5. Maintenance Only minimum maintenance is required for this series of UPS. The battery is sealed lead acid maintenance free. It only needs to be kept charging to obtain the expected life. Whether it is started or not, the UPS would charge batteries once it is connected to mains and provide protection for over-charging and deep discharging. -
Page 29: Troubleshooting And Performance Of Product
6. Troubleshooting and performance of product The following messages are the information that users would find on UPS when it meets some problems. Users can judge if the fault is caused by external factors and know how to deal with it by making full use of the information. 1. - Page 30 four seconds Battery Voltage Once per ● ★ ★ abnormal warning second Bypass mode Main AC Normal Once every Eliminate after starting voltage in bypass ● ★ two minutes the UPS mode Main AC high Once every voltage warning in ★...
-
Page 31: Troubleshooting
Troubleshooting When the fault occurs, firstly, perform troubleshooting by referring to the troubleshooting table. If the fault still exists, please contact the franchiser. Fault Cause Solution The “INPUT” Anti-connection of letters on LCD mains live and neutral Re-connect the input power cable and make display section or mains is out of a correct connection... -
Page 32: Emc Standard/Safety Standard
EMC standard/Safety standard ◆Our product are manufactured according to the following EMC international grade standard and has passed the CE authentication： EMC standard number Sefety standard number IEC62040-2 IEC92040-1 IEC61000-4-2 GB4943-5 IEC61000-4-3 IEC61000-4-4 IEC61000-4-5 Product Performance Model 1KVAS/H 2KVAS/H 3KVAS/H Rated capacity 900W/1KVA 1800W/2KVA... -
Page 33: Communication Interface
Full load ≥ 94% ≤3% (100％ linear load ) Output voltage distortion ≤5% (100％ nonlinear load ) Input battery voltage 24 VDC 48 VDC 72VDC Internal battery capacity 12V/9AH sealed lead acid maintenance free battery ( only refers Batter Internal battery type to standard UPS ) Full load ≥... - Page 34 6.5.2 RS232 cable specifications When connecting the UPS with PC by RS232 cable, it needs to use the standard RS232 cable, the detailed cable NO. are as following: PIN 1（hole）to computer serial PIN 2 （needle） to UPS serial 6.5.3 Emergency Power-off EPO is used to shut down the UPS from a distance.
- Page 35 You can set the EPO polarity. See the“EPO Input Polarity”setting in“User Settings” NOTE Depending on user configuration, the pins must be shorted or opened to keep the UPS running. To restart the UPS, reconnect (re-open) the EPO connector pins and turn on the UPS manually. Maximum resistance in the shorted loop is 10 ohm.
- Page 36 6.5.5 Optional communication interface ① USB communication interface USB communication interface: Install the intelligent monitoring software UPSilon2000 which is equipped with the UPS. Then it can achieve the communication with monitoring device directly. When RS232 and USB are provided, only one of them will be chosen and USB is preferred.
- Page 37 POWERPACK PLU S SE RIE S 1- 2- 3 kVA O N L I N E U P S Makelsan Makine Kimya Elektrik San. ve Tic. A.Ş. Headquarter & Factory Ankara Office İzmir Office İstanbul Deri Organize Sanayi Bölgesi Alsancak Sk.
